FCC ID: Q87-WAP200 Report No.: RF950508L03 Technical Description This device is an Wireless-G Access Point with Power Over Ethernet and RangeBooster, which operates in the 2.4GHz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by AC adapter or POE. The antenna used in this product is Omni-directional Dipole antenna with R-SMA connector. The other instruction, please have a look at the users manual.

FCC ID: Q87-WAP200 Report No: SA950508L03 1 RF EXPOSURE REPORT REPORT NO.: SA950508L03 MODEL NO.: WAP200 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617 (USA) ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: Q87-WAP200 Report No: SA950508L03 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: Q87-WAP200 Report No: SA950508L03 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: Q87-WAP200 Report No: SA950508L03 4 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1.8dBi or 1.513561 (numeric). 6.2 Output Power into antenna & RF Exposure at Distance 20cm: For 802.11b DSSS MODULATION: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241218.0300.0051.0 6243745.1860.0141.0 11246236.0580.0111.0 For 802.11g OFDM MODULATION: Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241235.6450.0111.0 6243770.9580.0211.0 11246256.4940.0171.0

Report No.: RF950508L031Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF950508L03 MODEL NO.: WAP200 RECEIVED: Aug. 16, 2006 TESTED: Aug. 17 ~ Sep. 11, 2006 ISSUED: Sep. 11, 2006 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617 (USA) ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 77 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF950508L032Report Format Version 2.0.4 TABLE OF CONTENTS 1.CERTIFICATION...........................................................................................................4 2.SUMMARY OF TEST RESULTS ..................................................................................5 2.1MEASUREMENT UNCERTAINTY................................................................................5 3.GENERAL INFORMATION ...........................................................................................6 3.1GENERAL DESCRIPTION OF EUT .............................................................................6 3.2DESCRIPTION OF TEST MODES ...............................................................................8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ..........................................................8 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............................10 3.2.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................12 3.2.4 DESCRIPTION OF SUPPORT UNITS .......................................................................12 4. TEST TYPES AND RESULTS ....................................................................................13 4.1CONDUCTED EMISSION MEASUREMENT .............................................................13 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT...........................................13 4.1.2 TEST INSTRUMENTS................................................................................................13 4.1.3 TEST PROCEDURES ................................................................................................14 4.1.4 DEVIATION FROM TEST STANDARD.......................................................................14 4.1.5 TEST SETUP..............................................................................................................15 4.1.6 EUT OPERATING CONDITIONS ...............................................................................15 4.1.7 TEST RESULTS .........................................................................................................16 4.2 RADIATED EMISSION MEASUREMENT ..................................................................34 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................34 4.2.2 TEST INSTRUMENTS................................................................................................35 4.2.3 TEST PROCEDURES ................................................................................................36 4.2.4 DEVIATION FROM TEST STANDARD.......................................................................37 4.2.5 TEST SETUP..............................................................................................................37 4.2.6 EUT OPERATING CONDITIONS ...............................................................................37 4.2.7 TEST RESULTS .........................................................................................................38 4.3 6dB BANDWIDTH MEASUREMENT..........................................................................47 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT .......................................................47 4.3.2 TEST INSTRUMENTS................................................................................................47 4.3.3 TEST PROCEDURE...................................................................................................48 4.3.4 DEVIATION FROM TEST STANDARD.......................................................................48 4.3.5 TEST SETUP..............................................................................................................48 4.3.6 EUT OPERATING CONDITIONS ...............................................................................48 4.3.7 TEST RESULTS .........................................................................................................49 4.4 MAXIMUM PEAK OUTPUT POWER..........................................................................55 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT ..........................55 4.4.2 INSTRUMENTS..........................................................................................................55 4.4.3 TEST PROCEDURES ................................................................................................56 4.4.4 DEVIATION FROM TEST STANDARD.......................................................................56 4.4.5 TEST SETUP..............................................................................................................56 4.4.6 EUT OPERATING CONDITIONS ...............................................................................56 Report No.: RF950508L033Report Format Version 2.0.4 4.4.7 TEST RESULTS .........................................................................................................57 4.5 POWER SPECTRAL DENSITY MEASUREMENT .....................................................58 4.5.1 LIMITS OF POWER SPECTRAL D…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (Test mode A) 2 CONDUCTED EMISSION TEST (Test mode B) 3 CONDUCTED EMISSION TEST (Test mode C) 4 RADIATED EMISSION BELOW 1GHz TEST (Test mode A) 5 RADIATED EMISSION BELOW 1GHz TEST (Test mode B) 6 RADIATED EMISSION BELOW 1GHz TEST (Test mode C) 7 RADIATED EMISSION ABOVE 1GHz TEST (Test mode A)
