PWJ024ATRANSMITTER MODEL ERONE 024A

RCS - 433LS 1A - General information The radiocontrol RCS-433LS has been designed for the control of automatic closing systems and anti-burglar systems thanks to its very high security coding system. (KeeLoq ® Hopping code). The code sent by the transmitter changes at each activation, avoiding any scanning and copying risk. A special algorithm allows to keep synchronysed transmitter and receiver. The operating frequency is 433,92 MHz. The receiver which makes the activation, once received the transmitter code, has to be connected during the installation to the device to control CONTENTS 1A - General information 1B - Technical specifications 1C - Main features 1 - TRANSMITTER INTRODUCTION 2 - CODING 3 - MEMORIZATION 4 - BATTERY ACCESS 5 - TROUBLESHOOTING G ET TI N G ST A RT ED 1B - Technical specifications Number of keys:2 / 4 Supply :1 Alkaline Battery 12V type 23A Battery life:12 - 18 months Current consumption :25 mA Operating frequency :433.92 MHz 64 Code combinations :2 Modulation :AM / ASK Rated e.r.p. :50 - 100 μW Range in free space:60 - 120 yd Operating temperature: -20 ÷ +55 °C Overall dimensions:3.26 x 1.88 x 0.62 in Weight:20 gr. ( gate, garage door, rolling shutters, sun-blinds, anti-burglar appliances, lighting ). All the receivers of the range RCS-433S can store into the EEPROM a serial number, a manufacturer key and a synchronism algorithm of more transmitters. Each transmitter ( or its different keys ) can be stored into different receivers and hence can do more functions. In order to use the unused keys of the transmitter it is enough to connect the dedicated receiver to the mechanism to drive ( i.e. electrolock of a pedestrian gate, a buzzer, etc. ). The product fully complies with the European Directives 99/5/CE, 89/336/CEE, 73/23/CEE and with the Part 15 of FCC Regulations. 1C - Main features Push-button C Red LED Thank you for choosing a RCS product. You are recommended to read this manual carefully before installing the product. RCS Push-button A Push-button B Push-button D Battery door Key holder ring Stand alone RCS-433LS2 RCS-433LS4 3 - MEMORIZATION 2 - CODING 4 - BATTERY ACCESS 5 - TROUBLESHOOTING FAULT SOLUTION The transmitter led blinks Check the receiver supply. Replace the transmitter battery IS-TLSGXUK Rev. 1 on 20.12.2002 To access the battery slide out the battery door Place the 23A alkaline battery between the 2 contacts. Respect the right polarity as indicated on the bottom of the box. NOTE: Please dispose of the batteries correctly, they are hazardous waste. Each transmitter is manufactured and sold with a different univocal serial number set-in-factory. The real transmitted code is the result of a special algorithm which combines a serial number, a manufacturer key and a synchronization number. The transmitter security code has to be stored onto the receiver or the receivers memory available. Your own installer or reseller will perform this operation during the installation or will give you the necessaries instructions during the selling. Don't forget that the still free buttons of your transmitter can be used for further wireless functions. Ask your installer the best suitable receiver. The radio emission isn’t verifiable The transmitter led is OFF. The radio emission isn’t verifiable The transmitter led is ON. Replace the transmitter battery GUARANTEE RCS-433LS - Type : S2TR2641E2 FCC ID : PWJ024A This device complies with FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept interference received, including interference that may cause undesired operation. Part. 15 of the Notice Any changes or modification to RCS equipment not expressly approved by RCS could void the user's authority to operate the equipment. REMOTE CONTROL SOLUTIONS College Park Commerce Center 2042 N. Rio Grande Ave. Suite A Orlando - FL 32804 U.S.A. Office: (407)-426-8687 Fax: (407)-428-9309 e-mail: [email protected] The guarantee period of all RCS transmitter batteries is 6 months, beginning from the manufacturer date. During this period, if the product does not work correctly, due to a defective component, the product will be repaired or substituted at the discretion of the producer. The guarantee does not cover the plastic container integrity. + _ 23A Battery Polarity 1A - General information The radiocontrol RCS-433LT has been designed for the programmable telephone entry systems, anti-burglar systems and access control systems. It has a very high security coding system. (KeeLoq ® Hopping code). The code sent by the transmitter changes at each activation, avoiding any scanning and copying risk. A special algorithm 1A - General information 1B - Technical specifications 1C - Main features 1 - TRANSMITTER INTRODUCTION 2 - CODING 3 - MEMORIZATION 4 - BATTERY ACCESS 5 - TROUBLESHOOTING G ET TI N G ST A RT ED 1B - Technical specifications Number of keys:2 / 4 Supply :1 Alkaline Battery 12V type 23A Battery life:12 - 18 months Current consumption :25 mA Operating frequency :433.92 MHz 64 Code combinations :2 Modulation :AM / ASK Rated e.r.p. :50 - 100 mW Range in free space:60 - 120 yd Operating temperature: -20 ÷ +55 °C Overall dimensions:3.26 x 1.88 x 0.62 in Weight:20 gr. allows to keep synchronyzed transmitter and receiver. The operating frequency is 433,92 MHz. The receiver RCS-433R type SELWR433, which operates with this transmitter, has a Wiegand 26 bit format output, suitable with any type of access control system, equipped with this type of protocol. The 23A Alkaline battery has a life of about 18 months. The product fully complies with the European Directives 99/5/CE, 89/336/CEE, 73/23/CEE and with the Part 15 of FCC 1C - Main features Push-button C Red LED CONTENTS Thank you for choosing a RCS product. You are recommended to read this manual carefully before installing the product. RCS Push-button A Push-button B Push-button D Battery door Key holder ring RCS - 433LT RCS-433LT2 RC…

Text truncated - open the document above for the full version.

ELPRO INNOTEK S.p.A. TCF-058 Annex 1b = External Photos Pag 1 of 4 TX ERONE S2TR2641E2 – Front external view TX ERONE S2TR2641E4 – Front external view ELPRO INNOTEK S.p.A. TCF-058 Annex 1b = External Photos Pag 2 of 4 TX ERONE S2TR2641E2-E4 – Back external view ELPRO INNOTEK S.p.A. TCF-058 Annex 1b = External Photos Pag 3 of 4 TX ERONE S2TW2641E2 – Front external view TX ERONE S2TW2641E4 – Front external view ELPRO INNOTEK S.p.A. TCF-058 Annex 1b = External Photos Pag 4 of 4 TX ERONE S2TW2641E2-E4 – Back external view TX ERONE 024A – Packaging external view

ELPRO INNOTEK S.p.A. TCF-058 Annex 2 = Labels Pag 1 of 1 ERONE , Series ERONE 024A – Types S2TR2641E2 / S2TR2641E4 / S2TW2641E2 / S2TW2641E4 LABELS – Scale 1:1 1 Product labels: Label N°1: This device complies with FCC Rules Part.15. Operation is subject to the following two conditions: 1) This device may not cause harmful interferences; 2) this devices must accept interference that may cause undesired operation. Freq. 433,92 MHz Label N°2: This device complies with FCC Rules Part.15. Operation is subject to the following two conditions: 1) This device may not cause harmful interferences; 2) this devices must accept interference that may cause undesired operation. Freq. 433,92 MHz FC: 001 S/N: 00001 NOTE1 : The transmitter is produced in 2 different versions which differ for the colour of the plastic box and for 1 bit on the transmitted frame, for a total of 4 different types, taking into account the number of push-buttons. The electronic card is identical for all. The product is also identified by the type assigned by the distributor, according to the following cross-reference: Main Alternative Model Number Erone 024A S2TR2641E2 RCS-433LS2 S2TR2641E4 RCS-433LS4 S2TW2641E2 RCS-433LT2 Types S2TW2641E4 RCS-433LT4 NOTE2 : In this case the GRANTEE CODE communicated by FCC is PWJ, so the FCC ID is composed by the string PWJ and by the Model number 024A. NOTE3 : The types identified by the letters S2TW have a univocal serial number that appears also on the label

ELPRO INNOTEK S.p.A. TCF-058 Annex 1c = Label locations Pag 1 of 1 TX ERONE S2TR2641E2-E4 – Back external view with label location TX ERONE S2TW2641E2-E4 – Back external view with label location

ELPRO INNOTEK S.p.A. TCF-058 Annex 1a = Photos Pag 1 of 1 ELECTRONIC CARD TX S2TR2641E4 – Front internal view ELECTRONIC CARD TX S2TR2641E2 – Front internal view ELECTRONIC CARD TX S2TR2641E2-E4 – back internal view

Attachment : 2 page 1 of 1 EMC 453/02 6.0.1 – Radio interference field strength radiated
