Q6M3SDSST-24MWireless Modem Module

DSST-24M Wireless Modem Module Introduction DSST-24M is a spread spectrum radio modem with TTL. It is designed for data acquisition and control application between host and remote sensors. It is also useful for those applications, the cable wire is inconvenient to be installed. The DSST-24M can be used in not only peer to peer mode but also multi-point structure. Based on direct sequence spread spectrum and RF technology operating In ISM bands. The Frequency Range is 2410.496MHz~2471.936MHz. The Channel Spacing is 4.096MHz. Specification ƒ Frequency Range: 2.4GHz (2410.496MHz ~ 2471.936MHz) ƒ Channel Spacing: 4.096MHz ƒ Radio technique: Direct sequence spread spectrum ƒ Number of channel: 16 ƒ Number of PN code: 16 ƒ Communication distance: Depend on external antenna, default is 300M ƒ Setting Method: Software setting ƒ Antenna: Can bend ƒ Antenna Connector : Reverse-Polarity SMA-Jack ƒ Data bit error rateè Antenna: < 1/1000@ -102dBm ƒ Input voltage: 5Vdc ƒ Operating temperature: -10 o C~50 o C ƒ Operating humility: 0~90% DSST-24M SETTING PIN A1,A2,A3,A4=FREQUENCY SETTING,(PIN A1 IS LSB,PIN A4 IS MSB) SHORT=0 OPEN=1 STEP=2.048MHz CH1 =2410.496 MHz CH6=2420.736 MHz CH10=2428.928 MHz PIN P7SHORT=PASSIVE OPEN=ACTIVE SET6,SET7OPERATING MODE SETTING CONNECT PIN FUNCTION: P1=+5Vin, P2=GND, P3=DATA IN, P4=DATA OUT, P5=DSR, P6=GND NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: † Reorient or relocate the receiving antenna. † Increase the separation between the equipment and receiver. † Connect the equipment into an outlet on a circuit different from that to which the receiver is needed. † Consult the dealer or an experienced radio/TV technician for help. CAUTION: 1. To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. 2. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users. For laptop installations, the antenna must be installed to ensure that the proper spacing is maintained in the event the users places the device in their lap during use (i.e. positioning of antennas must be placed in the upper portion of the LCD panel only to ensure 20 cm will be maintained if the user places the device in their lap for use) and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as the 2 conditions above are met, further transmitter testing will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in devices where the antenna may be installed such that 20 cm may be maintained between the antenna and users (for example access points, routers, wireless ASDL modems, certain laptop configurations, and similar equipment). The final end product must be labeled in a visible area with the following: "Contains TX FCC ID: Q6M3SDSST-24M". RF Exposure Manual Information That Must be Included The users manual for end users must include the following information in a prominent location "IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter." Additional Information That Must be Provided to OEM Integrators The end user should NOT be provided any instructions on how to remove or install the device.

FCC ID: Q6M3SDSST-24M Date: Mar. 25, 2005 Modular Approval Request Letter Dear Sir, There’s a Wireless modem module that would like to have your authorization as a modular approval. The specific product as below, Wireless modem module, with its designed features and specified description, meets special requirements for full modular approval on FCC Public Notice DA 00-1407 by cross-reference list below. Company : ICP Das Co., Ltd. Model Name : Wireless modem Model Number : DSST-24M FCC ID : Q6M3SDSST-24M Requirement of Public Notice DA00-1407 Reference to DSST-24M 1. The modular transmitter must have its own RF shielding. The module has its own RF shielding. Please see external photo.pdf 2. The modular transmitter must have buffered modulation/data inputs. The modular has buffered data inputs, it is integrated in chip W9310. Please see diagram.pdf 3. The modular transmitter must have its own power supply regulation. All power lines derived from the host device are regulated before energizing other circuits internal to the DSST-24M. Please see circuit.pdf 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The DSST-24M meets the FCC antenna requirements. It has a unique connector. Please see external photo.pdf 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. The DSST-24M was tested in a stand-alone configuration via at extended li ne connect to channel control panel. Please see spurious set-up photo.pdf 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. The label position of DSST-24M is clearly indicated. Please see the label.pdf 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The DSST-24M is compliant with all applicable FCC rules. Detail instructions are given in the Users Manual. Please see Installation guide.pdf 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). The DSST-24M comply with applicable RF exposure requirements. Please see RF safety evaluation. pdf Yours sincerely, Jerry Liu Supervisor Intertek Testing Service Taiwan Ltd.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 9, 2005 RE: ICP Das Co., LTD. FCC ID: Q6M3SDSST-24M I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) Please provide a detailed Block Diagram of the RF module/ RF section. 2.) The upper frequency listed on Form 731 is specified as 2441.216MHz. This does not match the Test Report. Please confirm the correct frequency range and modify the Form 731 if needed. 3.) If this module is intended to be used inside a notebook computer or any device which draws power from AC mains, then AC Conducted emissions testing must be performed. Otherwise the Grant will limit operations of this Module to battery operated systems only. Please advise. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Photo 1: External photo of EUT DSST-24M Photo 2: External photo of EUT DSST-24M Photo 3: External photo of EUT Antenna Connector Connector Type: SMA Reverse DSST-24M

Photo 1: External photo of EUT DSST-24M Photo 2: External photo of EUT DSST-24M

Label location

Photo 1: Internal photo of EUT DSST-24M Photo 2: Internal photo of EUT DSST-24M Photo 3: Internal photo of EUT DSST-24M Photo 4: Internal photo of EUT DSST-24M Photo 5: Internal photo of EUT DSST-24M Photo 6: Internal photo of EUT DSST-24M Photo 7: Internal photo of EUT DSST-24M Photo 8: Internal photo of EUT DSST-24M Photo 9: Internal photo of EUT Antenna DSST-24M

FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 1 of 5 Marx Yan Maximum Permissible Exposure (MPE) Evaluation Report Report No. : EME-050073 Model No. : DSST-24M Issued Date : Sep. 15, 2004 Applicant : ICP Das Co., Ltd. No. 111, Kuangfu No. Rd., Hukou Shiang, Hsinchu, Taiwan Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 5 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result in this report only applies to the tested sample. Project Engineer Reviewed By Jerry Liu FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 2 of 5 Table of Contents Summary of Tests.........................................................................................................3 1. Introduction..............................................................................................................4 2. RF Exposure Limit....................................................................................................4 3. RF Exposure calculations..........................................................................................5 4. Test results................................................................................................................5 FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 3 of 5 Summary of Tests MPE Evaluation meet FCC OET No. 65: 1997/ IEEE C95.1-1999 Wireless Modem -Model: DSST-24M FCC ID: Q6M3SDSST-24M Test Reference Results MPE Evaluation FCC Guidelines for Human Exposure IEEE C95.1 Complies FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 4 of 5 1. Introduction The EUT operates in the 2.4GHz ISM band. The EUT (antenna included) is compliant with modular approval and the normal operation distance (after installing in other device, such as router or access point), 20cm from the human body; therefore, the EUT is defined as a Mobile Device. The reason to do the MPE Evaluation is to avoid the RF hazard to human body. The maximum output power and gain of the antenna were used to calculate the limited Power density (S) at 20cm distance away from the product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A) Limits for Occupational / Control Exposures 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 (B) Limits for General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 F= Frequency in MHz FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 5 of 5 3. RF Exposure calculations From § FCC 1.1310 table 1, the maximum permissible RF exposure for an uncontrolled environment is 1mW/(cm 2 ) Power density (S) is calculated by the following formula: S = (P * G)/4πR 2 where, S = Power density (mW/cm 2 ) P = Output power to antenna (mW) R = Distance between radiating structure and observation point (cm) G = Gain of antenna in numeric π = 3.1416 Example: Assume a mobile device operates at 2412MHz and its maximum output power is 50mW, and the maximum gain of antenna is 1 (numeric) /0dBi. then the power density (S) = (50 * 1)/4*π*20 2 = 0.00995 (mW/cm 2 ) 4. Test results Channel Channel Frequency (MHz) Maximum antenna gain (numeric) Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 1 2410.496 2.15 42.27 0.02682 1.0 8 2439.168 2.15 45.50 0.02385 1.0 16 2471.936 2.15 61.66 0.03940 1.0 The Notice in Installation Manual has been stated as below: While installing and operating this transmitter, the radio frequency exposure limit of 1mW/(cm*cm) may be exceeded at distances close to the transmitter. therefore, the user must maintain a minimum distance of 20 cm from the device at all time.

FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 1 of 32 Marx Yan EMC TEST REPORT Report No. : EME-050043 Model No. : DSST-24M Issued Date : Mar. 25, 2005 Applicant : ICP Das Co., Ltd. No. 111, Kuangfu N. Rd., Hukou Shiang, Hsinchu, Taiwan Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 32 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). Project Engineer Reviewed By Jerry Liu FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 2 of 32 Table of Contents Summary of Tests..........................................................................................................4 1. General information..................................................................................................5 1.1 Identification of the EUT.....................................................................................5 1.2 Additional information about the EUT.................................................................5 1.3 Antenna description.............................................................................................6 1.4 Peripherals equipment..........................................................................................6 2. Test specifications.....................................................................................................7 2.1 Test standard........................................................................................................7 2.2 Operation mode...................................................................................................7 2.3 Test equipment.....................................................................................................8 3. Minimum 6dB Bandwidth test...................................................................................9 3.1 Operating environment........................................................................................9 3.2 Test setup & procedure........................................................................................9 3.3 Measured data of Minimum 6dB Bandwidth test results......................................9 4. Maximum Output Power test...................................................................................13 4.1 Operating environment......................................................................................13 4.2 Test setup & procedure......................................................................................13 4.3 Measured data of Maximum Output Power test results.......................................13 5. Radiated Emission test.............................................................................................14 5.1 Operating environment......................................................................................14 5.2 Test setup & procedure......................................................................................14 5.3 Emission limits..................................................................................................15 5.4 Radiated spurious emission test data..................................................................16 5.4.1 Measurement results: frequencies equal to or less than 1 GHz.........................16 5.4.2 Measurement results: frequency above 1GHz.................................................17 6. Power Spectrum Density test...................................................................................20 6.1 Operating environment......................................................................................20 6.2 Test setup & procedure......................................................................................20 6.3 Measured data of Power Spectrum Density test results.......................................20 7. Emission on the band edge §FCC 15.247(C)............................................................24 7.1 Band-edge (Radiated method)............................................................................25 FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 3 of 32 8. Power Line Conducted Emission test §FCC 15.207.................................................29 8.1 Operating environment......................................................................................29 8.2 Test setup & procedure......................................................................................29 8.3 Emission limit...................................................................................................30 8.4 Uncertainty of Conducted Emission...................................................................30 8.5 Power Line Conducted Emission test data..........................................................31 FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 4 of 32 Summary of Tests Wireless Modem-Model: DSST-24M FCC ID: Q6M3SDSST-24M Test Reference Results Minimum 6dB Bandwidth test 15.247(a)(2) Complies Maximum Output Power test 15.247(b) Complies Radiated Spurious Emission test 15.205, 15.209 Complies Power Spectrum Density test 15.247(d) Complies Power Line Conducted Emission test 15.207 Complies FCC ID. : Q6M3SDSST-24M Report No.: EME-050043 Page 5 of 32 1. General information 1.1 Identification of the EUT Applicant : ICP Das Co., Ltd. Product : Wireless Modem Model No. : DSST-24M FCC ID. : Q6M3SDSST-24M Frequency Range : 2410.496MHz ~ 2471.936MHz Channel Number : 16 channels Frequency of Each Channel : 2410.496+4.096n, n=0~15 Type of Modulation : GFSK Rated Power : 5Vdc for RF module Power Cord : N/A Sample Received : Jan. 12, 2005 Test Date(s) : Jan. 12, 2005 ~ Mar. 25, 2005 A FCC DoC report has been generated for the client. 1.2 Additional information about t…

Text truncated - open the document above for the full version.

Photo 1: Conducted Emission Test Set-up DSST-24M Photo 2: Conducted Emission Test Set-up DSST-24M

Photo 1: Radiated Emission Test Set-up DSST-24 M Photo 2: Radiated Emission Test Set-up DSST-24 M
