PVCGTP224Wireless Audio Video Transmitter

EXHIBIT E Block Diagram

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 May 22, 2002 RE: FCC ID: PVCGTP224 Attention: Jack Tsai I have a few comments on this Application. 1 The Bi-log Antenna (CBL6141A from Schaffner) serial # 4206 shows that it was out of cal when the test was performed. The Antenna is listed as having to be calibrated by 03/09/02, yet the test was performed 5/14/02. Section 3.1 shows that this antenna was used for the test. Please provide a test report with properly calibrated test equipment. xx 2 Section 3.1 of the report says that the final radiated emissions was done in an anechoic chamber. The test setup photos and the table in section 3.4 of the report say it was done on an OATS. Please correct the report to be consistent for OATS testing. xx 3 Because item one is out of calibration, the following becomes a concern. The Tx chip in the device is listed as a 10mW device (10dBm). This being the case, assuming the 10mW was delivered to the antenna terminal and with a 1.26 gain antenna the dBuV level at 3 meters would be approximately 100+dBuV. The report states that the highest measured reading was 77+ dBuV at 3 meters. Please clarify the actual power rating of the chip Tx power and please verify, using calibrated antenna(s), what the field strength is at 3 meters is. This request is in conjunction with item 1 above. xx 4 The RF exposure calculations are used to estimate the closest range the device can operate to a person so a claim of compliance to 1.1307 can be made. The RF exposure statement you provided only uses the field strength, gain and distance to calculate the value of S. This does not provide the distance factor necessary to make a claim of categorical exclusion as specified in 1.1306. Please correct this RF exposure statement to provide the minimum distance the device is allowed to be to the person by which categorical exclusion is made. xx 5 Also, please note that this distance statement provided categorical exclusion needs to be in the manual. A statement similar to “The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.” Is sufficient. xx 6 Please note that since there is no request for confidentiality, no part of this application will be held confidential. If confidentiality is requested, please provide a letter requesting confidentiality under 0.457 and 0.459 of CFR47. If confidentiality is requested please specify which parts are confidential. Only schematics, theory of operations and block diagrams are typically held confidential. xx Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Dennis : 1. Attached the calibrated certificate for your reference. Corrected page attached. 2. Under 1GHz tested in OATS , above 1GHz in chamber Corrected page attached 3. Because the spurious, decrease the power , so 77 dBuV/m It is right . 4. Attached the statement. 5. attached the manual . 6. No confidentially requested TRC Jacob Lin

LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : PVCGTP224 Model No.: GTP224 LABEL Size: 42 X22 mm LABEL Position: LABEL

LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : PVCGTP224 Model No.: GTP224 LABEL Size: 42 X22 mm LABEL Position: LABEL

u APPLICATION & FEATURES: 2.4GHz A/V Module uses FM modulation technology to provide ISM band wireless audio and video connection. Multi channels are specially designed to enhance the function of automatic channel switching as will as digital PLL and uP Technology. l The major applications can be the followings: Wireless Audio/Video Sender. Wireless Security System. l The features are: Compact Size & Low Cost ( module include all baseband circuit ). Provide High Quality Video and Stereo Audio Transmission. Multi Channel ( enhance channel for special purpose application ). ELECTRICAL SPECIFICATION: TX MODULE: AVMT15T/D ITEM SPEC REMARK Frequency 2400MHz ~ 2483MHz Tx Power 10dBm Typical Channel Number 4 2415,2435,2455,2475MHz Frequency Stability ±100KHz Typical Video Input Level 1Vp-p Typical Audio Input Level 1Vrms Typical Supply Voltage 3.3V +/- 0.05V Current Consumption 50mA Typical Antenna Port Half Pitch Pin Header 1.27mm Pitch Baseband Interface Half Pitch Pin Header 1.27mm Pitch Dimension (mm) 44Wx17Dx6H Unit is mm Operating Temperature 10 ~ 50 ° C RX MODULE: AVMR9T/D ITEM SPEC REMARK Frequency 2400MHz ~ 2483MHz Rx Sensitivity -90dBm Typical Channel Number 4 2415,2435,2455,2475MHz Lo Stability ±100KHz Typical Video Output Level 1Vp-p +/- 0.1V Typical Video Differential Phase 10 ° Typical Video Differential Gain 5% Typical Audio Output Level 1Vrms Typical Audio SNR 50dB Typical Supply Voltage 5V +/- 0.05V Current Consumption 150mA Typical Antenna Port Half Pitch Pin Header 1.27mm Pitch Baseband Interface Half Pitch Pin Header 1.27mm Pitch Dimension 40Wx32Dx6H Unit is mm Operating Temperature 10 ~ 50 ° C AVMT15T APPLICATION CIRCUIT ( TACT SWITCH ) 1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:23-Mar-2001Sheet of File:E:\Hartronics\..\AVSENDER_TX3.SchDrawn By: J2 AUDIO1_IN J3 VIDEO_IN D4 LED D3 LED D2 LED D1 LED R1 330 3V SW1 TACT_SW AVMT15T APPLICATION CIRCUIT(TACT SWITCH) C5 470uF C1 NFM21CC220U1H3 C2 NFM21CC220U1H3 C3 NFM21CC220U1H3 J1 AUDIO2_IN C4 NFM21CC220U1H3 LED_CH1 1 LED_CH2 2 LED_CH3 3 SW 4 LED_CH4 5 3V 6 VIDEO 7 GND 8 AUDIO1 9 AUDIO2 10 ANT 11 GND 12 U1 AVMT15T AVMT15D APPLICATION CIRCUIT ( DIP SWITCH ) 1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:23-Mar-2001Sheet of File:E:\Hartronics\..\AVSENDER_TX4.SchDrawn By: J2 AUDIO1_IN J3 VIDEO_IN 3V AVMT15D APPLICATION CIRCUIT(DIP SWITCH) C5 470uF S1 S2 S3 S1 S2 S3OOOOGGGG G GG GG GG GO O O O O O O O CH1 2410MHzCH2 2430MHzCH3 2450MHzCH4 2470MHzCH5 2370MHzCH6 2390MHzCH7 2490MHzCH8 2510MHz C1 NFM21CC220U1H3 C2 NFM21CC220U1H3 C3 NFM21CC220U1H3 C4 NFM21CC220U1H3 J1 AUDIO2_IN LED_CH1 1 LED_CH2 2 LED_CH3 3 SW 4 LED_CH4 5 3V 6 VIDEO 7 GND 8 AUDIO1 9 AUDIO2 10 ANT 11 GND 12 U? AVMT15D AVMR9T APPLICATION CIRCUIT ( TACT SWITCH ) 1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:23-Mar-2001Sheet of File:E:\Hartronics\..\AVSENDER_RX1.SchDrawn By: J1 AUDIO2_OUT J2 AUDIO1_OUT J3 VIDEO_OUT D4 LED D3 LED D2 LED D1 LED R1 680 5V SW1 TACT_SW AVMR9T APPLICATION CIRCUIT(TACT SWITCH) LED_CH1 1 LED_CH2 2 LED_CH3 3 SW 4 LED_CH4 5 5V 6 VIDEO 7 GND 8 AUDIO1 9 AUDIO2 10 ANT 11 GND 12 U1 AVMR9T L1 15uH C2 47pFC3 470uF C1 NFM21CC101U1H3 C4 NFM21CC101U1H3 C5 NFM21CC101U1H3 C6 NFM21CC101U1H3 AVMR9D APPLICATION CIRCUIT ( DIP SWITCH ) 1234 A B C D 4321 D C B A Title NumberRevisionSize A4 Date:23-Mar-2001Sheet of File:E:\Hartronics\..\AVSENDER_RX2.SchDrawn By: J1 AUDIO2_OUT J2 AUDIO1_OUT J3 VIDEO_OUT 5V AVMR9D APPLICATION CIRCUIT(DIP SWITCH) LED_CH1 1 LED_CH2 2 LED_CH3 3 SW 4 LED_CH4 5 5V 6 VIDEO 7 GND 8 AUDIO1 9 AUDIO2 10 ANT 11 GND 12 U1 AVMR9D L1 15uH C2 47pFC3 470uF C1 NFM21CC101U1H3 C4 NFM21CC101U1H3 C5 NFM21CC101U1H3 C6 NFM21CC101U1H3 S1 S2 S3 S1 S2 S3OOOOGGGG G GG GG GG GO O O O O O O O CH1 2410MHzCH2 2430MHzCH3 2450MHzCH4 2470MHzCH5 2370MHzCH6 2390MHzCH7 2490MHzCH8 2510MHz AVMT15 FOOTPRINT & DIMENSION(TOP VIEW): AVMR9 FOOTPRINT & DIMENSION(TOP VIEW):

Test Report ----------------------------------------------------------------------------- 1/33 Report No.: GA215146, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 MEASUREMENT REPORT of Wireless Audio Video Transmitter Applicant : GRANDTEC ELECTRONIC CORP. Product Name : GRAND AV Wireless (AVW-1000) Model No. : GTP224 FCC ID : PVCGTP224 EUT : Audio/Video Transmitter Report No. : GA215146 Followed by : 47 CFR, Part 15, Subpart C Test by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 2, Lane 194 Huan-Ho Street, Hsichih, Taipei Hsien 221, Taiwan, R.O.C. Test Report ----------------------------------------------------------------------------- 3/33 Report No.: GA215146, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 CONTENTS I. GENERAL 1.1 Introduction ..................................................................................................................... 5 1.2 Description of EUT ......................................................................................................... 5 1.3 Description of Support Equipment ................................................................................ 6 1.4 Configuration of System Under Test ............................................................................. 7 1.5 Test Procedure ................................................................................................................. 9 1.6 Location of the Test Site ................................................................................................. 9 1.7 General Test Condition ................................................................................................... 9 II. Conducted Emissions Measurements 2.1 Test Condition & Setup ................................................................................................ 10 2.2 List of Test Instruments ................................................................................................ 10 2.3 Test Configuration ......................................................................................................... 11 2.4 Test Result of Conducted Emissions ........................................................................... 13 III. Radiated Emissions Measurements 3.1 Test Condition & Setup ................................................................................................ 16 3.2 List of Test Instruments ................................................................................................ 17 3.3 Test Instruments Configuration .................................................................................... 18 3.4 Test Result of Radiated Emissions ............................................................................... 20 3.5 Test Result of Spurious Radiated Emissions ............................................................... 21 . Verify Frequencies and Channels.................................................................................... 28 Appendix A .............................................................................................................................. 29 Appendix B .............................................................................................................................. 31 Test Report ----------------------------------------------------------------------------- 4/33 Report No.: GA215146, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 TABLES Table 1 Power Line Conducted Emissions [Channel 1]........................................................................................................... 13 Table 2 Power Line Conducted Emissions [Channel 3]........................................................................................................... 14 Table 3 Power Line Conducted Emissions [Channel 4]........................................................................................................... 15 Table 4 Open Field Radiated Emissions [Channel 1, Horizontal, 30MHz1GHz]........................................................... 21 Table 5 Open Field Radiated Emissions [Channel 1, Horizontal, 1GHz24GHz] .......................................................... 22 Table 6 Open Field Radiated Emissions [Channel 1, Vertical, 30MHz1GHz] .............................................................. 22 Table 7 Open Field Radiated Emissions [Channel 1, Vertical, 1GHz24GHz] .............................................................. 23 Table 8 Open Field Radiated Emissions [Channel 3, Horizontal, 30MHz1GHz]........................................................... 23 Table 9 Open Field Radiated Emissions [Channel 3, Horizontal, 1GHz24GHz] .......................................................... 24 Table 10 Open Field Radiated Emissions [Channel 3, Vertical, 30MHz1GHz] .............................................................. 24 Table 11 Open Field Radiated Emissions [Channel 3, Vertical, 1GHz24GHz] .............................................................. 25 Table 12 Open Field Radiated Emissions [Channel 4, Horizontal, 30MHz1GHz]........................................................... 25 Table 13 Open Field Radiated Emissions [Channel 4, Horizontal, 1GHz24GHz] .......................................................... 26 Table 14 Open Field Radiated Emissions [Channel 4, Vertical, 30MHz1GHz] .............................................................. 26 Table 15 Open Field Radiated Emissions [Channel 4, Vertical, 1GHz24GHz] .............................................................. 27 Test Report ----------------------------------------------------------------------------- 5/33 Report No.: GA215146, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Applicant in support of audio…

Text truncated - open the document above for the full version.

Test Report ----------------------------------------------------------------------------- 16/33 Report No.: GA215146, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 . Radiated Emissions Measurements 3.1 Test Condition & Setup The EUT was placed in an anechoic chamber and scanned at 3-meter distance to determine its emission characteristics. The physical arrangement of the EUT was varied (within the scope of arrangements likely to be encountered in actual use) to determine the effect on the unit's emanations in amplitude, directivity, and frequency. The exact system configuration, which produced the highest emission was noted so it could be reproduced later during the final tests. This was done to ensure that the final measurements would demonstrate the worst-case interference potential of the EUT. Final radiation measurement (frequency above 1GHz) was made in a three-meter anechoic chamber. The frequency below 1GHz was made in a three-meter OATS. The EUT system was placed on a nonconductive turntable, which is 0.8 meters height, top surface 1.0 x 1.5 meter. The spectrum was examined from 30MHz to 1000MHz using an Hewlett Packard 8546A & 85460A EMI Receiver, Schaffner whole range Bi-Log antenna (Model No.: CBL6141A) is used to measure frequency from 30 MHz to 1GHz.The final test is used the spectrum HP 8546A & 85460A and spectrum was examined from 1GHz to 24GHz using an Hewlett Packard 8564E Spectrum Analyzer, EMCO Horn Antenna for 1G to 24 G Hz. At each frequency, the EUT was rotated 360 degrees, and the antenna was raised and lowered from one to four meters to find the maximum emission levels. Measurements were taken using both horizontal and vertical antenna polarization. Appropriate preamplifiers were used for improving sensitivity and precautions were taken to avoid overloading or desensitizing the spectrum analyzer. There are two spectrum analyzers use on this testing, HP 8546A & 85460A for frequency 30MHz to 1000MHz, and 8564E for frequency 1GHz to 24GHz. No post-detector video filters were used in the test. The spectrum analyzer's was set in the quasi-peak mode. (spectrum was examined from 30MHz to 1000MHz), the spectrum analyzer's bandwidth was set to 1MHz (spectrum was examined from 1GHz to 24GHz) and the analyzer was operated in the peak and average mode. The actual field intensity in decibels referenced to 1 microvolt per meter (dBV/m) is determined by algebraically adding the measured reading in dBV, the antenna factor (dB), and cable loss (dB) at the appropriate frequency. Test Report ----------------------------------------------------------------------------- 17/33 Report No.: GA215146, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26935155, Fax:886-2-26934440 For frequency between 30MHz to 1000MHz FIa (dBV/m) = FIr (dBV) – Correction Factors FIa : Actual Field Intensity FIr : Reading of the Field Intensity Correction Factor = Antenna Factor + (Cable Loss – Amplitude Gain) For frequency between 1GHz to 24GHz FIa (dBV/m) = FIr (dBV) + Correction Factor FIa : Actual Field Intensity FIr : Reading of the Field Intensity Correction Factors = Antenna Factor + Cable Loss – Amplifier Gain 3.2 List of Test Instruments Calibration Date Instrument Name Model No. Brand Serial No. Last time Next time EMI Receiver 8546A H P 3520A00242 06/29/01 06/29/02 RF Filter Section 85460A H P 3448A00217 06/29/01 06/29/02 Bi-log Antenna CBL6141A Schaffner 4206 05/03/02 05/03/03 Switch/Control Unit 3488A HP N/A 11/20/01 11/20/02 (> 30MHz) Auto Switch Box ASB-01 TRC 9904-01 11/20/01 11/20/02 (> 30MHz) Spectrum Analyzer 8564E HP US36433002 08/01/01 08/01/02 Microwave Preamplifier 83051A HP 3232A00347 08/01/01 08/01/02 Horn Antenna 3115 EMCO 9704 – 5178 08/01/01 08/01/02 Anechoic Chamber (cable calibrated together) 05/20/01 05/20/02

Test configuration Test Configuration of Radiated Emission
