AP0127450, AP0127460 RF Module Operating in the 2.4 GHz bands REFERENCE GUIDE Regulatory Compliance FCC/IC - Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules and IC RSS standards. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. It is the responsibility of the installer to ensure that when using the outdoor antenna kits, only those antennas certified with the product are used. The use of any antenna other than those certified with the product is expressly forbidden by FCC rules 47 CFR part 15.204 and IC RSS standards. Il est de la responsabilité de l'installateur de s'assurer que lorsque vous utilisez les kits d'antennes extérieures, seules les antennes certifiés avec le produit sont utilisés. L'utilisation d'une antenne autre que ceux qui sont certifiés avec le produit est expressément interdite par la réglementation FCC partie 47 CFR 15.204 et IC normes RSS. Outdoor units and antennas should be installed ONLY by experienced installation professionals who are familiar with local building and safety codes and, wherever applicable, are licensed by the appropriate government regulatory authorities. Failure to do so may void the product warranty and may expose the end user or the service provider to legal and financial Caution liabilities. Resellers or distributors of this equipment are not liable for injury, damage or violation of regulations associated with the installation of outdoor units or antennas. The installer should configure the output power level of antennas according to country regulations and antenna type. AP0127450, AP0127460 Reference Guide i Warning Avertissement Les unités extérieures et les antennes doivent être installés que par des professionnels expérimentés d'installation qui sont familiers avec les normes locales et les codes de sécurité et, si applicable, sont agréées par les autorités gouvernementales de réglementation compétents. Ne pas le faire peut annuler la garantie du produit et peuvent exposer l'utilisateur final ou le fournisseur de services d'obligations juridiques et financiers. Revendeurs ou distributeurs de ces équipements ne sont pas responsables des blessures, des dommages ou violation des règlements liés à l'installation des unités extérieures ou des antennes. L'installateur doit configurer le niveau de puissance de sortie des antennes conformément aux réglementations nationales et le type d'antenne. This equipment should be installed and operated with a minimum distance of 354cm between the radiator and your body. Warning Cet équipement doit être installé et utilisé à une distance minimale de 354cm entre le radiateur et votre corps. The module is granted to operate under FCC certification in the 2.4 GHz band only. Warning This device complies with Part 15 of the FCC rules and with Industry Canada license- exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Cet appareil est conforme la norme d'Industrie Canada exempts de licence RSS (s). Son fonctionnement est soumis aux deux conditions suivantes: 1. Cet appareil ne peut pas causer d'interférences, et 2. Cet appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numrique de la classe B est conforme la norme NMB-003 du Canada AP0127450, AP0127460 Reference Guide ii Prudence Avertissement Overview The AP0127450, AP0127460 is an RF module operating in the 2.4 GHz frequency band. It is a TDD OFDM radio supporting 802.11b/g/HT20/HT40 WiFi operating modes and 5 MHz, 10 MHz, 20 MHz and 40 MHz channel bandwidths based on 802.11n. The RF module can support 2x2 and 3x3 radio chains. The RF module cannot work as a stand-alone device. It can operate and be controlled only when attached to a digital main board and altogether assembled in an enclosure suitable for outdoor use. The assembly of the RF module attached to the digital main board is hereafter referred to as ‘ODU’. The ODU in its various outdoor enclosures is manufactured by RADWIN. The RF module is certified as a limited modular approval type with the FCC ID: Q3KRW24MOD and IC: 5100A-RW24MOD. Condition of Use The AP0127450, AP0127460 RF module is a proprietary radio interface and can only be connected to digital boards manufactured by RADWIN. The ODU resides in an outdoor enclosure also manufactured and assembled by RADWIN or its subcontractors. The RF module is not for sale to the general public. FCC rules and IC Regulation Restrictions The ODU firmware is factory programmed to operate under the FCC rules and Industry Canada regulation restrictions. The firmware is locked and inaccessible by…

Text truncated - open the document above for the full version.

Letter of Authorization Company: RADWIN Ltd. Address: 27 Habarzel Street, Tel Aviv, Israel, 69710 Product Name: RF module operating in the 2.4 GHz band Model Number: RADWIN AP0127450, AP0127460 We authorize MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, to act on our behalf on all matters concerning the above named equipment. This shall include the following: - Testing - Approval applications and procedures - Payment of approval fees We declare that MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566, USA, is allowed to forward all information related to the approval project to the applied notified body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Itai Rubinstein Date: November 4, 2012 Title: Engineering Department Manager Signature of applicant

FCC Confidentiality Form December 12, 2012 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Gentlemen: This letter is to comply with Section 0.457(d)(2)(i) pertaining to confidential material. Radwin Ltd. would like the following documents regarding this submission for FCC ID: Q3KRW5XMOD to be kept confidential. 1) Block Diagram 2) Schematics 3) Bill of Material The above material contains trade secrets and technical data, which would customarily be guarded from competitors. RADWIN Ltd. would not want them to be accessible to the general public. The product is an RF module assembled inside outdoor enclosures mounted on top of large towers and mounting poles and serviceable only by the licensee or his designated technicians. . Sincerely, Itai Rubinstein Engineering Department Manager RADWIN Ltd. RADWIN Ltd. 27 Habarzel St Tel-Aviv, 69710, Israel, Tel- 972-3-766-2900, Fax-972-3-766-2902

www.radwin.com Address goes here Address goes here Address goes here Modular Approval Request Letter To: Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To: Industry Canada Certification and Engineering Bureau 3701 Carling Avenue Bldg. 94 P.O. Box 11490, Station “H” Ottawa, Ontario K2H 8S2 CANADA RE: Limited Modular Approval Request Dear certification officers, Pursuant to the FCC Rule 15.212 Modular transmitters and KDB 966369 D01 Module Certification Guide v01r03, RADWIN Ltd. herby applies for Limited Modular Approval for the Models AP0127450, AP0127460 under FCC ID: Q3KRW24MOD and IC: 5100A-RW24MOD. The justification for the application is based on the attestation that RADWIN Ltd., being the sole manufacturer and the assembling factory of both the module and the final product, has full control over the production line and the final product. The module is assembled in enclosures manufactured and tested by RADWIN or its approved subcontractors. The module will not be marketed, distributed or sold to the general public as it is incapable of operating as a standalone product. It is installed only in devices manufactured by RADWIN Ltd. or its approved subcontractors. According to the requirements in section 15.212 of FCC rules - 1. The module has its own RF shielding as shown in the presented in the photo at the end of this document. 2. The module has buffered data/modulation inputs provided by the Atheros. 3. The module has on board the power supply regulation. 4. The module is supplied with unique antenna connector. The module is installed into the device at RADWIN’s production line with the unique antenna cabling and connectors, as tested. Only the RADWIN antennas detailed in the manual are marketed with the module. The final installation of the unit is done only by professional installers trained by RADWIN representatives. www.radwin.com Address goes here Address goes here Address goes here 5. The unit was tested in a stand-alone configuration. The test was performed with an open configuration enclosure with the module exposed and attached to a digital board representing typical RADWIN host configuration. 6. The module will be labeled with the FCC ID: Q3KRW24MOD and IC: 5100A-RW24MOD as shown in the photo at the end of this document. The device into which the module is installed will also display a label referring to the enclosed module as shown at the end of this document: “Contains FCC ID: Q3KRW24MOD, Contains IC: 5100A-RW24MOD”. 7. The module was tested for compliance with FCC rule Part 15 subparts C. The integration of the module is done by RADWIN and there is no access to RADWIN manufactured device by third party. 8. The module complies with RF exposure requirements as shown in the MPE documents. Photographs Module with the RF shielding and Label External Label sample attached to host enclosure Itai Rubinstein December 13, 2012 Engineering Department Manager RADWIN Ltd.

www.radwin.com Address goes here Address goes here Address goes here Operational Description of AP0127450, AP0127450 The AP0127450, AP0127450 are RF radio modules designed to operate in the 2.4 GHz band. They support 802.11b/g/HT20/HT40 WiFi operating modes and 5, 10, 20 and 40 MHz channel bandwidths based on 802.11n standard. The modulation supported is Per 802.11 – CCK, BPSK, QPSK, 16QAM, 64QAM, DSSS, OFDM The RF modules can only operate when installed into a digital board specifically designed by RADWIN for that purpose. They will not operate in any other constellation and they are not designated for general public use. The enclosures in which the modules are installed are produced by RADWIN. The firmware and management of the device are RADWIN proprietary. The device can only be operated by RADWIN’s permission according to the certification.

Maximum Permissible Exposure FCC, Part 15 Subpart C §15.247(i) Industry Canada RSS-Gen §5.6 Calculations for Maximum Permissible Exposure Levels Power Density = Pd (mW/cm 2 ) = EIRP/(4d 2 ) EIRP = P * G P = Peak output power (mW) G = Antenna numeric gain (numeric) d = Separation distance (cm) Numeric Gain = 10 ^ (G (dBi)/10) Because the EUT belongs to the General Population/Uncontrolled Exposure the limit of power density is 1.0 mW/cm 2 Note: for mobile or fixed location transmitters the minimum separation distance is 20cm, even if calculations indicate the MPE distance to be less. Specification Maximum Permissible Exposure Limits §15.247(i) Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency levels in excess of the Commission’s guidelines. FCC §1.1310 Limit = 1mW / cm 2 from 1.310 Table 1 RSS-Gen §5.6 Category I and Category II equipment shall comply with the applicable requirements of RSS-102. Laboratory Measurement Uncertainty for Power Measurements Measurement uncertainty 1.33 dB Antenna Model Type Ant Gain (dBi) Numeric Gain (numeric) Peak Output Power (dBm) Peak Output Power (mW) Calculated Safe Distance @ 1mW/cm 2 Limit(cm) Power Density @ 20cm (mW/cm 2 ) RW-9462-0827 Sector Dual Pole Cross Polarized 80 Deg 9 7.9 27.0 501.19 17.80 0.79 MT0129070 Omni Directiona l Antenna 8 6.3 28.0 630.96 17.80 0.79 RW-9463-0825 Omni Directiona l Antenna 6.3 4.3 29.7 933.25 17.80 0.79 RW-9461-0827 Omni Directiona l Antenna 4 2.5 30.0 1000.00 14.14 0.50

COVER PAGE Test of AP0127450, AP0127460 To: FCC 47 CFR Part 15.247 & IC RSS-210 Test Report Serial No.: RDWN14-U1 Rev A TITLE PAGE TEST REPORT FROM Test of AP0127450, AP0127460 to To FCC 47 CFR Part 15.247 & IC RSS-210 Test Report Serial No.: RDWN14-U1 Rev A This report supersedes: NONE Applicant: RADWIN Ltd 27 Habarzel Street Tel Aviv, 69710 Israel Product Function: Wireless Access Point Copy No: pdf Issue Date: 12th December 2012 This Test Report is Issued Under the Authority of; MiCOM Labs, Inc. 440 Boulder Cour t, Suite 200 MiCOM Labs is an ISO 17025 Accredited Testing Laboratory Pleasanton, CA 94566 USA Phone: +1 (925) 462-0304 Fax: +1 (925) 462-0306 www.micomlabs.com TEST CERTIFICATE #2381.01 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. Title: To: AP0127450, AP0127460 FCC 47 CFR Part 15.247 & IC RSS-210 Serial #: Issue Date: Page: 3 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. RDWN14- U1 Rev A 12th December 2012 This page has been left intentionally blank Title: To: Serial #: Issue Date: Page: 4 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com AP0127450, AP0127460 FCC 47 CF R Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 TABLE OF CONTENTS TEST RESULT CERTIFICATE ........................................................................................ 10 1. REFERENCES AND MEASUREMENT UNCERTAINTY ........................................ 11 1.1. Normative References ............................................................................................. 11 1.2. Test and Uncertainty Procedures ............................................................................ 12 2. PRODUCT DETAILS AND TEST CONFIGURATIONS .......................................... 13 2.1. Technical Details ..................................................................................................... 13 2.2. Scope of Test Program ............................................................................................ 14 2.3. Equipment Model(s) and Serial Number(s) ............................................................. 18 2.4. Antenna Details ....................................................................................................... 18 2.5. Cabling and I/O Ports .............................................................................................. 18 2.6. Test Configurations.................................................................................................. 19 2,400 – 2483.5 MHz ........................................................................................................ 20 2.7. Equipment Modifications.......................................................................................... 21 2.8. Deviations from the Test Standard .......................................................................... 21 3. TEST EQUIPMENT CONFIGURATION(S) .............................................................. 22 3.1. Conducted RF Emission Test Set-up ...................................................................... 22 3.2. Radiated Spurious Emission Test Set-up > 1 GHz.................................................. 23 3.3. Digital Emissions Test Set-up (0.03 – 1 GHz) ......................................................... 24 3.4. ac Wireline Emission Test Set-up ............................................................................ 25 4. TEST SUMMARY ...................................................................................................... 26 5. TEST RESULTS - Device Characteristics ....................................................... 28 5.1. Conducted Testing................................................................................................... 28 5.1.1. 6 dB and 99 % Bandwidth ........................................................................28 5.1.2. Peak Output Power ..................................................................................38 5.1.3. Power Spectral Density ............................................................................52 5.1.4. Maximum Permissible Exposure ..............................................................58 5.1.5. Conducted Spurious Emissions ...............................................................60 5.2. Radiated Emission Testing ...................................................................................... 70 5.1.1. Receiver Radiated Spurious Emissions (above 1 GHz).........................142 5.2.1. Digital Emissions (0.03-1 GHz) ..............................................................146 5.2.2. AC Wireline Conducted Emissions (150 kHz – 30 MHz)........................150 6. PHOTOGRAPHS..................................................................................................... 153 6.1. Conducted Test Setup ........................................................................................... 153 6.2. Test Setup - Digital Emissions below 1 GHz ......................................................... 154 6.3. Radiated Emissions Test Setup >1 GHz 6.3 dBi Antenna..................................... 155 6.4. Radiated Emissions Test Setup >1 GHz 8 dBi Antenna........................................ 156 6.5. Radiated Emissions Test Setup >1 GHz 9 dBi Sector Antenna ............................ 157 7. TEST EQUIPMENT ................................................................................................. 158 APPENDIX ..................................................…

Text truncated - open the document above for the full version.

Title: To: Serial #: Issue Date: Page: 159 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com AP0127450, AP0127460 FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 APPENDIX A. SUPPORTING INFORMATION A.1. CONDUCTED TEST PLOTS Title: To: Serial #: Issue Date: Page: 160 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com AP0127450, AP0127460 FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 A.1.1. 6 dB & 99% Bandwidth 6 dB 99% Variant: 802.11n HT-20, Channel: 2412.00 MHz, Chain A, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2403.062 MHz : 0.831 dBm M2 : 2418.212 MHz : 7.058 dBm Delta1 : 17.796 MHz : 0.931 dBm T1 : 2403.142 MHz : 1.964 dBm T2 : 2420.778 MHz : 1.762 dBm OBW : 17.715 MHz Measured 6 dB Bandwidth: 17.796 MHz Limit: 0.5 MHz Margin: -17.30 MHz Back to the Matrix Title: To: Serial #: Issue Date: Page: 161 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com AP0127450, AP0127460 FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 6 dB 99% Variant: 802.11n HT-20, Channel: 2412.00 MHz, Chain B, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2403.062 MHz : 0.274 dBm M2 : 2406.990 MHz : 7.018 dBm Delta1 : 17.796 MHz : 1.716 dBm T1 : 2403.142 MHz : 1.527 dBm T2 : 2420.778 MHz : 1.990 dBm OBW : 17.715 MHz Measured 6 dB Bandwidth: 17.796 MHz Limit: 0.5 MHz Margin: -17.30 MHz Back to the Matrix Title: To: Serial #: Issue Date: Page: 162 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com AP0127450, AP0127460 FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 6 dB 99% Variant: 802.11n HT-20, Channel: 2437.00 MHz, Chain A, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2428.062 MHz : 1.215 dBm M2 : 2443.212 MHz : 7.367 dBm Delta1 : 17.796 MHz : 0.767 dBm T1 : 2428.062 MHz : 1.215 dBm T2 : 2445.778 MHz : 1.982 dBm OBW : 17.796 MHz Measured 6 dB Bandwidth: 17.796 MHz Limit: 0.5 MHz Margin: -17.30 MHz Back to the Matrix Title: To: Serial #: Issue Date: Page: 163 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com AP0127450, AP0127460 FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 6 dB 99% Variant: 802.11n HT-20, Channel: 2437.00 MHz, Chain B, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2428.062 MHz : 0.237 dBm M2 : 2431.910 MHz : 7.396 dBm Delta1 : 17.796 MHz : 1.509 dBm T1 : 2428.142 MHz : 1.691 dBm T2 : 2445.778 MHz : 1.746 dBm OBW : 17.715 MHz Measured 6 dB Bandwidth: 17.796 MHz Limit: 0.5 MHz Margin: -17.30 MHz Back to the Matrix Title: To: Serial #: Issue Date: Page: 164 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com AP0127450, AP0127460 FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 6 dB 99% Variant: 802.11n HT-20, Channel: 2462.00 MHz, Chain A, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2452.982 MHz : -4.695 dBm M2 : 2455.707 MHz : 7.101 dBm Delta1 : 17.876 MHz : 7.037 dBm T1 : 2453.062 MHz : 1.201 dBm T2 : 2470.778 MHz : 2.342 dBm OBW : 17.796 MHz Measured 6 dB Bandwidth: 17.876 MHz Limit: 0.5 MHz Margin: -17.38 MHz Back to the Matrix Title: To: Serial #: Issue Date: Page: 165 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com AP0127450, AP0127460 FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 6 dB 99% Variant: 802.11n HT-20, Channel: 2462.00 MHz, Chain B, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2453.062 MHz : 0.701 dBm M2 : 2456.910 MHz : 7.400 dBm Delta1 : 17.796 MHz : 1.452 dBm T1 : 2453.14…

Text truncated - open the document above for the full version.

Title: AP0127450, AP0127460 To: Serial #: Issue Date: Page: 280 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 A.1.3. Power Spectral Density power density Variant: 802.11n HT-20, Channel: 2412.00 MHz, Chain A, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2408.249 MHz : -6.295 dBm Limit: 4.990 dBm Margin: -11.28 dB Back to the Matrix Title: AP0127450, AP0127460 To: Serial #: Issue Date: Page: 281 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 power density Variant: 802.11n HT-20, Channel: 2412.00 MHz, Chain B, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2408.225 MHz : -6.482 dBm Limit: 4.990 dBm Margin: -11.47 dB Back to the Matrix Title: AP0127450, AP0127460 To: Serial #: Issue Date: Page: 282 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 power density Variant: 802.11n HT-20, Channel: 2437.00 MHz, Chain A, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2443.897 MHz : -5.805 dBm Limit: 4.990 dBm Margin: -10.79 dB Back to the Matrix Title: AP0127450, AP0127460 To: Serial #: Issue Date: Page: 283 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 power density Variant: 802.11n HT-20, Channel: 2437.00 MHz, Chain B, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2438.554 MHz : -5.964 dBm Limit: 4.990 dBm Margin: -10.95 dB Back to the Matrix Title: AP0127450, AP0127460 To: Serial #: Issue Date: Page: 284 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 power density Variant: 802.11n HT-20, Channel: 2462.00 MHz, Chain A, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2457.310 MHz : -6.082 dBm Limit: 4.990 dBm Margin: -11.07 dB Back to the Matrix Title: AP0127450, AP0127460 To: Serial #: Issue Date: Page: 285 of 440 This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 440 Boulder Court, Suite 200, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com FCC 47 CFR Part 15.247 & IC RSS-210 RDWN14-U1 Rev A 12th December 2012 power density Variant: 802.11n HT-20, Channel: 2462.00 MHz, Chain B, Temp: Ambient, Voltage: 48.00 Vdc Analyser Setup Marker : Frequency : Amplitude Test Results Detector = MAX PEAK Sweep Count = 0 RF Atten (dB) = 20 Trace Mode = VIEW M1 : 2459.191 MHz : -6.855 dBm Limit: 4.990 dBm Margin: -11.84 dB Back to the Matrix Title: AP0127450, AP0127460 To: Serial #: Issue Date: Page: 286 of 440 This te…
