PPQ-WP8722Access Point

Page 1/10LITE-ON USER’S MANUAL ACCESS POINT MODEL NAME: WP8722, WP8722-BT BRAND: LITE-ON Page 2/10LITE-ON 1.PRODUCT DESCRIPTION ......................................................................................................... 4 1.1PRODUCTDELIVERABLES........................................................................................................... 4 2.HARDWARE REQUIREMENTS................................................................................................ 4 2.1MAIN CHIPSET............................................................................................................................. 4 2.2ENCLOSURE ANDMECHANICAL.................................................................................................. 5 2.3MOUNTING.................................................................................................................................. 6 2.4ANTENNA ANDWIRELESS........................................................................................................... 7 2.5ETHERNET PORT.......................................................................................................................... 8 2.6LEDINDICATORFUNCTIONDEFINITION: .................................................................................... 8 2.7POWERSUPPLY........................................................................................................................... 8 2.8FACTORYDEFAULTRESET......................................................................................................... 8 2.9DEBUG PORT............................................................................................................................... 8 3.SOFTWARE REQUIREMENT ................................................................................................... 8 4.RF CAPABILITY .......................................................................................................................... 9 4.1TRANSMITE POWER(SINGLE CHAIN) ........................................................................................... 9 4.2RXSENSITIVITY(SINGLE CHAIN) ................................................................................................ 9 5.PHYSICAL AND ENVIRONMENTAL .................................................................................... 10 6.DEFAULT COUNTRY LIST OF REGULATORY CERTIFICATION ................................ 10 Page 3/10LITE-ON Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ˗Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. This device and its antenna(s) must not be co-located with any other transmitters except in accordance with FCC multi transmitter product procedures. Referring to the multi transmitter policy, multiple transmitter(s) and module(s) can be operated simultaneously without C2PC. IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. Page 4/10LITE-ON 1.Product Description The product is structured as SOC QCA9563 + Radio QCA9886. One radio offers 802.11n 300Mbps at 2.4GHz and another radio offers 802.11ac 866Mbps at 5GHz. See Figure-01 The product connects to the backbone network through Giga-bit Ethernet interface with 802.3af/at PoE PD which is able to be powered by PoE switch remotely. The product also supports DC12V power source option for the environment where PoE is not available. Note: Optional features are not included in default SKU and to be quoted separately if required afterwards. 1.1Product Deliverables The AP and its embedded software Standard Mounting kits (ceiling tie rail adapters for 15mm, 24mm and 38mm) User documentations (TBD) Getting Started Guide Regulatory flyer (TBD) Warranty/SLA (TBD, on website only) Registration card (TBD, con website only) 2.Hardware requirements 2.1Main chipset (Note:all components equiped for product are commercial grade) SOC:Qualcomm QCA9563 SOC 11ac RF:Qualcomm QCA9886 (PCIe interface) GE PHY:Qualcomm QCA8033 PoE controller:AS1138 Flash:SPI NOR 64M Bytes - 1×SPI NOR 64M Bytes (Default) Page 5/10LITE-ON - 2×SPI NOR 32M Bytes (Optional) Flash: 128MB NAND Flash (optional, to be charged separately if required) DDR2:128Mbytes 2.2Enclosure and Mechanical The dimension for…

Text truncated - open the document above for the full version.

WP8722-BT Antenna Test Report 2020/01/07 John Hsieh WP8722-BT Under Test Antenna Placement and Coordinate 2G Antenna S-parameter Ant1 Ant2 Return Loss > 10dB Return Loss > 10dB Isolation > 20dB 5G Antenna S-parameter Ant3 Ant4 Return Loss > 10dB Return Loss > 10dB Isolation > 25dB Antenna Gain and Eff. Ant#2G12G25G15G2 Peak Gain4.6dBi4.5dBi5.1dBi5.3dBi Efficiency72%70%71%74% Azimuth Plane (XY Plane) Aggregate Pattern X Y 2G Antenna pattern 2G1 2G2 X Y X Y Z Y Z Y Z X Z X 5G Antenna pattern 5G1 5G2 X Y X Y Z Y Z Y Z X Z X Summary ⚫Antenna gain is higher than 4.5dBi, radiation efficiency is above 70% ⚫Aggregate pattern of azimuth plane (XY plane) is more omni- directional than previous design , it is suitable for table stand or ceiling mount .

WP8722 Antenna Test Report 2019/12/25 John Hsieh Antenna Placement and Coordinate 2G1 2G2 5G1 5G2 2G Antenna S-parameter 5G Antenna S-parameter Ant3Ant4 Isolation Antenna Gain and Eff. Ant#2G12G25G15G2 Peak Gain4.6dBi4.5dBi5.1dBi5.3dBi Efficiency72%70%71%74% Azimuth Plane (XY Plane)aggregate pattern X Y X Y X Y 2G5G 2G Antenna pattern X Z Y Z X Y 2G1 X Z Y Z X Y 2G2 5G Antenna pattern X Z Y Z X Y 5G1 X Z Y Z X Y 5G2 Summary ⚫Antenna gain is higher than 4.5dBi, radiation efficiency is above 70% ⚫Antenna gain pattern is omni-directional in azimuth plane (see Page.6 XY Plane), the pattern is suitable for indoor access point , place on table or client mount.

Declaration for model numbers Hereby, We Name: LITE-ON Technology Corp. Address: Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City, 23585, Taiwan declares that this equipment: Product description:Access Point Type designation(s):WP8722, WP8722-BT Trademark:LITE-ON The differences between all model numbers are for marketing purpose, the circuit design and layout between of all model numbers are the same. Date:Jan. 02, 2020 City:New Taipei City Name:TC Wu Function:Deputy Director(R & D Division) Signature:

RF_160, Issue 02 Declaration of Authorization We Name:LITE-ON Technology Corp. Address:Bldg. C, 90, Chien 1 Rd., Chung-Ho, City:New Taipei City, 23585 Country:Taiwan Declare that: Name Representative of agent: Delia Feng (1) Agent Company name:Cerpass Technology Corporation Address:No.10, Lane 2, Lianfu Street, Luzhu Dist., City:Taoyuan City 33848 Country:Taiwan, R.O.C. is authorized to apply for Certification of the following product(s): Product description: Access Point Type designation:WP8722, WP8722-BT Trademark:LITE-ON on our behalf. Date:Jan. 02, 2020 City:New Taipei City Name:TC Wu (2) Function:Deputy Director(R & D Division) Signature: Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosureDate: 10-Aug-09 RF_501, Issue 5Page 1 of 1 Company Name:LITE-ON Technology Corp. Address:Bldg. C, 90, Chien 1 Rd., Chung-Ho, City:New Taipei City, 23585 Country:Taiwan To:Telefication B.V.,Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject:Request for confidentiality FCC ID:PPQ-WP8722 Reference number:###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of MaterialBlock Diagrams Operational DescriptionSchematic DiagramsTune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicanthereby requests Short-Term Confidential treatment of the following materials (note 1): Internal PhotosUser’s ManualTest Set-up PhotosExternal Photos Justification:Marketing purpose Planned Release Date STC:180days after grant date(notes 2, 3, 4, 5) Date:2020/03/19Name and signature of applicant:TC Wu Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

CERPASS TECHNOLOGY CORP. Report No.: 1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 Page No. : 1 of 7 Photographs of EUT CERPASS TECHNOLOGY CORP. Report No.: 1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 Page No. : 2 of 7 CERPASS TECHNOLOGY CORP. Report No.: 1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 Page No. : 3 of 7

Label & Location or Rear side of EUT Label Location WP8722 MM125556807A0 (客戶):Generic (材質):壓花底50#白色特多龍 (局部空白LABEL):509101154677 (顏色):BLACK (表面處理):NO (尺寸):69.5x19.5mm (公差):+-0.3mm Unit label 69.5mm 19.5mm Input(PoE + 802.3at): 48V ,400mA Input(DC Jack): 12V ,1A WP8722 1.84mm 1:1 1.84mm MAC ID: 內容由業務提供 MAC: E8:C7:4F:XX:XX:XX Ethernet MAC地址用LITEON廠內的 S/N:內容由業務提供 (條碼使用code128) 文字顯示為:WP8722XXXXXX (XXXXXXMAC Address6) 條碼顯示為:WP8722XXXXXX 請使用業務提供的Excel:Ethernet 条码扫描内容:E8C74FXXXXXX Access Point SN: WP8722XXXXXX Arial bold 3.5pt , 高度 :3mm Arial 4pt Arial 3.5pt Eth. MAC: E8:C7:4F:XX:XX:XX 802.11 a/n/ac + b/g/n This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including int erference that may cause undesired operation. FC C I D: PPQ-WP8722 每台分配32个MAC地址， 每台的base MAC必须是以00/20/40/60/80/A0/C0/E0结尾 Made in China yxue 2019--10-17 69.5mm 19.5mm Input(PoE + 802.3at): 48V ,400mA Input(DC Jack): 12V ,1A WP8722 1.84mm 2:1 1.84mm Access Point SN: WP8722XXXXXX Arial bold 3.5pt , 高度 :3mm Arial 4pt Arial 3.5pt Eth. MAC: E8:C7:4F:XX:XX:XX 802.11 a/n/ac + b/g/n This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including int erference that may cause undesired operation. FC C I D: PPQ-WP8722 Made in China WP8722-BT MM125560807A0 (客戶):Generic (材質):壓花底50#白色特多龍 (局部空白LABEL):509 (顏色):BLACK (表面處理):NO (尺寸):69.5x19.5mm (公差):+-0.3mm Unit label 69.5mm 19.5mm Input(PoE + 802.3at): 48V ,400mA Input(DC Jack): 12V ,1A WP8722-BT 1.84mm 1:1 1.84mm MAC ID: 內容由業務提供 MAC: E8:C7:4F:XX:XX:XX Ethernet MAC地址用LITEON廠內的 S/N:內容由業務提供 (條碼使用code128) 文字顯示為:E8C74FXXXXXX (XXXXXXMAC Address6) 條碼顯示為:E8C74FXXXXXX 請使用業務提供的Excel:Ethernet 条码扫描内容:E8C74FXXXXXX Access Point SN: E8C74FXXXXXX Arial bold 3.5pt , 高度 :3mm Arial 4pt Arial 3.5pt Eth. MAC: E8:C7:4F:XX:XX:XX 802.11 a/n/ac + b/g/n This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including int erference that may cause undesired operation. FC C I D: PPQ-WP8722 Made in China yxue 2019--11-06 XXXXX/SDPPI/XXXXX 2544 69.5mm 19.5mm Input(PoE + 802.3at): 48V ,400mA Input(DC Jack): 12V ,1A WP8722-BT 1.84mm 2:1 1.84mm Access Point SN: E8C74FXXXXXX Arial bold 3.5pt , 高度 :3mm Arial 4pt Arial 3.5pt Eth. MAC: E8:C7:4F:XX:XX:XX 802.11 a/n/ac + b/g/n This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including int erference that may cause undesired operation. FC C I D: PPQ-WP8722 Made in China XXXXX/SDPPI/XXXXX 2544

CERPASS TECHNOLOGY CORP. Report No.: 1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 Page No. : 4 of 7 CERPASS TECHNOLOGY CORP. Report No.: 1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 Page No. : 5 of 7 Antenna position Antenna position CERPASS TECHNOLOGY CORP. Report No.: 1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 Page No. : 6 of 7 RF Chip CERPASS TECHNOLOGY CORP. Report No.: 1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 Page No. : 7 of 7

CERPASS TECHNOLOGY CORP. Report No.: TEFE1912251 CERPASS TECHNOLOGY CORP. Issued date : Mar. 18, 2020 T-FD-511-0 V1.2 Page No. : 108 of 110 FCC ID : PPQ-WP8722 13. Radio Frequency Exposure 13.1. Applicable Standards The measurements shown in this test report were made in accordance with the procedures given in FCC Part 2 (Section 2.1091) 13.2. EUT Specification Frequency band (Operating) WLAN: 2412MHz ~ 2462MHz WLAN: 5150MHz ~ 5250MHz WLAN: 5250MHz ~ 5350MHz WLAN: 5470MHz ~ 5725MHz WLAN: 5725MHz ~ 5850MHz Bluetooth: 2402MHz ~ 2480MHz Device category Portable (<20cm separation) Mobile (>20cm separation) Exposure classification Occupational/Controlled exposure (S = 5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: 1. The maximum conducted output power is 21.05dBm (127.257mW) at 5230MHz (with 5.3 dBi antenna gain.) 2. DTS device is not subject to routine RF evaluation; MPE estimate is used to justify the compliance. 3. For mobile or fixed location transmitters, no SAR consideration applied. The maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger. 13.3. Test Results No non-compliance noted. CERPASS TECHNOLOGY CORP. Report No.: TEFE1912251 CERPASS TECHNOLOGY CORP. Issued date : Mar. 18, 2020 T-FD-511-0 V1.2 Page No. : 109 of 110 FCC ID : PPQ-WP8722 13.4. Calculation Given d GP E   30 & 3770 2 E S Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S   Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields   2 2 0796.0 100/3770 1000/30 d GP d GP S      Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 CERPASS TECHNOLOGY CORP. Report No.: TEFE1912251 CERPASS TECHNOLOGY CORP. Issued date : Mar. 18, 2020 T-FD-511-0 V1.2 Page No. : 110 of 110 FCC ID : PPQ-WP8722 13.5. Maximum Permissible Exposure Channel Frequency (MHz) Max. Conducted output power(dBm) Max. Tune up power (dBm) Antenna Gain(dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 5180-5240 21.05 23.05 5.3 20 0.136 1 5745-5825 20.83 22.83 5.3 20 0.129 1 Maximum Permissible Exposure (Co-location) Modulation Type Channel Frequency (MHz) Max. Conducted output power (dBm) Max. Tune up power (dBm) Antenna Gain(dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) MPE Ratio 11g 2412-2462 29.31 31.31 4.6 20 0.776 1.000 0.776 11ac VHT40 5150-5250 21.05 23.05 5.3 20 0.136 1.000 0.136 Co-location Total 0.912 ∑MPE ratios Limit 1

CERPASS TECHNOLOGY CORP. Report No.: TEFU1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 T-FD-503-0 Ver 1.2 Page No. : 1 of 28 FCC ID. : PPQ-WP8722 FCC RADIO TEST REPORT Applicant : LITE-ON Technology Corp. Address : Bldg. C, 90, Chien 1 Rd., Chung-Ho, New Taipei City, 23585, Taiwan Equipment : Access Point Model No. : WP8722, WP8722-BT Trade Name : LITE-ON FCC ID : PPQ-WP8722 I HEREBY CERTIFY THAT : The sample was received on Dec. 27, 2019 and the testing was completed on Mar. 10, 2020 at Cerpass Technology Corp. The test result refers exclusively to the test presented test model / sample. Without written approval of Cerpass Technology Corp., the test report shall not be reproduced except in full. Approved by: Mark Liao / Supervisor Laboratory Accreditation: Cerpass Technology Corporation Test Laboratory CERPASS TECHNOLOGY CORP. Report No.: TEFU1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 T-FD-503-0 Ver 1.2 Page No. : 2 of 28 FCC ID. : PPQ-WP8722 Contents 1. Summary of Test Procedure and Test Results ................................................................................. 4 1.1 Applicable Standards ................................................................................................................. 4 2. Test Configuration of Equipment under Test ................................................................................... 5 2.1 Feature of Equipment under Test ............................................................................................... 5 2.2 Test Mode and Test Software ..................................................................................................... 6 2.3 Description of Test System ......................................................................................................... 6 2.4 General Information of Test ........................................................................................................ 7 2.5 Measurement Uncertainty .......................................................................................................... 8 3. Test Equipment and Ancillaries Used for Tests ............................................................................... 9 4. Test of AC Power Line Conducted Emission ................................................................................. 11 4.1 Test Result and Data ................................................................................................................ 11 4.2 Test Photographs (30MHz ~ 1GHz) ......................................................................................... 15 5. Test of Spurious Emission (Radiated) ............................................................................................ 17 5.1 Test Limit .................................................................................................................................. 17 5.2 Test Procedures ....................................................................................................................... 17 5.3 Typical Test Setup .................................................................................................................... 18 5.4 Test Result and Data (9kHz ~ 30MHz) ..................................................................................... 19 5.5 Test Result and Data (30MHz ~ 1GHz) .................................................................................... 19 5.6 Test Result and Data (1GHz ~ 25GHz) .................................................................................... 23 5.7 Restricted Bands of Operation ................................................................................................. 25 5.8 Test Photographs (30MHz ~ 1GHz) ......................................................................................... 26 5.9 Test Photographs (1GHz ~ 25GHz) ......................................................................................... 28 CERPASS TECHNOLOGY CORP. Report No.: TEFU1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 T-FD-503-0 Ver 1.2 Page No. : 3 of 28 FCC ID. : PPQ-WP8722 History of this test report Report No. Issue Date Description TEFU1912251 Mar. 18, 2020 Original CERPASS TECHNOLOGY CORP. Report No.: TEFU1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 T-FD-503-0 Ver 1.2 Page No. : 4 of 28 FCC ID. : PPQ-WP8722 1. Summary of Test Procedure and Test Results 1.1 Applicable Standards ANSI C63.10:2013 FCC Rule . Description of Test Result 15.203 . CO-LOCATION PASS *The lab has lowered the uncertainty risk of test equipment, environment, and staff technicians according to ISO-IEC17025. Therefore we define test result as compliant when it complies with the standard without further evaluation of test result uncertainty. *This EUT has been also tested and compiled with the requirement of FCC Part 15, Subpart B, recorded in a separate test report(TEFD1912251). CERPASS TECHNOLOGY CORP. Report No.: TEFU1912251 Cerpass Technology Corp. Issued Date : Mar. 18, 2020 T-FD-503-0 Ver 1.2 Page No. : 5 of 28 FCC ID. : PPQ-WP8722 2. Test Configuration of Equipment under Test 2.1 Feature of Equipment under Test Frequency Range 802.11b/g/n: 2400-2483.5MHz 802.11a/n/ac: 5150-5250MHz, 5725-5850MHz Modulation Type 802.11b: CCK, DQPSK, DBPSK 802.11g/n/a: BPSK, QPSK, 16QAM, 64QAM 802.11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM Modulation Technology DSSS, OFDM Data Rate 802.11b: 1, 2, 5.5, 11Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11n: MCS0 – MCS15, HT20/40 802.11a: 6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11ac: MCS0 – MCS9, VHT20/40/80 Antenna Type PIFA Antenna Antenna Gain 2400-2483.5MHz: ANT A: 4.6dBi, ANT B: 4.5dBi 5150-5250MHz: ANT A: 5.1dBi, ANT B: 5.3dBi 5725-5850MHz: ANT A: 5.1dBi, ANT B: 5.3dBi Note: For more details, please refer to the User’s manual of the EUT. Difference description Model No. Remark WP8722 Market segmentation. WP8722-BT Antenna list: Antenna Number Brand Model Name Ant. Type Connector Support…
