PS6R3000-A1WLAN Base Station and Subscriber Unit

070-20000330-01 Rev A, July 2001 P ACKET W AVE Fixed Wireless Broadband Access System P ACKET W AVE 100 S ERIES S UBSCRIBER E QUIPMENT Installation and Operation Manual PacketWave 100 Installation and Operation ©Copyright 2001 by Aperto Networks All rights reserved. Specifications subject to change. Aperto, PacketWave, and WaveCenter are trademarks of Aperto Networks. All other trademarks used herein are the property of their respective owners. Aperto Networks 1637 South Main Street Milpitas, CA 95035 USA Phone: 408.719.9977 Fax: 408.719.9970 www.apertonet.com iii070-20000330-01 REGULATORY INFORMATION PART 1 5 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con- ditions: 1) this device may not cause harmful electromagnetic interference, and 2) this device must accept any interference received includinginterference that may cause undes- ired operations. FCC NOTICE: Radio and Television Interference The PacketWave 100 Series Subscriber Equipment has been tested and found to comply with the lim- its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful inter- ference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment or device. • Connect the equipment to an outlet other than the receiver's. • Consult a dealer or an experienced radio/TV technician for assistance. v070-20000330-01 Rev A TABLE OF CONTENTS Table of Contents P REFACE Scope of This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii Intended Audience for this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii General Cautions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix C HAPTER 1. Q UICK S TART G UIDE C HAPTER 2. O VERVIEW Subscriber Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 Outdoor Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-2 Indoor Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3 Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4 C HAPTER 3. S ITE P LANNING Location of the Indoor Unit (Bridge/Router) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-1 Location of the Outdoor Unit (Radio/Antenna) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-2 Cables and Cable Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3 Subscriber LAN/Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-3 C HAPTER 4. O UTDOOR U NIT I NSTALLATION Installation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-1 Mounting the Outdoor Unit (Radio/Antenna) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2 Running Cables Between Outdoor and Indoor Units . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-2 Signal Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-3 Control Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-4 vi070-20000330-01 Rev A C HAPTER 1. C HAPTER 5. I NDOOR U NIT I NSTALLATION Installation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-1 Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3 Connecting Radio/Antenna Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-3 Connecting to the Local PC or LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-4 Powering Up the Indoor Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5-5 C HAPTER 6. S TARTING U P Running the CPE Installation (Antenna Alignment) Tool . . . . . . . . . . . . . . . . . . . . . . . . .6-1 Connection to the PacketWave Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2 Setting Up the Local Computer(s) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-2 C HAPTER 7. M ANAGEMENT I NTERFACES Front-Panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-1 Web Interface (GUI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2 Accessing the Web Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-2 Home Page: Connectivity View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-4 Configuration Pages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-5 Device Control Utilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-8 Fault Reporting . …

Text truncated - open the document above for the full version.

PACKETWAVE Fixed Wireless Broadband Access System PACKETWAVE 1000 SERIES BASE STATION EQUIPMENT Installation, Configuration, and Operation Manual 070-20000340-01 Rev. A, July 2001 PacketWave 1000 Manual ©Copyright 2001 by Aperto Networks All rights reserved. Specifications subject to change. Aperto, PacketWave, WaveCenter, RapidBurst, OptimaLink, and ServiceQ are trademarks of Aperto Networks. All other trademarks used herein are the property of their respective owners. Aperto Networks 1637 South Main Street Milpitas, CA 95035 USA Phone: 408.719.9977 Fax: 408.719.9970 www.apertonet.com iii070-20000330-01 REGULATORY INFORMATION PART 1 5 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two con- ditions: 1) this device may not cause harmful electromagnetic interference, and 2) this device must accept any interference received includinginterference that may cause undes- ired operations. FCC NOTICE: Radio and Television Interference The PacketWave 100 Series Subscriber Equipment has been tested and found to comply with the lim- its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful inter- ference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment or device. • Connect the equipment to an outlet other than the receiver's. • Consult a dealer or an experienced radio/TV technician for assistance. v070-20000340-01 Rev A TABLE OF CONTENTS Table of Contents PREFACE Scope of This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .x Intended Audience for this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .x General Cautions and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi CHAPTER 1. QUICKSTART GUIDE Planning, Site Preparation, and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2 Installing and Starting Base Station Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-5 Installing and Starting Subscriber Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-6 CHAPTER 2. PACKETWAVE SYSTEM OVERVIEW Conceptual Overview of the PacketWave System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-1 Cell Size, Capacity, and Scalability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3 Multiple Frequency Bands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3 IP-Based System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4 Range of Backhaul Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4 Subscriber and Network Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-4 Technological Innovations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5 RapidBurst . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5 OptimaLink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5 ServiceQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-5 Base Station (Cell Site) Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6 Base Station Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-6 Multiple Base Station Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7 Base Station Radios and Antennas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-7 Subscriber Site Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-8 The PacketWave System’s IP Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-10 Address Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13 Clustering Wireless Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13 SU-to-SU Bridging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-13 Multiple Subnets on a Wireless Subsystem (WSS) . . . . . . . . . . . . . . . .2-14 Variable-Length Subnets (VLSM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-15 Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-16 vi070-20000340-01 Rev A TABLE OF CONTENTS DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-16 TFTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-16 SNTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17 DNS Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17 SMTP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-17 System Log Server (Syslo…

Text truncated - open the document above for the full version.

CHAPTER 6. BSU AND SUBSCRIBER CONFIGURATION 6–6070-20000340-01 Rev A Managing Configuration Files Before using the WaveCenter Configuration Manager, be sure you understand the principles of configuration file management discussed below. Opening and Loading Files When you click on the BSU or subscriber Indoor Unit (CPE) icon on the WaveCenter Configuration Manager home screen, a new (“blank”) configuration file is opened with the default parameters. You can then load an existing file by selecting File — Open from the menu bar, or the file open icon on the toolbar. The Configuration Man- ager will let you browse for the desired file. NOTE: Some screens have a new instance icon on the right side. This icon does not cause a new configuration file to be opened; rather, it causes a new instance to be opened, and is displayed only on pages which can be configured multiple times for multiple instances (such as multiple SNMP managers; see Figure6-2). Saving Files There are two methods for saving configuration files, as identified in Table6-A: •Selecting File — Save as from the page menu line. The Configuration Manager will prompt for a file name. •Clicking on the Generate BSC Config or Generate Configuration File (CPE) button. The Configuration Manager will prompt with the suggested file name in the format bsc_<MACaddress>.cfg or cpe_<MACaddress>.cfg, using the MAC address entered during configuration. See the discussion of file names below. NOTE: Some screens have a page save icon on the right side. This icon does not cause the configuration file to be saved; rather, it causes the current instance to be added to the configuration file which is being created or modified. The page save icon is displayed only on pages which can be configured multiple times for multiple instances (such as multiple SNMP managers; see Figure6-2). File Names Configuration files are required to have unique names so that each BSU and sub- scriber Indoor Unit can download the correct configuration file from the TFTP server. Table6-B identifies the naming convention suggested by Aperto, which uses MAC addresses to guarantee uniqueness. These are the default names used when you click on the Generate BSC Config or Generate Configuration File button, as described above. While the naming convention identified in Table6-B is recommended, it is not required. You can use any other format you wish, as long as the names are unique. 6–7070-20000340-01 Rev A CHAPTER 6. BSU AND SUBSCRIBER CONFIGURATION Storage Location To be accessed by the Base Station Units and subscriber Indoor Units when they boot, the configuration files must be specified in the DHCP server’s configuration file and stored in the default directory (typically, \tftpboot) of the TFTP server. You can save directly to that directory when creating the configuration files, or save to a different location and then transfer the files before booting the configured units. Configuration Template Files It will often be efficient to create generic configuration files which can be used as templates when adding new BSUs, WSSs, or subscribers. You create and save a configuration template the same way you create and save a con- figuration file, but save it with a descriptive file name rather than a file name linking it by MAC address to a specific unit. Then, when you want to use the template as the basis for a new configuration file, you load the template, make any changes necessary, and save the file using the correct file name for the new unit. NOTE: Similarly, you can base a new configuration file on an existing configuration file by loading the existing file, editing it, and saving it using the proper file name for the new unit. Downloading Configuration Files After the configuration files have been created and stored on the TFTP server, the con- figured devices need to be booted up. (The Base Station Unit must be operational when a subscriber Indoor Unit is initialized, or the initialization will fail.) The booted device will then automatically download its configuration from the TFTP server. Each Base Station Unit and subscriber Indoor Unit stores its configuration in non-volatile memory. When it reboots, it downloads the latest configuration from the TFTP server if it is able to, and then makes any changes to its configuration based on a comparison of the downloaded configuration with the stored configu- ration. If the device cannot successfully download its configuration from the TFTP server, it operates with its stored configuration. Table6-BSuggested Convention for Naming Configuration Files Configured EntityFile Name FormatExample Base Station Unitbsc_<MACaddress>.cfgbsc_00013b0002e4.cfg (for MAC 00:01:3b:00:02:e4) Subscribercpe_<MACaddress>.cfgcpe_00013b00025d.cfg (for MAC 00:01:3b:00:02:5d) CHAPTER 6. BSU AND SUBSCRIBER CONFIGURATION 6–8070-20000340-01 Rev A USING THE WAVECENTER CONFIGURATION MANAGER To configure a cell using the WaveCenter Configuration Manager, follow this general procedure: 1.Launch the WaveCenter Configuration Manager by clicking on the desktop icon. The program’s home screen will be displayed, as shown in Figure6-1. 2.Click on the BSU icon. A BSU Configuration Manager window will open. 3.Configure the Base Station Unit as described later in this chapter, under the heading Base Station Configuration. NOTE: If there are multiple BSUs, you may want to create and use a template file. See the section Managing Configuration Files earlier in this chapter. 4.When you are done, click on the Generate BSC Config button to save the BSU configuration. 5.Close the BSU Configuration Manager window. If there is another BSU to con- figure, return to step 2. If there is no other BSU to configure, go to step 6. 6.Click on the home page’s subscriber Indoor Unit (CPE) icon. A subscriber CPE Configuration Manager window will open. 7.Configure the subscriber equipment as described in the section Subscriber Equipment Configuration later in this chapter. NOTE: You may w…

Text truncated - open the document above for the full version.

tel: 650-726-1263 fax: 650-726-1252 [email protected] Thomas N. Cokenias EMC &Radio Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018email: [email protected] 5 Sept 2000 FCC Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Attention: Application Examiner Reviewing Engineer Re: Request for confidentiality per Section 0.459 of FCC Rules Applicant: Aperto Networks . FCC ID: PS6R3000-A1 To whom it may concern, Request is hereby submitted, on behalf of my client, Aperto Networks, to withhold from public review certain portions of the application for equipment certification for the referenced FCC identifier. In particular, the following sections of the application and report are requested to be kept confidential: Schematics Block Diagram Theory of Operations Rationale for request for confidentiality: Aperto Networks has invested considerable time and materials in research and development to produce the referenced product. Disclosure of the confidential portions of this application to competitors would give them competitive advantage in developing similar products. If you have questions or need further information, please contact the undersigned. Sincerely, tel: 650-726-1263 fax: 650-726-1252 [email protected] THOMAS N. COKENIAS EMC Consultant/Agent for Aperto Networks.

TCB RF Exposure Review Procedure Statement FCC ID: PS6R3000-A1 Transmitter Category Device Type Product Category Approval and Review Procedures Used Specific Procedures: V Part 15 Fixed And Mobil Transmitter UNII Section K SP(2), SP(3), SP(7), SP(8) and SP(9) Grant Condition : The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures with a separation distance of at least 1.5 meters from all persons during normal operation. Users andinstallers must be provided with antenna installation instructions and transmitter operating conditions, includingantenna co-location requirements of § 1.1307(b)(3), for satisfying RF exposure compliance. SP 2 Output power: Verified pages 5 & 7 of test report 15.05dBm, 0.0316WAntenna Gain: The flat panel BSU antenna achieves 15 dBi gain The flat panel CPE antenna achieves 18 dBi gainCable Loss: Any cable attached will reduce output powerAntenna Installation Instructions: See Section 5 of BSE Installation Manual See Section 4.2 of Subscriber Unit Users ManualDuty Cycle: 100% SP 3 Page 3 of subscriber Unit Users ManualPage 3 of Base Station Equipment Installation Manual. SP 7 BSE Installation Manual: Preface pages X & XI, and Section 1 contain instructions andWarnings.Subscriber Unit Users Manual: Preface pages V III, IX, and Section 1 contain ins tructions and Warnings. SP 8 Page 3 of Subscriber Unit Users ManualPage 3 of Base Station Equipment Installation Manual.Numerous Cautionary and Warning Statements are contained in both manuals SP 9 Grant condition has been verified. Reviewed by Barbara L. JudgeCompliance Certification ServicesAugust 30,2001

tel: 650-726-1263 fax: 650-726-1252 [email protected] Thomas N. Cokenias EMC &Radio Approvals Test & Consulting Services for Commercial, Military, International Compliance P.O. Box 1086 El Granada, CA 94018email: [email protected] Aperto Networks28 August 2001 1637 S. Main Street Milpitas, CA 95035 Attention: Dean S.K. Chang Director, Product Management Re: FCC qualified AC/DC power supplies for subscriber unit radio FCC ID: PS6R3000-A1 Dear Dean, Data taken 25 July 2001 at Elliott Laboratories indicates that the following AC to DC converters met FCC class B limits for AC conducted emissions: 1. UMEC Model: UP0451E-18P, s/n: TA064808 2. EDAC Model: EA1050B, s/n: 4 3. APS Model: AD-740U-1180, no serial number noted 4. Powdec Model: WP30180I, no serial number 5. IPS power supply model CUP45-13-2 S/N A-45-0004006 Per our conversation today, you indicated that Aperto will be supplying one of the above models with each production unit. This is to advise that your product will be in compliance with FCC requirements so long as one of the above AC to DC converters is supplied, however, should Aperto decide to use a different supplier or model number, additional testing and an update to your FCC submission will be required. If you have questions or need further information, please don't hesitate to contact me. Sincerely, tel: 650-726-1263 fax: 650-726-1252 [email protected] THOMAS N. COKENIAS EMC Consultant/FCC Agent for Aperto Inc.

This device complies with Part 15 of theFCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation. FCC ID: PS6R3000-A1 This device complies with Part 15 of theFCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference that may cause undesired operation. FCC ID: PS6R3000-A1

Aperto Networks FCC ID: PS6R3000-A1 Photographs, Subscriber Indoor Unit

Aperto Networks FCC ID: PS6R3000-A1 Photographs, Base Station Indoor Unit

File: Product Compliance Matrix.docIssue 1. Product Compliance Matrix Model No: FPA19-55VH-APO2/821 Notes: Date: 15/05/01 Engineer: D. Irvine V Port PCB No: 3352-E Parasite No: 3353-D Denotes Non-Compliance Specification 5.250 GHz 5.625 GHz 5.875 GHz Gain (dBi/dBiC) 18 dBi Nom, 17 dBi Min 18.4 18.4 18.1 Azimuth HPBW ( ° ° ° ° ) 17 ° Typ 19 19 17 Elevation HPBW ( ° ° ° ° ) 17 ° Typ 18 18 17 Electrical Tilt ( ° ° ° ° ) N/A Azimuth RPE (Side lobes,Null fill, front to back etc.) Side lobes: –12dB Max Front to Back: -30 dB Min -15.3-46.0 -14.0-34.0 -13.8-29.6 Elevation RPE (Side lobes,Null fill, front to back etc.) Side lobes: –12dB Max Front to Back: -30 dB Min -14.3-45.0 -13.2-34.5 -14.7-30.6 Azimuth Cross Polar/AxialRatio (dB) -25dB Typ, -20 dB Min -22.1 -22.1 -20.7 Elevation Cross Polar/AxialRatio (dB) -25dB Typ, -20 dB Min -19.0 -26.2 -26.3 Return Loss (dB) -14 dB Typ, -12 dB Max -18.0 -17.0 -14.0 Isolation (dB) -25 dB Typ, -22 dB Min <-40 <-40 <-40 File: Product Compliance Matrix.docIssue 1. Product Compliance Matrix Model No: FPA19-55VH-APO2/821 Notes: Date: 15/05/01 Engineer: D. Irvine H Port PCB No: 3352-E Parasite No: 3353-D Denotes Non-Compliance Specification 5.250 GHz 5.625 GHz 5.875 GHz Gain (dBi/dBiC) 18 dBi Nom, 17 dBi Min 17.3 18.0 18.3 Azimuth HPBW ( ° ° ° ° ) 17 ° Typ 18 18 16.5 Elevation HPBW ( ° ° ° ° ) 17 ° Typ 19 170 17.5 Electrical Tilt ( ° ° ° ° ) N/A Azimuth RPE (Side lobes,Null fill, front to back etc.) Side lobes: –12dB Max Front to Back: -30 dB Min -14.0 >-40 -13.3 >-35 -12.2 >-29 Elevation RPE (Side lobes,Null fill, front to back etc.) Side lobes: –12dB Max Front to Back: -30 dB Min -17.0 >-35 -18.0 >-40 -14.4 -30 Azimuth Cross Polar/AxialRatio (dB) -25dB Typ, -20 dB Min -17.3 -28.9 -30.0 Elevation Cross Polar/AxialRatio (dB) -25dB Typ, -20 dB Min -23.9 -27.7 -24.4 Return Loss (dB) -14 dB Typ, -12 dB Max -14.0 -19.0 -23.0 Isolation (dB) -25 dB Typ, -22 dB Min <-40 <-40 <-40

.350 .018 Dia. .20 Min. .300 Max. Max. Max. 17 14 8 C .300 .150 .10 .600 Marking .80 .50 Square Corner Pin 1 CO-770 Series 4 Pin DIP Oven Controlled Crystal Oscillator Features Extremely Small Dimensions Very Fast Warm-up Low Power Consumption Shock Resistance: 2000g/0.3 ms (1/2 sine) Vibration Resistance: 10g/10 to 2000 Hz Acceleration Sensitivity: 3.5 x 10 -9 /G Standard 10 MHz Version Available from Stock Applications Telecom Transmission and Switching Equipment Wireless Communication Equipment Networking Equipment Description The model CO-770, low profile 4 Pin DIP Oven Controlled Crystal Oscillator (OCXO) is available in frequencies from 10 kHz to 24 MHz with higher frequencies available to 80 MHz on special order. This unit provides exceptionally low aging rates and temperature stabilities in an extremely small package. It measures only 0.50" x 0.80" x 0.35" (12.7mm x 20.3mm x 8.9mm); provides aging rates of <3 x 10 -9 /day average, <7 x 10 -7 /first year and <4 x 10 -6 over 10 years with temperature stabilities from 5 x 10 -8 over to Wider temperature ranges are available to to The CO-770 series offers a +5V or +12V supply and HCMOS or clipped sinewave output options. Pin Function 7 1 8 14 Frequency control 0V, Case Output Vcc Vectron International 166 Glover Avenue, Norwalk, CT 06856 Tel: 1-88-VECTRON-1 Fax: 1-888-FAX-VECTRON Frequency10 MHz Standard. Advertised specifications available from 10 kHz to 24 MHz. Available to 80 MHz on special order. Temperature Stabilityto B58: 5 x 10 -8 to D17: 1 x 10 -7 to H27: 2 x 10 -7 Aging<3 x 10 -9 /day average, <7 x 10 -7 first year, <4 x 10 -6 for 10 years Frequency vs. Supply 4%)1 x 10 -7 Short Term(Allan Variance)<5 x 10 -10 , 0.1 seconds to 10 seconds Supply/OutputType Supply VoltageOutput CO-770+12 Vdc 0.5VHCMOS* CO-771+ 5 Vdc 0.2VClipped Sine (1-2VPK-PK into 1K W) CO-772+ 5 Vdc 0.2VHCMOS* CO-773+12 Vdc 0.5VClipped Sine (1-2VPK-PK into 1K W) *Symmetry(@50% Vdd)60/40 to 40/60 *Rise/Fall Time:(10-90%) (15pF load)<7ns *Level 0 and 1<0.4V, >4.5V Input Current+12 Vdc +5 Vdc <25 mA @ <60 mA @ <40 mA @ -<80 mA @ - Turn-on Current+12 Vdc +5 Vdc <120 mA first 10 seconds<200 mA first 10 seconds Warm-Up @ C<1 x 10 -6 15 seconds (24 hours off relative to the frequency <1 x 10 -7 60 seconds 2 hours after turn-on)<5 x 10 -8 10 minutes Phase Noise (Typical @ 10 MHz)+12 Vdc+5 Vdc Sine and HCMOSOffsetPhase NoisePhase Noise 1 Hz- 70 dBc/Hz- 60 dBc/Hz 10 Hz-100 dBc/Hz- 90 dBc/Hz 100 Hz-125 dBc/Hz-120 dBc/Hz 1 kHz-135 dBc/Hz-130 dBc/Hz Acceleration Sensitivity:(Worst case axis)3.5 x 10 -9 /G Frequency Voltage Control4 ppm range with 0 to +5V input (external resistor adjustment available on special order) Size0.50" x 0.80" x 0.35" (12.7 x 20.3 x 8.9 mm) Base4 pin DIP package with standoffs How To Order CO-77 at Supply/OutputFrequency Temperature Stability Option USA: Vectron International 166 Glover Avenue, Norwalk, CT 06856 Tel: 1-88-VECTRON-1 Fax: 1-888-FAX-VECTRON EUROPE: In Denmark, Finland, Ireland, Italy, Isreal, Norway, Spain, UK: Tel: 44(0) 1703 766 288 Fax: 44 (0) 1703 766 822 In Austria, Belgium, France, Germany, Luxembourg, Netherlands, Sweden, Switzerland: Tel: 49 (0) 72 63 648 0 Fax: 49(0) 72 63 619 6 ASIA: In China, Taiwan, Japan: Tel: 1-603-598-0070 Fax: 1-603-598-0075 In Korea, Singapore, Australia, India: Tel: 1-203-853-4433 Fax: 1-203-849-1423 Vectron International reserves the right to make changes to the product(s) and/or information contained herein without notice. No liability is assumed as a result of their use or application. No rights under any patent accompany the sale of any such product(s) or information. CO-770 4 Pin DIP Oven Controlled Crystal Oscillator Performance Characteristics Parameter For Additional Information Please Contact: Characteristic

Aperto NetworksFCC ID: PS6R3000-A1 15.407(f) RF Exposure Information Worst case MPE Calculations : 15 dBm into 18 dBi Antenna (CPE): RF Haz ard Dista nce Calculatio n mW/cm2 from Table1:1.00 Max RF PowerTX AntennaMPE P, dBmG, dBiSafe Distance, cm 15.018.012.6 Basis of Calculations: E^2/3770 = S, mW/cm2 E, V/m = (Pwatts*Ggain*30)^.5/d, meters d = ((Pwatts*G*30)/3770*S))^0.5Pwatts*Ggain = 10^(PdBm-30+GdBi)/10) NOTE: To meet FCC require ments for fixed location transmitters, minimum separation distance is 1.5m, even if calculations indicate MPE distance is less The user manual will require a minimum separation of 1.5m for this product. Refer to user manual page, separate attachment.

Aperto NetworksFCC ID: PS6R3000-A1 1 of 27 EXHIBIT 2:Product Description and Operation Overview General Overview The Aperto Networks upper U-NII band radio consists of a indoor unit (IDU) network interface and an outdoor unit (ODU) radio head. The IDU connects to the digital network via CAT5 cable. The IDU is connected to the ODU via shielded CAT5 cable for control and an RG6 with F connector for signal/data. (from user manual): Frequency Band: Full-duplex operation in the UNII …
