Linksys Regulatory Information LINKSYS MAX-STREAM AC2600 MU-MIMO GIGABIT ROUTER Model# EA8100 V2 Table of Contents Wireless Regulatory Information FCC Statement FCC Radiation Exposure Statement Innovation, Science and Economic Development Canada Statement Innovation, Science and Economic Development Canada Radiation Exposure Statement Restrictions in the 5 GHz Band Additional requirements for the band 5600-5650 MHz Avis d’Innovation, Sciences et Développement économique Canada Avis d’Innovation, Sciences et Développement économique Canada concernant l’exposition aux radiofréquences Restrictions dans la bande 5 GHz Prescriptions supplémentaires pour la bande 5600-5650 MHz Wireless Disclaimer Avis de non-responsabilité concernant les appareils sans fil NCC 警語 限用物質含有情況標示聲明 Safety Notices EU Declaration of Conformity National Restrictions Antenna Restrictions Third-Party Software or Firmware EU Radiation Exposure Statement WEEE Information User Information for Consumer Products Covered by EU Directive 2012/19/EU on Waste Electric and Electronic Equipment (WEEE) Wireless Regulatory Information FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the equipment and devices • Connect the equipment to an outlet other than the receiver’s • Consult a dealer or an experienced radio/TV technician for assistance FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. 2.4GHz operation of this product in the USA is firmware-limited to channels 1 through 11. The device for the band 5150-5250 MHz is only for indoor usage. FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 35 cm between the radiator and your body.This device and it’s antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in ac- cordance with FCC multi-transmitter product procedures. Innovation, Science and Economic Development Canada Statement CAN ICES-3 (B)/NMB-3 (B) The device complies with ISED’s lincense-exempt RSS standards. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible. The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure. Note that this is not intended to prohibit transmission of control or signaling information or the use of repetitive codes where required by the technology. Innovation, Science and Economic Development Canada Radiation Exposure Statement This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 35 cm between the radiator & your body. This device and it’s antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with ISED multi-transmitter product procedures. Restrictions in the 5 GHz Band The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems. This device has been designed to operate with an antenna having a maximum net gain of 0.94 dBi and 1.44 dBi at 2.4 GHz and 5 GHz respectively. Antenna having a higher gain is strictly prohibited per regulations of ISED. The required antenna impedance is 50 ohms. The maximum antenna gain (Please see the table below) permitted (for devices in the bands 5250-5350 MHz and 5470- 5725 MHz) to comply with the EIRP limit and the maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complites with EIRP limits specified for point to point and non-point-to-point operation as appropriate because high power radars are allocated as primary users (meaning they have priority) in 5250- 5350 MHz and 5650-5850 MHz, these radars could cause interference and/or damage to license exempt LAN devices. No. Antenna Type For 2.4 GHz Net Gain (dBi) For 5 GHz Net Gain (dBi) Antenna Connector 1 Dipole 0.38 0.78 I-PEX (MHF) 2 Dipole 0.63 0.96 I-PEX (MHF) 3 Dipole 0.64 0.84 I-PEX (MHF) 4 Dipole 0.94 1.44 I-PEX (MHF) Additional requirements for the band 5600-5650 MHz Until further notice, devices subject to this Section shall not be capable of transmitting in the band 5600-5650 MHz, so that Environment Canada weather radars operating in this band are protected. Avis d’Innovation, Sciences et Développement économique Canada CAN ICES-3 (B)/NMB-3 (B…
