PVCGTP218Audio Video Transmitter

Dear sir: 1. The Test Setup photos have been submitted, file name is TestSetup.PDF. 2. The EUT(Tx) is not include USB interface, just EUT(Rx) must be connect the USB cable into the USB port of PC. About this, please see the P. 4 of User’s manual.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 August 26, 2002 RE: Grandtec Electronic FCC ID: PVCGTP218 I have a few comments on this Application. 1.) Please provide Test Setup photos as a separate exhibit. 2.) According to the manual, this device utilizes a USB port. Was this device also tested as a computer peripheral? The Test Setup Photos (inside Test Report) indicate it was tested with a VCR only. Please supply additional test data with EUT connected to a computing system. William H. Graff President and Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC ID : PVCGTP218 Model No.: GRAND RF Grabber USB LABEL Size : 45 X 25 mm LABEL Position : LABEL

Test Report ----------------------------------------------------------------------------- 1/28 Report No.: GA215139, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 MEASUREMENT REPORT of Wireless Audio Video Transmitter Applicant : GRANDTEC ELECTRONIC CORP. Product Name : 2.4GHz Wireless Audio/Video Transmitter with USB Video Capture Model No. : GRAND RF Grabber USB; GRAND RF CMOS USB; GRAND RF CCD USB FCC ID : PVCGTP218 EUT : Audio/Video Transmitter Report No. : GA215139 Followed by : 47 CFR, Part 15, Subpart C Test by : Training Research Co., Ltd. TEL : 886-2-26461146 FAX : 886-2-26461778 15, Lane 530 Pa-Lian Rd., Sec. 1, Hsichih, Taipei Hsien 221, Taiwan, R.O.C. Test Report ----------------------------------------------------------------------------- 3/28 Report No.: GA215139, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 CONTENTS I. GENERAL 1.1 Introduction ..................................................................................................................... 5 1.2 Description of EUT ......................................................................................................... 5 1.3 Description of Support Equipment ................................................................................ 6 1.4 Configuration of System Under Test ............................................................................. 7 1.5 Test Procedure ................................................................................................................. 8 1.6 Location of the Test Site ................................................................................................. 8 1.7 General Test Condition ................................................................................................... 8 II. Conducted Emissions Measurements 2.1 Test Condition & Setup ................................................................................................. 9 2.2 List of Test Instruments ................................................................................................. 9 2.3 Test Configuration ......................................................................................................... 10 2.4 Test Result of Conducted Emissions ........................................................................... 12 III. Radiated Emissions Measurements 3.1 Test Condition & Setup ................................................................................................ 14 3.2 List of Test Instruments ................................................................................................ 15 3.3 Test Instruments Configuration .................................................................................... 16 3.4 Test Result of Radiated Emissions ............................................................................... 18 3.5 Test Result of Spurious Radiated Emissions ............................................................... 19 . Verify Frequencies and Channels.................................................................................... 24 Appendix A .............................................................................................................................. 25 Appendix B .............................................................................................................................. 27 Test Report ----------------------------------------------------------------------------- 4/28 Report No.: GA215139, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 TABLES Table 1 Power Line Conducted Emissions [Channel 1]........................................................................................................... 12 Table 2 Power Line Conducted Emissions [Channel 3]........................................................................................................... 13 Table 3 Open Field Radiated Emissions [Channel 1, Horizontal, 30MHz1GHz]........................................................... 19 Table 4 Open Field Radiated Emissions [Channel 1, Vertical, 30MHz1GHz] .............................................................. 19 Table 5 Anechoic Chamber Radiated Emissions [Channel 1, Horizontal, 1GHz24GHz] .......................................................... 20 Table 6 Anechoic Chamber Radiated Emissions [Channel 1, Vertical, 1GHz24GHz] .............................................................. 20 Table 7 Anechoic Chamber Radiated Emissions [Channel 3, Horizontal, 1GHz24GHz] .......................................................... 21 Table 8 Anechoic Chamber Radiated Emissions [Channel 3, Vertical, 1GHz24GHz] .............................................................. 21 Table 9 Anechoic Chamber Radiated Emissions [Channel 4, Horizontal, 1GHz24GHz] .......................................................... 22 Table 10 Anechoic Chamber Radiated Emissions [Channel 4, Vertical, 1GHz24GHz] .............................................................. 22 Test Report ----------------------------------------------------------------------------- 5/28 Report No.: GA215139, FCC Part 15 Class B Training Research Co., Ltd., TEL:886-2-26461146, Fax:886-2-26461778 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Applicant in support of audio/video transmitter certification in accordance with Part 2 Subpart J and Part 15 Subpart A and C of the Commission's Rules and Regulations. 1.2 Description of EUT Product Name : 2.4GHz Wireless Audio/Video Transmitter with USB Video Capture Model No. : GRAND RF Grabber USB; GRAND RF CMOS USB; GRAND RF CCD USB FCC ID : PVCGTP218 Frequency Range : 2410 – 2470 MHz Support Channel : 4 Channel Power Type : Powered by adaptor Model: YAD-0600800C I/P: 120Vac, 60Hz, 9.5W O/P: 6Vdc, 800mA Power Cable : 190cm long, non-shielded, no ferrite core Audio/Video Cable : 1.75 m long, non-shiel…

Text truncated - open the document above for the full version.

Conducted Emissions Test Setup Conducted Emissions Test Setup Radiated Emissions Test Setup Radiated Emissions Test Setup
