Q87-E2000Dual-Band Wireless-N Gigabit Router

USER GUIDE Dual-Band Wireless-N Gigabit Router Model: WRT320N E2000 About This Guide i Dual-Band Wireless-N Gigabit Router About This Guide Icon Descriptions While reading through the User Guide you may see various icons that call attention to specific items. Below is a description of these icons: NOTE: This check mark indicates that there is a note of interest and is something that you should pay special attention to while using the product. WARNING: This exclamation point indicates that there is a caution or warning and it is something that could damage your property or product. WEB: This globe icon indicates a noteworthy website address or e-mail address. Online Resources Website addresses in this document are listed without http:// in front of the address because most current web browsers do not require it. If you use an older web browser, you may have to add http:// in front of the web address. ResourceWebsite Linksyswww.linksys.com Linksys International www.linksys.com/international Glossarywww.linksys.com/glossary Network Securitywww.linksys.com/security Copyright and Trademarks Linksys, Cisco and the Cisco Logo are registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2009 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders. Table of Contents ii Dual-Band Wireless-N Gigabit Router Chapter 1: Product Overview 4 Front Panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Back Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Placement Positions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Chapter 2: Wireless Security Checklist 6 General Network Security Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Additional Security Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Chapter 3: Advanced Con!guration 7 Setup > Basic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Setup > DDNS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Setup > MAC Address Clone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Setup > Advanced Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Wireless > Basic Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Wireless > Wireless Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Wireless > Wireless MAC Filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Wireless > Advanced Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 Security > Firewall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Security > VPN Passthrough . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Access Restrictions > Internet Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Applications and Gaming > Single Port Forwarding. . . . . . . . . . . . . . . . . . . . . . . .20 Applications and Gaming > Port Range Forwarding . . . . . . . . . . . . . . . . . . . . . . .21 Applications & Gaming > Port Range Triggering . . . . . . . . . . . . . . . . . . . . . . . . . .21 Applications and Gaming > DMZ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Applications and Gaming > QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Administration > Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Administration > Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Administration > Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Administration > Factory Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Administration > Firmware Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Status > Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Status > Local Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 Status > Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Appendix A: Troubleshooting 29 Appendix B: Speci!cations 30 Appendix C: Warranty Information 31 Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 Exclusions and Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 Obtaining Warranty Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31 Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 Table of Contents iii Dual-Band Wireless-N Gigabit Router Appendix D: Regulatory Information 33 FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 FCC Radiation Exposure Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Safety Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Industry Canada Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Restrictions in the 5 GHz Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Avis d’Industrie Canada. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 Restrictions dans la bande 5 GHz. . . . . . . . . .…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT

(Fig. 1) FCC ID: Q87-E2000 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. Label

Page 2 Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Adapter: EA0121WAA Page 9 Page 10 Adapter: MU12-G120100-A1 Page 11

FCC ID: Q87-E2000 Report No. : RF971120H03D Technical Description This device is a Dual-Band Wireless-N Gigabit Router operates in both the 5GHz and 2.4GHz Bands with DSSS and OFDM technique. The transmitter rate could be 11Mbps for 11b; 54Mbps for 11a/g; 130Mbps for Draft 802.11n (20MHz); 270Mbps for Draft 802.11n (40MHz). The transmitter of the EUT is powered from power adapter. NOTE: 1. There are three antennas provided to this EUT, please refer to the following table: Antenna Gain Transmitter / Circuit For 2.4GHz Gain (dBi) For 5.15~ 5.25GHz Gain (dBi) For 5.725~ 5.850GHz Gain (dBi) Antenna Type Connector Chain(0)J9 2.0 4.3 5.6 PIFA UFL Chain(1)J14 4.5 5.6 4.9 PIFA UFL Chain(2)J10 4.2 4.4 4.5 PIFA UFL 2. The EUT incorporates a MIMO function with draft 802.11n. Physically, the EUT provides two completed transmitters and three completed receivers. 3. The EUT is 2 * 3 spatial MIMO (2Tx & 3Rx) without beam forming function. The antenna configurations are two transmitter antennas and three receiver antennas, as there are 3 PIFA antennas. Spatial multiplexing modes for simultaneous transmission using 2 antennas, and for simultaneous receiver using 3 antennas. The 11a and 11bg legacy mode is limited to single transmitter only. 4. When the EUT operating in draft 802.11n, the software operation, which is defined by manufacturer, MCS (Modulation and Coding Schemes) from 0 to 15. 5. The EUT complies with draft 802.11n standards and backwards compatible with 802. 11a, 802.11b, 802.11g products. 6. The above EUT information was declared by manufacturer and for more detailed features description, please refer to the manufacturer's specifications or user's manual. FCC ID: Q87-E2000 Report No. : RF971120H03D FCC 15.407(c) states : The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of hoe this requirement is met. Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SE971120H03D 1 Report Format Version 3.0.0 RF EXPOSURE REPORT REPORT NO.: SA971120H03D MODEL NO.: E2000 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617(USA) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan Report No.: SE971120H03D 2 Report Format Version 3.0.0 RF Exposure Measurement 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500 ... ... F/300 6 1500-100,000 ... ... 5 6 (B)Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 6 1500-100,000 ... ... 1.0 30 F = Frequency in MHz Report No.: SE971120H03D 3 Report Format Version 3.0.0 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/cm 2 . If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device Report No.: SE971120H03D 4 Report Format Version 3.0.0 6. Test Results 6.1 Antenna Gain There are three antennas provided to this EUT, please refer to the following table: Antenna Gain Transmitter / Circuit For 2.4GHz Gain (dBi) For 5.15~ 5.25GHz Gain (dBi) For 5.725~ 5.850GHz Gain (dBi) Antenna Type Connector Chain(0)J9 2.0 4.3 5.6 PIFA UFL Chain(1)J14 4.5 5.6 4.9 PIFA UFL Chain(2)J10 4.2 4.4 4.5 PIFA UFL Report No.: SE971120H03D 5 Report Format Version 3.0.0 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: For 15.247(2.4GHz) : For Part 802.11b: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 120.20 0.038 1.0 6 2437 154.9 0.049 1.0 11 2462 114.8 0.036 1.0 For Part 802.11g: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 229.1 0.072 1.0 6 2437 302.0 0.095 1.0 11 2462 204.0 0.064 1.0 DRAFT 802.11n (20MHz) OFDM Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2412 376.8 0.211 1.0 6 2437 625.6 0.351 1.0 11 2462 381.0 0.214 1.0 DRAFT 802.11n (40MHz) OFDM Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 2422 249.1 0.140 1.0 4 2437 663.0 0.372 1.0 7 2452 252.1 0.141 1.0 Report No.: SE971120H03D 6 Report Format Version 3.0.0 For 15.247(5GHz) : For Part 802.11a: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5745 218.8 0.158 1.0 3 5785 166.0 0.120 1.0 5 5825 223.9 0.162 1.0 For DRAFT 802.11n (20MHz) OFDM: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5745 350.2 0.253 1.0 3 5785 337.6 0.244 1.0 5 5825 375.2 0.271 1.0 DRAFT 802.11n (40MHz) OFDM Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5755 352.1 0.254 1.0 2 5795 387.8 0.280 1.0 Report No.: SE971120H03D 7 Report Format Version 3.0.0 For 15.407(5GHz) : For Part 802.11a: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5180 22.4 0.012 1.0 2 5200 24.0 0.013 1.0 4 5240 26.9 0.014 1.0 For DRAFT 802.11n (20MHz) OFDM: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5180 26.7 0.019 1.0 2 5200 27.0 0.020 1.0 4 5240 25.5 0.018 1.0 DRAFT 802.11n (40MHz) OFDM Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1 5190 37.9 0.027 1.0 2 5230 49.1 0.035 1.0

Report No.: RF971120H03D 1 Report Format Version 3.0.0 FCC TEST REPORT (15.247) REPORT NO.: RF971120H03D MODEL NO.: E2000 RECEIVED: Nov. 20, 2008 TESTED: Dec. 22 to 23, 2008 & April 16 to 17, 2009 ISSUED: Dec. 18, 2009 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617(USA) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch TEST LOCATION: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 177 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF971120H03D 2 Report Format Version 3.0.0 Table of Contents 1. CERTIFICATION....................................................................................................6 2. SUMMARY OF TEST RESULTS............................................................................7 2.1 MEASUREMENT UNCERTAINTY..........................................................................9 3. GENERAL INFORMATION...................................................................................10 3.1 GENERAL DESCRIPTION OF EUT.....................................................................10 3.2 DESCRIPTION OF TEST MODES.......................................................................13 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.......................14 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................18 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................19 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................20 4. TEST TYPES AND RESULTS (802.11B & G, 2400 ~ 2483.5MHZ BAND).............22 4.1 CONDUCTED EMISSION MEASUREMENT........................................................22 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................22 4.1.2 TEST INSTRUMENTS..........................................................................................22 4.1.3 TEST PROCEDURES..........................................................................................23 4.1.4 DEVIATION FROM TEST STANDARD.................................................................23 4.1.5 TEST SETUP.......................................................................................................24 4.1.6 EUT OPERATING CONDITIONS.........................................................................25 4.1.7 TEST RESULTS-ADAPTER 1..............................................................................26 4.1.8 TEST RESULTS-ADAPTER 2..............................................................................28 4.2 RADIATED EMISSION MEASUREMENT.............................................................30 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................30 4.2.2 TEST INSTRUMENTS..........................................................................................31 4.2.3 TEST PROCEDURES..........................................................................................33 4.2.4 DEVIATION FROM TEST STANDARD.................................................................33 4.2.5 TEST SETUP.......................................................................................................34 4.2.6 EUT OPERATING CONDITIONS.........................................................................35 BELOW 1GHZ TEST DATA..............................................................................................36 4.2.7 TEST RESULTS-ADAPTER 1..............................................................................36 4.2.8 TEST RESULTS-ADAPTER 2..............................................................................37 ABOVE 1GHZ TEST DATA..............................................................................................38 4.2.9 TEST RESULTS...................................................................................................38 4.3 6DB BANDWIDTH MEASUREMENT...................................................................66 4.3.1 LIMITS OF 6DB BANDWIDTH MEASUREMENT.................................................66 4.3.2 TEST INSTRUMENTS..........................................................................................66 4.3.3 TEST PROCEDURE.............................................................................................67 4.3.4 DEVIATION FROM TEST STANDARD.................................................................67 4.3.5 TEST SETUP.......................................................................................................67 4.3.6 EUT OPERATING CONDITIONS.........................................................................67 Report No.: RF971120H03D 3 Report Format Version 3.0.0 4.3.7 TEST RESULTS...................................................................................................68 4.4 MAXIMUM PEAK OUTPUT POWER....................................................................80 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.....................80 4.4.2 INSTRUMENTS....................................................................................................80 4.4.3 TEST PROCEDURES..........................................................................................81 4.4.4 DEVIATION FROM TEST STANDARD.................................................................81 4.4.5 TEST SETUP.......................................................................................................81 4.4.6 EUT OPERATING CONDITIONS.........................................................................81 4.4.7 TEST RESULTS....................…

Text truncated - open the document above for the full version.

Report No.: RF971120H03D-1 1 Report Format Version 3.0.0 FCC TEST REPORT (15.407) REPORT NO.: RF971120H03D-1 MODEL NO.: E2000 RECEIVED: Nov. 20, 2008 TESTED: Dec. 22 to 23, 2008 & April 16 to 17, 2009 ISSUED: Dec. 18, 2009 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617(USA) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch TEST LOCATION: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 117 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF971120H03D-1 2 Report Format Version 3.0.0 Table of Contents 1. CERTIFICATION....................................................................................................4 2. SUMMARY OF TEST RESULTS............................................................................5 2.1 MEASUREMENT UNCERTAINTY.............................................................................6 3. GENERAL INFORMATION.....................................................................................7 3.1 GENERAL DESCRIPTION OF EUT.......................................................................7 3.2 DESCRIPTION OF TEST MODES.......................................................................10 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.......................11 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.......................................14 3.4 DESCRIPTION OF SUPPORT UNITS..................................................................15 3.5 CONFIGURATION OF SYSTEM UNDER TEST...................................................16 4. TEST TYPES AND RESULTS..............................................................................18 4.1 CONDUCTED EMISSION MEASUREMENT........................................................18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT......................................18 4.1.2 TEST INSTRUMENTS..........................................................................................18 4.1.3 TEST PROCEDURES..........................................................................................19 4.1.4 DEVIATION FROM TEST STANDARD.................................................................19 4.1.5 TEST SETUP.......................................................................................................20 4.1.6 EUT OPERATING CONDITIONS.........................................................................21 4.1.7 TEST RESULTS-ADAPTER 1..............................................................................22 4.1.8 TEST RESULTS-ADAPTER 2..............................................................................24 4.2 RADIATED EMISSION MEASUREMENT.............................................................26 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...........................................26 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS..........27 4.2.3 TEST INSTRUMENTS..........................................................................................28 4.2.4 TEST PROCEDURES..........................................................................................30 4.2.5 DEVIATION FROM TEST STANDARD.................................................................30 4.2.6 TEST SETUP.......................................................................................................31 4.2.7 EUT OPERATING CONDITION............................................................................31 BELOW 1GHZ TEST DATA..............................................................................................32 4.2.8 TEST RESULTS-ADAPTER 1..............................................................................32 4.2.9 TEST RESULTS-ADAPTER 2..............................................................................33 ABOVE 1GHZ TEST DATA..............................................................................................34 4.2.10 TEST RESULTS...................................................................................................34 4.3 PEAK TRANSMIT POWER MEASUREMENT......................................................54 4.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT....................................54 4.3.2 TEST INSTRUMENTS..........................................................................................54 4.3.3 TEST PROCEDURE.............................................................................................55 4.3.4 DEVIATION FROM TEST STANDARD.................................................................55 4.3.5 TEST SETUP.......................................................................................................55 Report No.: RF971120H03D-1 3 Report Format Version 3.0.0 4.3.6 EUT OPERATING CONDITIONS.........................................................................55 4.3.7 TEST RESULTS...................................................................................................56 4.4 PEAK POWER EXCURSION MEASUREMENT...................................................75 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT.................................75 4.4.2 TEST INSTRUMENTS..........................................................................................75 4.4.3 TEST PROCEDURE.............................................................................................76 4.4.4 DEVIATION FROM TEST STANDARD.................................................................76 4.4.5 TEST SETUP.......................................................................................................76 4.4.6 EUT OPERATING CONDITIONS................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 971120H03 971120H03 2 RADIATED EMISSION TEST 971120H03 971120H03
