Q87-WAP54GXWireless-G Access Point with SRX

A Division of Cisco Systems, Inc. ® Model No. Access Point with SRX Wireless-G WAP54GX User Guide WIRELESS GHz 2.4 802.11g Wireless-G Access Point with SRX Copyright and Trademarks Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2005 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders. How to Use this User Guide The user guide to the Wireless-G Access Point with SRX has been designed to make understanding networking with the Access Point easier than ever. Look for the following items when reading this User Guide: In addition to these symbols, there are definitions for technical terms that are presented like this: Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like this: Figure numbers and descriptions can also be found in the “List of Figures” section. This exclamation point means there is a caution or warning and is something that could damage your property or the Access Point. word: definition. This checkmark means there is a note of interest and is something you should pay special attention to while using the Access Point. This question mark provides you with a reminder about something you might need to do while using the Access Point. Figure 0-1: Sample Figure Description WAP54GX-UG-50616NC BW WARNING:This product contains chemicals, including lead, known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. Wireless-G Access Point with SRX Table of Contents Chapter 1: Introduction1 Welcome1 What’s in this User Guide?2 Chapter 2: Planning Your Wireless Network4 Network Topology4 Roaming4 Network Layout5 Chapter 3: Getting to Know the Wireless-G Access Point with SRX6 The Front Panel6 The Back Panel7 Chapter 4: Connecting the Wireless-G Access Point with SRX8 Overview8 Connections for Setup8 Chapter 5: Setting up the Wireless-G Access Point with SRX9 Overview9 Using the Setup Wizard9 Chapter 6: Configuring the Wireless-G Access Point with SRX19 Overview19 Navigating the Utility19 Accessing the Utility21 The Setup - Network Setup Tab21 The Wireless - Basic Wireless Settings Tab23 The Wireless - Wireless Security Tab24 The Wireless - Wireless MAC Filter Tab27 The Wireless - Advanced Wireless Settings Tab28 The Administration - Management Tab30 The Administration - Log Tab31 The Administration - Factory Defaults Tab32 The Administration - Firmware Upgrade Tab32 The Status - Local Network Tab33 The Status - Wireless Network Tab34 Appendix A: Troubleshooting35 Wireless-G Access Point with SRX Frequently Asked Questions35 Appendix B: Wireless Security39 Security Precautions39 Security Threats Facing Wireless Networks39 Appendix C: Upgrading Firmware42 Appendix D: Windows Help43 Appendix E: Glossary44 Appendix F: Specifications51 Appendix G: Warranty Information53 Appendix H: Regulatory Information54 Appendix I: Contact Information55 Wireless-G Access Point with SRX List of Figures Figure 3-1: Front Panel6 Figure 3-2: Back Panel7 Figure 4-1: Connect the Ethernet Network Cable8 Figure 4-2: Connect the Power8 Figure 5-1: Welcome Screen9 Figure 5-2: Connect the Network Cable to the Router or Switch Screen10 Figure 5-3: Connect the Network Cable to the Access Point Screen10 Figure 5-4: Power on the Access Point Screen11 Figure 5-5: Check the Access Point’s Status Screen11 Figure 5-6: Select the Access Point Screen12 Figure 5-7: Password Screen12 Figure 5-8: Basic Settings Screen13 Figure 5-9: Wireless Settings Screen14 Figure 5-10: Security Settings Screen15 Figure 5-11: WEP Settings Screen15 Figure 5-12: WPA Personal Settings Screen16 Figure 5-13: WPA2 Personal Settings Screen16 Figure 5-14: WPA2 Mixed Mode Settings Screen17 Figure 5-15: Confirm New Settings Screen18 Figure 5-16: Congratulations Screen18 Figure 6-1: Login Screen21 Figure 6-2: Setup - Automatic Configuration - DHCP Screen21 Figure 6-3: Setup - Static IP Screen22 Figure 6-4: Wireless - Basic Wireless Settings Screen23 Figure 6-5: Wireless - Wireless Security (WPA-Personal) Screen24 Figure 6-6: Wireless Security - WPA2-Personal Screen24 Figure 6-7: Wireless Security - WPA2-Mixed Screen25 Figure 6-8: Wireless Security - WPA-Enterprise Screen25 Wireless-G Access Point with SRX Figure 6-9: Wireless Security - RADIUS Screen26 Figure 6-10: Wireless Security - WEP Screen26 Figure 6-11: Wireless - Wireless MAC Filter Screen27 Figure 6-12: Wireless - Wireless Client Table27 Figure 6-13: Wireless - Advanced Wireless Settings Screen28 Figure 6-14: Administration - Management Screen30 Figure 6-15: Administration - Log Screen31 Figure 6-16: View Log Screen31 Figure 6-17: Administration - Factory Defaults Screen32 Figure 6-18: Administration - Firmware Upgrade Screen32 Figure 6-19: Status - Local Network Screen33 Figure 6-20: Status - Wireless Network Screen34 Figure C-1: Firmware Upgrade42 1 Chapter 1: Introduction Welcome Wireless-G Access Point with SRX Chapter 1: Introduction Welcome Thank you for choosing the Wireless-G Access Point with SRX. This Access Point will allow you to network wirelessly better than ever. How does the Access Point do all of this? An access point allows for greater range and mobility within your wireless network while also allowing you to connect the wireless network to a wired environment. And with SRX, you have greater range and speed. But what does all of this mean? Networks are useful tools for sharing computer resources. You can access one printer from different computers and access data located on another computer's hard drive. Networks are even used for playing multiplayer video games. So, networks are not only useful in homes and offices, they can also be fun. PCs on a wired network create a LAN, or Local Area Network. They are connected with Ethernet c…

Text truncated - open the document above for the full version.

13 Chapter 5: Setting up the Wireless-G Access Point with SRX Using the Setup Wizard Wireless-G Access Point with SRX 9. The Basic Settings screen will appear next. Enter a descriptive name in the Device Name field. Create a password that will control access to the Access Point’s Web-based Utility and Setup Wizard. If your network router will automatically assign an IP address to the Access Point, then select Automatic- DHCP. If you want to assign a static or fixed IP address to the Access Point, then select Static IP. Enter the IP Address, Subnet Mask, and Default Gateway settings. If you are not sure what changes you should make, then keep the default values. Then, click the Next button to continue or Back to return to the previous page. Device Name - Enter a descriptive name for the Access Point. Password - Enter a password that will control access to the Utility and Setup Wizard. IP Address - This IP address must be unique to your network. (The default IP address is 192.168.1.245.) Subnet Mask - The Access Point's Subnet Mask must be the same as the subnet mask of your Ethernet network. Default Gateway - Enter the IP address of your network gateway (usually your router). Click the Next button to continue or the Back button to return to the previous screen. Figure 5-8: Basic Settings Screen 14 Chapter 5: Setting up the Wireless-G Access Point with SRX Using the Setup Wizard Wireless-G Access Point with SRX Configuring the Access Point’s Wireless Settings 1. The Setup Wizard will ask you to enter the SSID, Channel, and Network Mode settings for your wireless network. SSID - Enter the name of your wireless network. The SSID must be identical for all devices in the network. The default setting is linksys (all lowercase). Channel - Select the operating channel for your wireless network. All of your wireless devices will use this channel to communicate. Network Mode - Select the wireless standards running on your network. If you have both 802.11g and 802.11b devices in your network, keep the default setting, Mixed Mode. If you have only 802.11g devices, select G-Only. If you have only 802.11b devices, select B-Only. If you want to disable your wireless network, select Disable. Click the Next button to continue or the Back button to return to the previous screen. Figure 5-9: Wireless Settings Screen 15 Chapter 5: Setting up the Wireless-G Access Point with SRX Using the Setup Wizard Wireless-G Access Point with SRX 2. Select the level of security you want to use: WEP or WPA/WPA2 Personal. WEP stands for Wired Equivalent Privacy, and WPA stands for Wi-Fi Protected Access. Click the Next button and proceed to step 3. If you do not want to use any wireless security method, select Disabled and then click the Next button. Proceed to step 4.. If you want to use WPA-Enterprise, it is available through the Access Point’s Web-based Utility. Select Disabled. Click the Next button and proceed to step 4. After you complete the Setup Wizard, refer to the Wireless Security tab in “Chapter 6: Configuring the Wireless-G Access Point with SRX.” 3. Proceed to the appropriate section for your security method. WEP WEP (64-Bit) To use 64-bit WEP encryption, select WEP (64-bit). Then enter a passphrase or WEP key. Passphrase - Enter a passphrase in the Passphrase field, so a WEP key is automatically generated. The passphrase is case-sensitive and should not be longer than 16 alphanumeric characters. It must match the passphrase of your other wireless network devices and is compatible with Linksys wireless products only. (If you have any non-Linksys wireless products, enter the WEP key manually on those products.) WEP Key - The WEP key you enter must match the WEP key of your wireless network. For 64-bit encryption, enter exactly 10 hexadecimal characters. Valid hexadecimal characters are “0” to “9” and “A” to “F”. Click the Next button to continue or the Back button to return to the previous screen. WEP (128-Bit) To use 128-bit WEP encryption, select WEP (128-bit). Then enter a passphrase or WEP key. Passphrase - Enter a passphrase in the Passphrase field, so a WEP key is automatically generated. The passphrase is case-sensitive and should not be longer than 16 alphanumeric characters. It must match the passphrase of your other wireless network devices and is compatible with Linksys wireless products only. (If you have any non-Linksys wireless products, enter the WEP key manually on those products.) WEP Key - The WEP key you enter must match the WEP key of your wireless network. For 128-bit encryption, enter exactly 26 hexadecimal characters. Valid hexadecimal characters are “0” to “9” and “A” to “F”. Click the Next button to continue or the Back button to return to the previous screen. Figure 5-11: WEP Settings Screen Figure 5-10: Security Settings Screen wep (wired equivalent privacy): a method of encrypting network data transmitted on a wireless network for greater security. encryption: encoding data transmitted in a network. 16 Chapter 5: Setting up the Wireless-G Access Point with SRX Using the Setup Wizard Wireless-G Access Point with SRX WPA/WPA2 Personal WPA Personal To use WPA Personal security, select WPA Personal from the Security drop-down menu. WPA Personal offers two encryption methods, TKIP and AES, with dynamic encryption keys. Select TKIP or AES for encryption. Then enter a Passphrase that is 8-32 characters in length. Encryption - Select TKIP or AES from the Encryption drop-down menu. Passphrase - Enter a Passphrase, also called a pre-shared key, of 8-32 characters in the Passphrase field. The longer and more complex your Passphrase is, the more secure your network will be. Click the Next button to continue or the Back button to return to the previous screen. WPA2 Personal To use WPA2 Personal security, select WPA2 Personal from the Security drop-down menu. WPA2 Personal uses AES encryption with dynamic keys. Enter a Passphrase that is 8-32 characters in length. Encryption - The default for WPA…

Text truncated - open the document above for the full version.

30 Chapter 6: Configuring the Wireless-G Access Point with SRX The Administration - Management Tab Wireless-G Access Point with SRX The Administration - Management Tab On this screen you can configure the password as well as back up or restore the Access Point’s configuration file. Management You should change the password that controls access to the Access Point’s Web-based Utility. AP’s Password Password. Create a Password for the Access Point’s Web-based Utility. Re-enter to Confirm. To confirm the new Password, enter it again in this field. Backup and Restore On this screen you can create a backup configuration file or save a configuration file to the Access Point. Backup Settings. To save a backup configuration file on a computer, click the Backup Settings button and follow the on-screen instructions. Restore Settings. To upload a configuration file to the Access Point, click the Restore Settings button and follow the on-screen instructions. Change these settings as described here and click Save Settings to apply your changes, or click Cancel Changes to cancel your changes. Click Help for more information. Figure 6-14: Administration - Management Screen 31 Chapter 6: Configuring the Wireless-G Access Point with SRX The Administration - Log Tab Wireless-G Access Point with SRX The Administration - Log Tab On this screen you can configure the log settings. Management You can have logs that keep track of the Access Point’s activities. Log To enable the Log support feature, select Enabled. Otherwise, select Disabled. Logviewer IP Address. If you have chosen to monitor the Access Point’s traffic, then you can designate a PC that will receive permanent log files periodically. In the field provided, enter the IP address of this PC. To view these permanent logs, you must use Logviewer software, which can be downloaded free of charge from www.linksys.com. View Log. To see a temporary log of the Access Point’s most recent activities, click this button. Click the Save Log button to save the log activity to a file. Click Refresh to refresh the screen. Click Clear to clear the entries. Click Close to close the screen. Change these settings as described here and click Save Settings to apply your changes, or click Cancel Changes to cancel your changes. Click Help for more information. Figure 6-16: View Log Screen Figure 6-15: Administration - Log Screen 32 Chapter 6: Configuring the Wireless-G Access Point with SRX The Administration - Factory Defaults Tab Wireless-G Access Point with SRX The Administration - Factory Defaults Tab On this screen you can restore the Access Point’s factory default settings. Management Write down any custom settings before you restore the factory defaults. Once the Access Point is reset, you will have to re-enter all of your configuration settings. Factory Defaults Restore Factory Defaults. To restore the Access Point's factory default settings, click this button. Then follow the on-screen instructions. Click Help for more information. The Administration - Firmware Upgrade Tab On this screen you can upgrade the Access Point’s firmware. Do not upgrade the firmware unless you are experiencing problems with the Access Point or the new firmware has a feature you want to use. Firmware Upgrade Before you upgrade the Access Point’s firmware, write down all of your custom settings. After you upgrade its firmware, you will have to re-enter all of your configuration settings. To upgrade the Access Point’s firmware: 1. Download the firmware upgrade file from the Linksys website, www.linksys.com. 2. Extract the firmware upgrade file on your computer. 3. On the Firmware Upgrade screen, enter the location of the firmware upgrade file in the field provided, or click the Browse button to find the file. 4. Click the Upgrade button, and follow the on-screen instructions. Click Help for more information. Figure 6-17: Administration - Factory Defaults Screen Figure 6-18: Administration - Firmware Upgrade Screen upgrade: to replace existing software or firmware with a newer version 33 Chapter 6: Configuring the Wireless-G Access Point with SRX The Status - Local Network Tab Wireless-G Access Point with SRX The Status - Local Network Tab The Local Network screen displays the Access Point’s current status information for the local network. AP’s Information Firmware Version. This is the version of the Access Point’s current firmware. Local Network MAC Address. The MAC address of the Access Point’s Local Area Network (LAN) interface is displayed here. AP’s IP Address. This shows the Access Point’s IP Address, as it appears on your local network. Subnet Mask. This shows the Access Point’s Subnet Mask. Default Gateway. Displayed here is the IP address of the Access Point’s Default Gateway. Click Help for more information. Figure 6-19: Status - Local Network Screen 34 Chapter 6: Configuring the Wireless-G Access Point with SRX The Status - Wireless Network Tab Wireless-G Access Point with SRX The Status - Wireless Network Tab The Wireless Network screen displays the Access Point’s current status information for its wireless network. Wireless Network MAC Address. The MAC Address of the Access Point’s wireless interface is displayed here. Mode. The Access Point’s mode is displayed here. Network Name (SSID). The Access Point’s main SSID is displayed here. Channel. The Access Point’s Channel setting for wireless broadcast is shown here. Security. The wireless security setting for the Access Point is displayed here. SSID Broadcast. Shown here is the setting of the Access Point’s SSID Broadcast feature. Click Help for more information. Figure 6-20: Status - Wireless Network Screen 35 Appendix A: Troubleshooting Frequently Asked Questions Wireless-G Access Point with SRX Appendix A: Troubleshooting This appendix provides solutions to problems that may occur during the installation and operation of the Wireless-G Access Point with SRX. Read the description below to solve your problems. If you can't find…

Text truncated - open the document above for the full version.

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 Date: May 31, 2005 FCC ID: Q87-WAP54GX Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, __________________________________________ Jennifer Yu / Associate Engineer Cisco-Linksys LLC Tel.: ( 949 ) 823-3188 Fax: ( 949 ) 823-3002 [email protected]

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 Agency Authorization Letter Date: May 31, 2005 To whom it may concern: We, the undersigned, hereby authorize Advance Data Technology Corp. (ADT) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by ADT within the scope of this authorization shall have the same effects as our own. This authorization shall expire six months from the original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, __________________________________________ Jennifer Yu / Associate Engineer Cisco-Linksys LLC Tel.: ( 949 ) 823-3188 Fax: ( 949 ) 823-3002 [email protected]

Model No.: WAP54GX Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3

FCC ID Label Location (FCC ID: Q87-WAP54GX)

Page 4 Page 5 Page 6 Page 7 Page 8 Page 9

FCC ID: Q87-WAP54GX Report No.: RF940511L04 Technical Description The Wireless-G Access Point with SRX combines smart antenna technology with standards-based Wireless-G (802.11g) networking. By overlaying the signals of two Wireless-G compatible radios, the "Multiple In, Multiple Out" (MIMO) technology effectively achieve greater throughput. Unlike ordinary wireless networking technologies that are confused by signal reflections, MIMO actually uses these reflections to increase the range and reduce "dead spots" in the wireless coverage area. The robust signal travels farther, maintaining wireless connections up to three times farther than standard Wireless-G. And the farther away you are, the more advantage you get—the higher data rate and reflection-friendly technology can yield up to better throughput than Wireless-G in some situations. The network avoids interference by dynamically switching to the clearest channel available. Even your standard Wireless-G and Wireless-B equipment will work better when communicating with SRX-enabled devices. The transmitter of the EUT is powered by AC adapter. The antenna is Dipole antenna with RPSMA connector. The other instruction, please have a look at the users manual.

FCC ID: Q87-WAP54GX Report No: SA 940511L04 1 RF EXPOSURE REPORT REPORT NO.: SA940511L04 MODEL NO.: WAP54GX ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: Q87-WAP54GX Report No: SA 940511L04 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: Q87-WAP54GX Report No: SA 940511L04 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This modular is specified to be installed in access point or router which is connected with host through wire. So it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: Q87-WAP54GX Report No: SA 940511L04 4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 2dBi or 1.585(numeric) and 7dBi or 5.012(numeric). 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm: Signal Chain 802.11b DSSS modulation Gain: 2dBi Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241235.6450.0111.0 6243770.9580.0221.0 11246251.5230.0161.0 802.11g OFDM modulation Gain: 2dBi Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241228.5100.0091.0 6243771.1210.0221.0 11246239.9020.0131.0 Dual Chain Gain: 2dBi PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 0 CHAIN 1 TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/CM2)) LIMIT OF POWER DENSITY (mW/CM2) 1241228.51028.24914.5514.5156.75917.540.0181.0 6243750.93350.23417.0717.01101.16720.050.0321.0 11246240.36540.27216.0616.0580.63719.070.0251.0

FCC ID: Q87-WAP54GX Report No.: RF940511L041Report Format Version 2.0.2 FCC TEST REPORT REPORT NO. : RF940511L04 MODEL NO. : WAP54GX RECEIVED : May 16, 2005 TESTED : May 16 ~ May 26, 2005 ISSUED : Jun. 02, 2005 APPLICANT : Cisco-Linksys LLC ADDRESS : 121 Theory Drive Irvine, CA 92617, U.S.A. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: 47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 107 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: Q87-WAP54GX Report No.: RF940511L042Report Format Version 2.0.2 TABLE OF CONTENTS 1. CERTIFICATION ............................................................................................ 5 2. SUMMARY OF TEST RESULTS.................................................................... 6 2.1 MEASUREMENT UNCERTAINTY.................................................................. 6 3. GENERAL INFORMATION ............................................................................ 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................... 7 3.2 DESCRIPTION OF TEST MODES ................................................................. 8 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ............................................. 9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ................ 10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................. 14 3.4 DESCRIPTION OF SUPPORT UNITS ......................................................... 14 4. TEST TYPES AND RESULTS (FOR SINGLE CHAIN (TX))......................... 15 4.1 CONDUCTED EMISSION MEASUREMENT ............................................... 15 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ............................. 15 4.1.2 TEST INSTRUMENTS .................................................................................. 15 4.1.3 TEST PROCEDURES................................................................................... 16 4.1.4 DEVIATION FROM TEST STANDARD......................................................... 16 4.1.5 TEST SETUP ................................................................................................ 17 4.1.6 EUT OPERATING CONDITIONS.................................................................. 17 4.1.7 TEST RESULTS............................................................................................ 18 4.2 RADIATED EMISSION MEASUREMENT .................................................... 24 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT .................................. 24 4.2.2 TEST INSTRUMENTS .................................................................................. 25 4.2.3 TEST PROCEDURES................................................................................... 26 4.2.4 DEVIATION FROM TEST STANDARD......................................................... 27 4.2.5 TEST SETUP ................................................................................................ 27 4.2.6 EUT OPERATING CONDITIONS.................................................................. 27 4.2.7 TEST RESULTS............................................................................................ 28 4.3 6dB BANDWIDTH MEASUREMENT............................................................ 36 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT.......................................... 36 4.3.2 TEST INSTRUMENTS .................................................................................. 36 4.3.3 TEST PROCEDURE ..................................................................................... 37 4.3.4 DEVIATION FROM TEST STANDARD......................................................... 37 4.3.5 TEST SETUP ................................................................................................ 37 4.3.6 EUT OPERATING CONDITIONS.................................................................. 37 4.3.7 TEST RESULTS............................................................................................ 38 4.…
