Draft: 10/25/2010 1 MINO HD WiFi (Jenner) USER GUIDE – ENGLISH SOURCE TEXT FOR USA PANEL 1 MINO HD WIRELESS QUICK START GUIDE VISUALS Set Up Wireless 1. Plug your video camera into your computer to instal l FlipShare software and setup wireless sharing features. (For instructions on installing FlipShare, see User Guide.) 2. Follow prompts in the FlipShare installation to: a. Add your email and phone contacts b. Link to your social networking accounts (e.g. Faceb ook) c. Authenticate your Flipshare.com sharing account d. Setup your wireless network(s) PANEL 2 LIVE STREAMING (Note: if you have not yet setup your wireless netw ork in FlipShare, please do so before attempting Live Streaming.) Connect • Press (sharing button image) to enable wireless sh aring • Press + and – to choose a wireless network, if one is not automatically selected follow steps from “Network Setup” Select • Press < and > to select Live Streaming • Press + and – to select a sharing recipient such a s email address, social media site, or FlipShare.com Share • Press (red record button) to begin recording video and streaming live to your video recipient • Press (red record button) to stop recording and end live streaming session PANEL 3 INSTANT SHARE (Note: if you have not yet setup your wireless netw ork in FlipShare, please do so before attempting Instant Share.) Connect • Press (sharing button image) to enable wireless in stant share • Press + and – to choose a wireless network, if one is not automatically selected follow steps from “Network Setup” Select • Press < and > to select Instant Share • Press < and > to view previous/next video to select which video you would like to share • Press + and – to select a sharing recipient such as an email add ress, Draft: 10/25/2010 2 social media site or Flipshare.com Share • Press (play button) to begin the Instant Share uplo ad PANEL 4 NETWORK SETUP Press and hold the (share button) and (red record b utton) at the same time to enter network setup. To add a new network (network name is visible): Pre ss + or – to select the network name from the list • Press the <, >, +, - to select letters from the ons creen keyboard, if a network password is required • Press (play button) to log onto the network To add a new network (network name does not appear) : • Press the (share button) to enter the network name • Press the <, >, +, - to select letters from the ons creen keyboard to enter the network name • Press + or – to select the type of network password required • Press the <, >, +, - to select letters from the ons creen keyboard, if a network password is required • Press (play button) to log onto the network PANEL 1 MINO HD USER GUIDE PANEL 2 Get Started Welcome to Flip Mino HD ™ 1 Press power button to turn on. Video camera setting s appear automatically when you first power on. Note: Video camera is shipped with a partially char ged battery. If battery is not charged, simply follow the steps in the Recharge Ba ttery section. Set Language • Use + - to select your language. Set Date • Use + - to adjust the current setting. • Use < > to select month/day/year. Set Time • Use + - to adjust the current setting. • Use < > to select hour/minute/am/pm. Tones • Use < > to turn the tones on and off. Draft: 10/25/2010 3 Recording Light • Use < > to turn the recording light on and off. To Return to Video Camera Setup Later Starting with the video camera OFF: 1 Press power button to turn on. 2 When Flip Video logo appears, press and hold record button until Select a Language appears. PANEL 3 Record and Play Touch-Sensitive Buttons Gently touch lighted icons with your finger to acti vate the controls on the back panel. Record Videos 1 Press to start/stop recording . 2 Press and hold + - to zoom in/out during recording. Play Videos 1 Press to play/pause. Press and hold to play all vi deos. 2 Press and hold + - to increase/decrease volume. 3 Press < > to view previous/next video. Note: Press and hold < > during playback to rewind/fast-forward. Deleting Videos 1 Press button. Select YES to confirm. Note: Delete button is locked when you first power on. To unlock, press and hold delete button. PANEL 4 Connect to Computer 1 Slide USB latch down. USB arm flips up automaticall y. 2 Connect USB arm to computer’s USB port. 3 The battery pack will begin recharging and you can install FlipShare™ software on your computer. Recharge Battery 1 Slide USB latch down. USB arm flips up automatical ly. 2 Connect USB arm to computer’s USB port. 3 Recording light turns on to indicate charging. When charged, the recording light turns off. • The video camera uses a sealed, rechargeable batt ery. • Fully recharging the battery takes about three ho urs. • The video camera may remain connected to your com puter after it is fully Draft: 10/25/2010 4 charged, but disconnecting it will help preserve th e battery pack’s lifespan and performance. • The optional Flip Video Power Adapter can charge the battery in about two hours. Note: Your computer must be powered on for your vid eo camera to charge. PANEL 5 Organize, Create and Share FLIPSHARE logo Pre-loaded FlipShare software makes editing and sha ring your videos easy. Just plug in your video camera, open FLIPVIDEO and launc h Setup FlipShare (PC) or Start FlipShare (Mac). FlipShare Features • Save videos to your computer. • Organize your videos. • Create custom movies • Capture snapshots • Share your videos via email or Flip Channels, or upload directly to: Facebook™ (logo) MySpace™ (logo) Twitter™ (logo) YouTube™ (logo) Visit the FlipShare software HELP section for detai led instructions on all features. PANEL 6 View On HD Television 1 Power off video camera and television. 2 Connect video camera to television with optional HD MI™ Cable from Flip Video (available at www.theflip.com/accessories). 3 Power on video camera and television. • Video camera screen turns off when connected to t elevision. 4 Switch your television to the appropriate VIDEO inp ut. • See television…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

LABEL LOCATION Label

Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13

Report No.: SA991004D02 1 Report Format Version 4.0.0 SAR TEST REPORT REPORT NO.: SA991004D02 MODEL NO.: M3260 FCC ID: Q87-M3260 IC ID: 3839A-M3260 RECEIVED: Oct. 04, 2010 TESTED: Jan. 19 ~ Jan. 20, 2011 ISSUED: Jan. 24, 2011 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive , Irvine California 92617 United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 31 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: SA991004D02 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.................................................................................................. 3 1. CERTIFICATION .............................................................................................................. 4 2. GENERAL INFORMATION .............................................................................................. 5 2.1 GENERAL DESCRIPTION OF EUT................................................................................. 5 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................. 7 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ........................................................ 8 2.4 TEST EQUIPMENT ........................................................................................................ 11 2.5 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................... 12 2.6 DESCRIPTION OF SUPPORT UNITS........................................................................... 15 3. DESCRIPTION OF ANTENNA LOCATION .................................................................... 16 4. RECIPES FOR TISSUE SIMULATING LIQUIDS ........................................................... 17 5. SYSTEM VALIDATION................................................................................................... 22 5.1. TEST PROCEDURE ...................................................................................................... 22 5.2. VALIDATION RESULTS ................................................................................................. 23 5.3. SYSTEM VALIDATION UNCERTAINTIES ..................................................................... 24 6. TEST RESULTS ............................................................................................................. 25 6.1 TEST PROCEDURES .................................................................................................... 25 6.2 CONDUCTED POWER .................................................................................................. 27 6.3 DESCRIPTION OF TEST CONDITION.......................................................................... 27 6.4 MEASURED SAR RESULT............................................................................................ 28 6.5 POWER DRIFT TABLE .................................................................................................. 29 6.6 SAR LIMITS ................................................................................................................... 30 6. INFORMATION ON THE TESTING LABORATORIES ................................................... 31 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report No.: SA991004D02 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Jan. 24, 2011 Report No.: SA991004D02 4 Report Format Version 4.0.0 1. CERTI FICATION PRODUCT: Digital Video Recorder MODEL: M3260 BRAND: CISCO APPLICANT: Cisco-Linksys LLC TESTED: Jan. 19 ~ Jan. 20, 2011 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093) FCC OET Bulletin 65, Supplement C (01-01) RSS-102 Issue 4 (2010-03) The above equipment (Model: M3260) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE:Jan. 24, 2011 Andrea Hsia / Specialist APPROVED BY : , DATE:Jan. 24, 2011 Gary Chang / Assistant Manager Report No.: SA991004D02 5 Report Format Version 4.0.0 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT EUT Digital Video Recorder MODEL NO. M3260 FCC ID Q87-M3260 IC ID 3839A-M3260 NOMINAL VOLTAGE 3.7Vdc from battery 5Vdc from AC adapter or host equipment (Charging only) MODULATION TYPE CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM MODULATION TECHNOLOGY DSSS, OFDM TRANSFER RATE 802.11b:11.0/ 5.5/ 2.0/ 1.0Mbps 802.11g: 54.0/ 48.0/ 36.0/ 24.0/ 18.0/ 12.0/ 9.0/ 6.0Mbps 802.11a: 54.0/ 48.0/ 36.0/ 24.0/ 18.0/ 12.0/ 9.0/ 6.0Mbps 802.11n: up to 22Mbps OPERATING FREQUENCY 2.4GHz: 2412 ~ 2472MHz 5.0GHz: 5745 ~ 5805MHz NUMBER OF CHANNEL 2.4GHz: 11 for 802.11b, 802.11g, 802.11n (20MHz) 7 for 802.11n (40MHz) 5.0GHz: 5 for 802.11a, 802.11n (20MHz) 2 for 802.11n (40MHz) MAXIMUM SAR (1g) 2.4GHz: 0.378W/kg 5.0GHz: 1.490W/kg ANTENNA TYPE Refer to note below ANTENNA CONNECTER Refer to note below DATA CABLE Shielded USB cable (1.2 m) Shielded HDMI cable (1.2 m) with two ferrite cores I/O PORTS Refer to user’s manual ACCESSORY DEVICES …

Text truncated - open the document above for the full version.

Report No.: SA991004D02-1 1 Report Format Version 4.0.0 SAR TEST REPORT REPORT NO.: SA991004D02-1 MODEL NO.: M3260 FCC ID: Q87-M3260 IC ID: 3839A-M3260 RECEIVED: Oct. 04, 2010 TESTED: Jan. 18 ~ Jan. 19, 2011 ISSUED: Jan. 24, 2011 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive , Irvine California 92617 United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 30 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: SA991004D02-1 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ................................................................................................. 3 1. CERTIFICATION .............................................................................................................. 4 2. GENERAL INFORMATION .............................................................................................. 5 2.1 GENERAL DESCRIPTION OF EUT ................................................................................ 5 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS ................................................. 7 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM........................................................ 8 2.4 TEST EQUIPMENT ........................................................................................................ 11 2.5 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION .................... 12 2.6 DESCRIPTION OF SUPPORT UNITS........................................................................... 15 3. DESCRIPTION OF ANTENNA LOCATION ................................................................... 16 4. RECIPES FOR TISSUE SIMULATING LIQUIDS........................................................... 17 5. SYSTEM VALIDATION .................................................................................................. 21 5.1. TEST PROCEDURE ...................................................................................................... 21 5.2. VALIDATION RESULTS ................................................................................................ 22 5.3. SYSTEM VALIDATION UNCERTAINTIES .................................................................... 23 6. TEST RESULTS............................................................................................................. 24 6.1 TEST PROCEDURES .................................................................................................... 24 6.2 CONDUCTED POWER .................................................................................................. 26 6.3 DESCRIPTION OF TEST CONDITION ......................................................................... 26 6.1 MEASURED SAR RESULT ........................................................................................... 27 6.4 POWER DRIFT TABLE .................................................................................................. 28 6.2 SAR LIMITS ................................................................................................................... 29 7. INFORMATION ON THE TESTING LABORATORIES .................................................. 30 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report No.: SA991004D02-1 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release N/A Jan. 24, 2011 Report No.: SA991004D02-1 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Digital Video Recorder MODEL: M3260 BRAND: CISCO APPLICANT: Cisco-Linksys LLC TESTED: Jan. 18 ~ Jan. 19, 2011 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093) FCC OET Bulletin 65, Supplement C (01-01) RSS-102 Issue 4 (2010-03) The above equipment (Model: M3260) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE:Jan. 24, 2011 Andrea Hsia / Specialist APPROVED BY : , DATE:Jan. 24, 2011 Gary Chang / Assistant Manager Report No.: SA991004D02-1 5 Report Format Version 4.0.0 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT EUT Digital Video Recorder MODEL NO. M3260 FCC ID Q87-M3260 IC ID 3839A-M3260 NOMINAL VOLTAGE 3.7Vdc from battery 5Vdc from AC adapter or host equipment (Charging only) MODULATION TYPE 64QAM, 16QAM, QPSK, BPSK MODULATION TECHNOLOGY OFDM TRANSFER RATE 802.11a: 54.0/ 48.0/ 36.0/ 24.0/ 18.0/ 12.0/ 9.0/ 6.0Mbps 802.11n: up to 22Mbps OPERATING FREQUENCY 5180.0 ~ 5240.0MHz NUMBER OF CHANNEL 4 for 802.11a, 802.11n (20MHz) 2 for 802.11n (40MHz) MAXIMUM SAR (1g) 1.550W/kg ANTENNA TYPE Refer to note below ANTENNA CONNECTER Refer to note below DATA CABLE Shielded USB cable (1.2 m) Shielded HDMI cable (1.2 m) with two ferrite cores I/O PORTS Refer to user’s manual ACCESSORY DEVICES Refer to note below NOTE: 1. The test data are separated into following test reports. REFERENCE REPORT WLAN 802.11b/g, 802.11n WLAN 802.11a, 802.11n (5745~5825 MHz) SA991004D02 WLAN 802.11a, 802.11n (5180~ 5240MHz) SA991004D02-1 2. The EUT incorporates a SISO fu…

Text truncated - open the document above for the full version.

D2: DOSIMETRIC E-FIELD PROBE D3: DAE D4: SYSTEM VALIDATION DIPOLE

D4: SYSTEM VALIDATION DIPOLE

Report No.: RF991004D02 1 Report Format Version 4.0.0 FCC TEST REPORT (15.247) REPORT NO.: RF991004D02 MODEL NO.: M3260 FCC ID: Q87-M3260 RECEIVED: Oct. 4, 2010 TESTED: Dec. 7 ~ 24, 2010 ISSUED: Jan. 25, 2011 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive , Irvine California 92617 United States ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 116 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF991004D02 2 Report Format Version 4.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD.................................................................................5 1. CERTIFICATION..............................................................................................6 2. SUMMARY OF TEST RESULTS......................................................................7 2.1 MEASUREMENT UNCERTAINTY...................................................................7 3. GENERAL INFORMATION..............................................................................8 3.1 GENERAL DESCRIPTION OF EUT.................................................................8 3.2 DESCRIPTION OF TEST MODES.................................................................10 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.............................................11 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL.................12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS................................17 3.4 DESCRIPTION OF SUPPORT UNITS...........................................................17 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND).....................................18 4.1 CONDUCTED EMISSION MEASUREMENT.................................................18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT...............................18 4.1.2 TEST INSTRUMENTS...................................................................................18 4.1.3 TEST PROCEDURES....................................................................................19 4.1.4 DEVIATION FROM TEST STANDARD..........................................................19 4.1.5 TEST SETUP.................................................................................................20 4.1.6 EUT OPERATING CONDITIONS...................................................................20 4.1.7 TEST RESULTS.............................................................................................21 4.2 RADIATED EMISSION MEASUREMENT......................................................25 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT....................................25 4.2.2 TEST INSTRUMENTS...................................................................................26 4.2.3 TEST PROCEDURES....................................................................................27 4.2.4 DEVIATION FROM TEST STANDARD..........................................................27 4.2.5 TEST SETUP.................................................................................................28 4.2.6 EUT OPERATING CONDITIONS...................................................................28 4.2.7 TEST RESULTS.............................................................................................29 4.3 6dB BANDWIDTH MEASUREMENT.............................................................44 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT...........................................44 4.3.2 TEST INSTRUMENTS...................................................................................44 4.3.3 TEST PROCEDURE......................................................................................44 4.3.4 DEVIATION FROM TEST STANDARD..........................................................44 4.3.5 TEST SETUP.................................................................................................45 4.3.6 EUT OPERATING CONDITIONS...................................................................45 4.3.7 TEST RESULTS.............................................................................................46 4.4 MAXIMUM OUTPUT POWER........................................................................50 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT.........................50 4.4.2 INSTRUMENTS.............................................................................................50 4.4.3 TEST PROCEDURES....................................................................................50 4.4.4 DEVIATION FROM TEST STANDARD..........................................................51 4.4.5 TEST SETUP.................................................................................................51 4.4.6 EUT OPERATING CONDITIONS...................................................................51 Report No.: RF991004D02 3 Report Format Version 4.0.0 4.4.7 TEST RESULTS.............................................................................................52 4.5 POWER SPECTRAL DENSITY MEASUREMENT.........................................53 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT......................53 4.5.2 TEST INSTRUMENTS...................................................................................53 4.5.3 TEST PROCEDURE......................................................................................53 4.5.4 DEVIATION FROM TEST STANDARD..........................................................54 4.5.5 TEST SETUP.................................................................................................54 4.5.6 EUT OPERATING CONDITION..............…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Mode B) 2 CONDUCTED EMISSION TEST (Mode C) 3 RADIATED EMISSION TEST (Mode A) 4 RADIATED EMISSION TEST (Mode B) 5 RADIATED EMISSION TEST (Mode C)

1 PHOTOGRAPHS OF THE TEST CONFIGURATION (SAR Test Set Up Photos) Back edge Front edge Top Bottom Right edge Left edge 2 Antenna Location Test Set Up
