PPQ-WN4640RWLAN Module

WN4640R Page 1/6 2015/6/4 User Manual WLAN Module WN4640R Liteon P/N : AAZ100136D0 Version 1.0 Author: Kaysa Lee Change History Revision Date Author Change List Version 1.0 2015 / 06 / 03 Kaysa Lee Initial release * This document contains confidential proprietary information and is property of LTC. The contents of this document should not be disclosed to unauthorized persons without the written consent of LTC. WN4640R Page 2/6 2015/6/4 CONTENT 1 PRODUCT OVERVIEW ...................................................................................................................... 3 1.1 DESCRIPTION ............................................................................................................................. 3 1.2 FEATURES .................................................................................................................................. 3 1.3 GENERAL SPECIFICATIONS ......................................................................................................... 3 1.4 BOARD OUTLINE ........................................................................................................................ 4 1.5 WTB CONNECTOR(....................................................................................................................5 1.6 PIN CONFIGURATION ................................................................................................................. 5 2 APPEARANCE, MARKING ................................................................................................................. 6 2.1 APPEARANCE ............................................................................................................................. 6 WN4640R Page 3/6 2015/6/4 1 PRODUCT OVERVIEW 1.1 DESCRIPTION WN4640R is a WLAN module which using MTK Chipset MT7603U 1.2 FEATURES  Operate at 2.4GHz band  150Mbps PHY Rate Support  2T2R Modes  20MHz Bandwidth Support  USB 2.0 support for date rates up to 12Mbps full speed and 480Mbps high speed  IEEE standards support: IEEE 802.11b/g and 802.11n  802.11i- WEP 64/128, AES, TKIP  RoHS compliance  Low Halogen compliance 1.3 GENERAL SPECIFICATIONS Main Chipset MT7603U Standard IEEE 802.11b/g/n Bus Interface USB 2.0 Form Factor 53.8mm x 20mm x 5mm Weight 4.3g Data Rate 802.11b: CCK, DQPSK, DBPSK 802.11g: 64QAM, 16QAM, QPSK, BPSK 802.11n: 64QAM, 16QAM, QPSK, BPSK Frequency Range 2.400 ~ 2.4835 GHz Transmit Output Power 11b: 15 +/- 1.5dBm 11g: 15 +/- 1.5dBm 11n: 15 +/- 1.5dBm Receive Sensitivity 11b @ 11Mbps: (Max.) : -85dBm , (Typical) : -91dBm (PER<8%) 11g @ 54Mbps: (Max.) : -69dBm , (Typical) : -77dBm (PER<10%) 11n @ MCS7: (Max.) : -67dBm , (Typical) : -74dBm (PER<10%) Temperature & Humidity Normal Test Condition: 25 +/- 2deg.C , 65 +/- 2% RH Operating: -10 to 70 deg.C Storage: -40 to 85 deg.C Operating Voltage 5V ±10% I/O supply voltage Antenna Type On Board Metallic Antenna x 2 WN4640R Page 4/6 2015/6/4 1.4 BOARD OUTLINE Dimension Tolerance : +/- 0.15mm WN4640R Page 5/6 2015/6/4 1.6 WTB CONNECTOR 1.7 PIN CONFIGURATION Pin Name Type Description 1 VCC - Ground 2 DM I/O USB Data - 3 DP I/O USB Data + 4 GND - Ground 5 RESET I/O LDO_RST_N WN4640R Page 6/6 2015/6/4 2 Appearance, Marking 2.1 Appearance Top Bottom

WN4640R Page 1/6 2015/6/4 User Manual WLAN Module WN4640R Liteon P/N : AAZ100136D0 Version 1.0 Author: Kaysa Lee Change History Revision Date Author Change List Version 1.0 2015 / 06 / 03 Kaysa Lee Initial release * This document contains confidential proprietary information and is property of LTC. The contents of this document should not be disclosed to unauthorized persons without the written consent of LTC. WN4640R Page 2/6 2015/6/4 CONTENT 1 PRODUCT OVERVIEW ...................................................................................................................... 3 1.1 DESCRIPTION ............................................................................................................................. 3 1.2 FEATURES .................................................................................................................................. 3 1.3 GENERAL SPECIFICATIONS ......................................................................................................... 3 1.4 BOARD OUTLINE ........................................................................................................................ 4 1.5 WTB CONNECTOR(....................................................................................................................5 1.6 PIN CONFIGURATION ................................................................................................................. 5 2 APPEARANCE, MARKING ................................................................................................................. 6 2.1 APPEARANCE ............................................................................................................................. 6 WN4640R Page 3/6 2015/6/4 1 PRODUCT OVERVIEW 1.1 DESCRIPTION WN4640R is a WLAN module which using MTK Chipset MT7603U 1.2 FEATURES  Operate at 2.4GHz band  150Mbps PHY Rate Support  2T2R Modes  20MHz Bandwidth Support  USB 2.0 support for date rates up to 12Mbps full speed and 480Mbps high speed  IEEE standards support: IEEE 802.11b/g and 802.11n  802.11i- WEP 64/128, AES, TKIP  RoHS compliance  Low Halogen compliance 1.3 GENERAL SPECIFICATIONS Main Chipset MT7603U Standard IEEE 802.11b/g/n Bus Interface USB 2.0 Form Factor 53.8mm x 20mm x 5mm Weight 4.3g Data Rate 802.11b: CCK, DQPSK, DBPSK 802.11g: 64QAM, 16QAM, QPSK, BPSK 802.11n: 64QAM, 16QAM, QPSK, BPSK Frequency Range 2.400 ~ 2.4835 GHz Transmit Output Power 11b: 15 +/- 1.5dBm 11g: 15 +/- 1.5dBm 11n: 15 +/- 1.5dBm Receive Sensitivity 11b @ 11Mbps: (Max.) : -85dBm , (Typical) : -91dBm (PER<8%) 11g @ 54Mbps: (Max.) : -69dBm , (Typical) : -77dBm (PER<10%) 11n @ MCS7: (Max.) : -67dBm , (Typical) : -74dBm (PER<10%) Temperature & Humidity Normal Test Condition: 25 +/- 2deg.C , 65 +/- 2% RH Operating: -10 to 70 deg.C Storage: -40 to 85 deg.C Operating Voltage 5V ±10% I/O supply voltage Antenna Type On Board Metallic Antenna x 2 WN4640R Page 4/6 2015/6/4 1.4 BOARD OUTLINE Dimension Tolerance : +/- 0.15mm WN4640R Page 5/6 2015/6/4 1.6 WTB CONNECTOR 1.7 PIN CONFIGURATION Pin Name Type Description 1 VCC - Ground 2 DM I/O USB Data - 3 DP I/O USB Data + 4 GND - Ground 5 RESET I/O LDO_RST_N WN4640R Page 6/6 2015/6/4 2 Appearance, Marking 2.1 Appearance Top Bottom

Lite LiteLite Lite- -- -On Technology Corp. On Technology Corp.On Technology Corp. On Technology Corp. Date (06/09/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request FCC ID: PPQ-WN4640R Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Lite-On Technology Corp. . hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, TC Wu Title: Director Lite-On Technology Corp. TEL: 886-2-2222-6181 FAX: 886-2-2226-6749 E-Mail: [email protected]

Lite LiteLite Lite- -- -On Technology Corp. On Technology Corp.On Technology Corp. On Technology Corp. Date (6/30/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL We, Lite-On Technology Corp.declare that This module support b/g/n function and has USB2.0 interface but it could not contact with PC or NB directly and could not support USB data transfer to a computer functionality that will be integrated into TV set. Yours sincerely, TC Wu Title: Director Lite-On Technology Corp. TEL: 886-2-2222-6181 FAX: 886-2-2226-6749 E-Mail: [email protected]

Lite-On Technology Corp. Date (06/09/2015) TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Modular Approval Request FCC ID: PPQ-WN4640R The following attestation addresses the requirements to support modular approval: Modular approval requirement Yes (provide brief statement) No * (a) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly Y (b) The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Y (c) The module must contain power supply regulation on the module Y (d) The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) Y (e) The module must demonstrate compliance in a stand-alone configuration Y (f) The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) Y (g) The module must comply with all specific rules applicable to the transmitter. The grantee must provide comprehensive instructions to explain compliance requirements Y Modular approval requirement Yes (provide brief statement) No * (h) The module must comply with RF exposure requirements Y * Please provide a detailed explanation if the answer is “No.” Yours sincerely, TC Wu Title: Director Lite-On Technology Corp. TEL: 886-2-2222-6181 FAX: 886-2-2226-6749 E-Mail: [email protected]

Example of Agents letter (for TCB – TCB approval): Lite LiteLite Lite- -- -On Technology Corp. On Technology Corp.On Technology Corp. On Technology Corp. Date (06/09/2015) TUV SUD BABT TCB/FCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, (Lite-On Technology Corp.,and Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C.), hereby authorize (Compliance Certification Services Inc./ David Wang., No.11,Wugong 6th Rd., Wugu Dist. New Taipei City 24891,Taiwan and 02-2299-9720) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 2016/06/08 Sincerely, TC Wu Title: Director Lite-On Technology Corp. TEL: 886-2-2222-6181 FAX: 886-2-2226-6749 E-Mail: [email protected]

Example of Agents letter (for TCB – TCB approval): Lite LiteLite Lite- -- -On Technology Corp. On Technology Corp.On Technology Corp. On Technology Corp. Date (06/09/2015) TUV SUD BABT TCB/FCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, (Lite-On Technology Corp.,and Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C.), hereby authorize (Compliance Certification Services Inc./ David Wang., No.11,Wugong 6th Rd., Wugu Dist. New Taipei City 24891,Taiwan and 02-2299-9720) to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 2016/06/08 Sincerely, TC Wu Title: Director Lite-On Technology Corp. TEL: 886-2-2222-6181 FAX: 886-2-2226-6749 E-Mail: [email protected]

Compliance Certification Services Inc. Report No.: T150604W01 Date of Issue: June 22, 2015 A1 - 1 / 4 Rev. 00 APPENDIX 1 - PHOTOGRAPHS OF EUT EXTERNAL PHOTOGRAPHS OF EUT

Compliance Certification Services Inc. Report No.: T150604W01 Date of Issue: June 22, 2015 A1 - 2 / 4 Rev. 00 INTERNAL PHOTOGRAPHS OF EUT RF IC Compliance Certification Services Inc. Report No.: T150604W01 Date of Issue: June 22, 2015 A1 - 3 / 4 Rev. 00 Compliance Certification Services Inc. Report No.: T150604W01 Date of Issue: June 22, 2015 A1 - 4 / 4 Rev. 00 Antenna

Compliance Certification Services Inc. Report No.: T150604W01 Date of Issue: June 22, 2015 A1 - 2 / 4 Rev. 00 INTERNAL PHOTOGRAPHS OF EUT RF IC Compliance Certification Services Inc. Report No.: T150604W01 Date of Issue: June 22, 2015 A1 - 3 / 4 Rev. 00 Compliance Certification Services Inc. Report No.: T150604W01 Date of Issue: June 22, 2015 A1 - 4 / 4 Rev. 00 Antenna

Compliance Certification Services Inc. Report No.: T150604W01-MF Date of Issue: June 25, 2015 Page 1 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. APPENDIX I RADIO FREQUENCY EXPOSURE LIMIT According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this chapter. EUT Specification EUT WLAN Module Model WN4640R RF Module MEDIATEK Model: MT7603UN Model Discrepancy N/A Frequency band (Operating) 802.11b/g/n HT20: 2.412GHz ~ 2.462GHz 802.11 n HT40: 2.422GHz ~ 2.452GHz Others Device category Portable (<20cm separation) Mobile (>20cm separation) Others Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna Specification PIFA Antenna 1. LITE-ON Technology Corporation / WN4640R 2.4GHz: Antenna Gain :2.93 dBi (Numeric gain:1.96) 2. LITE-ON Technology Corporation / WN4640R 2.4GHz: Antenna Gain :2.71 dBi (Numeric gain:1.87) Maximum Average output power IEEE 802.11b Mode: 23.48 dBm(222.844 mW) IEEE 802.11g Mode:24.12 dBm(258.226 mW) IEEE 802.11n HT 20 Mode: 25.83 dBm(382.825 mW) IEEE 802.11n HT 40 Mode: 25.76 dBm(376.704 mW) Maximum Tune up Power IEEE 802.11b Mode: 25.00 dBm(316.228 mW) IEEE 802.11g Mode:26.00 dBm(398.107 mW) IEEE 802.11n HT 20 Mode: 27.50 dBm(562.341 mW) IEEE 802.11n HT 40 Mode: 27.50 dBm(562.341 mW) Evaluation applied MPE Evaluation* SAR Evaluation N/A Compliance Certification Services Inc. Report No.: T150604W01-MF Date of Issue: June 25, 2015 Page 2 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 2015/6/25 Initial Issue ALL Becca Chen Compliance Certification Services Inc. Report No.: T150604W01-MF Date of Issue: June 25, 2015 Page 3 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TEST RESULTS No non-compliance noted. Calculation Given d GP E   30 & 377 2 E S Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 377 30 d GP S   Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields   22 0796.0 100/377 1000/30 d GP d GP S      Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 Compliance Certification Services Inc. Report No.: T150604W01-MF Date of Issue: June 25, 2015 Page 4 Rev.00 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Maximum Permissible Exposure Substituting the MPE safe distance using d = 20 cm into Equation 1: GPS000199.0 Where P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 IEEE 802.11b mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm2) 62437316.2281.96200.12331 IEEE 802.11g mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm2) 62437398.1071.96200.15531 IEEE 802.11n HT20 mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm2) 62437562.3411.96200.21931 IEEE 802.11n HT40 mode: Ch.Frq.(MHz)P (mW)Gain (num.)D (cm) Power density in mW / cm 2 Limit (mW/cm2) 62437562.3411.96200.21931

Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 126 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For WLAN Module Model: WN4640R Trade Name: LITE-ON Issued to Lite-On Technology Corp. Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: June 22, 2015 Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 2 Rev. 00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 June 22, 2015 Initial Issue ALL Becca Chen Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 3 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .................................................................................................... 4 2. EUT DESCRIPTION ........................................................................................................................... 5 3. TEST METHODOLOGY .................................................................................................................... 6 3.1 EUT CONFIGURATION ................................................................................................................. 6 3.2 EUT EXERCISE ............................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES .................................................................................................. 6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .................................................... 7 3.5 DESCRIPTION OF TEST MODES ................................................................................................. 8 4. INSTRUMENT CALIBRATION ........................................................................................................ 9 4.1 MEASURING INSTRUMENT CALIBRATION ............................................................................ 9 4.2 MEASUREMENT EQUIPMENT USED ......................................................................................... 9 4.3 MEASUREMENT UNCERTAINTY ............................................................................................. 10 5. FACILITIES AND ACCREDITATIONS ........................................................................................ 11 5.1 FACILITIES ................................................................................................................................... 11 5.2 EQUIPMENT ................................................................................................................................. 11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS ...................................................................... 12 6. SETUP OF EQUIPMENT UNDER TEST ....................................................................................... 13 6.1 SETUP CONFIGURATION OF EUT ............................................................................................ 13 6.2 SUPPORT EQUIPMENT ............................................................................................................... 13 7. FCC PART 15.247 REQUIREMENTS ............................................................................................. 14 7.1 6DB BANDWIDTH ....................................................................................................................... 14 7.2 PEAK POWER ............................................................................................................................... 34 7.3 AVERAGE POWER ...................................................................................................................... 36 7.4 BAND EDGES MEASUREMENT ................................................................................................ 38 7.5 PEAK POWER SPECTRAL DENSITY ........................................................................................ 68 7.6 SPURIOUS EMISSIONS ............................................................................................................... 88 7.7 RADIATED EMISSIONS ............................................................................................................ 107 7.8 POWERLINE CONDUCTED EMISSIONS ................................................................................ 124 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................. 125 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 4 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: Lite-On Technology Corp. Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Equipment Under Test: WLAN Module Trade Name: LITE-ON Model Number: WN4640R Date of Test: June 14 ~ 16, 2015 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10: 2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Miller Lee Angel Cheng Manager Section Manager Compliance …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. Page 1 / 126 Rev. 00 FCC 47 CFR PART 15 SUBPART C TEST REPORT For WLAN Module Model: WN4640R Trade Name: LITE-ON Issued to Lite-On Technology Corp. Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Issued by Compliance Certification Services Inc. No.11, Wugong 6th Rd., Wugu Dist., New Taipei City 24891, Taiwan. (R.O.C.) http://www.ccsrf.com [email protected] Issued Date: June 22, 2015 Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 2 Rev. 00 Revision History Rev. Issue Date Revisions Effect Page Revised By 00 June 22, 2015 Initial Issue ALL Becca Chen Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 3 Rev. 00 TABLE OF CONTENTS 1. TEST RESULT CERTIFICATION .................................................................................................... 4 2. EUT DESCRIPTION ........................................................................................................................... 5 3. TEST METHODOLOGY .................................................................................................................... 6 3.1 EUT CONFIGURATION ................................................................................................................. 6 3.2 EUT EXERCISE ............................................................................................................................... 6 3.3 GENERAL TEST PROCEDURES .................................................................................................. 6 3.4 FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS .................................................... 7 3.5 DESCRIPTION OF TEST MODES ................................................................................................. 8 4. INSTRUMENT CALIBRATION ........................................................................................................ 9 4.1 MEASURING INSTRUMENT CALIBRATION ............................................................................ 9 4.2 MEASUREMENT EQUIPMENT USED ......................................................................................... 9 4.3 MEASUREMENT UNCERTAINTY ............................................................................................. 10 5. FACILITIES AND ACCREDITATIONS ........................................................................................ 11 5.1 FACILITIES ................................................................................................................................... 11 5.2 EQUIPMENT ................................................................................................................................. 11 5.3 TABLE OF ACCREDITATIONS AND LISTINGS ...................................................................... 12 6. SETUP OF EQUIPMENT UNDER TEST ....................................................................................... 13 6.1 SETUP CONFIGURATION OF EUT ............................................................................................ 13 6.2 SUPPORT EQUIPMENT ............................................................................................................... 13 7. FCC PART 15.247 REQUIREMENTS ............................................................................................. 14 7.1 6DB BANDWIDTH ....................................................................................................................... 14 7.2 PEAK POWER ............................................................................................................................... 34 7.3 AVERAGE POWER ...................................................................................................................... 36 7.4 BAND EDGES MEASUREMENT ................................................................................................ 38 7.5 PEAK POWER SPECTRAL DENSITY ........................................................................................ 68 7.6 SPURIOUS EMISSIONS ............................................................................................................... 88 7.7 RADIATED EMISSIONS ............................................................................................................ 107 7.8 POWERLINE CONDUCTED EMISSIONS ................................................................................ 124 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................. 125 APPENDIX 1 - PHOTOGRAPHS OF EUT Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 4 Rev. 00 1. TEST RESULT CERTIFICATION Applicant: Lite-On Technology Corp. Bldg. C, 90, Chien 1 Road, Chung Ho, New Taipei City 23585, Taiwan, R.O.C Equipment Under Test: WLAN Module Trade Name: LITE-ON Model Number: WN4640R Date of Test: June 14 ~ 16, 2015 APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.10: 2009 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.247. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Miller Lee Angel Cheng Manager Section Manager Compliance …

Text truncated - open the document above for the full version.

Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 125 Rev. 00 APPENDIX I PHOTOGRAPHS OF TEST SETUP Conducted Emissions Setup Photos Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 126 Rev. 00 Radiated Emissions Setup Photos

Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 125 Rev. 00 APPENDIX I PHOTOGRAPHS OF TEST SETUP Conducted Emissions Setup Photos Compliance Certification Services Inc. FCC ID: PPQ-WN4640R Report No.: T150604W01-RP Page 126 Rev. 00 Radiated Emissions Setup Photos
