PWO824WB56In-Building Bidirectional Amplifier

AMPS IN BUILDING Bi-directional Amplifier #801102 (43dB Model) #801103 (50dB Model) #801104 (60dB Model) FCC ID: PWO824WB56 IC: 4726A-824WB56 iDEN IN BUILDING Bi-directional Amplifier #804001 (43dB Model) #804003 (50dB Model) #804004 (60dB Model) FCC ID: PWO806WB56 IC: 4726A-806WB56 Installation Guide Wilson Electronics, Inc. 3301 E. Deseret Drive, St. George, Utah 84790 For additional technical support go to www.wilsonelectronics.com Phone: 1-866-294-1660 Fax: 1-435-656-2432 IN BUILDING Wireless The term “IC:” before the radio certification number only signifies that Industry of Canada technical specifications were met. 23 1. PURPOSE OF THE AMPS/iDEN AMPLIFIER The AMPS/iDEN Bi-directional Amplifier improves RF coverage for areas in which low signal strength or no signal is a problem. 2. PACKAGE CONTENTS 2.1 AMPS/iDEN Bi-directional Amplifier 2.2 AC-to-DC (110 volt) Power Supply 3. HOW THE AMPS/iDEN AMPLIFIER FUNCTIONS The signal is received by the outside antenna from the cell site. The signal is then AMPLIFIED and transmitted to your phone through the inside antenna. When the phone transmits, the signal is received by the inside antenna and then AMPLIFIED and transmitted to the cell site through the outside antenna. The information provided by Wilson Electronics, Inc. is believed to be complete and accurate. However, no responsibility is assumed by Wilson Electronics, Inc. for any business or per- sonal losses arising from its use, or for any infringements of patents or other rights of third parties that may result from its use. Copyright © 2004 Wilson Electronics, Inc. 23 4. AMPLIFIER INSTALLATION (see illustration on 4-5) 4.1 Installing the Wilson Cellular Outside Antenna 4.1.1 Select a location on the roof using your AMPS/iDEN phone in test mode to find the best signal strength. (See leaflet titled PHONE TEST MODES) 4.1.2 The Outside Antenna should be located in an area with at least a 3’ radius clear of obstructions and other radiating elements. NOTE: Mount the AMPLIFIER away from direct sunlight, excessive heat and/or moisture. The amplifier needs proper ventilation. DO NOT place the amplifier in an air-tight enclosure. WARNING: The outside antenna used with this amplifier must be fixed- mounted on an outdoor permanent structure with a separation of at least 20 feet from all persons during normal operation. 4.2 Installing The Amplifier WARNING: Connecting amplifier directly to cell phone may damage phone. 4.2.1 Mount the AMPLIFIER on a wall or ceiling using #6 screws. 4.2.2 Connect the Outside Antenna to the AMPLIFIER side labeled “OUTSIDE ANTENNA”. 4.2.3 Connect the Inside Antenna to the AMPLIFIER side labeled “INSIDE ANTENNA”. 4.2.4 Verify that both the OUTSIDE and INSIDE antennas are connected be- fore connecting the AC-DC power supply to the power outlet. 4.3 Installing The Wilson Cellular Inside Antenna 4.3.1 The Inside Antenna should be centered in the weak signal area. The INSIDE ANTENNA should be at least 7’ from the ground. WARNING: The inside antenna used with this amplifier must be mounted with a separation distance of at least 8 inches from all persons and must not be co-located or operating in conjunction with any other antenna or amplifier. 4.4 When covering large areas a splitter can be used to allow for more than one inside antenna. Extension cables can also be used if the weak signal area is located far from the location of the outside antenna. NOTE: A minimum of 20’ coax extension is recommended for isolation between antennas. 45 ����� ����������� ��������� ��������������� ������������������� ���� ���� �������� �������� ����� �������������� ������������ ������������ ���������������� ������������������� ������������� ��������������� ������������ 5. AMPLIFIER SPECIFICATIONS FOR AMPS 43dB, 50dB & 60dB MODELS Part #: 801102 (43dB Model) & 801103 (50dB Model) & 801104 (60dB Model) 43dB50dB60dB Frequency824-849MHz Uplink 869-894MHz Downlink Gain (up/down)(43dB/43dB) (50dB/50dB) (60dB/60dB) Flatness (up/down)(+/- 4dB/+/-4dB) (+/- 4dB/+/-6dB)(+/- 4dB/+/-6dB) Max RF (up/down)(+31dBm/+15dBm)(+35dBm/+15dBm)(+35dBm/+15dBm) Noise Figure (down)(3dB nominal) (3dB nominal)(3dB nominal) IsolationUplink/Downlink More than 90dB Power Consumption13.8V, 1.5A 45 AMPLIFIER LAYOUT KEEP A SEPARATION DISTANCE OF AT LEAST 20ft HORIZONTAL AND 5ft VERTI- CAL BETWEEN ANTENNAS If using the Yagi Antenna, make sure the Yagi is pointed AWAY from the inside antenna. ����� ����������� ��������� ��������������� ������������������� ���� ���� �������� �������� ����� �������������� ������������ ������������ ���������������� ������������������� ������������� ��������������� ������������ AMPLIFIER SPECIFICATIONS FOR iDEN 43dB, 50dB & 60dB MODELS Part #: 804001 (43dB Model) & 804003 (50dB Model) & 804004 (60dB Model) 43dB50dB60dB Frequency806-821MHz Uplink 851-866MHz Downlink Gain (up/down)(43dB/43dB) (50dB/50dB) (60dB/60dB) Flatness (up/down)(+/- 4dB/+/-4dB) (+/- 4dB/+/-6dB)(+/- 4dB/+/-6dB) Max RF (up/down)(+35dBm/+15dBm)(+35dBm/+15dBm)(+35dBm/+15dBm) Noise Figure (down)(3dB nominal) (3dB nominal)(3dB nominal) IsolationUplink/Downlink More than 90dB Power Consumption13.8V, 1.5A AMPS/iDEN AMPLIFIER PHYSICAL SPECIFICATIONS Connectors FME-Male 50 Ohms Dimensions 5.5x4.3x1.4 (inch) or 14.0x10.8x3.5 (cm) Weight 1.32 Pounds or 600G 67 6. OPTIONAL ACCESSORIES/ANTENNA OPTIONS 6.1 2-Way RF Splitter - allows for multiple inside antennas. 6.2 Coax Cable Extensions 50Ω (see chart on next page) 6.3 Antenna Options: Inside Antenna Options Outside Antenna Option 301103 - Magnet Mount 301111 - Yagi 301106 - Stealth 301113 - Mini Magnet 6.4 N-Female To FME-Female Adapter - Adapts 9913 Coax to fit the AMPS/ iDEN Bi-directional Amplifier 6.5 Lightning Suppressor WARNING: Lightning protection is recommended for all installations. 6.6 DC Power Cable 7. TECH SUPPORT If you need further assistance with your installation: 1) Call us Toll-Free at 866-294-1660 2) E-mail tech support at [email protected] 3) Go to www.wils…

Text truncated - open the document above for the full version.

November 11, 2003 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with section 0.457(d)(2)(i) pertaining to confidential material. Wilson Electronics, Inc. would like the following documents regarding this submission for FCC ID: PWO824WB56 to be kept confidential. 1. CONFIDENTIAL PWO824WB56-43db.JPG, PWO824WB56-50db.JPG, PWO824WB56- 60db.JPG The above material contains trade secrets or technical data, which would customarily be guarded from competitors. We do not want these documents to be accessible to the general public. Sincerely, Patrick Cook, Design Engineer Page 2

Front Back Top Left Right Bottom Close-Up

• 2.1033(c) (11) Label showing the information to be placed thereon. LABEL Bottom View Page 2

Inside Back Cover Board Overall Overall Front of Board Top Left Front Top Right Front Bottom Left Front Bottom Right Front Back of Board 1

Operational Description: The In Building Bi-directional Amplifier Improves RF coverage for cellular phones by amplifying the receive and transmit signals. DC Voltages: TX: DC Volts 5V Current 300mA – 1.5A RX DC Volts 3.6V Current 50mA

Tune Up Procedure The amplifiers are factory set. They are not able to be tuned by the customer.
