Version 1.0 HANBit CFC-xxxSx Series 1 / 1 HANBit Electronics Co., Ltd. 1. PRODUCT OVERVIEW GENERAL DESCRIPTION The CFCxxxSx series CompactFlash card is a flash technology based with ATA interface flash memory card. It is constructed with flash disk controller chip and NAND-type (Samsung) flash memory device. The CompactFlash card operates in both 3.3-Volt and 5.0-Volt power supplies. It comes in capacity of 16, 32, 64, 96, 128, 192, 256, 384 MB and up to 512 MB formatted for type-I card. By optimizing flash memory management, the life of this card can be extended to its maximum level. Because the ECC function is included, the correctness of data transfer between the card and the mobile device can be guaranteed. The power down and sleep modes of the card can ensure longer life of the batteries in the mobile devices. It is a perfect choice of solid-state mass-storage cards for battery backup handheld devices such as Digital Camera, Audio Player, PDA, GPS, or the applications which require high environment tolerance with high performance sustained write speed. FEATURES - ATA / True IDE compatible host interface - ATA command set compatible - Very high performance, very low power consumption - Automatic error correction - Support 3 power save mode : stop/idle/active - Support for CIS implemented with 256 bytes of attribute memory - Support for 8 or 16 bit host transfers - 3.3V/5.0V operation voltage - Host data transfer rate : 20MB/s - Flash data transfer rate : 10MB/s - Host Interface bus width : 8/16 bit Access - Flash Interface bus width : 8 bit Access - Capacity : Min. 16MB ~ Max. 512MB - MTBF : 1,000,000 hours, minimum 30,000 insertions - Operating vibration : 15G peak to peak maximum - Operating shock : 1,000G maximum PRODUCT SPECIFICATIONS Capacities : Compact Flash Card Min.16MB ~ Max.512MB, ATA/IDE Interface Mode, Support 3 power save mode, 3.3V/5.0V Operating Part No. CFCxxxSx Version 1.0 HANBit CFC-xxxSx Series 2 / 2 HANBit Electronics Co., Ltd. 16, 32, 48, 64, 96, 128, 192, 256, 384 and up to 512 MB (formatted) System Compatibility : Please refer to the compatibility list of index. Performance : Data Transfer Rates : up to 4.2 MB/s in ATA PIO mode 4 To/from Flash memory : up to 12.4 MB/s To/from host : up to 20MB/s Sustained write : up to 2.9MB/s in ATA PIO mode 4 Sustained read : up to 5.62MB/s in ATA PIO mode 4 Operating Voltage : 3.3V / 5.0V ± 10% Power consumption : Read mode 30 mA (typ), 40 mA (Max) Write mode 30 mA (typ), 40 mA (Max) Stop mode 30 μA (typ) Environment conditions : Operating temperature 0°C to + 65°C Storage temperature - 20°C to + 70°C Relative humidity 95%(Max) Dimension : Weight Capacity dependent Length 36.4 ± 0.15 mm (1.433 ± 0.006 in.) Width 42.8 ± 0.10 mm (1.685 ± 0.004 in.) Thickness 3.3 mm ± 0.10 mm (0.130 ± 0.004 in.) Version 1.0 HANBit CFC-xxxSx Series 3 / 3 HANBit Electronics Co., Ltd. ELECTRICAL SPECIFICATIONS Table 1.1 Absolute Maximum Ratings Symbol Parameter Ratings Unit V DD Supply voltage - 0.3 to + 7.0 V V IN Input voltage - 0.3 to + 7.0 V I IN DC input current - 10 mA T STG Storage temperature - 20 to + 85 °C Table 1.2 Recommended Operating Conditions Symbol Parameter Ratings Unit 5V 4.75 to 5.25 V V DD DC Supply voltage 3.3V 3.0 to 3.6 V T a Storage temperature - 20 to +70 °C Table 1.3 DC Characteristics (Ta=0°C to 70°C, V DD =3.0 to 5.3V) Symbol Parameter Min. Typ. Max. Unit I DD Operating Current 30 70 mA I ds Stop Current 50 150 μA V DD High Level Output Voltage 2.4 V V DD Low Level Output Voltage 0.4 V Version 1.0 HANBit CFC-xxxSx Series 4 / 4 HANBit Electronics Co., Ltd. PHYSYCAL SPECIFICATION Note: The optional notched configuration was shown in the CF Specification Rev. 1.0. In specification Rev. 1.2, the notch was removed for ease of tooling. This optional configuration can be used but it is not recommended. Figure 1.1 Type I CompactFlash Storage Card Dimensions Version 1.0 HANBit CFC-xxxSx Series 5 / 5 HANBit Electronics Co., Ltd. Electrical Interface Physical Description The host is connected to the CompactFlash Storage Card or CF+ Card using a standard 50-pin connector. The connector in the host consists of two rows of 25 male contacts each on 50 mil (1.27 mm) centers. Pin Assignments and Pin Type The signal/pin assignments are listed in Table 4. Low active signals have a “-” prefix. Pin types are Input, Output or Input/Output. Section 4.3 defines the DC characteristics for all input and output type structures. Electrical Description The CompactFlash Storage Card functions in three basic modes: 1) PC Card ATA using I/O Mode 2) PC Card ATA using Memory Mode 3) True IDE Mode Which is compatible with most disk drives. CompactFlash Storage Cards are required to support all three modes. The CF Cards normally function in the first and second modes, however they can optionally function in True IDE mode. The configuration of the CompactFlash Card will be controlled using the standard PCMCIA configuration registers starting at address 200h in the Attribute Memory space of the storage card or for True IDE Mode, pin 9 being grounded. The configuration of the CF Card will be controlled using configuration registers starting at the address defined in the configuration Tuple (CISTPL_CONFIG) in the Attribute Memory space of the CF Card. Signal description describes the I/O signals. Signals whose source is the host are designated as inputs while signals that the CompactFlash Storage Card sources are outputs. The CompactFlash Storage Card logic levels conform to those specified in the PCMCIA Release 2.1 specification. Each signal has three possible operating modes: 1) PC Card Memory mode 2) PC Card I/O mode 3) True IDE True IDE mode is required for CompactFlash Storage cards. All outputs from the card are totem pole except the data bus signals that are bi-directional tri-state. 2. PIN INFORMATION Version 1.0 HANBit CFC-xxxSx Series 6 / 6 HANBit Electronics Co., Ltd. PIN ASSIGNMENTS AND PIN TYPE Table 2.1 Pin Assignment and Pin type PC Card Me…

Text truncated - open the document above for the full version.

BLOCK DIAGRAM HOST Interface ARM7TDMI CPU CORE (20MHz) Bus Router DMA0 DMA1 Timer Address Decoder PAMCIA/ ATA CIS (256B) Interrupt Controller System Manager Bus Interface Bus Arbitration System Bus Controller Memory Controller (ROM/SRAM) SRAM (8KB) AGP ROM (32KB) CONTROLLER Reset IC Flash 0 Flash 1 Flash 2 Flash 3 X’tal Flash Memory DataI/O Control Local Bus S-Bus

Test report Our reference : KEL01I-B017K Page : B1 of Appendix Issued date : 2001-10-23 Appendix-B : External Photographs of E.U.T <FRONT VIEW OF EUT> <REAR VIEW OF EUT>

Test report Our reference : KEL01I-B017K Page : D1 of Appendix Issued date : 2001-10-23 Appendix-D : FCC ID label location information and Sample - FCC ID label location information The label included following statement will be attached on the rear bottom of product. - FCC ID label sample

Test report Our reference : KEL01I-B017K Page : C1 of Appendix Issued date : 2001-10-23 Appendix-C : Internal Photographs of E.U.T <INTERNAL VIEW OF E.U.T>

CERTIFICATE OF COMPLIANCE 352 Youngduk-Ri, Kihung-Eup, Yongin-City, Kyunggi-Do, Korea 449-908 TEL : (82)31-206-4693 FAX : (82)31-206-3051 http://www.kesilab.com [email protected] http://www.koreaemc.co.kr [email protected] (CLASS B) CERTIFICATION OF COMPLIANCE is hereby issued to the named Applicant and is VALID ONLY for the equipment identified below: Date of Tested : Oct. 20. 2001 Applicant’s Name : HANBit Electronics Co., Ltd. Applicant’s Address : 414-5, Woncheon-Dong, Paldal-Gu, Suwon-City, Kyoungki-Do, Korea Manufacturer’s Name : HANBit Electronics Co., Ltd. Manufacturer’s Address : 414-5, Woncheon-Dong, Paldal-Gu, Suwon-City, Kyoungki-Do, Korea Declares that the product Product Description : Compact Flash Card Brand Name : Model Number : HANBit CompactFlash FCC ID : PYZHANBIT-CFC Conforms to FCC Rules and Regulations Part 15 Subpart B requirements. This product herewith complies with the requirements of the FCC Rules and Regulations as listed below: Part 15.107: Conducted Emissions. Part 15.109: Radiated Spurious Emissions. TESTED and CERTIFIED by: KOREA EMC LABORATORY 352 Youngduk-Ri, Kihung-Eup, Yongin-Si, Kyunggi-Do, 449-908, KOREA Date : Oct. 23. 2001 Report No : KEL01I-B017K Authorized Signature : M. S. CHO / President Test report Our reference : KEL01I-B017K Page : 2 of 13 Issued date : 2001-10-23 Korea EMC Laboratory TABLE OF CONTENTS DESCRIPTION Page 0. VERIFICATION OF COMPLIANCE 3 1. GENERAL INFORMATION 1.1 Product Description 4 1.2 Related Submittal(s)/Grant(s) 4 1.3 Tested System Details 4 1.4 System Configuration 4 1.5 General Setup of the test Shield room 5 1.6 Test Facility 5 2. Measurement Procedure 2.1 System test configuration 6 2.1.1 Video mode Justification 6 2.1.2 EUT Exercise S/W 6 2.2 Special Accessories 6 2.3 Equipment Modification 6 2.4 System Configuration Diagram 6 2.5 Preliminary testing 7 2.6 Shielded Enclosure 7 2.7 Data Reporting Format 7 2.8 Operating Condition 7 2.9 Conditioning of the EUT 7 2.10 Power Line Conducted Emissions 8 2.11 Open field Radiated Emissions Tests 8 3. Measurement Data 3.1 Conducted Emission Data 9 3.2 Conducted Emission Graph 10 3.3 Radiated Emission Data 11 3.4 Summary 12 4. Labeling Requirement 13 Appendix - A : Test set-up Photographs (Conducted and Radiated) - B : External Photographs of E.U.T - C : Internal Photographs of E.U.T - D : FCC ID label location information and sample - E : Block Diagram - F : User’s Manual Test report Our reference : KEL01I-B017K Page : 3 of 13 Issued date : 2001-10-23 Korea EMC Laboratory 0 . VERIFICATION OF COMPLIANCE Equipment Under Test : Compact Flash Card Model Number : HANBit CompactFlash Serial Number : Prototype Manufacturer : HANBit Electronics Co., Ltd. 414-5, Woncheon-Dong, Paldal-Gu, Suwon-City, Kyunggi-Do, Korea. Type of Test : FCC CLASS B Report Number : KEL01I-B017K Date Tested : Oct. 20. 2001 Tested By : S. J. LEE The results show that the sample equipment tested as described in this reports is in compliance with the CLASS B conducted and radiated emission limits of FCC Rules Part 15, Subpart B. Test report Our reference : KEL01I-B017K Page : 4 of 13 Issued date : 2001-10-23 Korea EMC Laboratory 1. GENERAL INFORMATION 1.1 PRODUCT DESCRIPTION The HANBit CompactFlash is a Compact Flash Card made by HANBit Electronics Co., Ltd. in Korea. Refer to the user's manual for more information. 1.2 Related Submittal(s)/Grant(s) N/A 1.3 Tested System Details Type MODEL NAME FCC ID Serial No Manufacturer ------------------------------------------------------------------------------------------------------------------------------------------ Compact Flash Card HANBit CompactFlash PYZHANBIT-CFC Prototype HANBit Electronics Co., Ltd. PC Brio 500 DoC NONE HP Monitor G790 GSS19001 M885200416 Viewsonic Corp. Keyboard SKR-1032 GJJSKR-1032 1EAC000237 SEJIN Mouse SMB-601 GJJB50PAQ SKBE020496 SEJIN Digital Camera COOLPIX885 DoC 2110905 ANAM Adapter EU-40 NONE Seiko Epson Corp. 1.4 System Configuration Type Model Name Serial NO Manufacturer Remark Compact Flash Card HANBit CompactFlash NONE HANBit Electronics Co., Ltd. KOREA Test report Our reference : KEL01I-B017K Page : 5 of 13 Issued date : 2001-10-23 Korea EMC Laboratory 1.5 General Set-up of the Test Shielded Room The EUT was set up in accordance with the suggested configuration given in FCC measurement Procedure ANSI C63.4, 1992. The measurement are performed in the shielded room which dimension is 3.0*7.0*2.5(m). The EUT was placed on a non conductive table which is 1.0*1.5(m), 80cm above an earthed ground plane and is kept at least 1m from any other earthed ground plane except the rear of table top being removed 40cm from a vertical conducting plane. Power to the EUT was provided through the LISN(KNW-407,Kyoritsu) which has the Impedance vs Frequency Characteristic in accordance with the Fig.1 Impedance Characteristic of LISN. Peripheral equipment required to provide a functional system(support equipment) for EUT testing was powered through another LISN(NSLK8128,Schwarzbeck). Power to the LISN was filtered to eliminate ambient signal interference. A coaxial type connector which provides a 50 Ohm terminating impedance was provided for the test instrument. The excess length of the power cord was wrapped in the two non metallic pegs attached to the top of the LISN. The two pegs are 9cm high, approximately 2.0cm in diameter and that are spaced 6cm on the center apart. 1.6 Test Facility Location: Korea EMC Laboratory 352 Yungduck-Ri Kihung-Eup,Yongin-City Kyungki-Do,Korea Site : - 3/10m Open Fielded Radiated - Indoor Line Conducted Room(Shielded) The Open Field Radiated and Indoor Line Conducted sites are constructed and calibrated to meet the FCC requirements in documents ANSI C63.4 1992. Korea EMC Lab. was refiled in FCC in 1998. INSTRUMENTATION Description Model Manufacturer Serial No. Last Cal. Due Cal. Test Receiver ESH-2 RodeSchwarz 893268/004 '2001.06.15. '2002.06.15 Test Receiver ESVS10 RodeSchwarz 825120/006 '2001.10.10. '2002.10…

Text truncated - open the document above for the full version.

Test report Our reference : KEL01I-B017K Page : A1 of Appendix Issued date : 2001-10-23 Appendix-A : Test Setup Photographs - Conducted Setup Photographs LINE CONDUCTED SETUP PHOTOGRAPH - FRONT VIEW LINE CONDUCTED SETUP PHOTOGRAPH - REAR VIEW Test report Our reference : KEL01I-B017K Page : A2 of Appendix Issued date : 2001-10-23 - Radiated Setup Photograph RADIATED EMISSION SETUP PHOTOGRAPH - FRONT VIEW ( 30 - 300 MHz ) RADIATED EMISSION SETUP PHOTOGRAPH - REAR VIEW ( 30 - 300 MHz ) Test report Our reference : KEL01I-B017K Page : A3 of Appendix Issued date : 2001-10-23 RADIATED EMISSION SETUP PHOTOGRAPH - FRONT VIEW ( 300- 1000 MHz ) RADIATED EMISSION SETUP PHOTOGRAPH - REAR VIEW ( 300 - 1000 MHz )
