Q3QHSWGOBI20002G/3G Wireless Wide Area Network Module for Tablet PC model CFT-003

User’s Guide Motion C5 Motion F5 © 2008 Motion Computing, Inc. All rights reserved. This document contains information protected by copyright. No part of this document may be reproduced in any form without written consent from Motion. The information in this document is provided “as is” and is subject to change without notice. Motion is not liable for errors or omissions in this document. Motion, Motion Computing, Speak Anywhere, and View Anywhere are trademarks or registered trademarks of Motion Computing, Inc. in the U.S.A. and other countries. Acrobat is a registered trademark of Adobe Systems Incorporated. Atheros, the Atheros logo, Super G, Super A/G, Wake- on-Wireless, and Wake-on-Theft are registered trademarks of Atheros Communications, Inc. AuthenTec is a registered trademark of AuthenTec, Inc. Bluetooth is a registered trademark owned by the Bluetooth SIG, Inc., U.S.A. and licensed to Motion Computing, Inc. Intel, Intel Inside, the Intel Inside logo, Pentium, Centrino, and PROSet are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Knowles and IntelliSonic are trademarks or registered trademarks of Knowles Acoustics, Inc. OmniPass is a trademark of Softex, Inc. Wi-Fi is a registered trademark of the Wi-Fi Alliance. Microsoft Windows, Windows Vista, Windows XP, Windows XP Tablet PC Edition, and Windows Journal are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. SigmaTel is a registered trademark and Universal Jacks is a trademark of SigmaTel Corporation. End users may not loan, rent, lease, lend, or otherwise transfer the CDs or DVDs provided for recovery purposes to another user, except as permitted in the End User License Agreement for such product. This product incorporates copy protection technology that is protected by U.S. and foreign patents, including patent numbers 5,315,448 and 6,836,549, and other intellectual property rights. The use of Macrovision's copy protection technology in the product must be authorized by Macrovision. Reverse engineering or disassembly is prohibited. Motion Computing, Inc. has made every effort to identify trademarked properties and owners on this page. All brands and product names used in this document are for identification purposes only and may be trademarks or registered trademarks of their respective companies. The warranties for Motion products are set forth in the express limited warranty statements accompanying such products. Nothing in this document constitutes an additional warranty. The Motion Computing products and services may be covered by one or more patent-protected inventions. Additional patents may also be pending. For more information, see www.motioncomputing.com/info/patents.asp. The end user may access only one operating system language version. L'utilisateur final ne peut accéder qu'à une seule version linguistique du système d'exploitation. Der Endbenutzer darf nur auf eine Sprachversion des Betriebssystems zugreifen. De eindgebruiker heeft slechts toegang tot één taalversie van het besturingssysteem. L'utente finale può accedere a una sola lingua del sistema operativo. El usuario final sólo podrá acceder a una versión de idioma del sistema operativo. Loppukäyttäjä voi käyttää vain yhtä käyttöjärjestelmän kieliversiota. Användaren har endast tillgång till en språkversion av operativsystemet. Slutbrugeren har kun adgang til ét af operativsystemets sprogversioner. Sluttbruker kan aksessere kun én av operativsystemets språkversjoner. Model numbers C5 (CFT-001) and F5 (CFT-002) PN 024-02-0086 Revision A01 January 2008 iii Contents Chapter 1Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Finding information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Right side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Top side. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Back side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Setting up the system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Restoring and backing up the tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Chapter 2Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Pen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Status lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Front panel buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Windows Security button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Fingerprint reader . . . . . . . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

Motion Tablet Model CFT-003 Safety and Regulatory Notices Guide MC-C5 Tablet PC (White)/ MC-F5 Tablet PC (Black) CFT-Series Docking Station TCD001 DRAFT © 2010 Motion Computing, Inc. All rights reserved. This document contains information protected by copyright. No part of this document may be reproduced in any form without written consent from Motion. The information in this document is provided “as is” and is subject to change without notice. Motion is not liable for errors or omissions in this document. Motion, Motion Computing, Speak Anywhere, and View Anywhere are trademarks or registered trademarks of Motion Computing, Inc. in the U.S.A. and other countries. Mayo Clinic and MayoClinic.com are trademarks of Mayo Foundation for Medical Education and Research. Novatel Wireless is a trademark of Novatel Wireless, Inc. Motion Computing, Inc. has made every effort to identify trademarked properties and owners on this page. All brands and product names used in this document are for identification purposes only and may be trademarks or registered trademarks of their respective companies. The warranties for Motion products are set forth in the express limited warranty statements accompanying such products. Nothing in this document constitutes an additional warranty. The Motion Computing products and services may be covered by one or more patent-protected inventions. Additional patents may also be pending. For more information, see www.motioncomputing.com/info/patents.asp. This product incorporates copy protection technology that is protected by U.S. and foreign patents, including patent numbers 5,315,448 and 6,836,549, and other intellectual property rights. The use of Macrovision's copy protection technology in the product must be authorized by Macrovision. Reverse engineering or disassembly is prohibited. PN 024-02-0156 Revision A07 March 2010 DRAFT 3 Contents English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Symbol Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Product Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Product Mounting and Installation Disclaimer . . . . . . . . . . . . . . . 8 Motion Tablet PC Model CFT-003 Information. . . . . . . . . . . . . . . . 9 Setup Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Basic Personal Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . .10 Tablet PC Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 High Risk and Dangerous Activity Warning . . . . . . . . . . . . . . .11 Clinical Usage Notice (C5 only) . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Tablet PC Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Cabling and Power Cord Precautions . . . . . . . . . . . . . . . . . . . .12 ITE Power Adapter Precautions . . . . . . . . . . . . . . . . . . . . . . . . . .13 Medical Power Adapter Precaution (C5 only) . . . . . . . . . . . . .13 Battery Pack Warnings and Precautions . . . . . . . . . . . . . . . . . .14 Battery Pack Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 Travel Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Component Replacement Precautions . . . . . . . . . . . . . . . . . . .16 Sound Pressure/Volume Notice . . . . . . . . . . . . . . . . . . . . . . . . . .16 Wireless Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Accessory Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Comfort and Health . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Environmental Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Regulatory and Safety Compliance. . . . . . . . . . . . . . . . . . . . . . .19 Federal Communications Commission Notice (USA). . .19 Airline Travel Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 IC notice (Canada only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Conformité Européne (CE) (European Union) . . . . . . . . .26 Radio Frequency Exposure Statement . . . . . . . . . . . . . . . .28 DRAFT 4Contents Wideband Transmission System Radio . . . . . . . . . . . . . . . .28 Laser Safety Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 Wireless Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 Australia/New Zealand (C-Tick) Statements . . . . . . . . . . .31 Australia/New Zealand (A-Tick) Statement . . . . . . . . . . . .31 NOM/NYCE Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 IRAM Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Other Notices and Marks (Tablet PC Model CFT-003 and Docking Station Model TCD001) . . . . . . . . . . . . . . . . . . . . . . . . .35 Medical Grade AC Adapter Notices . . . . . . . . . . . . . . . . . . .35 California Proposition 65 Notice . . . . . . . . . . . . . . . . . . . . . .35 Battery Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 Laser Safety Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 Docking Station (TCD001) Information. . . . . . . . . . . . . . . . . . . . . .36 Setup Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 Clinical Usage Notice (C5 only) . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Basic Personal Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . .37 Docking Station Precautions . . . . .…

Text truncated - open the document above for the full version.

Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 31 of 38 FCC Part 22H/24E Test Report 14 EXHIBIT C - EUT PHOTOGRAPHS 14.1 WWAN Module Front View 14.2 WWAN Module Bottom View Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 32 of 38 FCC Part 22H/24E Test Report 14.3 WWAN Module built into the Host Tablet PC (CFT-003 White) 14.4 Host Tablet PC Front Side View WWAN Module Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 33 of 38 FCC Part 22H/24E Test Report 14.5 Host Tablet PC Back Side View 14.6 Host Tablet PC Right Side View Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 34 of 38 FCC Part 22H/24E Test Report 14.7 Host Tablet PC Left Side View 14.8 Host Tablet PC Bottom Side View Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 35 of 38 FCC Part 22H/24E Test Report 14.9 Battery 14.10 Tablet PC AC/DC Power Adapter

IC ID: 4587A-GOBI2000 FCC ID: N7NGOBI2 LBL P/N: LBL P/N: Template MC-X5 WWAN Label Gobi2000 FCC ID: N7NGOBI2 IC ID: 4587A-GOBI2000 FCC ID: Q3QHSWGOBI2000 FCC ID: Q3QHSWGOBI2000 per ROHS IC ID: 2417C-GOBI2 IC ID: 2417C-GOBI2

IC ID: 4587A-GOBI2000 LBL P/N: LBL P/N: Template MC-X5 WWAN Label Gobi2000 IC ID: 4587A-GOBI2000 FCC ID: Q3QHSWGOBI2000 FCC ID: Q3QHSWGOBI2000 per ROHS

Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 36 of 38 FCC Part 22H/24E Test Report 14.11 WWAN Module Internal Top View 14.12 WWAN Module Internal Bottom View Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 37 of 38 FCC Part 22H/24E Test Report 14.13 Host Tablet PC Internal – Main board Top View 14.14 Host Tablet PC Internal – Main board Bottom View Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 38 of 38 FCC Part 22H/24E Test Report 14.15 Host Tablet PC Internal -LCD Board Assembly (with Antenna) Bottom View ***** END OF REPORT *****

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “*” (Rev.2) SAR EVALUATION REPORT For Motion Computing Incorporated 8601 Ranch Road 2222, Building 2, Austin, TX 78730, USA Report Type: Original Report Product Type: Tablet PC with WWAN Module Test Engineer: Arthur Tie Report Number: R1001201-SAR Report Date: 2010-04-12 Reviewed By: Boni Baniqued EMC/RF Supervisor Prepared By: (84) Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732 9164 FCC ID : Q3QHSWGOBI2000 IC: 4587A-GOBI2000 Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000, IC: 4587A-GOBI2000 Report Number: R1001201-SAR Page 2 of 104 SAR Evaluation Report Summary of Test Results Rule Part(s): FCC §2.1093, IC RSS-102, Issue 4 Test Procedure(s): FCC OET Bulletin 65-C; IEEE 1528-2003 Device Category: Exposure Category: Portable Device General Population/Uncontrolled Exposure Device Type: Tablet PC with WWAN Module Modulation: GMSK/QPSK/WCDMA TX Frequency Range: 824-849 MHz (GPRS 850) 824-849 MHz (CDMA 850) 824-849 MHz (WCDMA-850) 1850-1910 MHz (GPRS 1900) 1850-1910 MHz (CDMA 1900) 1850-1910 MHz (WCDMA-1900) Conducted RF Power: 32.31 dBm (GPRS 850) 24.61 dBm (CDMA 850) 24.13 dBm (WCDMA-850) 29.76 dBm (GPRS 1900) 24.55 dBm (CDMA 1900) 24.48 dBm (WCDMA-1900) Antenna Type(s): Antenna: PIFA Battery Type(s): Li-ion Battery 24 VDC/1.7 A Face-Head Accessories: None 0.222 W/Kg Body Tissue GPRS 850 Band 0.386 W/Kg Body Tissue CDMA 850 Band 0.378 W/Kg Body Tissue WCDMA 850 Band 0.438 W/Kg Body Tissue GPRS 1900 Band 1.470 W/Kg Body Tissue CDMA 1900 Band Max. SAR Level(s) Measured: 1.490 W/Kg Body Tissue WCDMA 1900 Band Tablet PC Embedded WWAN Module Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000, IC: 4587A-GOBI2000 Report Number: R1001201-SAR Page 3 of 104 SAR Evaluation Report TABLE OF CONTENTS REFERENCE, STANDARDS AND GUILDELINES ................................................................................................6 SAR LIMITS.................................................................................................................................................................6 EUT DESCRIPTION ....................................................................................................................................................8 TEST FACILITIES AND ACCREDITATION ..........................................................................................................9 DESCRIPTION OF TEST SYSTEM ........................................................................................................................10 MEASUREMENT SYSTEM DIAGRAM...........................................................................................................................12 DASY4 MEASUREMENT SERVER...............................................................................................................................13 EQUIPMENT LIST AND CALIBRATION .............................................................................................................21 EQUIPMENTS LIST & CALIBRATION INFO...................................................................................................................21 SAR MEASUREMENT SYSTEM VERIFICATION ..............................................................................................22 SYSTEM ACCURACY VERIFICATION...........................................................................................................................22 EUT TEST STRATEGY AND METHODOLOGY .................................................................................................23 TEST POSITIONS FOR DEVICE OPERATING NEXT TO A PERSON’S EAR........................................................................23 CHEEK/TOUCH POSITION...........................................................................................................................................24 EAR/TILT POSITION....................................................................................................................................................24 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS..............................................................................25 SAR EVALUATION PROCEDURE.................................................................................................................................26 THE EVALUATION WAS PERFORMED WITH THE FOLLOWING PROCEDURE: ..................................................................26 DASY4 SAR EVALUATION PROCEDURE...................................................................................................................27 FCC 3G MEASUREMENT PROCEDURES............................................................................................................29 PROCEDURES USED TO ESTABLISH RF SIGNAL FOR SAR ..........................................................................................29 SAR MEASUREMENT CONDITIONS FOR HSDPA DATA DEVICES...............................................................................29 SAR MEASUREMENT RESULTS ...........................................................................................................................33 SAR TEST DATA........................................................................................................................................................33 APPENDIX A – MEASUREMENT UNCERTAINTY............................................................................................36 APPENDIX B – PROBE CALIBRATION CERTIFICA…

Text truncated - open the document above for the full version.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 22H, 24E TEST AND MEASUREMENT REPORT For Motion Computing Incorporated 8601 Ranch Road 2222, Building 2, Austin, TX 78730, USA Report Type: Original Report Product Type: Tablet PC with WWAN Module Test Engineer: Jack Liu Report Number: R1001201-2224 Report Date: 2009-04-07 Reviewed By: Boni Baniqued EMC/RF Supervisor Prepared By: (84) Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732 9164 FCC ID: Q3QHSWGOBI2000 Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 2 of 38 FCC Part 22H/24E Test Report TABLE OF CONTENTS 1 GENERAL INFORMATION.............................................................................................................................. 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................ 4 1.2 MECHANICAL DESCRIPTION........................................................................................................................... 4 1.3 EUT PHOTO.................................................................................................................................................... 5 1.4 OBJECTIVE...................................................................................................................................................... 5 1.5 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................... 5 1.6 TEST METHODOLOGY..................................................................................................................................... 6 1.7 MEASUREMENT UNCERTAINTY...................................................................................................................... 6 1.8 TEST FACILITY............................................................................................................................................... 6 2 SYSTEM TEST CONFIGURATION ................................................................................................................. 7 2.1 JUSTIFICATION................................................................................................................................................ 7 2.2 EUT EXERCISE SOFTWARE............................................................................................................................. 7 2.3 SPECIAL ACCESSORIES................................................................................................................................... 7 2.4 EQUIPMENT MODIFICATIONS.......................................................................................................................... 7 2.5 REMOTE SUPPORT EQUIPMENT....................................................................................................................... 7 2.6 LOCAL SUPPORT EQUIPMENT......................................................................................................................... 7 2.7 EUT INTERNAL CONFIGURATION DETAILS..................................................................................................... 7 2.8 POWER SUPPLY AND LINE FILTERS................................................................................................................. 8 2.9 TEST SETUP BLOCK DIAGRAM FOR RADIATED EMISSIONS TESTS.................................................................. 8 3 SUMMARY OF TEST RESULTS ...................................................................................................................... 9 4 FCC §2.1046, §22.913(A) & §24.232 – RF OUTPUT POWER....................................................................... 10 4.1 APPLICABLE STANDARD...............................................................................................................................10 4.2 TEST PROCEDURE......................................................................................................................................... 10 4.3 BASE STATION SIMULATOR SETTINGS.......................................................................................................... 11 4.4 TEST EQUIPMENT LIST AND DETAILS........................................................................................................... 12 4.5 TEST ENVIRONMENTAL CONDITIONS............................................................................................................ 12 4.6 TEST RESULTS.............................................................................................................................................. 13 5 FCC §2.1047 - MODULATION CHARACTERISTIC................................................................................... 18 5.1 APPLICABLE STANDARD...............................................................................................................................18 6 FCC §2.1049, §22.917, §22.905 & §24.238 - OCCUPIED BANDWIDTH ..................................................... 19 6.1 APPLICABLE STANDARD...............................................................................................................................19 6.2 TEST RESULTS.............................................................................................................................................. 19 7 FCC §2.1051, §22.917 & §24.238(A) - SPURIOUS EMISSIONS AT ANTENNA TERMINALS............... 20 7.…

Text truncated - open the document above for the full version.

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. This report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP*, NIST, or any agency of the Federal Government. * This report may contain data that are not covered by the NVLAP accreditation and are marked with an asterisk “*” (Rev.2) FCC PART 22H, 24E TEST AND MEASUREMENT REPORT For Motion Computing Incorporated 8601 Ranch Road 2222, Building 2, Austin, TX 78730, USA Report Type: Original Report Product Type: Tablet PC with WWAN Module Test Engineer: Jack Liu Report Number: R1001201-2224 Report Date: 2009-04-07 Reviewed By: Boni Baniqued EMC/RF Supervisor Prepared By: (84) Bay Area Compliance Laboratories Corp. 1274 Anvilwood Avenue, Sunnyvale, CA 94089, USA Tel: (408) 732-9162 Fax: (408) 732 9164 FCC ID: Q3QHSWGOBI2000 Motion Computing Incorporated FCC ID: Q3QHSWGOBI2000 Report Number: R1001201-2224 Page 2 of 38 FCC Part 22H/24E Test Report TABLE OF CONTENTS 1 GENERAL INFORMATION.............................................................................................................................. 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT)........................................................................ 4 1.2 MECHANICAL DESCRIPTION........................................................................................................................... 4 1.3 EUT PHOTO.................................................................................................................................................... 5 1.4 OBJECTIVE...................................................................................................................................................... 5 1.5 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................... 5 1.6 TEST METHODOLOGY..................................................................................................................................... 6 1.7 MEASUREMENT UNCERTAINTY...................................................................................................................... 6 1.8 TEST FACILITY............................................................................................................................................... 6 2 SYSTEM TEST CONFIGURATION ................................................................................................................. 7 2.1 JUSTIFICATION................................................................................................................................................ 7 2.2 EUT EXERCISE SOFTWARE............................................................................................................................. 7 2.3 SPECIAL ACCESSORIES................................................................................................................................... 7 2.4 EQUIPMENT MODIFICATIONS.......................................................................................................................... 7 2.5 REMOTE SUPPORT EQUIPMENT....................................................................................................................... 7 2.6 LOCAL SUPPORT EQUIPMENT......................................................................................................................... 7 2.7 EUT INTERNAL CONFIGURATION DETAILS..................................................................................................... 7 2.8 POWER SUPPLY AND LINE FILTERS................................................................................................................. 8 2.9 TEST SETUP BLOCK DIAGRAM FOR RADIATED EMISSIONS TESTS....................…

Text truncated - open the document above for the full version.
