Re: Certification for Hafele WT2000T Transmitter Model: WT2000T FCC ID: PW3110 IC: 4645A-110 USER'S MANUAL INFORMATION (PRELIMINARY) The User's Manual is in preparation. The following material will be contained in the manual: FCC ID: PW3110 IC: 4645A-110 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressively approved by the party responsible for compliance could void the user's authority to operate the equipment. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met.

Re: Certification for Hafele WT2000T Transmitter Model: WT2000T FCC ID: PW3110 IC: 4645A-110 POWER OF ATTORNEY A letter granting Valdis V. Liepa the Power of Attorney is on file and can be provided when so requested. Re: Certification for Hafele WT2000T Transmitter Model: WT2000T FCC ID: PW3110 IC: 4645A-110 REQUEST FOR CONFIDENTIALITY Pursuant to 47 CRF 0.459, Hafele America Co. requests that a part of the subject application be held confidential. This comprises Exhibits (5) Schematics (10) Parts List (Part of Exhibit only) Hafele America Co. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. If there are any questions regarding this request, please contact me at the above address or call 734-483-4211, fax 734-647-2106 or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist University of Michigan June 9, 2003 Re: Certification for Hafele WT2000T Transmitter Model: WT2000T FCC ID: PW3110 IC: 4645A-110 STATEMENT OF MODIFICATIONS There were no modifications made to the DUT by this test laboratory. (Also see Section 3.1 of the attached Test Report). _____________________ Valdis V. Liepa Research Scientist Re: Certification for Hafele WT2000T Transmitter Model: WT2000T FCC ID: PW3110 IC: 4645A-110 GENERAL PRODUCT INFORMATION The device, for which certification is pursued, has been designed by: Hafele America Co. 3901 Cheyenne Dr., PO Box. 4000 Archdale, NC 27263-4000 Mr. John O’Meara Tel: 914-669-5927 Fax: 914-646-8715 It will be manufactured by: Hafele America Co 3901 Cheyenne Dr., PO Box. 4000 Archdale, NC 27263-4000 Mr. John O’Meara Tel: 914-669-5927 Fax: 914-646-8715 Canadian Contact: Häfele Canada Inc. 5323 John Lucas Drive Burlington, Ontario, L7L 6A8 Canada Martin Häfele, General Manager Tel: 905 336 6608 ext 430 Fax: 1 905 319 4445 [email protected]

BLOCK-DIAGRAM WT-2000 80C51 prozessor system monitoring-LEDs red/green RS-485 interface + power supply IR-interface transponder- interface 80C51 prozessor system I/O RS-485 interface + power supply RTC monitoring-LEDs reset push button RAM buffered switching regulator RS-232 interface transformer 8 - 36 VAC 3 VA 110VAC 4 x relay output (COM,NC,NO) 2 x TTL-output 4 x TTL-input online operating software-update 4 max. 100m transponder interface: TIRIS: 134,2 kHz or LEGIC: 13,56 MHz C.Meier 17.01.02 SPX 9600 Baud 9600 Baud Reader Unit Control Unit

June 9, 2003 American Telecommunications Certification Body, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 RE: Certification Application FCC ID: PW3110 Please find enclosed application materials for certification of Hafele America Co. WT2000T Transmitter. Note: 1) portions of this submittal are filed Confidential 2) a list of the modifications made is provided in Attestations. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist

June 9, 2003 Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Re: Certification for Hafele WT2000T Transmitter Model: WT2000T FCC ID: PW3110 IC: 4645A-110 Please find enclosed application materials for certification of Hafele America Co. WT2000T Transmitter. We tested it and found it to comply with FCC Part 15. If there are any questions regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647-2106, or e-mail [email protected]. Sincerely, Valdis V. Liepa Research Scientist June 9, 2003 Certification and Engineering Bureau Industry Canada 3701 Carling Avenue, Bldg. 94 Ottawa, Ontario K2H 8S2 Re: Certification for Hafele WT2000T Transmitter Model: WT2000T FCC ID: PW3110 IC: 4645A-110 Please find enclosed application materials for certification of Hafele America Co. WT2000T Transmitter. We tested the device and found it to comply with RSS-210. The product is identified by: IC: 4645A-110 If there are any questions, suggestions, etc., regarding the application or testing performed, please contact me at the above address or call 734-483-4211, fax 734-647- 2106; e-mail: [email protected]. Sincerely, Valdis V. Liepa Research Scientist

WT2000 T Complete System WT2000 T Power Supply (top) WT2000 T Power Supply (bottom) WT2000 T Control Box (top) WT2000 T Control Box (bottom)

FCC ID: PW3110 Model: WT2000T IC: 4645A-110 This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. ID Label will be attached on side of Tiris Module

WT2000T Case Apart (top) WT2000T Case Apart (bottom) WT2000T DUT Apart (top) WT2000T DUT Apart (top) WT2000T PCB1 (top) WT2000T PCB1 (bottom) WT2000T PCB2 (top) WT2000T PCB2 (bottom) WT2000T PCB3 (top) WT2000T PCB3 (bottom) WT2000 T Contol Box apart (top) WT2000 T Contol Box apart (bottom) WT2000 T Contol Box PCB (top) WT2000 T Contol Box PCB (bottom)

Description of Operation The DUT continually interrogates for a transponder. During this interrogation, the DUT transmits 54 ms wide pulses with 132.5 ms period. When a transponder is found the DUT significantly decreases its peak output power and initiates a charge phase. This generates an electromagnetic filed around the antenna coil from which the transponder accumulates and stores energy on its internal charge capacitor. This energy is used to power the transponder in the read phase, where it sends back an id/control code after each charging pulse. The code is then validated against a known value and depending on match, a signal is returned to the controller module.

The University of Michigan Radiation Laboratory 3228 EECS Building Ann Arbor, MI 48109-2122 Tel: (734) 764-0500 Measured Radio Frequency Emissions From Hafele America Transmitter Model: WT2000T Report No. 415031-168 June 2, 2003 Copyright © 2003 For: Hafele America Co. 3901 Cheyenne Drive Archdale, NC 27263 Contact: Rudor Teich RMT Associates, Inc. Tel: 973-669-8214 Fax: 973-669-5161 Tests supervised by: Measurements made by:Joseph D. BrunettReport approved by: _____________________ Edward A. CourtneyValdis V. Liepa Research Scientist Summary Tests for compliance with FCC Regulations, Part 15, Subpart C, and for compliance with Industry Canada RSS-210, were performed on Hafele America transmitter, model WT2000T. This device is subject to Rules and Regulations as a transmitter. In testing completed 25-May-03, the device tested in the worst case met the allowed specifications for transmitter radiated emissions by 31.3 dB (see p. 7); digital emissions, Class B, were met by 3.9 dB (see p. 7); FCC/CISPR Class B conducted were met by 12.0 dB (see p. 7). 2 1. Introduction Hafele America model WT2000T was tested for compliance with FCC Regulations, Part 15, adopted under Docket 87-389, April 18, 1989, and with Industry Canada RSS-210, Issue 5, November, 2001. The tests were performed at the University of Michigan Radiation Laboratory Willow Run Test Range following the procedures described in ANSI C63.4-1992 "Methods of Measurement of Radio-Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". The Site description and attenuation characteristics of the Open Site facility are on file with FCC Laboratory, Columbia, Maryland (FCC Reg. No: 91050) and with Industry Canada, Ottawa, ON (File Ref. No: IC 2057). 2. Test Procedures and Equipment Used The pertinent test equipment commonly used in our facility for measurements is listed in Table 2.1 below. The middle column identifies the specific equipment used in these tests. Table 2.1 Test Equipment. Test InstrumentEqpt. UsedManufacturer/Model Spectrum Analyzer (0.1-1500 MHz) Hewlett-Packard, 182T/8558B Spectrum Analyzer (9kHz-22GHz)XHewlett-Packard 8593A SN: 3107A01358 Spectrum Analyzer (9kHz-26GHz)XHewlett-Packard 8593E, SN: 3412A01131 Spectrum Analyzer (9kHz-26GHz)Hewlett-Packard 8563E, SN: 3310A01174 Spectrum Analyzer (9kHz-40GHz)Hewlett-Packard 8564E, SN: 3745A01031 Power MeterHewlett-Packard, 432A Power MeterAnritsu, ML4803A/MP Harmonic Mixer (26-40 GHz)Hewlett-Packard 11970A, SN: 3003A08327 Harmonic Mixer (40-60 GHz)Hewlett-Packard 11970U, SN: 2332A00500 Harmonic Mixer (75-110 GHz)Hewlett-Packard 11970W, SN: 2521A00179 Harmonic Mixer (140-220 GHz)Pacific Millimeter Prod., GMA, SN: 26 S-Band Std. Gain Horn S/A, Model SGH-2.6 C-Band Std. Gain HornUniversity of Michigan, NRL design XN-Band Std. Gain Horn University of Michigan, NRL design X-Band Std. Gain Horn S/A, Model 12-8.2 X-band horn (8.2- 12.4 GHz)Narda 640 X-band horn (8.2- 12.4 GHz)Scientific Atlanta , 12-8.2, SN: 730 K-band horn (18-26.5 GHz)FXR, Inc., K638KF Ka-band horn (26.5-40 GHz)FXR, Inc., U638A U-band horn (40-60 GHz)Custom Microwave, HO19 W-band horn(75-110 GHz)Custom Microwave, HO10 G-band horn (140-220 GHz)Custom Microwave, HO5R Bicone Antenna (30-250 MHz)XUniversity of Michigan, RLBC-1 Bicone Antenna (200-1000 MHz)XUniversity of Michigan, RLBC-2 Dipole Antenna Set (30-1000 MHz) XUniversity of Michigan, RLDP-1,-2,-3 Dipole Antenna Set (30-1000 MHz) EMCO 2131C, SN: 992 Active Rod Antenna (30 Hz-50 MHz)EMCO 3301B, SN: 3223 Active Loop Antenna (30 Hz-50 MHz)XEMCO 6502, SN:2855 Ridge-horn Antenna (300-5000 MHz)XUniversity of Michigan Amplifier (5-1000 MHz)XAvantek, A11-1, A25-1S Amplifier (5-4500 MHz)XAvantek Amplifier (4.5-13 GHz)Avantek, AFT-12665 Amplifier (6-16 GHz)Trek Amplifier (16-26 GHz)Avantek LISN BoxUniversity of Michigan Signal GeneratorHewlett-Packard 8657B 3 3. Configurations and Identification of Device Under Test The DUT is a 135 kHz wall mounted RFID system. This system consists of a T/R module (including coupling coil antenna) and a "passive" transponder imbedded in a special key/card. The transponder in the key is considered passive because it uses the energy supplied by the transmitter coil to operate its micro and, hence, is not subject to the regulations. A multi-wire harness, a power supply, and a control box were used in testing. Power was supplied from switching power supply as provided by the manufacturer. The DUT was designed and manufactured by Hafele America Co. It is identified as: Hafele America Transmitter Model: WT2000T FCC ID: PW3110 CANADA: 4645A-110 3.1 EMI Relevant Modifications No EMI Relevant Modifications were performed by this test laboratory. 4. Emission Limits 4.1 Radiated Emission Limits The DUT tested falls under the category of an Intentional Radiators and the Digital Devices, subject to Subpart C, Section 15.209; and Subpart B, Section 15.109 (transmitter generated signals excluded); and Subpart A, Section 15.33. The applicable testing frequencies with corresponding emission limits are given in Tables 4.1 and 4.2 below. As a digital device, it is exempt. Table 4.1. Radiated Emission Limits (FCC: 15.205, 15.35; IC: RSS-210 (6.2.2(r), 6.3)). (Transmitter) Frequency (MHz) Fundamental and Spurious* (μ V/m) 0.009-0.490 0.490-1.705 2400/F(kHz), 300m 24,000/F(kHz), 30m 0.090-0.110 0.49-0.51 Restricted Bands * Harmonics must be below the fundamental. For extrapolation to other distances, see Section 6.6. 4 Table 4.2. Radiated Emission Limits (FCC: 15.33, 15.35, 15.109; IC: RSS-210, 6.2.2(r)). (Digital Class B) Freq. (MHz) E lim (3m) μ V/mE lim dB(μ V/m) 30-8810040.0 88-21615043.5 216-96020046.0 960-200050054.0 Note:Average readings apply above 1000 MHz (1 MHz BW) Quasi-Peak readings apply to 1000 MHz (120 kHz BW) 4.2 Conductive Emission Limits Table 4.3 Conducted Emission Limits (FCC:15.107 (CISPR); IC: RSS-210, 6.6). Frequency Class A (dBμV)Class B (dBμV) MHz Quasi-peakAverageQuasi-peakAverage .15…
