Applicant/Grantee Primex, Inc. FCC ID: PZ3-SNSE Section 15.212 Modular Transmitters Request for Modular Approval Request for Limited Modular Approval Requirements EUT Conditions Comply (Y/N) Single Modular Approval Requirements 1 The radio elements of the modular transmitter must have their own shielding. The physical crystal and tuning capacitors may be located external to the shielded radio elements. The modular device is equipped with metal shielding to cover RF section. Y 2 The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. All inputs to the module are buffered. Y 3 The modular transmitter must have its own power supply regulation. The module has its own internal power supply regulation that works from input voltages of 4 to 30VDC. Y 4 The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. The EUT has a permanently attached printed circuit trace antenna and meets this requirement. Y 5 The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing for compliance with Part 15 requirements. Unless the transmitter module will be battery powered, it must comply with the AC line conducted requirements found in Section 15.207. AC or DC power lines and data input/output lines connected to the module must not contain ferrites, unless they will be marketed with the module (see Section 15.27(a)). The length of these lines shall be the length typical of actual use or, if that length is The device was tested in a standalone configuration. Y unknown, at least 10 centimeters to insure that there is no coupling between the case of the module and supporting equipment. Any accessories, peripherals, or support equipment connected to the module during testing shall be unmodified and commercially available (see Section 15.31(i)). 6 The modular transmitter must be equipped with either a permanently affixed label or must be capable of electronically displaying its FCC identification number. (A) If using a permanently affixed label, the modular transmitter must be labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: XYZMODEL1” or “Contains FCC ID: XYZMODEL1.” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. (B) If the modular transmitter uses an electronic display of the FCC identification number, the information must be readily accessible and visible on the modular transmitter or on the device in which it is installed. If the module is installed inside another device, then the outside of the device into which the module is installed must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC certified transmitter module(s).” Any similar wording that expresses the same meaning may be used. The user manual must include instructions on how to access the electronic display. A copy of these instructions must be included in the application for equipment authorization. The modular device has a label showing the FCC ID number on its exterior. This modular device is intended to not mount inside of another device, but rather alongside another device. Thus, a second label for the device it is mounted to is not supplied. Y 7 The modular transmitter must comply with any specific rules or operating requirements that ordinarily apply to a complete transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy Please Refer to the “Emergency Light Monitoring Installation and Users Guide”. Y of these instructions must be included in the application for equipment authorization. 8 The modular transmitter must comply with any applicable RF exposure requirements in its final configuration. The EUT meets the RF exposure compliance. Y A limited modular approval may be granted for single or split modular transmitters that do not comply with all of the above requirements, e.g., shielding, minimum signaling amplitude, buffered modulation/data inputs, or power supply regulation, if the manufacturer can demonstrate by alternative means in the application for equipment authorization that the modular transmitter meets all the applicable Part 15 requirements under the operating conditions in which the transmitter will be used. Limited modular approval also may be granted in those instances where compliance with RF exposure rules is demonstrated only for particular product configurations. The applicant for certification must state how control of the end product into which the module will be installed will be maintained such that full compliance of the end product is always ensured.

SNS Antenna Specification Antenna Type: Internal Inverted L PCB Trace Antenna Frequency Range: 2.4GHz~2.5GHz Impedence: 50Ω Gain: -1.2 dBi 2:1 SWR Bandwidth: 25MHz Radiation Pattern: Omni-directional

PROPOSED FCC/IC ID LABEL AND LOCATION Bottom of Module FCC /IC Label Location PRIMEX, INC. FCC ID : PZ3-SNSE IC : 4256A-SNSE Model: SNSELM100 PROPOSED FCC ID LABEL FOR HOST DEVICE PRIMEX, INC. This device contains FCC ID : PZ3-SNSE, IC : 4256A-SNSE

FCC CFR47 PART 15 SUBPART C INDUSTRY CANADA RSS-210 ISSUE 7 CERTIFICATION TEST REPORT FOR EMERGENCY LIGHTING CONTROLLER MODEL NUMBER: SNSELM100 FCC ID: PZ3-SNSE IC: 4256A-SNSE REPORT NUMBER: 10U13541-1 ISSUE DATE: DECEMBER 6, 2010 Prepared for Primex, Inc. N3211 Highway H Lake Geneva, WI 53147 Prepared by COMPLIANCE CERTIFICATION SERVICES (UL CCS) 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 REPORT NO: 10U13541-1 DATE: DECEMBER 2, 2010 FCC ID: PZ3-SNSE IC: 4256A-SNSE Page 2 of 84 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. Revision History Rev. Issue Date Revisions Revised By -- 12/06/10 Initial Issue F. Ibrahim REPORT NO: 10U13541-1 DATE: DECEMBER 2, 2010 FCC ID: PZ3-SNSE IC: 4256A-SNSE Page 3 of 84 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS.................................................................................... 5 2. TEST METHODOLOGY ........................................................................................................ 6 3. FACILITIES AND ACCREDITATION.................................................................................... 6 4. CALIBRATION AND UNCERTAINTY .................................................................................. 6 4.1. MEASURING INSTRUMENT CALIBRATION ............................................................... 6 4.2. SAMPLE CALCULATION.............................................................................................. 6 4.3. MEASUREMENT UNCERTAINTY................................................................................ 6 5. EQUIPMENT UNDER TEST ................................................................................................. 7 5.1. DESCRIPTION OF EUT................................................................................................ 7 5.2. MAXIMUM OUTPUT POWER....................................................................................... 7 5.3. DESCRIPTION OF AVAILABLE ANTENNAS............................................................... 7 5.4. SOFTWARE AND FIRMWARE..................................................................................... 7 5.5. WORST-CASE CONFIGURATION AND MODE .......................................................... 7 5.6. DESCRIPTION OF TEST SETUP................................................................................. 8 6. TEST AND MEASUREMENT EQUIPMENT ....................................................................... 10 7. ANTENNA PORT TEST RESULTS .................................................................................... 11 7.1. 802.11b MODE IN THE 2.4 GHz BAND...................................................................... 11 7.1.1. 6 dB BANDWIDTH .............................................................................................. 11 7.1.2. 99% BANDWIDTH .............................................................................................. 15 7.1.3. PEAK POWER .................................................................................................... 19 7.1.4. AVERAGE POWER ............................................................................................ 20 7.1.5. POWER SPECTRAL DENSITY .......................................................................... 21 7.1.6. CONDUCTED SPURIOUS EMISSIONS............................................................. 25 7.2. 802.11g MODE IN THE 2.4 GHz BAND...................................................................... 32 7.2.1. 6 dB BANDWIDTH .............................................................................................. 32 7.2.2. 99% BANDWIDTH .............................................................................................. 36 7.2.3. PEAK POWER .................................................................................................... 40 7.2.4. AVERAGE POWER ............................................................................................ 41 7.2.5. POWER SPECTRAL DENSITY .......................................................................... 42 7.2.6. CONDUCTED SPURIOUS EMISSIONS............................................................. 46 8. RADIATED TEST RESULTS .............................................................................................. 53 8.1. LIMITS AND PROCEDURE ........................................................................................ 53 8.2. TRANSMITTER ABOVE 1 GHz .................................................................................. 54 8.2.1. TX ABOVE 1 GHz FOR 802.11b MODE IN THE 2.4 GHz BAND ....................... 54 8.2.2. TX ABOVE 1 GHz FOR 802.11g MODE IN THE 2.4 GHz BAND ....................... 63 8.3. RECEIVER ABOVE 1 GHz ......................................................................................... 72 REPORT NO: 10U13541-1 DATE: DECEMBER 2, 2010 FCC ID: PZ3-SNSE IC: 4256A-SNSE Page 4 of 84 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. 8.4. WORST-CASE BELOW 1 GHz................................................................................... 73 9. MAXIMUM PERMISSIBLE EXPOSURE ............................................................................. 76 10. SETUP PHOTOS ............................................................................................................ 80 REPORT NO: 10U13541-1 DATE: DECEMBE…

Text truncated - open the document above for the full version.

REPORT NO: 10U13541-1 DATE: DECEMBER 2, 2010 FCC ID: PZ3-SNSE IC: 4256A-SNSE Page 80 of 84 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. 10. SETUP PHOTOS ANTENNA PORT CONDUCTED RF MEASUREMENT SETUP ANTENNA PORT CONDUCTED PHOTO REPORT NO: 10U13541-1 DATE: DECEMBER 2, 2010 FCC ID: PZ3-SNSE IC: 4256A-SNSE Page 81 of 84 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. RADIATED RF MEASUREMENT SETUP RADIATED FRONT PHOTO RADIATED BACK PHOTO REPORT NO: 10U13541-1 DATE: DECEMBER 2, 2010 FCC ID: PZ3-SNSE IC: 4256A-SNSE Page 82 of 84 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. RADIATED RF MEASUREMENT SETUP FOR PORTABLE CONFIGURATION X-AXIS FRONT PHOTO X-AXIS BACK PHOTO REPORT NO: 10U13541-1 DATE: DECEMBER 2, 2010 FCC ID: PZ3-SNSE IC: 4256A-SNSE Page 83 of 84 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. Y-AXIS FRONT PHOTO Y-AXIS BACK PHOTO REPORT NO: 10U13541-1 DATE: DECEMBER 2, 2010 FCC ID: PZ3-SNSE IC: 4256A-SNSE Page 84 of 84 COMPLIANCE CERTIFICATION SERVICES (UL CCS) FORM NO: CCSUP4701D 47173 BENICIA STREET, FREMONT, CA 94538, USA TEL: (510) 771-1000 FAX: (510) 661-0888 This report shall not be reproduced except in full, without the written approval of UL CCS. END OF REPORT Z-AXIS FRONT PHOTO Z-AXIS BACK PHOTO
