PWO460008Model 460008 Signal Booster

Contents: How it Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Before Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Quick Installation Overview . . . . . . . . . . . . . . . . . . . . . . . .2 Installing the Outside Antenna . . . . . . . . . . . . . . . . . . . . . .2 Installing the Low-Profile Antenna . . . . . . . . . . . . . . . . . . .3 Installing a Wilson Electronics Signal Booster . . . . . . . . . .3 Powering Up a Wilson Electronics Signal Booster . . . . . .3 Understanding the Signal Booster Lights . . . . . . . . . . . . .4 Warnings and Recommendations . . . . . . . . . . . . . . . . . . .4 Guarantee and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . .6 Signal Booster Specifications . . . . . . . . . . . . . .Back Cover Note: This manual contains important safety and operating information . Please read and follow the instructions in this manual . Failure to do so could be hazardous and result in damage to your Signal Booster . Mobile 4G Smart Technology ™ Signal Booster Appearance of device and accessories may vary . 12 Contact Wilson Electronics’s Technical Support Team with any questions at 866-294-1660 Or email: [email protected] Mon.- Fri. Hours: 7am to 6 pm MST. Signal Booster DC power supply 5V / 2 .5A (859948) How it Works Your new Wilson Signal Booster has been carefully engineered to significantly improve the performance of your cell phone and cellular data card in mobile applications . Together with an Outside Antenna, the Signal Booster’s state-of-the-art technology is designed to increase your signal, reduce dropped calls and increase data communication rates . The Outside Antenna will collect the cell tower signal and send it through the cable to the Signal Booster which is then boosted and sent to the Inside Antenna . Result – improved signal! KIT CONFIGURATION Wilson Electronics manufactures a wide variety of antennas to help you customize your Signal Booster for your specific application . See your dealer or visit www.WilsonElectronics.com . Installation Instructions for the Following Wilson Electronics Signal Boosters: Mobile 4G Smart Technology ™ Signal Booster Model # 460008 FCC ID: PWO460008 INSIDE ANTENNA OPTIONS OUTSIDE ANTENNA OPTIONS 311127 - Slim Low Profile w/ 10’ RG174 311106 - Low Profile w/ 10’ RG58 Mini-Mag 301126 w/ 12 .5 RG174 cable- SMA 301113 w/ 12 .5 RG174 cable - FME 12” Mag Mount 311103 w/ 12 .5’ RG174 311125 w/ 12 .5’ RG174 311128 w/ 12 .5’ RG174 314202 w/ 12 .5’ RG174 311703 w/ 12 .5’ RG174 Trucker Antenna 311101 w/10 .5’ RG58 311701 w/10 .5’ RG58 Trucker Antenna 311119 w/13 .5’ RG58 311133 w/13 .5’ RG58 Marine Antenna 311130-5810 w/10 .5’ RG58 Glass Mount 311102 w/14’ RG58 311114 w/14’ RG58 NMO Antenna Kit 311104-5810 • 800/1900 NMO Antenna • 10’ RG58 Cable Kit 311112-5810 • 800/1900 NMO Antenna • 10’ RG58 Cable Kit 314203-5810 • 800/900/1900 NMO Antenna • 10’ RG58 Cable Kit 311112-40015 • 800/1900 NMO Antenna • 15’ LMR400 cable Kit 314203-40015 • 800/900/1900 NMO antenna • 15’ LMR400 cable Kit 311104-40015 • 800/1900 NMO Antenna • 15’ LMR400 Cable Kit 311104-17410 • 800/1900 NMO antenna • 10’ RG174 cable Kit 311112-17410 • 800/1900 NMO antenna • 10’ RG174 cable Kit 314203-17410 • 800/900/1900 NMO antenna • 10’ RG174 cable 2 Contact Wilson Electronics’s Technical Support Team with any questions at 866-294-1660 Or email: [email protected] Mon.- Fri. Hours: 7am to 6 pm MST. Warning: In a wireless installation, do not plug the Signal Booster directly into the cell phone and/or data card using an antenna adapter . It may damage the Signal Booster, cell phone and/or data card . ! ! Quick Installation Overview Magnet - Mount Antenna Shown Part #301103 Carefully Pull Down Door Seal Run Cable Under Seal Tuck Cable Under Seal Installing the Outside Antenna To receive the best cell signal, select a location in the center of the vehicle’s roof 12 inches away from any other antennas or windows . If the vehicle has a sunroof, it is important to separate the Inside and Outside Antennas by at least five feet . This prevents the Signal Booster from overloading or oscillating . As shown above . Follow the specific antenna installation instructions included with the Outside Antenna . Separation of the Inside and Outside Antennas is very important . The metal roof of the vehicle acts as a barrier and helps shield the two antennas from each other, preventing oscillation (feedback) . The Outside Antenna must be installed vertically . Signal performance will be degraded if the antenna is not vertical . The antenna cable may run through the door to the Signal Booster . For a more professional looking installation, run the antenna cable under the door seal . The antenna cable is small enough to easily tuck under the door seal or plastic molding . Carefully pull down the door seal . Run the cable through the seal and push the seal back into place . This prevents constant wear and tear on the cable as the door opens and closes . Warning: Do not plug in the DC power supply until the Outside and Inside Antenna cables are attached to the Signal Booster . HUMMERHUMMER Installation Diagram Outside Antenna Inside Antenna Distance between antennas through a sunroof must be 5 feet or more . DC Power Supply Signal Booster Cell Phone PDA Notebook Before Getting Started This guide will help you properly install your Wilson Electronics Five Band Mobile Wireless Signal Booster . It is important to read through all of the installation steps for your particular application prior to installing any equipment. Read through the instructions, visualize where all the equipment will need to be installed and do a soft installation before mounting any equipment . Contact Wilson Electronics Technical Support Team with any questions at 866-294-1660 . 34 Contact Wilson Electronics’s Technical Support Team with any questions at 866-294-1660 Or email: [email protected] Mon.- Fri. Hours: 7am to 6 pm…

Text truncated - open the document above for the full version.

January 13, 2014 Attestation For Wilson Signal Booster: FCC ID PWO460008 Each Signal Booster certificated under FCC ID PWO460008 is manufactured and individually tested to ensure FCC compliance: (1) Licensee consent is not required for FCC certification equipment authorization purposes, but licensee consent does remain applicable per 20.21 provisions for both provider specific and wideband boosters. (2) NPS and other compliance/safeguard features have been implemented. (3) NPS and other compliance/safeguard features are defaulted to be “On” (in operation). (4) NPS and other compliance/safeguard features cannot be field reconfigured, disabled, or removed. (5) This consumer booster is not user programmable, does not need fine tuning or adjustment, and does not require professional installation. (6) Future software upgrade will not cause non-compliance. Sincerely, Patrick L. Cook Senior Research and Development Engineer

December 10, 2013 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: Data Confidentiality To Whom It May Concern: Wilson Electronics, Inc. respectfully requests confidentiality of certain documentation provided with the submission of our model 460008 Signal Booster under FCC ID: PWO460008 in accordance with sections 0.457 and 0.459 of the Commission’s regulations. We request that the following documents be kept confidential: 1. Schematic Diagram & Parts List 2. Operational Description 3. Block Diagram The above material is confidential and contains proprietary trade secrets and technical data which must be kept from competitors. Public access to these items could result in duplication of our circuitry and/or techniques thereby reducing our competitive advantage and causing us severe damage. Sincerely, Patrick L. Cook Senior Research and Development Engineer

December 10, 2013 To: Whom it May Concern Subject: Final Amplification Stage Voltage and Current Please note that the maximum voltages and currents for the final amplification stages of the Model 460008 Signal Booster are: Uplink Amplifier (704-716 MHz): 4.3 V, 0.5 A Downlink Amplifier (734-746 MHz): 4.3 V, 0.5 A Uplink Amplifier (777-787 MHz): 4.3 V, 0.5 A Downlink Amplifier (746-756 MHz): 4.3 V, 0.5 A Uplink Amplifier (824-849 MHz): 4.3 V, 0.5 A Downlink Amplifier (869-894 MHz): 4.3 V, 0.5 A Uplink Amplifier (1850-1915 MHz): 4.3 V, 0.5 A Downlink Amplifier (1930-1995 MHz): 4.3 V, 0.5 A Uplink Amplifier (1710-1755 MHz): 4.3 V, 0.5 A Downlink Amplifier (2110-2155 MHz): 4.3 V, 0.5 A Patrick L. Cook Senior Research and Development Engineer

December 10, 2013 Tuning and Adjustment of Wilson Model 460008 Signal Booster There are no external tuning adjustments. The amplifier is factory set to not exceed maximum gains, power levels, and downlink dependent region (RSSI) set points as provided in the test results. Sincerely, Patrick L. Cook Senior Research and Development Engineer

Page 1 of 1 FCC ID: PWO460008 CT Project: P1350021 From: John Erhard Date: 1/20/14 1. The form 731 has the power listed in dBm and will need to be in Watts. Please correct. CT – Form 731 power is listed in watts. 2. This device operates in the 1700 MHz AWS bands and per recent FCC communications there is a 10m antenna height restriction which must be contained in the installation instructions. Wilson – Please refer to User Manual_Rev1 Exhibit. 3. There are multiple labeling requirements for boosters and not all are met. Recent discussions with the FCC indicate that the warning label from KDB 935210 D02 Signal Boosters Certification v01 must be followed exactly both on the product and in the user’s manual. Please correct as necessary. Wilson – Please refer to Label and Location_Rev1 Exhibit. 4. Please explain the plots for Uplink noise timing, specifically how the 1 second requirement is shown in these results. CT - For the Uplink Noise Timing plots, the first marker (MR) is the reference marker where the Downlink signal level was increased and marker (M1) is the time it took the booster to react to the increase in the Downlink signal level per KDB 935210 D03 Wideband Consumer Signal Booster Measurement Guidance DR04-41516c. This explanation has been included on page 20 of the test report. 5. MSCL is required in the test report, please correct CT – The MSCL values have been added to the variable gain tables on page 88 and 89 of the test report. Response by: Wilson and Compliance Testing LLC Submitted by: Compliance Testing LLC Date: 1/29/14

December 10, 2013 Subject: Antenna Kitting Re: FCC ID: PWO460008 To Whom It May Concern: The antenna kitting options for model 460008 signal booster were done for 19 Outside Antenna kit options and 2 Inside Antenna kit options. The order of the attached calculations is as follows: Outside Antenna Kit Options: 1. Kits 311103, 311125, 311128, 314202 2. Kit 311703 3. Kit 301113, 301126 4. Kit 311101 5. Kit 311701 6. Kit 311119 7. Kit 311133 8. Kit 311104-17410 9. Kit 311112-17410 10. Kit 314203-17410 11. Kit 311130-5810 12. Kit 311114 13. Kit 311102 14. Kit 311104-5810 15. Kit 311112-5810 16. Kit 314203-5810 17. Kit 311104-40015 18. Kit 311112-40015 19. Kit 314203-40015 Inside Antenna Kit Options: 1. Kit 311127 2. Kit 311106 Sincerely, Patrick L. Cook Senior Research and Development Engineer FCC ID:PWO460008 Final Output Power Limited to 30 dBm EIRP in all frequency bands Uplink Frequency (MHz)704-716777-787824-8491710-17551850-1915 Uplink Output Power (dBm)25.724.425.123.825.2 1 Magnet Mount w/12.5' RG-174Kit Numbers:311103311125311128314202 Antenna Gains (dBi)-4.880.091.97-6.992.51 Coax Loss (dB)2.83.03.74.54.7 Final Gain less Loss (dB)-7.7-2.9-1.7-11.5-2.2 Output Power plus Final Gain (dBm EIRP)18.0221.4923.3712.3123.0 2 Magnet Mount w/12.5' RG-174311703 Antenna Gains (dBi)-15.07-4.230.69-1.991.13 Coax Loss (dB)2.83.03.74.54.7 Final Gain less Loss (dB)-17.9-7.2-3.0-6.5-3.6 Output Power plus Final Gain (dBm EIRP)7.8317.1722.0917.321.63 3 Mini-Mag Mount w/12.5' RG-174301113301126 Antenna Gains (dBi)-0.36-2.15-1.921.161.85 Coax Loss (dB)2.833.74.54.7 Final Gain less Loss (dB)-3.2-5.2-5.6-3.3-2.9 Output Power plus Final Gain (dBm EIRP)22.5419.2519.4820.4622.4 4 Trucker Antenna w/10.5' RG-58311101 Antenna Gains (dBi)-4.510.41.72-3.626.12 Coax Loss (dB)1.21.31.42.22.3 Final Gain less Loss (dB)-5.7-0.90.3-5.83.8 Output Power plus Final Gain (dBm EIRP)20.023.525.418.029.0 5Trucker Antenna w/10.5' RG-58311701 Antenna Gains (dBi)-14.11-0.712.18-0.152.66 Coax Loss (dB)1.21.31.42.22.3 Final Gain less Loss (dB)-15.3-2.00.8-2.40.4 Output Power plus Final Gain (dBm EIRP)10.3922.3925.8821.4525.6 6 Trucker Antenna w/13.5' RG-58311119 Antenna Gains (dBi)-1.360.361.21-2.33.57 Coax Loss (dB)1.61.71.72.82.9 Final Gain less Loss (dB)-3.0-1.3-0.5-5.10.7 Output Power plus Final Gain (dBm EIRP)22.723.0624.6118.725.87 7 Trucker Antenna w/13.5' RG-58311133 Antenna Gains (dBi)-3.30.21.15-4.754.22 Coax Loss (dB)1.61.71.72.82.9 Final Gain less Loss (dB)-4.9-1.6-0.6-7.61.3 Output Power plus Final Gain (dBm EIRP)20.922.924.616.326.5 8 NMO Antenna 10' RG-174311104-17410 Antenna Gains (dBi)-4.1-0.92.48-3.511.8 Coax Loss (dB)2.32.43.03.63.8 Final Gain less Loss (dB)-6.4-3.3-0.5-7.1-2.0 Output Power plus Final Gain (dBm EIRP)19.3321.0724.5816.6923.2 9 NMO Antenna 10' RG-174311112-17410 Antenna Gains (dBi)-3.16-0.452.47-2.6-0.65 Coax Loss (dB)2.32.43.03.63.8 Final Gain less Loss (dB)-5.5-2.9-0.5-6.2-4.5 Output Power plus Final Gain (dBm EIRP)20.2421.5524.5717.620.75 10 NMO Antenna 10' RG-174314203-17410 Antenna Gains (dBi)-1.570.481.82-5.740.75 Coax Loss (dB)2.32.43.03.63.8 Final Gain less Loss (dB)-3.9-1.9-1.2-9.3-3.1 Output Power plus Final Gain (dBm EIRP)21.822.523.914.522.2 Mobile Outside Antenna Kit Options FCC ID:PWO460008 Final Output Power Limited to 30 dBm EIRP in all frequency bands Uplink Frequency (MHz)704-716777-787824-8491710-17551850-1915 Uplink Output Power (dBm)25.724.425.123.825.2 11 Marine Antenna w/10' RG-58311130-5810 Antenna Gains (dBi)-1.0-1.60.65-1.683.57 Coax Loss (dB)1.21.21.32.12.1 Final Gain less Loss (dB)-2.2-2.9-0.6-3.71.4 Output Power plus Final Gain (dBm EIRP)23.5521.524.520.126.6 12 Mini-Glass Mount w/14' RG-58311114 Antenna Gains (dBi)-7.53-6.11-5.392.571.44 Coax Loss (dB)1.61.71.82.93.0 Final Gain less Loss (dB)-9.1-7.8-7.2-0.3-1.6 Output Power plus Final Gain (dBm EIRP)16.616.617.923.523.6 13 Glass Mount w/14' RG-58311102 Antenna Gains (dBi)-3.68-2.54-0.862.193.39 Coax Loss (dB)1.61.71.82.93.0 Final Gain less Loss (dB)-5.3-4.2-2.7-0.70.4 Output Power plus Final Gain (dBm EIRP)20.4220.1622.4423.0925.6 14 NMO Antenna w/10' RG-58311104-5810 Antenna Gains (dBi)-4.1-0.92.48-3.511.8 Coax Loss (dB)1.21.21.32.12.1 Final Gain less Loss (dB)-5.3-2.11.2-5.6-0.3 Output Power plus Final Gain (dBm EIRP)20.4322.2726.2818.1924.9 15 NMO Antenna w/10' RG-58311112-5810 Antenna Gains (dBi)-3.16-0.452.47-2.6-0.65 Coax Loss (dB)1.21.21.32.12.1 Final Gain less Loss (dB)-4.4-1.71.2-4.7-2.8 Output Power plus Final Gain (dBm EIRP)21.3422.7526.2719.122.45 16 NMO Antenna w/10' RG-58314203-5810 Antenna Gains (dBi)-1.570.481.82-5.740.75 Coax Loss (dB)1.21.21.32.12.1 Final Gain less Loss (dB)-2.8-0.70.5-7.8-1.4 Output Power plus Final Gain (dBm EIRP)22.923.725.616.023.9 17 NMO Antenna w/15'LMR 400311104-40015 Antenna Gains (dBi)-4.1-0.92.48-3.511.8 Coax Loss (dB)0.80.80.91.11.3 Final Gain less Loss (dB)-4.9-1.71.6-4.60.5 Output Power plus Final Gain (dBm EIRP)20.8322.6726.719.1925.7 18 NMO Antenna w/15'LMR 400311112-40015 Antenna Gains (dBi)-3.16-0.452.47-2.6-0.65 Coax Loss (dB)0.80.80.91.11.3 Final Gain less Loss (dB)-4.0-1.31.6-3.7-2.0 Output Power plus Final Gain (dBm EIRP)21.7423.1526.6720.123.25 19 NMO Antenna w/15'LMR 400314203-40015 Antenna Gains (dBi)-1.570.481.82-5.740.75 Coax Loss (dB)0.80.80.91.11.3 Final Gain less Loss (dB)-2.4-0.30.9-6.8-0.6 Output Power plus Final Gain (dBm EIRP)23.324.126.017.024.7 314203-17410 Mobile Outside Antenna Kit Options FCC ID:PWO460008 Uplink Frequency Band (MHz) 704-716777-787824-8491710-17551850-1915 Measured Uplink Gain (dB) 49.448.9048.6045.8049.10 Measured RSSI Shutoff (dBm/MHz) -60.00-60.00-57.30-47.50-53.00 MSCL Minimum (dB) 23.4022.9025.3032.3030.10 1.5' Separation Distance Path Loss (dB) 22.6923.5324.1230.4431.16 Polarity Loss (dB) 3.03.03.03.03.0 Max Antenna Gain Less Cable Loss (dB) 2.293.631.821.144.06 1Inside Antenna Kit 311127: Slim Low Profile with 10' RG-174 Antenna Gain Less Cable Loss (dB) -5.1-3.6-1.7-6.2-6.9 Margin (dB) -7.38-7.18-3.47-7.33-10.97 2Inside Ant…

Text truncated - open the document above for the full version.

December 3, 2013 Subject: RF MPE EXPOSURE Re: FCC ID: PWO460008 To Whom It May Concern: The MPE calculations for model 460008 signal booster were done for each frequency band: 1700/2100 MHz, 800 MHz, 700 MHz Band 13, 700 MHz Band 17, and 1900 MHz. For each band two calculations were done; these included the different possibilities of antennas that may be connected to this signal booster: mobile outside and inside antennas. The order of the attached calculations is as follows: 1700/2100 MHz band: 1. Mobile Outside Antenna: 311114 2. Inside Antenna: 311106 800 MHz band: 1. Mobile Outside Antenna: 311104 2. Inside Antenna: 311127 700 MHz Band 13: 1. Mobile Outside Antenna: 314203 2. Inside Antenna: 311127 700 MHz Band 17: 1. Mobile Outside Antenna: 301126 2. Inside Antenna: 311127 1900 MHz band: 1. Mobile Outside Antenna: 311101 2. Inside Antenna: 311106 A booster’s uplink power must not exceed 1 watt equivalent isotropic radiated power (EIRP) for each band of operation. Composite downlink power must not exceed 0.05 watt EIRP for each band of operation ( 20.21(e)(8)(i)(D)). The following formula was used to calculate the equivalent isotropic radiated power: EIRP= Power Out (Watts)*Duty Cycle Percent*Antenna Gain (non-log)*Coax loss (non-log) The power density (mW/cm 2 ) is calculated using the following formula: Calculated Power Density=1000*EIRP (Watts)/(4*π*(Distance from Antenna (cm)^2)) Sincerely, Patrick L. Cook Senior Research and Development Engineer Minimum Safe Distance From Antennas Based upon FCC OET Bulletin 65 and other FCC Sources 12/10/2013, 1:46 PM460008 1700 MHz Outside INPUT DATA Frequency MHz1710 Pout Watts0.23988 Duty Cycle Percent100.0% Ant. Gain dBi2.57 Coax Loss dB0.00 Distance From Antenna In cm20.3 Ant. Gain less Coax Loss dBi2.57 Distance From Antenna In Inches8.00 EIRP (Watts)0.4335 FCC Power Density Limit (mw/cm 2 ) 1.00 Calculated Power Density (mw/cm 2 ) 0.0836 REFERENCE DATA Pout dBm23.80 Antenna Gain (non-log)1.81 Coax loss (non-log)1.00 General FCC Limit (mw/cm 2 ) 1.00 Antenna # 311114 RESULTS OF CALCULATIONS Minimum Safe Distance From Antennas Based upon FCC OET Bulletin 65 and other FCC Sources 12/10/2013, 1:46 PM460008 2100 MHz Inside INPUT DATA Frequency MHz2110 Pout Watts0.00363 Duty Cycle Percent100.0% Ant. Gain dBi0.15 Coax Loss dB0.00 Distance From Antenna In cm20.3 Ant. Gain less Coax Loss dBi0.15 Distance From Antenna In Inches8.00 EIRP (Watts)0.0038 FCC Power Density Limit (mw/cm 2 ) 1.00 Calculated Power Density (mw/cm 2 ) 0.0007 REFERENCE DATA Pout dBm5.60 Antenna Gain (non-log)1.04 Coax loss (non-log)1.00 General FCC Limit (mw/cm 2 ) 1.00 Antenna # 311106 RESULTS OF CALCULATIONS Minimum Safe Distance From Antennas Based upon FCC OET Bulletin 65 and other FCC Sources 12/10/2013, 1:46 PM460008 800 MHz Outside INPUT DATA Frequency MHz824 Pout Watts0.32359 Duty Cycle Percent100.0% Ant. Gain dBi2.48 Coax Loss dB0.00 Distance From Antenna In cm20.3 Ant. Gain less Coax Loss dBi2.48 Distance From Antenna In Inches8.00 EIRP (Watts)0.5728 FCC Power Density Limit (mw/cm 2 ) 0.55 Calculated Power Density (mw/cm 2 ) 0.1105 REFERENCE DATA Pout dBm25.10 Antenna Gain (non-log)1.77 Coax loss (non-log)1.00 General FCC Limit (mw/cm 2 ) f/1500 Antenna # 311104 RESULTS OF CALCULATIONS Minimum Safe Distance From Antennas Based upon FCC OET Bulletin 65 and other FCC Sources 12/10/2013, 1:46 PM460008 800 MHz Inside INPUT DATA Frequency MHz869 Pout Watts0.00076 Duty Cycle Percent100.0% Ant. Gain dBi2.19 Coax Loss dB0.00 Distance From Antenna In cm20.3 Ant. Gain less Coax Loss dBi2.19 Distance From Antenna In Inches8.00 EIRP (Watts)0.0013 FCC Power Density Limit (mw/cm 2 ) 0.58 Calculated Power Density (mw/cm 2 ) 0.0002 REFERENCE DATA Pout dBm-1.20 Antenna Gain (non-log)1.66 Coax loss (non-log)1.00 General FCC Limit (mw/cm 2 ) f/1500 Antenna # 311127 RESULTS OF CALCULATIONS Minimum Safe Distance From Antennas Based upon FCC OET Bulletin 65 and other FCC Sources 12/10/2013, 1:46 PM460008 700 MHz Band 13 Outside INPUT DATA Frequency MHz776 Pout Watts0.27542 Duty Cycle Percent100.0% Ant. Gain dBi0.48 Coax Loss dB0.00 Distance From Antenna In cm20.3 Ant. Gain less Coax Loss dBi0.48 Distance From Antenna In Inches8.00 EIRP (Watts)0.3076 FCC Power Density Limit (mw/cm 2 ) 0.52 Calculated Power Density (mw/cm 2 ) 0.0593 REFERENCE DATA Pout dBm24.40 Antenna Gain (non-log)1.12 Coax loss (non-log)1.00 General FCC Limit (mw/cm 2 ) f/1500 Antenna # 314203 RESULTS OF CALCULATIONS Minimum Safe Distance From Antennas Based upon FCC OET Bulletin 65 and other FCC Sources 12/10/2013, 1:47 PM460008 700 MHz Band 13 Inside INPUT DATA Frequency MHz746 Pout Watts0.00039 Duty Cycle Percent100.0% Ant. Gain dBi-2.25 Coax Loss dB0.00 Distance From Antenna In cm20.3 Ant. Gain less Coax Loss dBi-2.25 Distance From Antenna In Inches8.00 EIRP (Watts)0.0002 FCC Power Density Limit (mw/cm 2 ) 0.50 Calculated Power Density (mw/cm 2 ) 0.0000 REFERENCE DATA Pout dBm-4.10 Antenna Gain (non-log)0.60 Coax loss (non-log)1.00 General FCC Limit (mw/cm 2 ) f/1500 Antenna # 311127 RESULTS OF CALCULATIONS Minimum Safe Distance From Antennas Based upon FCC OET Bulletin 65 and other FCC Sources 12/10/2013, 1:47 PM460008 700 MHz Band 17 Outside INPUT DATA Frequency MHz704 Pout Watts0.37154 Duty Cycle Percent100.0% Ant. Gain dBi-0.36 Coax Loss dB0.00 Distance From Antenna In cm20.3 Ant. Gain less Coax Loss dBi-0.36 Distance From Antenna In Inches8.00 EIRP (Watts)0.3420 FCC Power Density Limit (mw/cm 2 ) 0.47 Calculated Power Density (mw/cm 2 ) 0.0660 REFERENCE DATA Pout dBm25.70 Antenna Gain (non-log)0.92 Coax loss (non-log)1.00 General FCC Limit (mw/cm 2 ) f/1500 Antenna # 301126 RESULTS OF CALCULATIONS Minimum Safe Distance From Antennas Based upon FCC OET Bulletin 65 and other FCC Sources 12/10/2013, 1:47 PM460008 700 MHz Band 17 Inside INPUT DATA Frequency MHz734 Pout Watts0.00037 Duty Cycle Percent100.0% Ant. Gain dBi-1.90 Coax Loss dB0.00 Distance From Antenna In cm20.3 Ant. Gain less Coax Loss dBi-1.90 Distanc…

Text truncated - open the document above for the full version.

August 20, 2013 To: Whom it May Concern Subject: Calculated Mobile Station Coupling Losses (MSCL) For FCCID: PWO460008 The following formulas were used to calculate MSCL with a 1.5’ foot path loss and a 45 degree polarity mismatch between the inside antenna and the mobile device: Path Loss dB = 36.6 dB + 20Log(F MHz) dB+ 20Log(D miles ) dB Polarity Loss dB = 10Log(E 1 /E 2 ) 2 dB = P L dB P L dB= 10Log(E 1 2 /(E 1 Sin(45 deg )) 2 ) dB = 20Log(1/Sin(45 deg )) dB = 3.01dB Where: E 1 = Maximum Possible Magnitude of the Electric Field from the Mobile Device E 2 = Magnitude of the electric field from the Mobile device with a 45deg polarity mismatch = E 1 Sin(  MSCL dB = Path Loss dB + Polarity Loss dB - Antenna Gain dB The results of the calculations are shown in the following table: Note: Antenna Gain with Coax Loss as measured. Sincerely Patrick L. Cook Uplink Center Frequency MHz707-710782836.51732.51880-1882.5 Path Loss (dB)22.6923.5324.1230.4431.16 Polarity Loss (dB)33333 Antenna Gain with Coax Loss0.220.04-1.96-3.68-2.10 MSCL (dB)25.4726.4929.0837.1236.26 E 1 E 2 45deg Senior Electrical Engineer

p1350021_FCC_Part 20_Rev 6.0 Page 1 of 141 Test Report Prepared for: Wilson Electronics, Inc. Model: 460008 Description: Quint Band Mobile Signal Booster FCC ID: PWO460008 To FCC Part 20 Date of Issue: January 20, 2014 On the behalf of the applicant: Wilson Electronics, Inc. 3301 E Deseret Drive St. George, UT 84790 To the attention of: Pat Cook, Sr. Electrical Engineer Ph: (435) 673-5021 Email: [email protected] Prepared By Compliance Testing, LLC 3356 N San Marcos Pl, Suite 107 Chandler, AZ 85225-7176 (866) 311-3268 phone / (480) 926-3598 fax www.compliancetesting.com Project No: p1350021 Greg Corbin Project Test Engineer This report may not be reproduced, except in full, without written permission from Compliance Testing All results contained herein relate only to the sample tested p1350021_FCC_Part 20_Rev 6.0 Page 2 of 141 Test Report Revision History Revision Date Revised By Reason for Revision 1.0 October 26, 2013 Greg Corbin Original Document 2.0 November 27, 2013 Greg Corbin Corrected typo in gain chart on page 83 3.0 January 6, 2014 Greg Corbin Added additional spurious emissions data on pages 56, 57, 68, 69, 70, 71 4.0 January 9, 2014 Greg Corbin Updated Conducted Emissions rule sections in the test summary table on page 6 and 57 to match the eCFR rule sections dated January 7, 2014. 5.0 January 20, 2014 Greg Corbin Added test details to test procedure on page 20 for the Uplink Noise Timing plots. Added MSCL values to the tables on pages 88 and 89. 6.0 January 28, 2014 Greg Corbin Corrected rule sections in the test summary table for Noise Limits and Uplink Inactivity on page 6. p1350021_FCC_Part 20_Rev 6.0 Page 3 of 141 Table of Contents Description Page Standard Test Conditions and Engineering Practices 5 Test Result Summary 6 Authorized Frequency Band 7 Maximum Power and Gain 13 Intermodulation 15 Out-of-Band Emissions 21 Conducted Spurious Emissions 55 Noise Limits 72 Uplink Inactivity 84 Variable Gain 88 Occupied Bandwidth 90 Oscillation Detection 121 Radiated Spurious 138 Test Equipment Utilized 141 p1350021_FCC_Part 20_Rev 6.0 Page 4 of 141 ILAC / A2LA Compliance Testing, LLC, has been accredited in accordance with the recognized International Standard ISO/IEC 17025:2005. This accreditation demonstrates technical competence for a defined scope and the operation of a laboratory quality management system (refer joint ISO-ILAC-IAF Communiqué dated January 2009) The tests results contained within this test report all fall within our scope of accreditation, unless noted below. Please refer to http://www.compliancetesting.com/labscope.html for current scope of accreditation. Testing Certificate Number: 2152.01 FCC OATS Reg, #933597 IC Reg. #2044A-1 Non-accredited tests contained in this report: N/A p1350021_FCC_Part 20_Rev 6.0 Page 5 of 141 Test and Measurement Data Subpart 2.1033(c)(14): All tests and measurement data shown were performed in accordance with FCC Rules and Regulations, Part 2, Subpart J and the following individual Parts: 20.21 in conjunction with latest version of Draft KDB 935210 D03 Wideband Consumer Signal Booster Measurement Guidance DR04-41516. Standard Test Conditions and Engineering Practices Except as noted herein, the following conditions and procedures were observed during the testing. In accordance with ANSI/C63.4-2009, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104°F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Environmental Conditions Temp (ºC) Humidity (%) Pressure (mbar) 23.6 – 28.4 25.4 – 43.9 958.1 – 974.8 Measurement results, unless otherwise noted, are worst-case measurements. EUT Description Model: 460008 Description: Quint Band Mobile Signal Booster Firmware: A460008A Software: 460008A Additional Information: The EUT is a mobile bi-directional amplifier for the boosting of cellular phone signals and data communication devices. The frequency bands listed in the table below are the bands used by the EUT. The modulation types and emission designators listed in the tables below represent the modulations that the cell phone providers use for each frequency band. GSK, CDMA, and WCDMA represent all the modulation types (phase and amplitude or a combination thereof) utilized within the industry. EDGE, HSPA, LTE etc. are all protocols or multiplexing techniques using the base modulations. Frequency Band (MHz) Uplink 704 - 716 776 - 787 824 - 849 1850 - 1915 1710 – 1755 Downlink 734 - 746 746 - 757 869 - 894 1930 - 1995 2110 - 2155 Modulation Type LTE GSM, CDMA, EDGE, HSPA. EVDO, LTE CDMA, HSPA, LTE, EDGE, EVDO Emission Designators CDMA HSPA LTE EVDO EDGE GSM F9W F9W G7D F9W G7W GXW EUT Operation during Tests The EUT was in a normal operating condition. p1350021_FCC_Part 20_Rev 6.0 Page 6 of 141 Test Result Summary Specification Test Name Pass, Fail, N/A Comments 20.21(e)(3) Authorized Frequency Band Pass 20.21(e)(8)(i)(B) 20.21(e)(8)(i)(C) 20.21(e)(8)(i)(D) Maximum Power and Gain Pass 20.21(e)(8)(i)(F) Intermodulation Pass 20.21(e)(8)(i)(E) Out-of-Band Emissions Pass 2.1051 22.917(a) 24.238((a) 27.53(c) 27.53(e) 27.53(f) 27.53(g) Conducted Spurious Emissions Pass 20.21(e)(8)(i)(A) Noise Limits Pass 20.21(e)(8)(i)(I) Uplink Inactivity Pass 21(e)(8)(i)(C) Variable Gain Pass 2.1049 Occupied Bandwidth Pass 20.21(e)(8)(ii)(A) Oscillation Detection Pass 2.1053 Radiated Spurious Pass 20.21(e)(8)(i)(B) Spectrum Block Filtering N/A This device does not use spectrum block filtering p1350021_FCC_Part 20_Rev 6.0 Page 7 of 141 Authorized Frequency Band Name of Test: Authorized Frequency Band Engineer: Greg Corbin Test Equipment Utilized: i00424, SMU 200A - S/N:101369 Test Date: 9/23/13 Test Procedure The EUT was connected to a spectrum analyzer through an attenuator with the losses bei…
