PW3108Doorknob Entry System

Hafele America Co.
Doorknob Entry System - FCC ID PW3108 - Hafele America Co.
Click to zoom

Application Details

Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant
Aug 19, 2002
Application Purpose
Original Equipment
Date of Application
Aug 19, 2002
Equipment Note
Doorknob Entry System
Frequency Range
0.13400000 - 0.13400000
Company
Hafele America Co.
Country
United States

Documents & Files

Select a file to view

Users Manual

↗

Block Diagram

↗

Cover Letter(s)

↗
↗
↗

External Photos

↗
↗

ID Label/Location Info

↗
↗

Internal Photos

↗
↗

Operational Description

↗

Test Report

↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Re: Certification for Hafele. DT2000 Transmitter Model: DT2000 FCC ID: PW3108 USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: PW3108 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. Mounting Instructions Door Terminal Basic European version     Contents Contents Area of use...................................................................................... 3 Technical information .................................................................... 3 Scope of delivery.............................................................................4 Mounting......................................................................................... 6 Disassambly.................................................................................... 20 Commissioning............................................................................... 21 Brief operating instructions........................................................... 22 Operation ........................................................................................ 24 Changing batteries ............................................................................ 48 Emergency opening via the profile cylinder ........................................ 51 Mounting Instructions 26 Attention! • It is essential that you read the "Commissioning" section of these instructions before commissioning (allocation of keys). Area of use The Door Terminal Basic is an electronic door fitting used principally in the hotel sector. It is mounted on interior doors with mortise locks acc. to DIN 18 251 and can also easily be retrofitted on the door leaf. Depending on the design, the fixing plate on the Door Terminal Basic can also be mounted on doors whose mortise locks deviate from DIN 18 251. Technical information • All Door Terminals Basic are supplied in the simple operating mode. In this operating mode, access rights for up to 26 electronic keys can be allocated directly at the Door Terminal Basic with a special Programming ADD Key-stick (green). These access rights can be withdrawn again from an authorised electronic key at the Door Terminal Basic using a Programming DELETE Key-stick (red). Please contact your Dialock distributor if a different operating mode is to be selected. • The Door Terminal Basic consists of the outer module (fixing plate with bracket and cover) that is mounted on the outer side of the door, and rosette fittings that are mounted on the inside of the door. • The Door Terminal Basic has no infrared interface but can be configured using Parameter and Special Transponders. • The Door Terminal Basic is battery-powered, and operated using electronic keys. Mounting Instructions 27 Scope of delivery             Door Terminal Basic : 1 1 outer module (fixing plate with bracket and cover) 2 1 set of rosette fittings 3 2 door handles Small parts bag: 4 1 chipboard screw, 3 x 20 5 1 retaining ring 6 1 pin, 3 x 22 7 1 pin, 4 x 22 8 2 adhesive labels (to assist mounting) Fastening parts: 9 1 square Spindle 10 4 countersunk screws M4 The length of the fastening parts depend on the thickness of the door leaf. Mounting Instructions 28 Accessories (not included in the scope of delivery): User and Programming Key-sticks 2 lithium batteries 1 release lever 1 pair of retaining ring pliers Mounting Instructions 29 Spare parts (not included in the scope of delivery):     1 1 cover (available in a variety of colors) 2 1 bag of fastening parts (square spindle and countersunk screws, M4) 3 1 small parts bag 4 1 fixing plate Mounting Instructions 30 Mounting Requirements: • DIN mortise lock Depending on the design of the fixing plate, it is also possible to use mortise locks on the Door Terminal Basic that deviate from the DIN norm (e.g. for Austria). The length of the following Door Terminal Basic components depends on the thickness of the door leaf and must therefore be selected appropriately: • the screws for attaching the rosettes • the square spindle Tools required and auxiliary mounting materials: • a drilling template • an electric drill • drill bits suitable for the door material: - Ø = 8 mm - Ø = 7 mm (depending on the rosette fittings used) - Ø = 6 mm • a hammer • retaining ring pliers • a screwdriver • a 3 mm Allen wrench Mounting Instructions 31 Adapting the Door Terminal Basic for right-facing door handles The Door Terminal Basic is adapted for left- or right-facing door handles using the pins on the back of the fixing plate (with the bracket). 1. Place the door handle on the bracket in such a way that the direction of door handle movement is appropriate for its use. 2. Turn the external square with the door handle at its upper limit (zero position) and hold it. Mounting Instructions 32 R80 R L L80 R45 L45 3. Using a hammer, lightly tap a 3 x 22 pin into the drilled hole labelled "R" on the back of the fixing plate. The spring of the door handle is under pressure. 4. Insert a 4 x 22 pin in the drilled hole labelled "R45°" on the back of the fixing plate for the door handle limit. If the door handle angle of rotation is to be greater than 45°: Ö Insert a 4 x 22 pin in the drilled hole labelled "R80°" on the back of the fixing plate. 5. Secure the pins with the adhesive labels so that they do not fall out. Mounting Instructions 33 6. Remove the door handle from the external square spindle. The Door Terminal Basic is adapted for a right-facing door handle. Proceed as follows if the pins have been insert…

Text truncated - open the document above for the full version.

Block Diagram

Coupling Solenoid Control Circuit EEPROM Battery 2 x 3.0 V PIC-Microcontroller Oscillator 4.00 MHz Tiris TM Encoder / Decoder Modulator / Demodulator (TMS3705A) Oscillator 4.00 MHz Antenna 134.2 kHz

Cover Letter(s)

Re: Certification for Hafele. DT2000 Transmitter Model: DT2000 FCC ID: PW3108 POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for Hafele. DT2000 Transmitter Model: DT2000 FCC ID: PW3108 REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Hafele America Co. requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Hafele America Co. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan July 31, 2002 Re: Certification for Hafele. DT2000 Transmitter Model: DT2000 FCC ID: PW3108 STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Hafele. DT2000 Transmitter Model: DT2000 FCC ID: PW3108 GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Hafele America Co. 3901 Cheyenne Dr., PO Box. 4000 Archdale, NC 27263-4000 Mr. John O’Meara Tel: 914-669-5927 Fax: 914-646-8715 It will be manufactured by: Hafele America Co 3901 Cheyenne Dr., PO Box. 4000 Archdale, NC 27263-4000 Mr. John O’Meara Tel: 914-669-5927 Fax: 914-646-8715

Cover Letter(s)

July 31, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: PW3108 Please find enclosed application materials for certification of Hafele DT2000 Transmitter. Note: 1) portions of this submittal are filed Confidential 2) a list of the modifications made is provided in Attestations. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

Cover Letter(s)

July 31, 2002 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: PW3108 Please find enclosed application materials for certification of Hafele DT2000 Transmitter. Note: 1) portions of this submittal are filed Confidential 2) a list of the modifications made is provided in Attestations. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

ID Label/Location Info

Label for Häfele DT2000, TIRIS This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that many cause undesired operation. FCC ID: PW3108

ID Label/Location Info

Label for Häfele DT2000, TIRIS This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that many cause undesired operation. FCC ID: PW3108
