Q3QWMIA123AGTablet PC with Atheros card

MOTION COMPUTING LE1600 AND LS800 TABLET PC MICROSOFT WINDOWS XP TABLET PC EDITION 2005 USER GUIDE Motion Computing LE1600 and LS800 Tablet PC User Guide ii Copyright Information Acrobat is a registered trademark of Adobe Systems Incorporated. Atheros. the Atheros logo, Super G, Super A/G, Wake-on-Wireless, and Wake-on-Theft are registered trademarks of Atheros Communications, Inc. AuthenTec is a registered trademark of AuthenTec, Inc. BLUETOOTH is a registered trademark owned by the Bluetooth SIG, Inc., U.S.A. and licensed to Motion Computing, Inc. Intel, Intel Inside, the Intel Inside logo, Pentium, and PROSet are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Knowles and IntelliSonic are trademarks or registered trademarks of Knowles Acoustics, Inc. Microsoft Windows, Windows XP, Windows XP Tablet PC Edition, and Windows Journal are either registered trademarks or trademarks of Microsoft Corporation in the United States and/ or other countries. Motion Computing, Speak Anywhere, and View Anywhere are trademarks or registered trademarks of Motion Computing, Inc. in the U.S. and other countries. OmniPass is a trademark of Softex, Inc. Realtek is a trademark of Realtek Semiconductor Corporation. SigmaTel is a registered trademark and Universal Jacks is a trademark of SigmaTel Corporation. Wi-Fi is a registered trademark of the Wi-Fi Alliance. Motion Computing, Inc. has made every effort to identify trademarked properties and owners on this page. All brands and product names used in this document are for identification purposes only and may be trademarks or registered trademarks of their respective companies. PATENTS: The Motion Computing products and services may be covered by one or more of the following protected inventions. Additional patents may also be pending. US PATENTS: D480,730. OTHER PATENTS: GB3009545, BG3009546, AUS154529, CAN101617, J1188539. For more information, see www.motioncomputing.com/info/patents. NOTICE: The information in this publication is subject to change without notice. MOTION COMPUTING, INC. SHALL NOT BE HELD LIABLE FOR TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN NOR FOR ACCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL. The information contained in this document is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for Motion Products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. This publication contains information protected by copyright. No part of this publication may be photocopied or reproduced in any form without prior written consent from Motion Computing, Inc. © 2005 Motion Computing, Inc. (April 2005) P/N 024-02-00xx Rev. X00 About This User Guide Motion Computing LE1600 and LS800 Tablet PC User Guide iii About This User Guide HOW TO SEARCH T HE PDF D OCUMENTATION You can search for and locate information in this user guide by using the following methods: • In the Bookmark navigation tab (left frame of PDF), select the section of the user guide you want to view. The section opens in the right frame of the PDF window. • In the Table of Contents, click on the section of the user guide you want to open. The section opens in the right frame of the window. • In the tool bar at the top of the PDF window, click the binoculars icon or select the menu Edit > Search, and enter the text describing the topic you want to view, and then tap (click) Search. Narrow your search by selecting the search settings options. • From the menu, select Edit > Find or press Ctrl+F, and type the text describing the topic you want to view, and then tap (click) Next. C AUTIONS, W ARNINGS AND N OTICES The following notices are found in this user guide: WARNING: Text set off in this way indicates that failure to follow directions in the warning could result in bodily harm or loss of life. CAUTION: Text set off in this way indicates that failure to follow directions in the CAUTION could result in damage to the equipment or loss of information. IMPORTANT: Text set off in this way presents information or instructions that should be followed or information of particular interest. NOTE: Text set off in this way presents information or instructions. M ENU ITEMS, B UTTONS, ICONS Menu items, icons, and instructions found in the procedures in this user guide are set apart by capitalizing them exactly as shown on screen. Examples are the Start menu, Dashboard, Tablet and Pen Settings icon, and Apply buttons. W RITING ON THE D ISPLAY Writing on the Motion Tablet PC digitizer display in this user guide refers to any handwritten input using the specially-designed Motion digitizer pen, that is provided. The display responds only to this pen and not to any other type of pen or to a stylus or other device such as those used with personal digital assistants (PDAs). The display surface may be damaged by ink pens or other pointed objects. I NKThe term ink refers to digital ink, i.e., hand-drawn or handwritten input and that can be displayed or converted into text. R EFERENCES TO U SING THE PEN AND P EN FUNCTION B UTTON Notations for using the Motion Digitizer Pen, which are found throughout this user guide, are described below: • Tap — Firmly tap the pen on the Tablet PC display, without pressing the function button on the pen; a tap equals a mouse left-click About This User Guide Motion Computing LE1600 and LS800 Tablet PC User Guide iv • Double-tap — Tap the pen twice on the display, without pressing the function button on the pen • Right-click — Press the function button on the pen and tap the pen on the display (equals a mouse right-click) • Press and hold — Press and hold the tip of the pen to the display with- out pressing the pen function button (equals a mouse right-click) • Tap and drag — T…

Text truncated - open the document above for the full version.

Safety and Regulatory Guide ƒ For Motion Tablet PCs and Accessories Product Safety Information Safety Compliance Notices Regulatory Notices Guide de sécurité et de réglementation ƒ Pour PC tablettes et accessoires Motion Informations relatives à la sécurité du produit Avis de conformité aux normes de sécurité Avis relatifs aux réglementations Sicherheits- und Vorschriftshandbuch ƒ Für Motion Tablet PCs und Zubehör Produktsicherheitshinweise Sicherheitseinhaltungserklärung Vorschriftseinhaltungserklärung ii Product Safety Information Motion TM Tablet PCs and accessories are designed to optimize safety, minimize strain, and withstand the rigors of portability. However, to further reduce the risk of personal injury or damage to the unit, certain precautions should be observed. The information in this document applies to the Motion Computing M-Series, LE-Series, and the LS- Series Tablet PCs unless noted otherwise. Product Mounting and Installation Disclaimer Motion Computing shall not be liable under any theory of liability (including, without limitation, contract, tort or statutory law) for any loss, damage, personal injury, or other damage of any nature (including, without limitation, direct, special, incidental or consequential damages) arising directly or indirectly as a result of improper or inappropriate placement, installation, or use of its products or any other application. In order to safely install and use Motion TM products, full consideration of occupants, systems (e.g., the location of fuel lines, navigation systems, brakes lines, electrical, drive train or other systems), air-bags and other back-up, warning or safety equipment is required. Without limiting the foregoing, Motion TM specifically disclaims any responsibility for the placement, use or installation of its products not consistent with (i) the original manufacturer’s or governmental or regulatory specifications and recommendations for the environment where the products will be placed, used or installed, (ii) Motion TM written product instruction sheets, or (iii) workmanship standards. Basic Personal Safety Precautions ■ Do not attempt to service the Tablet PC nor its components yourself. Perform only those service installations for which Motion provides special instructions, for example, swapping the battery, adding an external battery, changing the hard disk drive (LE-Series and M-Series only), or changing memory modules. See the Motion web site at www.motioncomputing.com for a list of serviceable accessories for your Tablet PC. ■ To avoid personal injury from electric shock or fire: • Completely power down the Tablet PC when replacing memory modules, changing the hard disk drive, cleaning the Tablet PC, its components, or chassis, or performing operations requiring similar steps. To do this, first turn the power off at the power switch, remove the battery, then disconnect the AC adapter from the electrical outlet or from any other type of external power source, such as an external battery • Do not operate the Tablet PC near water, for example, near a bathtub, kitchen sink or laundry tub, in a wet basement, by a swimming pool, or in the rain. The cases, portfolios, and other accessories currently offered by English 1 Motion are not designed to be water resistant nor water tight. Visit the Motion website to see the most current list of accessories. • Do not connect or disconnect any cables or perform maintenance or reconfiguration of this product during an electrical storm. • Avoid using the wired modem or LAN during an electrical storm, as a remote risk of electric shock from lightning exists. • Do not push foreign objects into air vents or other openings of the Tablet PC or accessories, such as the PCA card slots or the optical disk drive bays. Doing so can short out interior components and may cause fire or electric shock. • When installing memory modules, ground yourself by touching a grounded conductive surface, such as a device with a grounded plug. Avoid touching the pins and leads on the memory module or internal circuitry of the Tablet PC. ■ If the Motion battery pack leaks and the fluid get in your eyes, do not rub them. Instead, rinse your eyes with clean running water and immediately seek medical attention. Otherwise, eye injury may result. ■ If acid leaking from the battery pack contacts your skin or clothing, immediately wash it away with running water. Otherwise, skin inflammation can occur. Environmental ■ The extraction and use of natural resources are required in the production of the equipment you purchased. The equipment may contain hazardous substances that could impact health and the environment if not disposed of using environmental disposal systems available in your region. ■ To prevent the dissemination of those substances in our environment and to diminish the impact on the natural resources, we encourage you to use the appropriate take-back environmental disposal systems. Those disposal systems will reuse or recycle most of the materials of your end-life equipment in compliance with current environmental conventions. ■ The crossed-out wheeled bin symbol prompts you to use those environmental disposal systems. ■ If you need more information about collection, disposal, reuse, and recycling systems, please contact your local or regional waste administration. ■ Also, you can contact Motion Computing, Inc. for more information about the environmental processes for our products. English 2 Set Up Precautions ■ When setting up the Tablet PC in the Motion FlexDock for the LE-Series, Motion MobileDock for the LS-Series, Desktop Stand, or Hardtop Keyboard (M-Series only), place it on a level surface so it does not fall over and damage the unit, docking station, keyboard, connectors, or other components. ■ When you move the Tablet PC between environments with very different humidity and/or temperature ranges, allow sufficient time to adjust to the new humidity or temperature. ■ Do not drop the Tablet …

Text truncated - open the document above for the full version.

Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Authority to Act as Agent to the Federal Communications Commission On our behalf, I appoint Nemko USA, Inc. to act as agent in the preparation of this application for equipment authorization to the Federal Communications Commission. I certify that submitted Exhibits properly describe the device or system for which equipment authorization is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Commission's regulations will have affixed to it a label identical to that submitted for approval with this application. APPLICANT ANTI-DRUG ABUSE CERTIFICATION: In signing this letter, Applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a), or, in the case of a non-individual applicant (e.g. corporation, partnership or other unincorporated association), no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. For the definition of a "party" for these purposes, see 47 CFR 1.2002(b). Date: Agreement expiration date: By: Contact Name: Don Bobo Contact Title: International Regulatory Engineer Telephone: 512-637-1149 Applicant Company Name: Motion Computing Inc.

Motion Computing, Inc. 8601 Ranch Road 2222, Building 2, Austin, TX 78730 512-637-1100 (Main); 512-637-1199 (Fax) 1-866-MTABLET (Sales) www.motioncomputing.com December 15, 2004 ATTN: Reviewing Engineer Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 RE: Confidentiality Request For: Motion Tablet PC LS800 Series (Series = LS800 followed by any derivative alpha or numeric suffixes AA-00) Model TS01 FCC ID: Q3QWMIA123AG To Whom It May Concern: This letter serves as an official request for confidentiality under FCC Rule Section 0.459. We have requested that the Schematics, Block Diagrams, Bill of Materials, and the LS800 Product Specification for the Motion Tablet PC LS800 series, model TS01 required for submission along with this application be kept from General Public review. The reason for this confidentiality request is due to information requested for this submission contains company proprietary information that could never get into the hands of our competitors of which could pose loss of revenue and possible patent infringements. Please contact me if there is any further information you may need. Sincerely, Don Bobo 512-637-1149 (Direct) 512-637-1199 (Fax) [email protected]

Page 6 Page 7

LS800 Antenna Locations

© 2006 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. 2867 Progress Place, Suite 4D • Escondido, CA 92029 • U.S.A. TEL (760) 737-3131 • FAX (760) 737-9131 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Motion Computing Dates of Test: March 17-22, 2006 8601 Ranch Road 2222, Building 2 May 22, 2006 Austin, TX 78730 Test Report Number: SAR.20060305 Revision B This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1999 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2003, OET Bulletin 65 Supp. C, RSS-102 and Safety Code 6 (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application has been denied FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Certificate # 2387.01 FCC ID: Q3QWMIA123AG IC Certificate: 4587A-LS800 Model(s): TS01 Test Sample: Engineering Unit Same as Production Unit Serial No.: 202191420 Equipment Type: Tablet PC Classification: Portable Transmitter Next to Body TX Frequency Range: 2412 - 2462 MHz, 5180 - 5240 MHz, 5260 - 5320 MHz, 5745 - 5825 MHz Frequency Tolerance: 2.4 GHz - ± 25 ppm, 5 GHz - ± 20 ppm, BT - ± 75 kHz Maximum RF Output: 2.4 GHz–18 dBm, 5.2 GHz–14 dBm, 5.8 GHz–14 dBm, Bluetooth–4 dBm Conducted Signal Modulation: DSSS/OFDM/Bluetooth Antenna Type (Length): (2) Internal, Part Number DC330018100 Battery: Sanyo Model BATEAX00L Application Type: Certification FCC Rule Parts: Part 15E IC Specification: RSS-102 FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 2 of 244 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Table of Contents 1. Introduction ...........................................................................................................................3 SAR Definition [5]......................................................................................................................3 2. SAR Measurement Setup .....................................................................................................4 Robotic System .........................................................................................................................4 System Hardware .....................................................................................................................4 System Description ...................................................................................................................4 E-Field Probe ALS-E-020 ......................................................................................................... 5 3. Robot Specifications .............................................................................................................7 4. Probe and Dipole Calibration ................................................................................................8 5. Phantom & Simulating Tissue Specifications........................................................................9 SAM Phantom ...........................................................................................................................9 Brain & Muscle Simulating Mixture Characterization ................................................................9 Device Holder ...........................................................................................................................9 6. Definition of Reference Points.............................................................................................10 Ear Reference Point................................................................................................................10 Device Reference Points ........................................................................................................10 7. Test Configuration Positions ...............................................................................................11 Positioning for Cheek/Touch [5] ..............................................................................................11 Positioning for Ear / 15 ̊ Tilt [5]................................................................................................12 Body Worn Configurations ......................................................................................................13 8. ANSI/IEEE C95.1 – 1999 RF Exposure Limits [2]...............................................................14 Uncontrolled Environment.......................................................................................................14 Controlled Environment .......................................................................................................... 14 9. Measurement Uncertainty ...................................................................................................15 10. System Validation ........................................................................................................... 16 Tissue Verification...................................................................................................................16 Test System Verification ......................................................................................................... 17 11. SAR Test Data Summary ................................................................................................18 Procedures Used To Establish Test Signal................................................…

Text truncated - open the document above for the full version.

FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 90 of 244 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Measurement Data Crest Factor : 1 Scan Type : Complete Tissue Temp. : 20.00 °C Ambient Temp. : 22.00 °C Set-up Date : 22-Mar-2006 Set-up Time : 11:11:39 AM Area Scan : 5x5x1 : Measurement x=10mm, y=10mm, z=4mm Zoom Scan : 5x5x8 : Measurement x=8mm, y=8mm, z=4mm Other Data DUT Position : Front Separation : 0 Channel : High - 11 1 gram SAR value : 0.122 W/kg 10 gram SAR value : 0.080 W/kg Area Scan Peak SAR : 0.132 W/kg Zoom Scan Peak SAR : 0.180 W/kg FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 91 of 244 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. SAR Test Report By Operator : Jay Measurement Date : 22-Mar-2006 Starting Time : 22-Mar-2006 10:19:58 AM End Time : 22-Mar-2006 10:33:06 AM Scanning Time : 788 secs Product Data Device Name : Motion Computing Serial No. : 202191420 Type : Other Model : TS01 Frequency : 2450.00 MHz Max. Transmit Pwr : 0.065 W Drift Time : 0 min(s) Length : 228 mm Width : 170 mm Depth : 23 mm Antenna Type : Internal - Aux Orientation : Front Power Drift-Start : 0.768 W/kg Power Drift-Finish: 0.755 W/kg Power Drift (%) : -1.746 Phantom Data Name : APREL-Uni Type : Uni-Phantom Size (mm) : 280 x 280 x 200 Serial No. : System Default Location : Center Description : Uni-Phantom Tissue Data Type : BODY Serial No. : 2450 Frequency : 2450.00 MHz Last Calib. Date : 22-Mar-2006 Temperature : 20.00 °C Ambient Temp. : 22.00 °C Humidity : 45.00 RH% Epsilon : 53.11 F/m Sigma : 1.97 S/m Density : 1000.00 kg/cu. m Probe Data Name : Probe 215 - RFEL Model : E020 Type : E-Field Triangle Serial No. : 215 Last Calib. Date : 10-Jun-2005 Frequency : 2450.00 MHz Duty Cycle Factor: 1 Conversion Factor: 4.6 Probe Sensitivity: 1.20 1.20 1.20 μV/(V/m) 2 Compression Point: 95.00 mV Offset : 1.56 mm FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 92 of 244 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Measurement Data Crest Factor : 1 Scan Type : Complete Tissue Temp. : 20.00 °C Ambient Temp. : 22.00 °C Set-up Date : 22-Mar-2006 Set-up Time : 11:11:39 AM Area Scan : 5x5x1 : Measurement x=10mm, y=10mm, z=4mm Zoom Scan : 5x5x8 : Measurement x=8mm, y=8mm, z=4mm Other Data DUT Position : Front Separation : 0 Channel : Mid - 6 1 gram SAR value : 1.115 W/kg 10 gram SAR value : 0.488 W/kg Area Scan Peak SAR : 1.420 W/kg Zoom Scan Peak SAR : 2.452 W/kg FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 93 of 244 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. SAR Test Report By Operator : Jay Measurement Date : 22-Mar-2006 Starting Time : 22-Mar-2006 09:23:09 AM End Time : 22-Mar-2006 09:44:17 AM Scanning Time : 1268 secs Product Data Device Name : Motion Computing Serial No. : 202191420 Type : Other Model : TS01 Frequency : 2450.00 MHz Max. Transmit Pwr : 0.065 W Drift Time : 0 min(s) Length : 228 mm Width : 170 mm Depth : 23 mm Antenna Type : Internal - Main Orientation : End Power Drift-Start : 0.454 W/kg Power Drift-Finish: 0.442 W/kg Power Drift (%) : -2.522 Phantom Data Name : APREL-Uni Type : Uni-Phantom Size (mm) : 280 x 280 x 200 Serial No. : System Default Location : Center Description : Uni-Phantom Tissue Data Type : BODY Serial No. : 2450 Frequency : 2450.00 MHz Last Calib. Date : 22-Mar-2006 Temperature : 20.00 °C Ambient Temp. : 22.00 °C Humidity : 45.00 RH% Epsilon : 53.11 F/m Sigma : 1.97 S/m Density : 1000.00 kg/cu. m Probe Data Name : Probe 215 - RFEL Model : E020 Type : E-Field Triangle Serial No. : 215 Last Calib. Date : 10-Jun-2005 Frequency : 2450.00 MHz Duty Cycle Factor: 1 Conversion Factor: 4.6 Probe Sensitivity: 1.20 1.20 1.20 μV/(V/m) 2 Compression Point: 95.00 mV Offset : 1.56 mm FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 94 of 244 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Measurement Data Crest Factor : 1 Scan Type : Complete Tissue Temp. : 20.00 °C Ambient Temp. : 22.00 °C Set-up Date : 22-Mar-2006 Set-up Time : 11:11:39 AM Area Scan : 5x5x1 : Measurement x=10mm, y=10mm, z=4mm Zoom Scan : 5x5x8 : Measurement x=8mm, y=8mm, z=4mm Other Data DUT Position : End Separation : 0 Channel : High - 11 1 gram SAR value : 0.456 W/kg 10 gram SAR value : 0.248 W/kg Area Scan Peak SAR : 0.494 W/kg Zoom Scan Peak SAR : 0.830 W/kg FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 95 of 244 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. SAR Test Report By Operator : Jay Measurement Date : 21-Mar-2006 Starting Time : 21-Mar-2006 04:07:01 PM End Time : 21-Mar-2006 04:20:13 PM Scanning Time : 792 secs Product Data Device Name : Motion Computing Serial No. : 202191420 Type : Other Model : TS01 Frequency : 2450.00 MHz Max. Transmit Pwr : 0.065 W Drift Time : 0 min(s) Length : 228 mm Width : 170 mm Depth : 23 mm Antenna Type : Internal - Aux Orientation : End Power Drift-Start : 1.546 W/kg Power Drift-Finish: 1.618 W/kg Power Drift (%) : 4.691 Phantom Data Name : APREL-Uni Type : Uni-Phantom Size (mm) : 280 x 280 x 200 Serial No. : System Default Location : Center Description : Uni-Phantom Tissue Data Type : BODY Serial No. : 2450 Frequency : 2450.00 MHz Last Calib. Date : 21-Mar-2006 Temperature : 20.00 °C Ambient Temp. : 22.00 °C Humidity : 44.00 RH% Epsilon : 51.93 F/m Sigma : 1.96 S/m Density : 1000.00 kg/cu. m Probe Data Name : Probe 215 - RFEL Model : E020 Type : E-Field Triangle Serial No. : 215 Last Calib. Date : 10-Jun-2005 Frequency : 2450.00 MHz Duty Cycle Factor: 1 Conversion Factor: 4.6 Probe Sensitivity: 1.20 1.20 1.20 μV/(V/m) 2 Compression Point: 95.00 mV Offset : 1.56 mm FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 96 of 244 This report shall not be reproduced except in full wit…

Text truncated - open the document above for the full version.

NCL Calibration Laboratories Division of APREL Laboratories. Page 8 of 10 This page has been reviewed for content and attested to on Page 2 of this document. Video Bandwidth Probe Frequency Characteristics -6 -5 -4 -3 -2 -1 0 1 110100100010000 Frequency (Hz) Video Bandwidth at 500 Hz 1 dB Video Bandwidth at 1.02 KHz: 3 dB NCL Calibration Laboratories Division of APREL Laboratories. Page 9 of 10 This page has been reviewed for content and attested to on Page 2 of this document. Conversion Factor Uncertainty Assessment Frequency: 5800MHz Epsilon: 49.6 (+/-5%) Sigma: 6.25 S/m (+/-10%) ConvF Channel X: 2.1 7%(K=2) Channel Y: 2.1 7%(K=2) Channel Z: 2.1 7%(K=2) To minimize the uncertainty calculation all tissue sensitivity values were calculated using a load impedance of 5 MΩ. Boundary Effect: For a distance of 2.4mm the evaluated uncertainty (increase in the probe sensitivity) is less than 2%. NCL Calibration Laboratories Division of APREL Laboratories. Page 10 of 10 This page has been reviewed for content and attested to on Page 2 of this document. Test Equipment The test equipment used during Probe Calibration, manufacturer, model number and, current calibration status are listed and located on the main APREL server R:\NCL\Calibration Equipment\Instrument List May 2005. FCC ID: Q3QWMIA123AG © 2006 RF Exposure Lab, LLC Page 221 of 244 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Appendix E – Dipole Calibration Data Sheets RF Exposure Lab, LLC Calibration File No: CAL.20060203 C E R T I F I C A T E O F C A L I B R A T I O N It is certified that the equipment identified below has been calibrated at RF Exposure Lab, LLC by qualified personnel following recognized procedures and using transfer standards traceable to NRC/NIST. Validation Dipole Manufacturer: APREL Laboratories Part Number: ALS-D-2450-S-2 Frequency: 2.4 GHz Serial No: RFE-278 Manufactured: 20 February 2004 Calibrated: 17 February 2006 Calibrated By: Signature on File Jay Moulton – Technical Manager Approved By: Signature on File Tamara Moulton – Quality Manager 2867 Progress Place, Suite 4D Tel: (760) 737-3131 Escondido, CA 92029 FAX: (760) 737-9131 CAL.20060203 Calibration Results Summary The following results relate to the Calibrated Dipole and should be used as a quick reference for the user. Mechanical Dimensions Length: 51.5 mm Height: 30.5 mm Electrical Specifications Head SWR: 1.0994 U Return Loss: -28.139 dB Impedance: 53.471 Ω System Validation Results Frequency 1 Gram 10 Gram 1.9 GHz 52.920 26.370 Body SWR: 1.1373 U Return Loss: -31.923 dB Impedance: 53.338 Ω System Validation Results Frequency 1 Gram 10 Gram 1.9 GHz 54.230 24.880 © 2006 RF Exposure Lab, LLC Page 2 of 11 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. CAL.20060203 Head Measurement Conditions The measurements were performed in the Uni-Phantom filled with head simulating liquid of the following electrical parameters at 2450 MHz: Relative Dielectricity 39.63 ± 5% Conductivity 1.82 mho/m ± 5% The APREL Laboratories ALSAS system with a dosimetric E-field probe E-020 (SN:215, Conversion factor 4.6 at 2450 MHz) was used for the measurements. The dipole was mounted so that the dipole feed point was positio…

Text truncated - open the document above for the full version.
