Q6KGT83000AAsset tracking and alert device

486 Thomas Jones Way, Exton, PA 19341 800-523-1430 • 610-280-2000 fax: 610-280-2077 • www.3sisecurity.com ESP ® User Instructions Your location has the latest innovation in security – ESP ® , Electronic Satellite Pursuit. Financial institutions use ESP as an apprehension and recovery tool to help combat bank robberies. Q&A – What’s happening? Q: How can I tell if the ESP device is active? A: Whenever the device is removed from the base plate, it automatically turns on and begins silently tracking. Q: How are the police notified about an active device? A: As soon as the ESP device is lifted from the base plate, it begins to transmit information to dispatch and police indicating the device’s location. Q: Is there anything I need to do to maintain the ESP device? A: You only need to remember to keep the device on its base plate at all times, unless handing it out with the other cash during a robbery. Revised 2/10 60-0800-020 Crime Doesn’t Pay with ESP In San Diego, CA, a lone robber enters a bank, taking off with almost $2,000. The teller included the ESP tracking device in with the other cash. As the robber flees, the ESP system automatically notifies local law enforcement and officers are on their way. Within minutes, the suspect is apprehended and police make a full recovery of the money. ESP – it works! About 3SI • 3SI Security Systems has helped protect cash at financial institutions for more than 38 years. • 3SI security products provide confidence to tellers and branch staff in the event of a robbery. • Currently there are more than 170,000 cash security devices installed worldwide! • 3SI’s cash security products have helped recover more than $95 million dollars worldwide! • 3SI’s industry leading customer service group is available toll free at 800-523-1430 to assist you. User Instructions Keep your ESP device on its base plate at all times! • The ESP device rests in the teller’s cash drawer or the vault on a base plate. • This base plate keeps the device turned off and preserves battery life. • If the device accidentally moves off the plate, it will turn on and begin to notify police. • To turn the device off, simply place it back on the base plate. • Never handle or remove the ESP device from the base plate unless giving it to a robber or directed to do so by your Supervisor or Security Officer. • Always transport the ESP device on a base plate in the cash drawer or on a spare base plate. Never hand strapped cash to a customer. It could be an ESP device. Maintenance Information Changing the Cash Strap A new cash strap must be attached while keeping the device in the cash drawer and on the base plate. It is important to keep the ESP device on the base plate at all times because the plate prevents the device from turning on and notifying police. Transporting the ESP Device If the cash drawer is placed in a vault at night, the device must remain on the base plate in the drawer or tray. Always transport and store the drawer in a flat, horizontal position, so the device cannot tilt or fall off its base plate. Battery Maintenance The battery is replaced annually by 3SI. No testing or maintenance is required by you. 3SI recommends that you DO NOT stamp the secure strap on the device. If You Are Robbed Simply remove the device from its base plate and hand it out with the other cash. The device will automatically turn on, notify police and begin silently tracking the robber. It’s that easy!

Model: GT83000 FCC ID: Q6KGT83000A IC ID: 5043A‐GT83000A

Model: GT83000 FCC ID: Q6KGT83000A IC ID: 5043A‐GT83000A

Prediction of MPE This device is to be used only for fixed and mobile applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all the persons and must not be co-located or operating in conjunction with any other antenna or transmitter. The table below is excerpted from Table 1B of 47 CFR 1.1310 titled Limits for Maximum Permissible Exposure (MPE), Limits for General Population/Uncontrolled Exposure: Frequency Range (MHz) Power density (mW/cm 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /1500 30 1500 – 100.000 1.0 30 Based on the above table the limits are: For 850 MHz frequency band device: 0.57 mW/cm 2 For 1900 MHz frequency band device: 1 mW/cm 2 § 2.1091: The limit for 850 MHz mobile operations where no routine evaluation is required is: 1.5W ERP The limit for 1700 / 1900 MHz mobile operations where no routine evaluation is required is: 3W EIRP Max permissive power according to §24.232 : 2W EIRP Max permissive power according to §§22.913 (a): 7W ERP Using the equation from page 19 of OET Bulletin 65, Edition 97-01: 2 4R PG S π = where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Compliance with MPE limits can be guaranteed as the calculation below shows: 850 MHz frequency band Maximum output power considerations: Mode Maximum conducted output power (dBm) Maximum conducted output power (mW) Duty cycle Equivalent conducted output power (Maximum conducted output power x duty cycle) (mW) GPRS 31.8 dBm 1514 25% 378 EDGE 25% WCDMA 100% HSDPA 100% HSUPA 100% P Maximum power input to the antenna:378 mW R Distance: 20 cm S MPE limit for uncontrolled exposure: 0,57 mW/cm 2 G 1 Antenna gain (dBi) to comply with MPE limits: 7.6 dBi ERP power limit according to §2.1091: 1,5 W ERP G 2 Antenna gain (dBi) to comply with ERP limits: 6.4 dBi (ERP = Equivalent conducted output power x Antenna gain / 1,64) ERP power limit according to §22.913: 7 W ERP G 3 Antenna gain (dBi) to comply with ERP limits: 7.5 dBi (ERP = Maximum conducted output power x Antenna gain / 1,64) G 850 MHz band Min (G 1 , G 2, G 3 ) 6.4 dBi Therefore the maximum antenna gain for mobile operation to comply with MPE and ERP limits shall not exceed 6.4 dBi. Max EIRP is 31.8 dBm or 1514 mW S = 1514 mW / 4π(20cm) 2 S = 0.301 mW/cm 2 Device complies with MPE limits. 1900 MHz frequency band Maximum output power considerations: Mode Maximum conducted output power (dBm) Maximum conducted output power (mW) Duty cycle Equivalent conducted output power (Maximum conducted output power x duty cycle) (mW) GPRS 29.4 871 25% 218 EDGE 25% WCDMA 100% HSDPA 100% HSUPA 100% P Maximum power input to the antenna: 218 mW R Distance: 20 cm S MPE limit for uncontrolled exposure: 1 mW/cm 2 G 1 Antenna gain (dBi) to comply with MPE limits: 23.0 dBi EIRP power limit according to §2.1091: 3 W EIRP G 2 Antenna gain (dBi) to comply with ERP limits: 13.7 dBi (EIRP = Equivalent conductedoutput power x Antenna gain ) ERP power limit according to §24.232: 2 W EIRP G 3 Antenna gain (dBi) to comply with ERP limits: 2.2 dBi (ERP = Maximum conducted output power x Antenna gain) G 1900 MHz band Min (G 1 , G 2, G 3 ) 2.2 dBi Therefore the maximum antenna gain for mobile operation to comply with MPE and ERP limits shall not exceed 2.2 dBi. Max EIRP is 29.4 dBm or 871 mW S = 871 mW / 4π(20cm) 2 S = 0.173 mW/cm 2 Device complies with MPE limits. Signed, Christopher Torio EMC Test Engineer 2011-04-26

Bluetooth Qualification Test Facility (BQTF) FCC listed: A2LA Accredited IC recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road Š Milpitas, CA 95035 Š U.S.A. Phone: + 1 (408) 586 6200 Š Fax: + 1 (408) 586 6299 Š E-mail: [email protected] Š http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2113686 Board of Directors: Dr. Harald Ansorge, Dr. Klaus Matkey, Hans Peter May V2.0 2009-10-30 The BLUETOOTH trademarks are owned by Bluetooth SIG, Inc., U.S.A. and licensed to CETECOM Inc. © Copyright by CETECOM FCC Test Report FOR: Model Name: GT83000 FCC ID: Q6KGT83000A 47 CFR Part 90 RSS-119 Issue 10 TEST REPORT #: EMC_3SISE_003_10001_FCC90 DATE: 2011-05-10 Test Report #: EMC_ 3SISE_003_10001_FCC90_Rev3 Date of Report : 2011-05-10 Page 2 of 27 TABLE OF CONTENTS 1 Assessment _____________________________________________________________________ 4 2 Administrative Data _____________________________________________________________ 5 2.1 Identification of the Testing Laboratory Issuing the EMC Test Report _____________________ 5 2.2 Identification of the Client __________________________________________________________ 5 2.3 Identification of the Manufacturer ___________________________________________________ 5 3 Equipment under Test (EUT) ______________________________________________________ 6 3.1 Specification of the Equipment under Test_____________________________________________ 6 3.2 Identification of the Equipment Under Test (EUT) ______________________________________ 7 3.3 Identification of Accessory equipment ________________________________________________ 7 4 Subject Of Investigation __________________________________________________________ 8 5 Measurements __________________________________________________________________ 9 5.1 Radiated Measurement Procedure ___________________________________________________ 9 5.1.1 Conducted Output Power Measurement procedure _____________________________________________ 10 5.2 Maximum Peak Output Power _____________________________________________________ 11 5.2.1 References: ____________________________________________________________________________ 11 5.2.2 Limits ________________________________________________________________________________ 11 5.2.3 Test Conditions: ________________________________________________________________________ 11 5.2.4 Test Result: ____________________________________________________________________________ 11 5.2.5 Test Plot ______________________________________________________________________________ 11 5.3 99% Occupied Bandwidth _________________________________________________________ 13 5.3.1 References: ____________________________________________________________________________ 13 5.3.2 Limits: ________________________________________________________________________________ 13 5.3.3 Test Result: ____________________________________________________________________________ 13 5.3.4 Test Data/plots: _________________________________________________________________________ 14 5.4 Modulation Characteristics ________________________________________________________ 16 5.5 Transmit Spectrum Mask__________________________________________________________ 16 5.5.1 References: ____________________________________________________________________________ 16 5.5.2 Limits: ________________________________________________________________________________ 16 5.5.3 Test Plot ______________________________________________________________________________ 16 5.6 Frequency Tolerance _____________________________________________________________ 18 5.6.1 References: ____________________________________________________________________________ 18 5.6.2 Limits: ________________________________________________________________________________ 18 5.6.3 Results: _______________________________________________________________________________ 18 5.7 Transmitter Spurious Emissions- Conducted__________________________________________ 19 5.7.1 References: ____________________________________________________________________________ 19 5.7.2 Limits ________________________________________________________________________________ 19 5.7.3 Test data/ plots: _________________________________________________________________________ 19 5.8 Transmitter Spurious Emissions- Radiated ___________________________________________ 20 5.8.1 References _____________________________________________________________________________ 20 5.8.2 Test Result: ____________________________________________________________________________ 20 Test Report #: EMC_ 3SISE_003_10001_FCC90_Rev3 Date of Report : 2011-05-10 Page 3 of 27 5.9 Reciever Spurious Emissions- Radiated ______________________________________________ 22 5.9.1 References _____________________________________________________________________________ 22 5.9.2 Test Result: ____________________________________________________________________________ 22 6 Test Equipment and Ancillaries used for tests ________________________________________ 24 7 BLOCK DIAGRAMS ___________________________________________________________ 25 8 Revision History _______________________________________________________________ 27 Test Report #: EMC_ 3SISE_003_10001_FCC90_Rev3 Date of Report : 2011-05-10 Page 4 of 27 1 Assessment The following device was tested against the applicable criteria specified in FCC rules Parts 90 of Title 47 of the Code of Federal Regulations and Industry Canada Standards RSS 119 Issue 10 and no deviations were ascertained during the course of the tests performed. Company Description Model # 3SI Security Systems Asset tracking and alert devices GT83000 This report is reviewed by: 2011-05-10 Compliance Sajay Jose (Test Lab Manager) Date Section Name Signature Responsible for the Report: 2011-05-10 Compliance Christopher Torio (EMC Test Engineer) Date Section Name Signature The test results of this test report relate exclusively to the test item specified in Section3. CETECO…
