PVCGTP212Audio Video Transmitter

FCC ID: PVCGTP212 A1: The Block diagram for transmitter has submitted. A2: All models’ PCB are the same and only for different customers. A3: Internal photographs of transmitter module has submitted. A4: The form 731 has corrected and submitted. A5: The users manual has corrected and submitted. A6: Because the unwanted emission will fail if the output power yields 97 dBV/m, so the client decreased the output power by external components. A7: The user manual has been corrected and submitted. A8: Corrected as submitted document. A9: Peak: RBW=1M, VBM=1M; Average: RBW=1M, VBW=10Hz A10: Corrected as attachment. A11: RBW=1M; VBM=1M Training Research Co., Ltd. Jacob Lin

Timothy : (1) Yes, they put a bypass capacitor on the ANT output which is located near the ANT connection on the main PCB. (2) I think you can see the component by internal photo. Maybe it is too small. (3)(4) I will do it after you can understand my explanation for (1) (2) . Wait for your further information ,Thanks ! Jacob Lin ----- Original Message ----- From: Timothy R. Johnson <[email protected]> To: Jacob <[email protected]> Sent: Friday, July 05, 2002 1:49 PM Subject: Re: Review of Grandtec Electronic Corp., FCC ID: PVCGTP212 Jacob, Thank you for your reply. Most of the information is resolved. However, I do not understand what your response to Question 6) means: "A6: Because the unwanted emission will fail if the output power yields 97 dBìV/m, so the client decreased the output power by external components." 1) Does this mean that modifications were required to pass? Yes or No. Please try and explain what was done. 2) Where are the external components you mentioned? The RF is a OEM module. I did not see any components after the Antenna output from the module. If there are components here, then this should be shown. 3) Please provide a higher resolution page 2 schematic. The one provided is not clear enough. 4) Also, the corrected pages to the test report were uploaded with the confidentiality checked. Please note that we can not hold test report information as confidential. Thanks, Tim To: "Timothy R. Johnson" <[email protected]> Subject: Re: Review of Grandtec Electronic Corp., FCC ID: PVCGTP212 Page 1 of 1Grandtec Elect PVCGTP212 7/14/2002Printed for "Timothy R. Johnson" <[email protected]>

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 30, 2002 RE: Grandtec Electronic Corp. FCC ID: PVCGTP212 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The block diagram provided is for the receiver. Please provide a block diagram for the transmitter. 2) Several model numbers are listed throughout the application. Please explain the differences between each of these models and also provide the justification made for which one was selected for testing. 3) Please provide internal photographs of the RF portion of the product with the shield removed. Since the RF section of this product is a separate component, please be sure to provide top and bottom photographs of the component as well. 4) The Form 731 should state the actual frequency tuning/transmission range of the device. Please adjust section 6 of the 731 form to state 2410-2470 MHz. 5) FYI, for products certified under 15.249, RF exposure information is not required. a) The users manual contains RF exposure information on the bottom of page 2. Please remove the section (3) contained at the bottom of page 2 in the users manual regarding RF Exposure information. b) We will ignore the RF Exposure exhibit provided. 6) An output of 1 dBm with a 1 dBi gain antenna should yield a field strength at 3 meters of around 97 dBuV/m (the limit is 94 dBuV). However the maximum reading obtained was 86 dBuV/m, which is about 10 dB lower than expected. Please explain this discrepancy. 7) The test report (page 6 of 30) states a TX power of 1 dBm, while the Users Manual (page 5 of 13) states 10 dBm. Given a 1/4 wave dipole and a limit of 94 dBuV/m @ 3 meters, the output power would have to be under 1 dBm. Please correct affected exhibits. 8) Please update section 1.6 of the test report to include information for the OAT's site used for < 1 GHz. testing. 9) Please confirm both the RBW & VBW settings used for peak and average radiated measurements above 1 GHz. 10) Please correct the tables on pages 20, 22, 23, & 24 of the test report to show the raw readings and the correction factors applied. 11) Please provide the RBW and VBW settings used for Appendix B. Also, please provide a calculation for this data showing compliance with 15.209. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. z Page 2June 30, 2002 Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : PVCGTP212 Model No.: 6.8’ LCD Monitor LABEL Size: 30 X14 mm LABEL Position: LABEL LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : PVCGTP212 Model No.: Grand GT-6801 LABEL Size: 30 X14 mm LABEL Position: LABEL LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : PVCGTP212 Model No.: Grand RF Guard CMOS LABEL Size: 30 X14 mm LABEL Position: LABEL LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : PVCGTP212 Model No.: Grand RF Guard CCD LABEL Size: 30 X14 mm LABEL Position: LABEL

u APPLICATION & FEATURES: 2.4GHz A/V Module uses FM modulation technology to provide ISM band wireless audio and video connection. Multi channels are specially designed to enhance the function of automatic channel switching as will as digital PLL and uP Technology. l The major applications can be the followings: Wireless Audio/Video Sender. Wireless Security System. l The features are: Compact Size & Low Cost ( module include all baseband circuit ). Provide High Quality Video and Stereo Audio Transmission. Multi Channel ( enhance channel for special purpose application ). ELECTRICAL SPECIFICATION: TX MODULE: AVMT15T/D ITEM SPEC REMARK Frequency 2400MHz ~ 2483MHz Tx Power 1dBm Typical Channel Number 4 2410,2430,2450,2470MHz Frequency Stability ±100KHz Typical Video Input Level 1Vp-p Typical Audio Input Level 1Vrms Typical Supply Voltage 3.3V +/- 0.05V Current Consumption 50mA Typical Antenna Port Half Pitch Pin Header 1.27mm Pitch Baseband Interface Half Pitch Pin Header 1.27mm Pitch Dimension (mm) 44Wx17Dx6H Unit is mm Operating Temperature 10 ~ 50 ° C RX MODULE: AVMR9T/D ITEM SPEC REMARK Frequency 2400MHz ~ 2483MHz Rx Sensitivity -90dBm Typical Channel Number 4 2410,2430,2450,2470MHz Lo Stability ±100KHz Typical Video Output Level 1Vp-p +/- 0.1V Typical Video Differential Phase 10 ° Typical Video Differential Gain 5% Typical Audio Output Level 1Vrms Typical Audio SNR 50dB Typical Supply Voltage 5V +/- 0.05V Current Consumption 150mA Typical Antenna Port Half Pitch Pin Header 1.27mm Pitch Baseband Interface Half Pitch Pin Header 1.27mm Pitch Dimension 40Wx32Dx6H Unit is mm Operating Temperature 10 ~ 50 ° C AVMT15T APPLICATION CIRCUIT ( TACT SWITCH ) 1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:23-Mar-2001Sheet of File:E:\Hartronics\..\AVSENDER_TX3.SchDrawn By: J2 AUDIO1_IN J3 VIDEO_IN D4 LED D3 LED D2 LED D1 LED R1 330 3V SW1 TACT_SW AVMT15T APPLICATION CIRCUIT(TACT SWITCH) C5 470uF C1 NFM21CC220U1H3 C2 NFM21CC220U1H3 C3 NFM21CC220U1H3 J1 AUDIO2_IN C4 NFM21CC220U1H3 LED_CH1 1 LED_CH2 2 LED_CH3 3 SW 4 LED_CH4 5 3V 6 VIDEO 7 GND 8 AUDIO1 9 AUDIO2 10 ANT 11 GND 12 U1 AVMT15T AVMT15D APPLICATION CIRCUIT ( DIP SWITCH ) 1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:23-Mar-2001Sheet of File:E:\Hartronics\..\AVSENDER_TX4.SchDrawn By: J2 AUDIO1_IN J3 VIDEO_IN 3V AVMT15D APPLICATION CIRCUIT(DIP SWITCH) C5 470uF S1 S2 S3 S1 S2 S3OOOOGGGG G GG GG GG GO O O O O O O O CH1 2410MHzCH2 2430MHzCH3 2450MHzCH4 2470MHzCH5 2370MHzCH6 2390MHzCH7 2490MHzCH8 2510MHz C1 NFM21CC220U1H3 C2 NFM21CC220U1H3 C3 NFM21CC220U1H3 C4 NFM21CC220U1H3 J1 AUDIO2_IN LED_CH1 1 LED_CH2 2 LED_CH3 3 SW 4 LED_CH4 5 3V 6 VIDEO 7 GND 8 AUDIO1 9 AUDIO2 10 ANT 11 GND 12 U? AVMT15D AVMR9T APPLICATION CIRCUIT ( TACT SWITCH ) 1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:23-Mar-2001Sheet of File:E:\Hartronics\..\AVSENDER_RX1.SchDrawn By: J1 AUDIO2_OUT J2 AUDIO1_OUT J3 VIDEO_OUT D4 LED D3 LED D2 LED D1 LED R1 680 5V SW1 TACT_SW AVMR9T APPLICATION CIRCUIT(TACT SWITCH) LED_CH1 1 LED_CH2 2 LED_CH3 3 SW 4 LED_CH4 5 5V 6 VIDEO 7 GND 8 AUDIO1 9 AUDIO2 10 ANT 11 GND 12 U1 AVMR9T L1 15uH C2 47pFC3 470uF C1 NFM21CC101U1H3 C4 NFM21CC101U1H3 C5 NFM21CC101U1H3 C6 NFM21CC101U1H3 AVMR9D APPLICATION CIRCUIT ( DIP SWITCH ) 1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:23-Mar-2001Sheet of File:E:\Hartronics\..\AVSENDER_RX2.SchDrawn By: J1 AUDIO2_OUT J2 AUDIO1_OUT J3 VIDEO_OUT 5V AVMR9D APPLICATION CIRCUIT(DIP SWITCH) LED_CH1 1 LED_CH2 2 LED_CH3 3 SW 4 LED_CH4 5 5V 6 VIDEO 7 GND 8 AUDIO1 9 AUDIO2 10 ANT 11 GND 12 U1 AVMR9D L1 15uH C2 47pFC3 470uF C1 NFM21CC101U1H3 C4 NFM21CC101U1H3 C5 NFM21CC101U1H3 C6 NFM21CC101U1H3 S1 S2 S3 S1 S2 S3OOOOGGGG G GG GG GG GO O O O O O O O CH1 2410MHzCH2 2430MHzCH3 2450MHzCH4 2470MHzCH5 2370MHzCH6 2390MHzCH7 2490MHzCH8 2510MHz AVMT15 FOOTPRINT & DIMENSION(TOP VIEW): AVMR9 FOOTPRINT & DIMENSION(TOP VIEW):

Test Report ----------------------------------------------------------------------------- 1/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 MEASUREMENT REPORT of Wireless Audio Video Transmitter Applicant : GRANDTEC ELECTRONIC CORP. Product Name : 2.4GHz AV Sender built-in color CMOS video camera Model No. : 6.8’ LCD Monitor; Grand GT-6801; Grand RF Guard CMOS; Grand RF Guard CCD FCC ID : PVCGTP212 EUT : Audio/Video Transmitter Report No. : GA215142 Followed by : 47 CFR, Part 15, Subpart C Test by : Training Research Co., Ltd. TEL : 886-2-26461146 FAX : 886-2-26461778 15, Lane 530 Pa-Lian Rd., Sec. 1, Hsichih, Taipei Hsien 221, Taiwan, R.O.C. Test Report ----------------------------------------------------------------------------- 3/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 CONTENTS I. GENERAL 1.1 Introduction ..................................................................................................................... 5 1.2 Description of EUT ......................................................................................................... 5 1.3 Description of Support Equipment ................................................................................ 6 1.4 Configuration of System Under Test ............................................................................. 7 1.5 Test Procedure ................................................................................................................. 9 1.6 Location of the Test Site ................................................................................................. 9 1.7 General Test Condition ................................................................................................... 9 II. Conducted Emissions Measurements 2.1 Test Condition & Setup ................................................................................................ 10 2.2 List of Test Instruments ................................................................................................ 10 2.3 Test Configuration ......................................................................................................... 11 2.4 Test Result of Conducted Emissions ........................................................................... 13 III. Radiated Emissions Measurements 3.1 Test Condition & Setup ................................................................................................ 16 3.2 List of Test Instruments ................................................................................................ 17 3.3 Test Instruments Configuration .................................................................................... 18 3.4 Test Result of Radiated Emissions ............................................................................... 20 3.5 Test Result of Spurious Radiated Emissions ............................................................... 21 . Verify Frequencies and Channels.................................................................................... 25 Appendix A .............................................................................................................................. 26 Appendix B .............................................................................................................................. 28 Test Report ----------------------------------------------------------------------------- 4/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 TABLES Table 1 Power Line Conducted Emissions [Channel 1]........................................................................................................... 13 Table 2 Power Line Conducted Emissions [Channel 3]........................................................................................................... 14 Table 3 Power Line Conducted Emissions [Channel 4]........................................................................................................... 15 Table 4 Open Field Radiated Emissions [Channel 1, Horizontal, 30MHz1GHz]........................................................... 21 Table 5 Open Field Radiated Emissions [Channel 1, Vertical, 30MHz1GHz] .............................................................. 21 Table 6 Open Field Radiated Emissions [Channel 1, Horizontal, 1GHz24GHz] .......................................................... 22 Table 7 Open Field Radiated Emissions [Channel 1, Vertical, 1GHz24GHz] .............................................................. 22 Table 8 Open Field Radiated Emissions [Channel 3, Horizontal, 1GHz24GHz] .......................................................... 23 Table 9 Open Field Radiated Emissions [Channel 3, Vertical, 1GHz24GHz] .............................................................. 23 Table 10 Open Field Radiated Emissions [Channel 4, Horizontal, 1GHz24GHz] .......................................................... 24 Table 11 Open Field Radiated Emissions [Channel 4, Vertical, 1GHz24GHz] .............................................................. 24 Test Report ----------------------------------------------------------------------------- 5/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Applicant in support of audio/video transmitter certification in accordance with Part 2 Subpart J and Part 15 Subpart A and C of the Commission's Rules and Regulations. 1.2 Description of EUT Product Name : 2.4GHz AV Sender built-in color CMOS video camera Model No. : 6.8’ LCD Monitor; Grand GT-6801; Grand RF Guard CMOS; Grand RF Guard CCD FCC ID : PVCGTP212 Frequency Range : 2400 – 2483 MHz Support Channel : 4 Channel Power Type : Powered by adaptor Model: YAD-0600800C I/P: 120V…

Text truncated - open the document above for the full version.

Test Report ----------------------------------------------------------------------------- 9/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 1.5 Test Procedure All measurements contained in this report were performed mainly according to the techniques described in Measurement procedure ANSI C63.4 (1992). 1.6 Location of the Test Site The radiated emissions measurements required by the rules were performed on the three-meter, Anechoic Chamber (Registration Number: 93906) and ten-meter OATS (Registration Number: 91035) maintained by Training Research Co., Ltd. 1F., No. 2, Lane 194, Huan-Ho Street, Hsichih, Taipei Hsien 221, Taiwan, R.O.C. Complete description and measurement data have been placed on file with the commission. The conducted power line emissions tests and other test items were performed in a anechoic chamber also located at Training Research Co., Ltd. 1F, No. 2, Lane 194, Huan-Ho Street, Hsichih, Taipei Hsien 221, Taiwan, R.O.C. Training Research Co., Ltd. is listed by the FCC as a facility available to do measurement work for others on a contract basis. 1.7 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests were chosen as that which produced the highest emission levels. However, only those conditions, which the EUT was considered likely to encounter in normal use were investigated. In test, the base and handset are tested separately. They were set in Ch1, Ch3 and Ch4 of EUT and continuously transmitting mode that controlled by test mode of EUT. Test Report ----------------------------------------------------------------------------- 20/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 3.4 Test Result of Radiated Emissions The peak values of fundamental emissions from the EUT at various antenna heights, antenna polarization, EUT orientation, etc. are recorded on the following. Product Name : 2.4GHz AV Sender built-in color CMOS video camera Model No. : 6.8’ LCD Monitor; Grand GT-6801; Grand RF Guard CMOS; Grand RF Guard CCD Open Field Fundamental Emissions Channel Frequency (MHz) A. P. (H/V) A.H. (m) Table (degree) Reading (Peak ) (dBV/m) Correction Factors (dB/m) Amplitude (Peak ) (dBV/m) Limit (dBV) Margin (dBV) 2412.63 H 1.00 74 78.88 6.40 85.28 94.00 -8.72 1 2412.68 V 1.00 137 78.65 6.40 85.05 94.00 -8.95 2451.42 H 1.00 32 79.26 6.60 85.86 94.00 -8.14 3 2451.73 V 1.00 154 78.80 6.60 85.40 94.00 -8.60 2470.43 H 1.00 190 79.12 6.80 85.92 94.00 -8.08 4 2470.24 V 1.00 128 79.27 6.80 86.07 94.00 -7.93 Note: 1. A. P. means antenna polarization, horizontal and vertical. 2. A. H. means antenna height. 3. Table means turntable turning position. 4. Amplitude means the fundamental emission measured. 5. Margin = Amplitude-limit Test Report ----------------------------------------------------------------------------- 22/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Table 6 Open Field Radiated Emissions for 1GHz ~ 24GHz [Channel 1, Horizontal] Radiated Emission Corrected Amplitude FCC Class B ( 3 m ) (dBV/m) Limit Frequency (GHz) Amplitude (dBV/m) Ant. H. (m) Table ( ) Correction Factors ( dB ) Peak Average Peak Average Margin (dB) *4.829 48.94 1.00 114 4.00 52.94 --- 74.0 54.00 -1.06 7.245 38.07 1.00 240 10.20 48.27 --- 74.0 54.00 -5.73 --- Note: 1. Margin = Corrected - Limit. 2. Peak Amplitude + Correction Factor = Corrected 3. The “ * “ means restricted bands. 4. Above emissions of 10GHz, passed by more than 20dB margin. 5. Peak: RBW=1M, VBM=1M; Average: RBW=1M, VBW=10Hz Table 7 Open Field Radiated Emissions for 1GHz ~ 24GHz [Channel 1, Vertical] Radiated Emission Corrected Amplitude FCC Class B ( 3 m ) (dBV/m) Limit Frequency (GHz) Amplitude (dBV/m) Ant. H. (m) Table ( ) Correction Factors ( dB ) Peak Average Peak Average Margin (dB) *4.832 48.61 1.00 42 4.00 52.61 --- 74.0 54.00 -1.39 *7.263 36.74 1.00 34 10.20 46.94 --- 74.0 54.00 -7.06 --- Note: 1. Margin = Corrected - Limit. 2. Peak Amplitude + Correction Factor = Corrected. 3. The “ * “ means restricted bands. 4. Above emissions of 10GHz, passed by more than 20dB margin. 5. Peak: RBW=1M, VBM=1M; Average: RBW=1M, VBW=10Hz Test Report ----------------------------------------------------------------------------- 23/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Table 8 Open Field Radiated Emissions for 1GHz ~ 24GHz [Channel 3 Horizontal] Radiated Emission Corrected Amplitude FCC Class B ( 3 m ) (dBV/m) Limit Frequency (GHz) Amplitude (dBV/m) Ant. H. (m) Table ( ) Correction Factors ( dB ) Peak Average Peak Average Margin (dB) *4.901.67 48.84 1.00 90 4.10 52.94 --- 74.0 54.00 -1.06 *7.348.54 39.21 1.00 162 10.40 49.61 --- 74.0 54.00 -4.39 --- Note: 1. Margin = Corrected - Limit. 2. Peak Amplitude + Correction Factor = Corrected. 3. The “ * “ means restricted bands. 4. Above emissions of 10GHz, passed by more than 20dB margin. 5. Peak: RBW=1M, VBM=1M; Average: RBW=1M, VBW=10Hz Table 9 Open Field Radiated Emissions for 1GHz ~ 24GHz [Channel 3, Vertical] Radiated Emission Corrected Amplitude FCC Class B ( 3 m ) (dBV/m) Limit Frequency (GHz) Amplitude (dBV/m) Ant. H. (m) Table ( ) Correction Factors ( dB ) Peak Average Peak Average Margin (dB) *4.901 46.67 1.00 215 4.10 50.77 --- 74.0 54.00 -3.23 *7.348 38.54 1.00 18 10.40 48.94 --- 74.0 54.00 -5.06 --- Note: 1. Margin = Corrected - Limit. 2. Peak Amplitude + Correction Factor = Corrected. 3. The “ * “ means restricted bands. 4. Above emissions of 10GHz, passed by more than 20dB margin. 5. Peak: RBW=1M, VBM=1M; Average: RBW=1M, VBW=10Hz Test Report ----------------------------------------------------------------------------- 24/30 Report No.…

Text truncated - open the document above for the full version.

Test Report ----------------------------------------------------------------------------- 11/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 2.3 Test configuration Test Report ----------------------------------------------------------------------------- 12/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Test Report ----------------------------------------------------------------------------- 18/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 3.3 Test Configuration of Radiated Emission Picture 1 Front View of the Test Configuration Test Report ----------------------------------------------------------------------------- 19/30 Report No.: GA215142, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 Picture 2 Rear View of the Test Configuration The test configuration for frequency between 1GHz to 24GHz is same as above.
