Q87-RE2000Wireless-N Range Extender

Wireless-N Range Extender Quick Installation Guide Linksys RE1000 RE2000 1 2 Insert the CD into your CD or DVD drive. Make sure that the computer is already connected to your home network. Click Set up your Linksys Extender. If you do not see this: For Windows, find and click Computer, then double-click the CD drive and the Setup icon. For Mac, double-click the CD icon on your desktop, then double-click the Setup icon. Follow the on-screen instructions. 3 DVD/CD-RW Drive (E:) Linksys Adapter Setup AutoPlay Always do this for software and games: Install or run program General options Set up your Linksys Roupter Published by Cisco Consumer Products LLC View more AutoPlay options in Control Panel Open folder to view files using Windows Explorer DVD/CD-RW Drive (E:) Linksys Router Setup Always do this for software and games: Install or run program General options Set up your Linksys Extender Published by Cisco Consumer Products LLC Set AutoPlay defaults in Control Panel Open folder to view files using Windows Explorer Speed up my system using Windows ReadyBoost Congratulations! Now that your extender is set up, visit Linksys.com/support if you have questions and to learn about advanced features Tips for Successful Setup ;Avoid placing the extender or the associated router near metal objects, reflective surfaces, and masonry walls. ;Place the extender close to the router or access point during initial setup, then move the extender to its final location after setup. ;For the best positioning of your extender, test it in multiple locations. Cisco, the Cisco logo, and Linksys are trademarks or registered trademarks of Cisco and/or its affiliates in the United States and other countries. A listing of Cisco’s trademarks can be found at www.cisco.com/go/trademarks. All other trademarks mentioned in this document are the property of their respective owners. © 2013 Cisco and/or its affiliates. All rights reserved. 3240-00766A 121112MS Linksys.com/support

Linksys RE2000 Regulatory Information Table of Contents i Linksys RE2000 Table of Contents Wireless Regulatory Information 1 FCC Statement 1 FCC Radiation Exposure Statement 1 Safety Notices 1 Safety Guidelines 1 Industry Canada Statement 2 Restrictions in the 5 GHz Band 2 Avis d’Industrie Canada 2 Restrictions dans la bande 5 GHz 2 Wireless Disclaimer 2 Avis de non-responsabilité concernant les appareils sans fil 2 Mexico 3 Declaration of Conformity with Regard to EU Directive 1999/5/EC (R&TTE Directive) 3 Wireless Equipment (Wireless -AC Product) 4 National Restrictions 4 Product Usage Restrictions 4 Technical Documents on www myciscohome com 4 WEEE Information 6 User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste Electric and Electronic Equipment (WEEE) 6 1 Linksys RE2000Wireless Regulatory Information Wireless Regulatory Information FCC Statement This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation This product has been tested and complies with the specifications for a Class B digital device, pursuant to Part 15 of the FCC Rules These limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used according to the instructions, may cause harmful interference to radio communications However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which is found by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna •Increase the separation between the equipment or devices •Connect the equipment to an outlet other than the receiver’s •Consult a dealer or an experienced radio/TV technician for assistance FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment IEEE 802 11b or 802 11g operation of this product in the USA is firmware-limited to channels 1 through 11 The device for the band 5150-5250 MHz is only for indoor usage to reduce the potential for harmful interference to co-channel mobile satellite systems FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment This equipment should be installed and operated with minimum distance 20 cm between the radiator and your body This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter Safety Notices WARNING: Do not use this product near water, for example, in a wet basement or near a swimming pool WARNING: Avoid using this product during an electrical storm There may be a remote risk of electric shock from lightning WARNING: This product contains lead, known to the State of California to cause cancer, and birth defects or other reproductive harm Wash hands after handling Safety Guidelines WARNING: Use the following safety guidelines to ensure your own personal safety and to help protect your product from potential damage To reduce the risk of bodily injury, electrical shock, fire, and damage to the equipment, observe the following precautions •Do not service this product except as explained in your system documentation •If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or contact your service provider/retailer: •The power cable or plug is damaged •An object has fallen into the product •The product has been exposed to water •The product has been dropped or damaged •The product does not operate correctly when you follow the operating instructions •Keep your system away from radiators and heat sources •Install product in a manner and location to ensure ventilation openings are not blocked •Do not spill food or liquids on your system components, and never operate the product in a wet environment If the system gets wet, contact your service provider/ retailer •Do not push any objects into the openings of your system Doing so can cause fire or electric shock by shorting out interior components •Operate the product only from the type of external power source indicated on the electrical ratings label 2 Linksys RE2000Wireless Regulatory Information •Be sure that attached devices are electrically rated to operate with the power available in your location •Position system cables and power cables carefully; route cables so that they cannot be stepped on or tripped over Be sure that nothing rests on any cables •Do not modify power cables or plugs •Always follow your local and national wiring rules Industry Canada Statement This Class B digital apparatus complies with Canadian ICES-003 and RSS210 Operation is subject to the following two conditions: 1 This device may not cause interference and 2 This device must accept any interference, including interference that may cause undesired operation of the device Industry Canada Radiation Exposure Statement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter Restrictions in the 5 GHz Band The device for the band 5150-5250 MHz is only for indoor usage to reduce potential for harmful interference to co- channel mobile satellite systems Because high power radars are allocated as primary users (meaning they have priority) in 5250-5350 MHz an…

Text truncated - open the document above for the full version.

Report No.:121129E05 1 of 11 CONSTRUCTION PHOTOS OF EUT EUT (White) Report No.:121129E05 2 of 11 EUT (Black) Report No.:121129E05 3 of 11 Report No.:121129E05 10 of 11 Report No.:121129E05 11 of 11

RE2000 Product label , International EMEA and APAC Material: PC + (T=0.3mm) Grey as bottom cover C

Report No.:121129E05 4 of 11 Report No.:121129E05 5 of 11 Report No.:121129E05 6 of 11 Report No.:121129E05 7 of 11 Report No.:121129E05 8 of 11 Report No.:121129E05 9 of 11

FCC ID: Q87-RE2000 IC ID: 3839A-RE2000 Report No.: RF121129E05 IC121129E05 Operational Description This device is a Wireless-N Range Extender, which operates in both 2.4G and 5GHz bands; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise ratio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by a 12Vdc power adapter. The antenna is a PIFA antenna. The other instruction, please have a look at the users manual. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc... ) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted.

Report No.: SA121129E05 1 of 6 Report Format Version 5.0.0 RF EXPOSURE REPORT REPORT NO.: SA121129E05 MODEL NO.: RE2000 FCC ID: Q87-RE2000 RECEIVED: Nov. 29, 2012 TESTED: Dec. 12, 2012 ISSUED: Jan. 17, 2013 APPLICANT: Cisco Consumer Products, LLC ADDRESS: 121 Theory Drive Irvine, CA 92617(USA) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: SA121129E05 2 of 6 Report Format Version 5.0.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..................................................................................... 3 1. CERTIFICATION ...................................................................................................... 4 2. RF EXPOSURE LIMIT .............................................................................................. 5 3. MPE CALCULATION FORMULA ............................................................................. 5 4. CLASSIFICATION .................................................................................................... 5 5. ANTENNA GAIN....................................................................................................... 5 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER ........................... 6 Report No.: SA121129E05 3 of 6 Report Format Version 5.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED SA121129E05 Original release Jan. 17, 2013 Report No.: SA121129E05 4 of 6 Report Format Version 5.0.0 1. CERTIFICATION PRODUCT: Wireless-N Range Extender BRAND NAME: Cisco MODEL NO.: RE2000 TEST SAMPLE: ENGINEERING SAMPLE APPLICANT: Cisco Consumer Products, LLC TESTED DATE: Dec. 12, 2012 STANDARDS: FCC Part 2 (Section 2.1091) FCC OET Bulletin 65, Supplement C (01-01) IEEE C95.1 The above equipment (Model: RE2000) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Oct. 26, 2012 ( Lori Chung, Specialist ) APPROVED BY : , DATE: Oct. 26, 2012 ( May Chen, Deputy Manager ) Report No.: SA121129E05 5 of 6 Report Format Version 5.0.0 2. RF EXPOSURE LIMIT LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 3. MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale pi = 3.1416 r = distance between observation point and center of the radiator in cm 4. CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. 5. ANTENNA GAIN Transmitter Circuit Antenna Type Antenna Gain (dBi) Connector Frequency range (MHz to MHz) Chain (0) PIFA 4.0 NA 2400~2500 4.0 5150~5850 Chain (1) PIFA 2.8 NA 2400~2500 3.8 5150~5850 For 802.11b/g/a mode will fix transmission on Chain (0). Report No.: SA121129E05 6 of 6 Report Format Version 5.0.0 6. CALCULATION RESULT OF MAXIMUM CONDUCTED POWER For 15.247(2.4GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 438.597 4.00 20 0.21918 1 For 15.247(5GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5745 ~ 5825 486.127 4.00 20 0.24293 1 For 15.407(5GHz): FREQUENCY BAND (MHz) MAX POWER (mW) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/ cm 2 ) LIMIT (mW/cm 2 ) 5180 ~ 5240 45.709 4.00 20 0.02284 1 --- END --- CONCLUSION: Both of the 2.4GHz and 5GHz WLAN can transmit simultaneously, the formula of calculated the MPE is: CPD 1 / LPD 1 + CPD 2 / LPD 2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.19107 / 1 + 0.26777 / 1 = 0.45884, which is less than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit.

Report No.: RF121129E05 1 of 87 Report Format Version 5.1.0 Reference No.: 110719E01, 120110E14 FCC TEST REPORT (15.247) REPORT NO.: RF121129E05 MODEL NO.: RE2000 FCC ID: Q87-RE2000 RECEIVED: Nov. 29, 2012 TESTED: Dec. 05 to 19, 2012 ISSUED: Jan. 17, 2013 APPLICANT: Cisco Consumer Products LLC ADDRESS: 121 Theory Drive Irvine, CA 92617(USA) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF121129E05 2 of 87 Report Format Version 5.1.0 Reference No.: 110719E01, 120110E14 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 5 1. CERTIFICATION .................................................................................................... 6 2. SUMMARY OF TEST RESULTS ............................................................................ 7 2.1 MEASUREMENT UNCERTAINTY .......................................................................... 8 3. GENERAL INFORMATION ..................................................................................... 9 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 9 3.2 DESCRIPTION OF TEST MODES ....................................................................... 12 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 13 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 16 3.4 DESCRIPTION OF SUPPORT UNITS .................................................................. 17 3.5 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 17 4. TEST TYPES AND RESULTS (For 2.4GHz, 2400 ~ 2483.5MHz Band) ................ 18 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 18 4.1.2 TEST INSTRUMENTS .......................................................................................... 18 4.1.3 TEST PROCEDURES .......................................................................................... 19 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 19 4.1.5 TEST SETUP ....................................................................................................... 20 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 20 4.1.7 TEST RESULTS ................................................................................................... 21 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 23 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 23 4.2.2 TEST INSTRUMENTS .......................................................................................... 24 4.2.3 TEST PROCEDURES .......................................................................................... 25 4.2.4 DEVIATION FROM TEST STANDARD ................................................................. 25 4.2.5 TEST SETUP ....................................................................................................... 26 4.2.6 EUT OPERATING CONDITIONS ......................................................................... 26 4.2.7 TEST RESULTS ................................................................................................... 27 4.3 6dB BANDWIDTH MEASUREMENT .................................................................... 40 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .................................................. 40 4.3.2 TEST INSTRUMENTS .......................................................................................... 40 4.3.3 TEST PROCEDURE ............................................................................................. 40 4.3.4 DEVIATION FROM TEST STANDARD ................................................................. 40 4.3.5 TEST SETUP ....................................................................................................... 40 4.3.6 EUT OPERATING CONDITIONS ...............................................…

Text truncated - open the document above for the full version.

Report No.: RF121129E05-1 1 of 50 Report Format Version 5.1.0 Report No.: 110719E01, 120110E14 FCC TEST REPORT (15.407) REPORT NO.: RF121129E05-1 MODEL NO.: RE2000 FCC ID: Q87-RE2000 RECEIVED: Nov. 29, 2012 TESTED: Dec. 05 to 19, 2012 ISSUED: Jan. 17, 2013 APPLICANT: Cisco Consumer Products, LLC ADDRESS: 121 Theory Drive Irvine, CA 92617(USA) ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS : No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan, R.O.C. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification Report No.: RF121129E05-1 2 of 50 Report Format Version 5.1.0 Report No.: 110719E01, 120110E14 Table of Contents RELEASE CONTROL RECORD ........................................................................................ 4 1. CERTIFICATION .................................................................................................... 5 2. SUMMARY OF TEST RESULTS ............................................................................ 6 2.1 MEASUREMENT UNCERTAINTY ................................................................................ 7 3. GENERAL INFORMATION ..................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ....................................................................... 8 3.2 DESCRIPTION OF TEST MODES ....................................................................... 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ........................ 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ....................................... 14 3.4 DUTY CYCLE OF TEST SIGNAL ......................................................................... 15 3.5 DESCRIPTION OF SUPPORT UNITS .................................................................. 16 3.6 CONFIGURATION OF SYSTEM UNDER TEST ................................................... 16 4. TEST TYPES AND RESULTS .............................................................................. 17 4.1 CONDUCTED EMISSION MEASUREMENT ........................................................ 17 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ...................................... 17 4.1.2 TEST INSTRUMENTS .......................................................................................... 17 4.1.3 TEST PROCEDURES .......................................................................................... 18 4.1.4 DEVIATION FROM TEST STANDARD ................................................................. 18 4.1.5 TEST SETUP ....................................................................................................... 19 4.1.6 EUT OPERATING CONDITIONS ......................................................................... 19 4.1.7 TEST RESULTS ................................................................................................... 20 4.2 RADIATED EMISSION AND BANDEDGE MEASUREMENT ................................ 22 4.2.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT .............. 22 4.2.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS.......... 22 4.2.3 TEST INSTRUMENTS .......................................................................................... 23 4.2.4 TEST PROCEDURES .......................................................................................... 24 4.2.5 DEVIATION FROM TEST STANDARD ................................................................. 24 4.2.6 TEST SETUP ....................................................................................................... 25 4.2.7 EUT OPERATING CONDITION ............................................................................ 25 4.2.8 TEST RESULTS ................................................................................................... 26 4.3 TRANSMIT POWER MEASUREMENT ................................................................ 35 4.3.1 LIMITS OF TRANSMIT POWER MEASUREMENT .............................................. 35 4.3.2 TEST INSTRUMENTS .......................................................................................... 35 4.3.3 TEST PROCEDURE ............................................................................................. 36 4.3.4 DEVIATION FROM TEST STANDARD ............................................................…

Text truncated - open the document above for the full version.

Report No.: 120927E07 1 of 3 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: 120927E07 2 of 3 RADIATED EMISSION TEST (X-plane) Report No.: 120927E07 3 of 3 RADIATED EMISSION TEST (Y-plane)
