Regulatory Information EA4500V3 Table of Contents Table of Contents Wireless Regulatory Information FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 Mexico Regulatory Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 EAC Mark of Conformity for Russia, Kazakhstan and Belarus . . . . . . . . . . 1 Avis d’Industrie Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Safety Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Declaration of Conformity with Regard to EU Directive 1999/5/EC (R&TTE Directive) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Wireless Equipment (Wireless-AC/N/G/A/B Products) . . . . . . . . . . . . . . . 8 National Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Product Usage Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Technical Documents on www .linksys .com . . . . . . . . . . . . . . . . . . . . . .9 WEEE Information User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste Electric and Electronic Equipment (WEEE) . . . . . . 10 1 Wireless Regulatory Information Wireless Regulatory Information FCC Statement This device complies with Part 15 of the FCC Rules . Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation . This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules . These limits are designed to provide reasonable protection against harmful interference in a residential installation . This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications . However, there is no guarantee that interference will not occur in a particular installation . If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna •Increase the separation between the equipment and devices •Connect the equipment to an outlet other than the receiver’s •Consult a dealer or an experienced radio/TV technician for assistance FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment . IEEE 802 .11b or 802 .11g operation of this product in the USA is firmware-limited to channels 1 through 11 . Mexico Regulatory Statement La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operación no deseada . EAC Mark of Conformity for Russia, Kazakhstan and Belarus FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment . This equipment should be installed and operated with minimum distance 27 cm between the radiator and your body . This device and it’s antennas(s) must not be co- located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures . Industry Canada Statement CAN ICES-3 (B)/NMB-3 (B) Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device . For product available in the USA/Canada market, only channel 1~11 can be operated . Selection of other channels is not possible . The device could automatically discontinue transmission in case of absence of information to transmit, or operational failure . Note that this is not intended to prohibit transmission of control or signaling information or the use of repetitive codes where required by the technology . Industry Canada Radiation Exposure Statement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment . This equipment should be installed and operated with minimum distance 27 cm between the radiator & your body . This device and it’s antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with IC multi- transmitter product procedures . Restrictions in the 5 GHz Band The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co-channel mobile satellite systems . This device has been designed to operate with an antenna having a maximum gain of 3 .57 dBi and 3 .90 dBi at 2 .4 GHz and 5 GHz respectively . Antenna having a higher gain is strictly prohibited per regulations of Industry Canada . The required antenna impedance is 50 ohms . The maximum antenna gain (Please see the table below) permitted (for devices in the bands 5250-5350 MHz and 5470-5725 MHz) to comply with the EIRP limit and because high power radars are allocated as primary users (meaning they have priority) in 5250-5350 MHz and 2 5650-5850 MHz, these radars could cause interference and/or damage to license exempt LAN devices . No. Antenna Type For 2.4 GHz Gain (dBi) For 5 GHz Gain (dBi) Antenna Connector 1PIFA2 .98 Band 1: 3 .18 Band 4: 2 .46 U .FL 2PIFA3 .56 Band 1: 2 .67 Band 4: 3 .88 U .FL 3PIFA3 .57 Band 1: 3 .19 Band 4: 3 .90 U .FL Additional requirements for the band 5600-5650 MHz Until further notice, devices subject to this Section shall not be capable of transmitting in the band 5600- 5650 MHz, so that Envir…

Text truncated - open the document above for the full version.

FRONT COVER Product Overview EA4500 V3 1 Setting Up: Basics Where to find more help 3 How to install your router 3 How to configure your router 4 How to connect to Linksys Smart Wi-Fi 4 How to connect directly to your router 5 How to improve your wireless connection speed 5 How to change your network’s name and password 5 How to change your router’s local access password 6 How to change your router’s time zone 6 How to test your Internet connection speed 7 How to connect devices to your network 7 How to connect a computer to your network 7 How to connect a USB printer 7 How to connect other devices 8 How to view device details 9 How to set up parental controls 10 How to set parental controls 10 How to configure your guest network 11 How to back up your router configuration 12 How to customize Linksys Smart Wi-Fi 12 Using widgets 12 Customizing the Device List 12 Using an External Drive Overview 13 How to attach a USB drive 13 How to use secured folder access 13 How to set up authorized users and shared folders 13 How to access shared folders 15 How to set up your router as a media server 15 How to connect your UPnP device to the media server 16 How to remotely access storage 16 Setting Up: Advanced How to manually set up your router 18 How to manually set up your Internet connection 18 How to associate multiple routers with your Linksys Smart Wi-Fi account 19 How to get the most out of your dual-band router 20 How to control access to your network 20 How to improve security using the built-in firewall 20 How to set up the DHCP server on your router 22 How to set up DHCP reservation 22 How to access your network on the Internet 23 How to clone a MAC address 24 How to connect to your corporate office using a VPN 24 How to optimize your router for gaming and voice 25 How to enable Voice over IP on your network 26 How to configure UPnP 27 How to use a router as an access point 27 How to put your new router behind an existing router 29 How to add your router to an existing router or gateway 29 How to share an Internet connection 29 How to extend your network 30 How to expose a device to the Internet 31 Port Forwarding and Port Triggering How to set up port forwarding 33 How to set up port forwarding for a single port 33 How to set up port forwarding for multiple ports 33 How to set up port forwarding for a range of ports 34 How to set up port range triggering for online gaming 35 Maintaining and Monitoring How to back up and restore your router configuration 36 How to upgrade the router’s firmware 36 How to restore factory defaults 37 How to check the status of your router 37 How to disable the Ethernet port status lights 38 How to test your Internet connection 38 How to configure and use logs 39 Troubleshooting Your router was not successfully set up 40 Your Internet cable is not plugged in message 40 Cannot access your router message 41 After setup 42 The Internet appears to be unavailable 42 Linksys Smart Wi-Fi does not open in your web browser 43 You cannot access Linksys Smart Wi-Fi 43 All other troubleshooting has been unsuccessful 43 Specifications Linksys EA4500 V3 44 Product Overview EA4500 V3 Front/top view Main green LED Back view  Ethernet ports — Connect Ethernet cables to these blue gigabit (10/100/1000) ports, and to wired devices on your network. NOTE For best performance, use CAT5E or higher rated cables on the Ethernet ports.  INTERNET port — Connect an Ethernet cable to this yellow gigabit (10/100/1000) port, and to a broadband Internet cable/DSL or fiber modem. NOTE For best performance, use CAT5E or higher rated cables on the Ethernet ports.  Wi-Fi Protected Setup™ button — Press to configure wireless security on Wi-Fi Protected Setup-enabled network devices.   USB 2.0 port — Connect and share USB drives on your network or on the Internet. Reset button — Press and hold for 10 seconds (until the power LED starts flashing) to reset the router to factory settings. You can also restore the factory settings using Linksys Smart Wi-Fi on the Internet or mobile app.  Power port — Connect the included AC power adapter.  Power switch — Press to turn on the router (European only). Top view Setting Up: Basics Where to find more help In addition to this User Guide, you can find help at these locations: Linksys.com/support/EA4500 V3 (documentation, downloads, FAQs, technical support, live chat, forums) Linksys Smart Wi-Fi help (connect to Linksys Smart Wi-Fi , then click Help at the top of the screen) How to install your router 1. If replacing an existing router, disconnect that router first. 2. Unplug and plug in your modem before connecting your new router. 3. Plug in your router to a power source. 4. Connect the Internet cable from your modem to the yellow Internet port on your router. Wait until the power light on the front of the router is solid. 5. Connect to the secure wireless name shown in the Quick Start Guide that came with your router. (You can change the network name and password later.) If you need help connecting to the network refer to your device documentation on the provided CD. Note: You will not have Internet access until router setup is complete. 6. Open a web browser to launch the Linksys Smart Wi-Fi Router setup instructions. If you don’t see the instructions, type linksyssmartwifi.com in the address bar. At the end of setup, follow the on-screen instructions to set up your Linksys Smart Wi-Fi account. Use Linksys Smart Wi-Fi to configure your router from any computer with an Internet connection. Manage your router’s settings: Change your router’s name and password Set up guest access Configure parental controls Connect devices to your network Test your Internet connection speed NOTE: As part of the router setup process, you will be sent a verification e-mail. From your home network, click the link in the e-mail to associate your router with the Linksys Smart Wi-Fi account. TIP: Print this page, then record your router and account settings in the table bel…

Text truncated - open the document above for the full version.

Date: 2015-01-29 Subject: Ad Hoc Mode Function Declaration FCC ID: Q87-EA4500V3 To Whom it may concern, This device is operating on 2.4GHz band (Channel 1 ~ 11) & 5GHz (Band 1 & 4) and not able to work on non-US frequencies. Please contact the one signed below or the authorized agent for this filing. Thank you. Regards, ----------------------------------- Daniel Wesey / Director of Global Requlatory Compliance Tel: 310-751-2816 E-mail: [email protected]

Date: 2015-01-29 FCC ID: Q87-EA4500V3 A U T H O R I Z A T I O N L E T T E R To whom it may concern: We, the undersigned, hereby authorize (name: Amanda Wu and Title: Senior Specialist)of Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (BV CPS Taoyuan) of Taiwan to act on our behalf in all manners relating to FCC application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by (name: Amanda Wu and Title: Senior Specialist) of BV CPS Taoyuan on our behalf shall have the same effect as acts of our own. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ----------------------------------- Daniel Wesey / Director of Global Requlatory Compliance Tel: 310-751-2816 E-mail: [email protected]

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: 1/28/2015 Subject: Request for Confidentiality FCC ID: Q87-EA4500V3 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation Operational Description (Software Operating Description) Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204,while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 2015/4/30. External Photos Internal Photos User Manual Test Setup photos It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Sincerely yours, Digitally signed by Daniel Wesey DN: cn=Daniel Wesey, o=Belkin Inc.,, ou=Regulatory Compliance, [email protected], c=US Date: 2015.01.29 18:11:19 ‐08'00' Daniel Wesey / Director of Global Requlatory Compliance Tel: 310-751-2816 E-mail: [email protected] Daniel Wesey

Report No.: 141027E05 Page 1 CONSTRUCTION PHOTOS OF EUT Main source Report No.: 141027E05 Page 2 Second source Report No.: 141027E05 Page 3 Adapter: IU24-2120200-WP Report No.: 141027E05 Page 4 Report No.: 141027E05 Page 5 Report No.: 141027E05 Page 6 Adapter: MU24-Y120200-A1 Report No.: 141027E05 Page 7 Adapter: PSA24R-120 Report No.: 141027E05 Page 8 Report No.: 141027E05 Page 9 Report No.: 141027E05 Page 10 Adapter: PSAC24A-120 Report No.: 141027E05 Page 11

REVAPPROVEDDATE REV SIZE DWG TITLE DWG NO. SCALESHEET REV A4A4 1/1 1 OF 1 SANDY CHEN RELEASE TO FILE DESCRIPTION REVISIONS PART NUMBER BLOCK PART NUMBER 4L-SAQ1L13-004 8830-21607 A00 A A 11/07/14 SAQ1-L1 WNC PROPRIETARY 20 Park Avenue II, Hsinchu Science Park, Hsinchu 308, Taiwan, R.O.C. Tel: 886-3-6667799 Fax: 886-3-5788726 11/07/14 11/07/14 11/07/14 HSINYUN LIN HSINYUN LIN SANDY CHEN LABEL, EU, PRODUCT, EA4500V3, SAQ1-L1 WNC: 4L-SAQ1L13-004 A 33.5 30.5 BLACK PANTONE 8402 C NOTES: 1. MATERIAL: WHITE PET, 75#, (t=0.075 mm) ADHESIVE: 壓克力背膠 ACRYLIC ADHESIVE with GLASSINE RELEASE PAPER FINISH: 上霧 MATTE PET, 25#, (t=0.025 mm) 2. COLOR: a. 底色印刷 PANTONE 8402 C b. 文字印刷 BLACK 3. TEMPERATURE RESISTANT= 85 0 C 4. 捲狀出貨 BELKIN WNC BELKIN: 8830-21607 A00 (Fig.1) FCC ID: Q87-EA4500V3 Label FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device.

Report No.: 141027E05 Page 1 CONSTRUCTION PHOTOS OF EUT Main source Report No.: 141027E05 Page 2 Report No.: 141027E05 Page 3 Report No.: 141027E05 Page 4 Report No.: 141027E05 Page 5 Second source Report No.: 141027E05 Page 6 Report No.: 141027E05 Page 7 Report No.: 141027E05 Page 8 Report No.: 141027E05 Page 9

Report No.: SA141027E05 Page No. 1 / 9 Report Format Version: 5.0.1 RF Exposure Report Report No.: SA141027E05 FCC ID: Q87-EA4500V3 Test Model: EA4500 V3 Received Date: Oct. 27, 2014 Test Date: Jan. 12, 2015 Issued Date: Jan. 29, 2015 Applicant: Linksys LLC Address: 121 Theory Drive Irvine California 92617 United States Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory Lab Address: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. Test Location (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. Report No.: SA141027E05 Page No. 2 / 9 Report Format Version: 5.0.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure Limit ................................................................................................................................ 5 3 MPE calculation Formula ..................................................................................................................... 5 4 Classification ......................................................................................................................................... 5 5 Antenna Gain ......................................................................................................................................... 6 6 Calculation Result Of Maximum Conducted Power .......................................................................... 7 Report No.: SA141027E05 Page No. 3 / 9 Report Format Version: 5.0.1 Release Control Record Issue No. Description Date Issued SA141027E05 Original release. Jan. 29, 2015 Report No.: SA141027E05 Page No. 4 / 9 Report Format Version: 5.0.1 1 Certificate of Conformity Product: 802.11 a/b/g/nAP Brand: Linksys Test Model: EA4500 V3 Sample Status: ENGINEERING SAMPLE Applicant: Linksys LLC Test Date: Jan. 12, 2015 Standards: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date:Jan. 29, 2015 Elsie Hsu / Specialist Approved by : , Date:Jan. 29, 2015 May Chen / Manager Report No.: SA141027E05 Page No. 5 / 9 Report Format Version: 5.0.1 2 RF Exposure Limit Limits For Maximum Permissible Exposure (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3 MPE calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4 Classification The antenna of this product, under normal use condition, is at least 27cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA141027E05 Page No. 6 / 9 Report Format Version: 5.0.1 5 Antenna Gain 1. The antennas provided to the EUT, please refer to the following table: 2.4GHz antenna No. Transmitter Circuit Brand Model Gain (dBi) (Include cable loss) Frequency range (GHz to GHz) Antenna Type Connecter Type 1 0 WNC 57EAAH15.0CH 2.98 2.4~2.4835 PIFA NA 3 1 WNC 57EAAH15.0CJ 3.26 2.4~2.4835 PIFA NA 6 2 WNC 57EAAH15.0CK 3.57 2.4~2.4835 PIFA NA 5GHz antenna No. Transmitter Circuit Brand Model Gain (dBi) (Include cable loss) Frequency range (GHz to GHz) Antenna Type Connecter Type 2 0 WNC 57EAAH15.0CL 3.18 5.15~5.25 PIFA i-pex(MHF) 2.46 5.725~5.850 PIFA i-pex(MHF) 4 1 WNC 57EAAH15.0CM 2.67 5.15~5.25 PIFA i-pex(MHF) 3.88 5.725~5.850 PIFA i-pex(MHF) 5 2 WNC 57EAAH15.0CN 3.19 5.15~5.25 PIFA i-pex(MHF) 3.90 5.725~5.850 PIFA i-pex(MHF) Report No.: SA141027E05 Page No. 7 / 9 Report Format Version: 5.0.1 6 Calculation Result Of Maximum Conducted Power For 15.247(2.4GHz): 802.11b FREQUENCY (MHz) CONDUCTED POWER (mW) ANTENNA GAIN (dBi) DISTANCE (c…
