FCC ID: Q87-WMP300N Report No.: RF950420L10 OPERATIONAL DESCRIPTION This device is a Wireless-N PCI Adapter, which operates in the 2.4GHz frequency spectrum with throughput of up to 270Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 270Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is Dipole antenna with R-SMA antenna connector. For more detailed instruction, please take a look at the user’s manual.

FCC ID: Q87-WMP300N Report No: SA950420L10 1 RF EXPOSURE REPORT REPORT NO.: SA950420L10 MODEL NO.: WMP300N ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617 (USA) ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. FCC ID: Q87-WMP300N Report No: SA950420L10 2 RF EXPOSURE MEASUREMENT (MOBILE DEVICE) 1. INTRODUCTION In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF EXPOSURE LIMIT According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) (A)LIMITS FOR OCCUPATIONAL / CONTROL EXPOSURES 300-1500......F/3006 1500-100,000......56 (B)LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: Q87-WMP300N Report No: SA950420L10 3 3. FRIIS FORMULA Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance r. Ref.: David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4. EUT OPERATING CONDITION The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. CLASSIFICATION This device is fixed inside the host equipment. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: Q87-WMP300N Report No: SA950420L10 4 6. TEST RESULTS 6.1 ANTENNA GAIN The maximum Gain measured in Fully Anechoic Chamber is –0.48dBi or 0.895 (numeric). 6.2 OUTPUT POWER INTO ANTENNA & RF EXPOSURE VALUE AT DISTANCE 20cm: 802.11b DSSS MODULATION: CHANNEL CHANNEL FREQUENCY (MHz) TOTAL OUTPUT POWER TO ANTENNA (mW) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 12412105.4390.0191.0 62437185.3530.0331.0 11246269.9840.0121.0 802.11g OFDM MODULATION: CHANNEL CHANNEL FREQUENCY (MHz) TOTAL OUTPUT POWER TO ANTENNA (mW) POWER DENSITY (mW/cm 2 ) LIMIT OF POWER DENSITY (mW/cm 2 ) 12412131.8260.0231.0 62437183.6540.0331.0 112462102.8020.0181.0 FCC ID: Q87-WMP300N Report No: SA950420L10 5 DRAFT 802.11n (20MHz) OFDM MODULATION: DUAL TX PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 0 CHAIN 1 TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/CM2)) LIMIT OF POWER DENSITY (mW/CM2) 1 2412 80.72480.35319.0719.05161.07722.070.029 1.0 62437 161.065160.32522.0722.05321.13925.070.057 1.0 112462 81.09680.91019.0919.08162.00622.100.029 1.0 DRAFT 802.11n (40MHz) OFDM MODULATION: DUAL TX PEAK POWER OUTPUT (mW) PEAK POWER OUTPUT (dBm) CHANNEL CHANNEL FREQUENCY (MHz) CHAIN 0 CHAIN 1 CHAIN 0 CHAIN 1 TOTAL PEAK POWER (mW) TOTAL PEAK POWER (dBm) POWER DENSITY (mW/CM2)) LIMIT OF POWER DENSITY (mW/CM2) 12422 71.94571.77918.5718.56143.72421.580.026 1.0 42437 91.20190.15719.6019.55181.35822.590.032 1.0 72452 61.23560.95417.8717.85122.18920.870.022 1.0

Report No.: RF950420L101Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF950420L10 MODEL NO.: WMP300N RECEIVED: Apr. 20, 2006 TESTED: Apr. 10 ~ Apr. 14, 2006 ISSUED: Apr. 28, 2006 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617 (USA) ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 105 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF950420L102Report Format Version 2.0.4 TABLE OF CONTENTS 1.CERTIFICATION ....................................................................................................4 2.SUMMARY OF TEST RESULTS ............................................................................5 2.1 MEASUREMENT UNCERTAINTY..........................................................................5 3.GENERAL INFORMATION.....................................................................................6 3.1GENERAL DESCRIPTION OF EUT.......................................................................6 3.2DESCRIPTION OF TEST MODES.........................................................................7 3.2.1CONFIGURATION OF SYSTEM UNDER TEST .................................................... 7 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL......................... 8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS ......................................10 3.4DESCRIPTION OF SUPPORT UNITS .................................................................10 4.TEST TYPES AND RESULTS .............................................................................. 11 4.1CONDUCTED EMISSION MEASUREMENT ....................................................... 11 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT .................................... 11 4.1.2TEST INSTRUMENTS ......................................................................................... 11 4.1.3TEST PROCEDURES .......................................................................................... 12 4.1.4DEVIATION FROM TEST STANDARD ................................................................ 12 4.1.5TEST SETUP ....................................................................................................... 13 4.1.6EUT OPERATING CONDITIONS ......................................................................... 13 4.1.7TEST RESULTS ................................................................................................... 14 4.2RADIATED EMISSION MEASUREMENT ............................................................32 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT ......................................... 32 4.2.2TEST INSTRUMENTS ......................................................................................... 33 4.2.3TEST PROCEDURES .......................................................................................... 34 4.2.4DEVIATION FROM TEST STANDARD ................................................................ 34 4.2.5TEST SETUP ....................................................................................................... 35 4.2.6EUT OPERATING CONDITIONS ......................................................................... 35 4.2.7TEST RESULTS ................................................................................................... 36 4.36dB BANDWIDTH MEASUREMENT ...................................................................51 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT................................................. 51 4.3.2TEST INSTRUMENTS ......................................................................................... 51 4.3.3TEST PROCEDURE ............................................................................................ 51 4.3.4DEVIATION FROM TEST STANDARD ................................................................ 51 4.3.5TEST SETUP ....................................................................................................... 52 4.3.6EUT OPERATING CONDITIONS......................................................................... 52 4.3.7TEST RESULTS ................................................................................................... 53 4.4MAXIMUM PEAK OUTPUT POWER ...................................................................65 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.................... 65 4.4.2INSTRUMENTS ................................................................................................... 65 4.4.3TEST PROCEDURES .......................................................................................... 65 4.4.4DEVIATION FROM TEST STANDARD ................................................................ 65 4.4.5TEST SETUP ....................................................................................................... 66 4.4.6EUT OPERATING CONDITIONS ......................................................................... 66 4.4.7TEST RESULTS ................................................................................................... 67 4.5POWER SPECTRAL DENSITY MEASUREMENT...............................................69 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT ............................ 69 4.5.2TEST INSTRUMENTS ......................................................................................... 69 4.5.3TEST PROCEDURE ............................................................................................ 69 4.5.4DEVIATION FROM TEST STANDARD ..................…

Text truncated - open the document above for the full version.

Report No.: RF950420L10102Report Format Version 2.0.4 5. PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Report No.: RF950420L10103Report Format Version 2.0.4 RADIATED EMISSION TEST
