Q3QHWNVWEX720Motion Computing LE1700 Tablet PC

Safety and Regulatory Guide ƒ For Motion Tablet PCs and Accessories Product Safety Information Safety Compliance Notices Regulatory Notices Guide de sécurité et de réglementation ƒ Pour PC tablettes et accessoires Motion Informations relatives à la sécurité du produit Avis de conformité aux normes de sécurité Avis relatifs aux réglementations Sicherheits- und Vorschriftshandbuch ƒ Für Motion Tablet PCs und Zubehör Produktsicherheitshinweise Sicherheitseinhaltungserklärung Vorschriftseinhaltungserklärung ii Table of Contents Patents........................................................................................................................... 1 Motion Computing, Inc. ........................................................................................... 1 Macrovision Corporation ......................................................................................... 1 Product Safety Information ........................................................................................... 1 Product Mounting and Installation Disclaimer......................................................... 1 Basic Personal Safety Precautions............................................................. 2 Environmental .......................................................................................................... 2 Set Up Precautions .......................................................................................... 3 Tablet PC Precautions ..................................................................................... 3 High Risk and Dangerous Activity Warning................................................... 4 Cabling and Power Cord Precautions .............................................................. 4 Power Adapter Precautions ............................................................................. 4 Battery Pack Warnings and Precautions.......................................................... 5 Battery Precautions (Carbon and Alkaline) ..................................................... 6 Battery Warnings (Carbon and Alkaline) ........................................................ 6 Battery Charger Precautions............................................................................ 6 Battery Pack Disposal ..................................................................................... 7 Travel Precautions........................................................................................... 7 Component Replacement Precautions (LE-Series only).................................. 7 Wireless Mini-PCI Devices............................................................................. 8 Accessory Precautions..................................................................................... 8 Motion-Recommended Third-Party Accessories............................................. 8 Comfort and Health .............................................................................................. 9 Regulatory and Safety Compliance ............................................................................... 9 Federal Communications Commission Notice (United States) ................................ 9 Unintentional Emitter per FCC Part 15............................................................. 10 Intentional Emitter per FCC Part 15 ................................................................. 11 Airline Travel Notice ........................................................................................ 15 IC Notice (Canada Only)........................................................................................ 15 Unintentional Emitter per ICES-003................................................................. 15 Intentional Emitter per RSS 210....................................................................... 16 Conformité Européne (CE) (European Union)....................................................... 18 Unintentional Emitter........................................................................................ 18 Intentional Emitter ............................................................................................ 18 Belegië/Belgique............................................................................................... 19 Deutschland...................................................................................................... 19 France............................................................................................................... 19 Italia.................................................................................................................. 20 Nederland......................................................................................................... 20 Wideband Transmission System Radio............................................................. 20 Other Notices and Marks........................................................................................ 21 Battery Notice ................................................................................................... 21 Laser Safety Notice........................................................................................... 21 Wireless Notices ............................................................................................... 21 Saudi Arabian Quality Mark ............................................................................. 21 Internal Bluetooth Module Notice .................................................................... 22 Français ...................................................................................................................... 23 Brevets.........................................................................................................................23 Motion Computing, Inc. ......................................................................................... 23 Macrovision Corporation .......................................................…

Text truncated - open the document above for the full version.

Motion™ LE1700 Tablet PC User’s Guide Windows XP Tablet PC Edition 2005 DRAFT © 2006 Motion Computing, Inc. All rights reserved. This document contains information protected by copyright. No part of this document may be reproduced in any form without written consent from Motion. The information in this document is provided “as is” and is subject to change without notice. Motion is not liable for errors or omissions in this document. Motion, Motion Computing, Speak Anywhere, and View Anywhere are trademarks or registered trademarks of Motion Computing, Inc. in the U.S.A. and other countries. Acrobat is a registered trademark of Adobe Systems Incorporated. Atheros. the Atheros logo, Super G, Super A/G, Wake- on-Wireless, and Wake-on-Theft are registered trademarks of Atheros Communications, Inc. AuthenTec is a registered trademark of AuthenTec, Inc. Bluetooth is a registered trademark owned by the Bluetooth SIG, Inc., U.S.A. and licensed to Motion Computing, Inc. Intel, Intel Inside, the Intel Inside logo, Pentium, Centrino, and PROSet are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Knowles and IntelliSonic are trademarks or registered trademarks of Knowles Acoustics, Inc. Microsoft Windows, Windows XP, Windows XP Tablet PC Edition, and Windows Journal are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. OmniPass is a trademark of Softex, Inc. Realtek is a trademark of Realtek Semiconductor Corporation. SigmaTel is a registered trademark and Universal Jacks is a trademark of SigmaTel Corporation. Wi-Fi is a registered trademark of the Wi-Fi Alliance. End users may not loan, rent, lease, lend, or otherwise transfer the CDs or DVDs provided for recovery purposes to another user, except as permitted in the End User License Agreement for such product. This product incorporates copy protection technology that is protected by U.S. and foreign patents, including patent numbers 5,315,448 and 6,836,549, and other intellectual property rights. The use of Macrovision's copy protection technology in the product must be authorized by Macrovision. Reverse engineering or disassembly is prohibited. Motion Computing, Inc. has made every effort to identify trademarked properties and owners on this page. All brands and product names used in this document are for identification purposes only and may be trademarks or registered trademarks of their respective companies. The warranties for Motion products are set forth in the express limited warranty statements accompanying such products. Nothing in this document constitutes an additional warranty. The Motion Computing products and services may be covered by one or more patent-protected inventions. Additional patents may also be pending. For more information, see www.motioncomputing.com/info/patents.asp. PN 024-02-0118 Revision X00 March 2007 iii Contents Chapter 1Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Finding information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Setting up the LE1700 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Chapter 2Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Pen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 WriteTouch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Front panel buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Status lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Windows Security button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Fingerprint reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 View Anywhere display (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Microphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Ambient light sensor (ALS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Accelerometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Infrared (IrDA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 USB 2.0 ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Headphones port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Microphone port . . . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA RE: Motion Computing LE1700 Series Tablet PC (Model: T006) FCC ID: Q3QHWNVWEX720 IC ID: 4587A-NVWEX720 Authority to Act as Agent to the Federal Communications Commission On our behalf, we Motion Computing Incorporated appoint Intertek Testing Services (an ETL-SEMKO Affiliate) NA, Inc. to act as agent in the preparation of this application for equipment authorization to the Federal Communications Commission. I certify that submitted Exhibits properly describe the device or system for which equipment authorization is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Commission's regulations will have affixed to it a label identical to that submitted for approval with this application. APPLICANT ANTI-DRUG ABUSE CERTIFICATION: In signing this letter, Applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a), or, in the case of a non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. For the definition of a "party" for these purposes, see 47 CFR 1.2002(b). Date: 2/6/07 Agreement expiration date: 3/31/07 By: Contact Name: Don Bobo Contact Title: International Regulatory Compliance Manager Telephone: 512-637-1100 ext. 1149 Applicant Company Name: Motion Computing Incorporated ®

December 4, 2006 ATTN: Reviewing Engineer RE: Motion Computing LE1700 Series Tablet PC (Model: T006) FCC ID: Q3QAWM7519ABG IC ID: 4587A-AWM7519ABG To Whom It May Concern: This letter has been generated to provide the reviewing Engineer the regulatory status for each Radio Frequency Device integrated into the LE1700 Tablet PC. The LE1700 tablet PC can be configured to support up to two RF Devices depending on the customers need. The two configurable RF Devices are Bluetooth and an 802.11 A/G WLAN. The Bluetooth device integrated into the LE1700 is an unmodified module manufactured by Universal Scientific Industrial Company LTD and is registered under FCC ID IXMUB22111S. The Bluetooth module consists of a small (36 x 13.8 mm), 4-layer FR4 PCB with all components mounted on the topside of the board. A majority of these components reside under a stamped metal shielding can; only the antenna matching components lie outside of the can. The module also includes its own integrated printed antenna and is certified for the North America and the EU (CE Mark CE0560!). This device is a Part 15 Spread Spectrum Transmitter operating in frequency bands 2402, 2441, 2480MHz and although the device was integrated and functioning during compliance testing we did not perform testing on this RF device due its low output power (0.0008 Watts). The WM7519A 802.11a/b/g + Super a/g device is an unmodified module manufactured by Accton Technology Corporation part number WM7519A and is registered under FCC ID PPD-AR5BXB6-M. The WM7519A network connection hardware transfers data at speeds of up to 54 Mbps instantaneous data rate over the air between two or more users or between a user and a wired network. The network connection hardware is designed to communicate wirelessly using the 2.4-GHz band (IEEE 802.11b/g compatible WLAN access points (AP) and WLAN clients) or using the 5.0-GHz band (IEEE 802.11a compatible WLAN APs and WLAN clients) and supports automatic switching between the two bands. The network connection hardware is compliant with all the latest IEEE 802.11 standards. The module is based on the PCI Express Mini-Card Electromechanical Rev 1.0 and advanced configuration and power interface (ACPI) 2.0c specifications. The Accton WM7519A (802.11a/b/g + Super a/g) module is based on the Atheros AR5424 chipset, which is an all CMOS, single chip solution for dual-band, multi-mode, IEEE 802.11 a/b/g WAN technology. It integrates a 2.4 and 5.0 –GHz radio, analog to digital and digital to analog converters (ADC/DAC), a baseband processor, multi-protocol media access control (MAC) and a PCI Express interface. It enables a high performance, cost effective, low power, compact solution that fits onto one side of a PCI Express Mini-Card. The PCI Express Mini-Card interface enables a new level of interconnection performance by upgrading the I/O bandwidth from a half-duplex 133MB/s to a full- duplex 250MB/s. The AR5424 implements half-duplex OFDM, CCK and DSSS baseband processing supporting all IEEE 802.11 a/b/g data rates. The AR5424 chipset supports modulation schemes BPSK, QPSK, 16 QAM, 64 QAM, DBPSK, DQPSK, and CCK. The WM7519A module uses the 5.170 to 5.825-GHz ISM frequency bands as defined by the IEEE 802.11a specification and supports channels 34, 36, 38, 40, 42, 44, 46, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 149, 153, 157, 161, 165. Channel support is regulatory Stock-Keeping Unit (SKU) dependent and subject to change. The WM7519A module also uses the 2.412 to 2.497-GHz frequency bands defined by the IEEE 802.11b/g specifications and supports channels 1 through 13. Channel support is regulatory Stock- Keeping Unit (SKU) dependent and subject to change. The WM7519A module supports 802.11e compatible bursting, The WM7519A supports data rates of 6 – 54Mbps (802.11a mode); 1 – 54Mbps (802.11g mode); 1 - 11Mbps (802.11b mode). The LE1700 configured with the WM7519A module only supports the geographic region of North America (US and Canada). In order to comply with the FCC Specific Absorption Rate standard Motion requested Accton to reduce the output power for all channels in the 2.4GHz and 5.0GHz bands (Please refer to Declaration Form provided by Accton Technology Corporation that lists the power settings that will be calibrated into each card prior to delivery to our manufacturing facility). We did not test this configuration for DFS/TPC due to relying on the manufacturers DFS/TPC test report to be used for our submission. Sincerely, Don Bobo Motion Computing Incorporated ® 8601 Ranch Road 2222 Building 2; Austin, TX 78730 512-637-1149 (Direct) 512-637-1199 (Fax) [email protected]

Motion Computing, Inc. 8601 Ranch Road 2222, Building 2, Austin, TX 78730 512-637-1100 (Main); 512-637-1199 (Fax) 1-866-MTABLET (Sales) www.motioncomputing.com February 6, 2007 ATTN: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: Confidentiality Request For: Motion Tablet PC Series LE1700 (Model T006) FCC ID: Q3QHWNVWEX720 Industry Canada ID: 4587A-NVWEX720 To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that all Schematics, Block Diagrams, and Pecos Product Specification for the Motion Tablet PC LE1700 series Model T006 required for submission along with this application be kept from General Public review. The reason for this confidentiality request is due to information requested for this submission contains company proprietary information that could never get into the hands of our competitors of which could pose loss of revenue and possible patent infringements. Please contact me if there is any further information you may need. Sincerely, Don Bobo Motion Computing Incorporated ® 8601 Ranch Road 2222 Building 2; Austin, TX 78730 512-637-1149 (Direct) 512-637-1199 (Fax) [email protected]

2/27/2007 Federal Communications Commission, EQUIPMENT APPROVAL SERVICES, P. O. Box 358315 Pittsburgh, PA 15251-5315 ATTN:Authorization & Evaluation Division PER: 47 CFR 0.457 and 0.459 RE: PKRNVWES720 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission's Rules, the Applicant hereby requests confidential treatment of some of the information accompanying this Application as listed below, i.e. Schematic, Block Diagrams, Theory of Operation, BOM Alignment/Tune-Up Procedures These materials contain trade secrets and proprietary information not customarily released to the public and the public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii) disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this Application. Sincerely, John Spall Staff Engineer, Novatel Wireless

From: Don Bobo [[email protected]] Sent: Wednesday, March 21, 2007 12:53 PM To: Roland Gubisch ES-BOX Cc: Ollie Moyrong ES-MPK; Terre Wolak ES-ATL; David Chernomordik ES-MPK; Krishna Vemuri ES-MPK Subject: RE: FCC ID: Q3QHWNVWEX720 Importance: High Hi Roland, You are correct in that the correct FCC ID for the Novatel Wireless CDMA radio is PKRNVWES720. When I generated the Motion FCC ID I followed the following legend: Q3Q = Motion Grantee Code HW = Hardware NVEX720 = Novatel Wireless Ex720 {Novatel offers the same module for both Sprint and Verizon, so I chose an “x” in front of the module identifier giving me flexibility to support both Verizon or Sprint since the modules are the same but as far as the grants are concerned the FCC ID for each supplier would be PKRNVWES720 = Sprint and PKRNVWV720 = Verizon} Ollie, Can you please update page 3 of the test report to reflect the correct FCC ID for the Novatel Wireless CDMA module and pass a new copy to Roland? Cordially, Don -------------------------------------------------------------------------------- From: Roland Gubisch ES-BOX [mailto:[email protected]] Sent: Wednesday, March 21, 2007 11:17 AM To: Don Bobo Cc: Ollie Moyrong ES-MPK; Terre Wolak ES-ATL Subject: RE: FCC ID: Q3QHWNVWEX720 Importance: High Don, For the sake of the TCB certification of this application, I need to upload to the FCC website the test report on file for the certified radio module, and I am having difficulty identifying the correct device. The test report for Motion Computing FCC ID: Q3QHWNVWEX720 lists on page 3 the internal radio module as: Novatel Communications FCC ID: HWNVWEX720 and "Original application" FCC ID: PKRNVWEX720 These do not match up to any existing FCC Grants, but the problem may be a simple typo. 1) HWN is the Grantee Code for Binfeld Engineering, and not Novatel, according to the FCC website. 2) PKR is the correct Grantee Code for Novatel, but there is no FCC ID: PKRNVWEX720 There IS a grant for FCC ID: PKRNVWES720, which appears to have the identical properties noted in the Form 731. Please confirm that this is the correct module. If so, the test report should be modified to show the correct internal module, and the reference to FCC ID: HWNVWEX720 should be deleted or explained. Thank you, Roland

From: Don Bobo [[email protected]] Sent: Wednesday, March 21, 2007 5:01 PM To: Roland Gubisch ES-BOX Cc: Terre Wolak ES-ATL Subject: RE: FCC ID: Q3QHWNVWEX720 Hi Roland, The current connection manager (carrier connection software) for Sprint does not allow the CDMA/EVDO module to operate at the same time as the 802.11 WLAN module. When you launch the Sprint connection software a dialogue box will pop up telling the user that simultaneous operation is not allowed and the Sprint software application disables the 802.11 module while the CDMA/EVDO module is being used. Once the user disconnects the Module from the carrier and closes the Sprint connection application the 802.11 device is then re-enabled and the CDMA/EVDO module becomes disabled. Thanks, Don -------------------------------------------------------------------------------- From: Roland Gubisch ES-BOX [mailto:[email protected]] Sent: Wednesday, March 21, 2007 3:49 PM To: Don Bobo Cc: Terre Wolak ES-ATL Subject: RE: FCC ID: Q3QHWNVWEX720 Don, Thank you for the clarification. Is it true that the CDMA/EVDO module cannot operate at the same time as the WLAN module? SAR evaluation was not performed with simultaneous operation of these modules. Regards, Roland

LE1700 External pictures LE1700 External pictures LE1700 External pictures LE1700 External pictures

NVWES720 Contains FCC ID: PKRNVWES720

FCC ID: PKRNVWES720 Contains Radio Device: Contains Radio Device: FCC ID: PKRNVWES720

ES720 Bottom View ES720 Top View

Company: Motion Computing Inc. FCC ID: Q3QHWNVWEX720 IC ID: 4587A-NVWEX720 Model(s): T006 Description: Tablet PC with Dual-Band Cellular/PCS CDMA/EV-DO & Bluetooth 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 1 of 58 Date(s) of Evaluation February 02, 05-06, 2007 Test Report Serial No. 010307Q3Q-T803-S24C Report Revision No. Revision 1.1 Test Report Issue Date February 09, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category General Population Certificate No. 2470.01 RF EXPOSURE EVALUATION SPECIFIC ABSORPTION RATE S S S A A A R R R T T T E E E S S S T T T R R R E E E P P P O O O R R R T T T FOR MOTION COMPUTING INC. T006 TABLET PC WITH NOVATEL ES720 DUAL-BAND CDMA/EV-DO AND USI UB2-2111-S BLUETOOTH Test Report Serial No. 010307Q3Q-T803-S24C Test Report Revision No. Revision 1.1 (Model Listing) Revision 1.0 (Initial Release) Test Lab and Location Celltech Compliance Testing & Engineering Lab (Celltech Labs Inc.) 1955 Moss Court Kelowna, BC Canada V1Y 9L3 Test Report Prepared By: Cheri Frangiadakis Test Report Writer Celltech Labs Inc. Test Report Reviewed By: Jonathan Hughes General Manager Celltech Labs Inc. Certificate No. 2470.01 IDENTIFIER(S) FCC ID: Q3QHWNVWEX720 IC: 4587A-NVWEX720 FCC OET Bulletin 65, Supplement C (01-01) FCC OET SAR Measurement Procedures for 3G Devices Test Standard(s) and Procedure(s) Industry Canada RSS-102 Issue 2 Company: Motion Computing Inc. FCC ID: Q3QHWNVWEX720 IC ID: 4587A-NVWEX720 Model(s): T006 Description: Tablet PC with Dual-Band Cellular/PCS CDMA/EV-DO & Bluetooth 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 2 of 58 Date(s) of Evaluation February 02, 05-06, 2007 Test Report Serial No. 010307Q3Q-T803-S24C Report Revision No. Revision 1.1 Test Report Issue Date February 09, 2007 Description of Test(s) Specific Absorption Rate RF Exposure Category General Population Certificate No. 2470.01 Celltech Labs Inc. declares under its sole responsibility that this wireless device was compliant with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6. The device was tested in accordance with the measurement procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), FCC OET SAR Measurement Procedures for 3G Devices and Industry Canada RSS-102 Issue 2 for the General Population / Uncontrolled Exposure environment. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. Test Report Approved By: Sean Johnston SAR Lab Manager Celltech Labs Inc. DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab and Location CELLTECH LABS INCORPORATED Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Tel.: 250-448-7047 e-mail: [email protected] Fax: 250-448-7046 Web site: www.celltechlabs.com Company Information MOTION COMPUTING INCORPORATED 8601 Ranch Road 2222, Building 2 Austin Texas, 78730 United States FCC IDENTIFIER: Q3QHWNVWEX720 IC IDENTIFIER:4587A-NVW EX720 Rule Part(s) Applied: FCC 47 CFR §2.1093 IC Health Canada Safety Code 6 FCC OET Bulletin 65, Supplement C (01-01) OET SAR Measurement Procedures for 3G Devices Test Procedure(s) Applied: IC RSS-102 Issue 2 FCC PCS Licensed Transmitter (PCB) 47 CFR Part 24 Subpart E 2 GHz Personal Communication Services RSS-133 Issue 3 Device Classification(s): IC 800 MHz Cellular Telephones Employing New Technologies RSS-132 Issue 2 Device Model & Description: T006 Tablet PC Internal Transmitter Type: Novatel ES720 Dual-Band CDMA/EV-DO (PCI-Express) CDMA 1xRTT 1xEv-Do Rev. 0 1xEv-DO Rev. A Co-located Transmitter(s): USI UB2-2111-S Bluetooth (Simultaneous Transmission) LCD User Orientation(s): 0 Degrees Landscape -90 Degrees Portrait 1851.25 - 1908.75 MHz PCS CDMA/EV-DO 824.70 - 848.31 MHz Cellular CDMA/EV-DO Transmit Frequency Range(s): 2402 - 2480 MHz Bluetooth -- PCS 24.8 dBm 0.302 Watts Average Conducted EV-DO Rev. 0/A L/M/H Channels Cellular 24.6 dBm 0.288 Watts Average Conducted CDMA 1xRTT Mid Channel Max. RF Output Power Tested: Bluetooth -0.97 dBm 0.8 mW Conducted Specification Mid Channel CDMA/EV-DO External Swivel 100° - Open Position 0° - Closed Position Antenna Type(s) Tested: Bluetooth Internal -- Battery Type(s) Tested: Lithium-ion 14.8 V (P/N: BATEDX20L4) - Standard Lithium-ion 14.8 V (P/N: BATEDX20L8) - Extended 1.32 W/kg 1g average EV-DO Rev. 0 & Bluetooth PCS Band Max. SAR Level(s) Evaluated: 0.651 W/kg1g average CDMA 1xRTT / EV-DO Rev. A Cellular Band Company: Motion Computing Inc. FCC ID: Q3QHWNVWEX720 IC ID: 4587A-NVWEX720 Model(s): T006 Description: Tablet PC with Dual-Band Cellular/PCS CDMA/EV-DO & Bluetooth 2007 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 3 of 58 Date(s) of Evaluation February 02, 05-06, 2007 Test Report Serial No. 010307Q3Q-T803-S24C Report Revision No. Revision…
