Q87-WPC4400NWireless-N Business Notebook Adapter

Model No. Model No. USER GUIDE BUSINESS SERIES Model No. Model No. Wireless-N with Ports Model No. WPC4400N 4-portuter Business Notebook Adapter Wireless Wireless-N Business Notebook Adapter Copyright and Trademarks Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders. How to Use this User Guide This user guide has been designed to make understanding networking with the Notebook Adapter easier than ever. Look for the following items when reading this User Guide: In addition to these symbols, there are definitions for technical terms that are presented like this: Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like this: Figure numbers and descriptions can also be found in the "List of Figures" section. This exclamation point means there is a caution or warning and is something that could damage your property or the Notebook Adapter. word: definition. This checkmark means there is a note of interest and is something you should pay special attention to while using the Notebook Adapter. This question mark provides you with a reminder about something you might need to do while using the Notebook Adapter. Figure 0-1: Sample Figure Description WPC4400N-UG-60524NC BW WARNING:This product contains chemicals, including lead, known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. Wireless-N Business Notebook Adapter Table of Contents Chapter 1: Introduction1 Welcome1 What’s in this User Guide?1 Chapter 2: Planning your Wireless Network3 Network Topology3 Roaming3 Network Layout4 Chapter 3: Getting to Know the Wireless-N Business Notebook Adapter5 The LED Indicators5 Chapter 4: Setting up and Connecting the Wireless-N Business Notebook Adapter6 Starting the Setup6 Connecting the Adapter7 Setting up the Adapter7 Chapter 5: Using the Wireless Network Monitor17 Accessing the Wireless Network Monitor17 Using the Wireless Network Monitors17 Link Information17 Profiles20 Create a New Profile21 Editing a Profile30 Site Survey37 Troubleshooting38 Administration38 Chapter 6: The Administrative Functions in the Wireless Network Monitor41 Accessing the Wireless Network Monitor41 Using the Administrative Functions in the Wireless Network Monitor41 Classification42 Security Monitor46 Appendix A: Troubleshooting50 Common Problems and Solutions50 Frequently Asked Questions51 Appendix B: Windows XP Wireless Zero Configuration54 Wireless-N Business Notebook Adapter Windows XP Wireless Zero Configuration54 Appendix C: Wireless Security57 Security Precautions57 Security Threats Facing Wireless Networks57 Appendix D: Windows Help60 Appendix E: Glossary61 Appendix F: Specifications66 Appendix G: Warranty Information68 Appendix H: Regulatory Information69 Appendix I: Contact Information75 Wireless-N Business Notebook Adapter List of Figures Figure 3-1: Front Panel 5 Figure 4-1: Setup Wizard’s Welcome Screen 6 Figure 4-2: Setup Wizard’s License Agreement 6 Figure 4-3: Connecting the Adapter 7 Figure 4-4: Available Wireless Network 7 Figure 4-5: WEP Key Needed for Connection 8 Figure 4-6: WPA - Personal Needed for Connection 8 Figure 4-7: Congratulations 9 Figure 4-8: Creating a Profile 10 Figure 4-9: Network Settings - Wireless Mode 10 Figure 4-10: Ad-Hoc Mode Settings 11 Figure 4-11: Wireless Security - WEP 11 Figure 4-12: Wireless Security - WPA Personal 12 Figure 4-13: Wireless Security - WPA2 Personal 12 Figure 4-14: Wireless Security - WPA Enterprise-EAP-TLS 13 Figure 4-15: Wireless Security - WPA Enterprise-PEAP 13 Figure 4-16: Wireless Security - WPA2 Enterprise-EAP 14 Figure 4-17: Wireless Security - WPA2 Enterprise-PEAP 14 Figure 4-18: Wireless Security - RADIUS - EAP-TLS 15 Figure 4-19: Wireless Security - RADIUS - PEAP 15 Figure 4-20: Wireless Security - LEAP 16 Figure 4-21: Congratulations Screen 16 Figure 5-1: Wireless Network Monitor Icon 17 Figure 5-2: Link Information - Connection 17 Figure 5-3: Link Information- Wireless Network Status 18 Figure 5-4: Link Information - Wireless Network Statistics 19 Figure 5-5: Profiles 20 Figure 5-6: Creating Profiles - Available Wireless Network 21 Figure 5-7: Creating Profiles - WEP Key Needed 21 Figure 5-8: Creating Profiles - WPA-Personal Needed 22 Figure 5-9: Creating Profiles - Congratulations 22 Figure 5-10: Creating Profiles - Manual Setup - Network Settings 23 Wireless-N Business Notebook Adapter Figure 5-11: Creating Profiles - Manual Setup - Wireless Mode 24 Figure 5-12: Creating Profiles - Manual Setup - Wireless Security - WEP 25 Figure 5-13: Creating Profiles - Manual Setup - Wireless Security - WPA Personal 25 Figure 5-14: Creating Profiles - Manual Setup - Wireless Security - WPA2 Personal 26 Figure 5-15: Creating Profiles - Manual Setup - Wireless Security - WPA Enterprise - EAP-TLS 26 Figure 5-16: Creating Profiles - Manual Setup - Wireless Security - WPA Enterprise - PEAP 26 Figure 5-17: Creating Profiles - Manual Setup - Wireless Security - WPA2 Enterprise - EAP-TLS 27 Figure 5-18: Creating Profiles - Manual Setup - Wireless Security - WPA2 Enterprise - PEAP 27 Figure 5-19: Creating Profiles - Manual Setup - Wireless Security - RADIUS 28 Figure 5-20: Creating Profiles - Manual Setup - Wireless Security - LEAP 28 Figure 5-21: Creating Profiles - Manual Setup - Confirm New Settings 29 Figure 5-22: Creating Profiles - Manual Setup - Congratulations 29 Figure 5-23: Editing Profiles - Wireless Mode 30 Figure 5-24: Editing Profiles - Ad Hoc Mode 30 Figure 5-25: Editing Profiles - Wireless Security 31 Figure 5-26: Editing Profiles - Wireless Security - WEP 31 Figure 5-27: Editing Profiles - Wireless Security - WPA Personal 32 Figure 5-28: Editing Pr…

Text truncated - open the document above for the full version.

39 Chapter 5: Using the Wireless Network Monitor Administration Wireless-N Business Notebook Adapter Log in as the Access Point's administrator: Enter the Access Point's administrative account and password and retype the password in the confirm field (default account name is admin and password is admin). Click Next to continue to the administrative options. Access Point Account This will let you modify your Access Point’s username and password. Figure 5-41: Administration - Login Access Point Account Figure 5-42: Administration - Modify Access Point Account 40 Chapter 5: Using the Wireless Network Monitor Administration Wireless-N Business Notebook Adapter Security Monitor Account The Security Monitor Account screen provides you with the function to create and modify your Security Monitor account. The Security Monitor account gives access to the administrative functions of the Wireless Network Monitor. Please enter the administrator’s username and password for modifying the Security Monitor account. Select an account from the drop-down menu to create or modify the username and password. There are a total of five accounts available. Click Save to save your existing changes. Email Alert This will let you enter the Access Point's name that will send alert messages via email and the email addresses for receiving instant alert messages. The username and password for the Security Monitor administrator account may or may not be the same as the Access Point's administrator account. Figure 5-43: Administration - Security Monitor Account Figure 5-44: Administration - Email Alert 41 Chapter 6: The Administrative Functions in the Wireless Network Monitor Accessing the Wireless Network Monitor Wireless-N Business Notebook Adapter Chapter 6: The Administrative Functions in the Wireless Network Monitor Use the administration functions in the Wireless Network Monitor to classify your wireless networks into different groups and monitor the activities and resources within your networks. The following functions under Classification and Security Monitor screens are only enabled after an administrator or privileged user enters a valid username and password. Accessing the Wireless Network Monitor After installing the Adapter, the Wireless Network Monitor icon will appear in the system tray of your computer. If the Wireless Network Monitor is enabled, then the icon will be green. If the Wireless Network Monitor is disabled or the Adapter is not connected, then the icon will be gray. Using the Administrative Functions in the Wireless Network Monitor The Administration tab will give you the access to the administrative tasks of the account information and other functions, such as classification and monitoring of your wireless networks.The Classification and Security Monitor function will be provided after login as the Security Monitor account at the Administration screen. To configure the trusted/untrusted wireless networks, click the Classification tab. To view the summarized report of the monitored wireless activities and alert messages, click the Security Monitor. Figure 6-1: Wireless Network Monitor Icon Figure 6-2: Administration - Login Security Monitor Account 42 Chapter 6: The Administrative Functions in the Wireless Network Monitor Classification Wireless-N Business Notebook Adapter Classification The Classification screen displays a summary of classified networks. The table shows the number of classified clients in your networks. It also shows the number of classified Access Points based on their Vendor, Network’s SSID, and Channel. You may uncheck the Receive classification rules to disable this station from receiving the network's current classification rules. The default condition is checked, so each station always receives classification rules in synchronization with other stations in the network. You may also click the Synchronize button to send out the classification rules to other users within your monitored wireless networks. Click Next to configure your trusted networks. AP Classification The AP Classification Screen lets you classify the existing Access Points as Trusted or Untrusted. A Trusted device is one that has been identified by the system administrator to be known and legitimate. An Untrusted device is one that is known and not legitimate. This device could be a malicious device or simply a neighborhood device not part of the network. Remaining devices that have not been classified can be considered Unclassified or Unknown. The left table lists the available unclassified wireless networks with their SSID, channels and MAC Addresses. The top right table lists the Access Points that have been classified as Trusted. The lower right table lists the Access Points that have been classified as Untrusted. You may check any items from the Unclassified Access Points table and click the arrow to classify your selections into Trusted Access Points or Untrusted Access Points. You may click Refresh to refresh the list or Back to go to the previous screen. NOTE:You will have to log in with a valid Security Monitor account to view this screen and all remaining screens in Chapter 6. Figure 6-3: Classification Figure 6-4: AP Classification 43 Chapter 6: The Administrative Functions in the Wireless Network Monitor Classification Wireless-N Business Notebook Adapter Client Classification The Client Classification Screen lets you classify the existing wireless clients into trusted networks and untrusted networks. New Client information is received from Linksys Business Series Access Points. New Clients start off as Unclassified until the System Administrator classifies them. A Trusted Client is one that has been identified by the System Administrator to be known and legitimate. An Untrusted Client is one that is known and not legitimate. This client could be a malicious client or simply a neighborhood client not part of the network. Remaining clients that have not been classified can be considered Unclass…

Text truncated - open the document above for the full version.

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 Date: June 8, 2006 FCC ID: Q87-WPC4400N Federal Communications Commission Authorization and Evaluation Division Subject: Short-term confidentiality request regarding application for certification of FCC ID: Q87-WPC4400N TO WHOM IT MAY CONCERN Pursuant to DA 04-1705 of the Commission’s public notice, we request short-term confidential treatment for the following information until 45 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Internal photos Test Setup photos User’s Manual Sincerely yours, __________________________________________ Jennifer Yu / Associate Engineer Cisco-Linksys LLC Tel.: ( 949 ) 823-3188 Fax: ( 949 ) 823-3002 [email protected]

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 Date: May 31, 2006 FCC ID: Q87-WPC4400N Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, __________________________________________ Jennifer Yu / Associate Engineer Cisco-Linksys LLC Tel.: ( 949 ) 823-3188 Fax: ( 949 ) 823-3002 [email protected]

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 Agency Authorization Letter Date: May 31, 2006 To whom it may concern: We, the undersigned, hereby authorize Advance Data Technology Corp. (ADT) of Taiwan to act on our behalf, as our agent, in the following matters related to the FCC approval of our products: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by ADT within the scope of this authorization shall have the same effects as our own. This authorization shall expire six months from the original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Thank you! Sincerely yours, __________________________________________ Jennifer Yu / Associate Engineer Cisco-Linksys LLC Tel.: ( 949 ) 823-3188 Fax: ( 949 ) 823-3002 [email protected]

Model No.: WPC4400N Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

Page 3 Page 4 Page 5

FCC ID: Q87-WPC4400N Report No.: RF950525L03 Technical Description This device is a Wireless-N Business Notebook Adapter, which operates in the 2.4GHz frequency spectrum with throughput of up to 300Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is printed antenna without connector. For more detailed instruction, please take a look at the user’s manual.

A - 1 APPENDIX A: TEST DATA Liquid Level Photo MSL 2450MHz D=155mm A - 2 Date/Time: 2006/6/8 07:11:03 Test Laboratory: Advance Data Technology N800C-11b 2Tx-CH1-Mode 1 DUT: Wireless-N Business Notebook Adapter ; Type: WPC4400N ; Test Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.95 mho/m; ε r = 51.1; ρ = 1000 kg/m 3 ; Liquid level : 155 mm Phantom section: Flat Section ; Separation distance : 13 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 23.3 degrees ; Liquid temp. : 22.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.13, 4.13, 4.13) ; Calibrated: 2005/9/15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 161 Low Channel 1/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.953 mW/g Low Channel 1/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 25.6 V/m Peak SAR (extrapolated) = 1.92 W/kg SAR(1 g) = 0.908 mW/g; SAR(10 g) = 0.480 mW/g Maximum value of SAR (measured) = 0.959 mW/g A - 3 Date/Time: 2006/6/8 07:30:22 Test Laboratory: Advance Data Technology N800C-11b 2Tx-CH6-Mode 1 DUT: Wireless-N Business Notebook Adapter ; Type: WPC4400N ; Test Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2437 MHz; σ = 1.99 mho/m; ε r = 51; ρ = 1000 kg/m 3 ; Liquid level : 155 mm Phantom section: Flat Section ; Separation distance : 13 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 23.3 degrees ; Liquid temp. : 22.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.13, 4.13, 4.13) ; Calibrated: 2005/9/15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 161 Mid Channel 6/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.24 mW/g Mid Channel 6/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 26.6 V/m Peak SAR (extrapolated) = 2.65 W/kg SAR(1 g) = 1.22 mW/g; SAR(10 g) = 0.636 mW/g Maximum value of SAR (measured) = 1.31 mW/g A - 4 Date/Time: 2006/6/8 07:51:17 Test Laboratory: Advance Data Technology N800C-11b 2Tx-CH11-Mode 1 DUT: Wireless-N Business Notebook Adapter ; Type: WPC4400N ; Test Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2462 MHz; σ = 2.04 mho/m; ε r = 51; ρ = 1000 kg/m 3 ; Liquid level : 155 mm Phantom section: Flat Section ; Separation distance : 13 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 23.3 degrees ; Liquid temp. : 22.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.13, 4.13, 4.13) ; Calibrated: 2005/9/15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 161 High Channel 11/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 1.13 mW/g High Channel 11/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 26.0 V/m Peak SAR (extrapolated) = 2.51 W/kg SAR(1 g) = 1.15 mW/g; SAR(10 g) = 0.600 mW/g Maximum value of SAR (measured) = 1.23 mW/g A - 5 Date/Time: 2006/6/8 08:23:12 Test Laboratory: Advance Data Technology N800C-11g 2Tx-CH1-Mode 2 DUT: Wireless-N Business Notebook Adapter ; Type: WPC4400N ; Test Frequency: 2412 MHz Communication System: 802.11g ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.95 mho/m; ε r = 51.1; ρ = 1000 kg/m 3 ; Liquid level : 155 mm Phantom section: Flat Section ; Separation distance : 13 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 23.3 degrees ; Liquid temp. : 22.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.13, 4.13, 4.13) ; Calibrated: 2005/9/15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.6 Build 23 ; Postprocessing SW: SEMCAD, V1.8 Build 161 Low Channel 1/Area Scan (7x11x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.424 mW/g Low Channel 1/Zoom Scan (7x7x7) (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 14.6 V/m Peak SAR (extrapolated) = 0.876 W/kg SAR(1 g) = 0.413 mW/g; SAR(10 g) = 0.218 mW/g Maximum value of SAR (measured) = 0.447 mW/g A - 6 Date/Time: 2006/6/8 08:44:31 Test Laboratory: Advance Data Technology N800C-11g 2Tx-CH6-Mode 2 DUT: Wireless-N Business Notebook Adapter ; Type: WPC4400N ; Test Frequency: 2437 MHz Communication System: 802.11g ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: OFDM Medium: MSL2450 Medium parameters used: f = 2437 MHz; σ = 1.99 mho/m; ε r = 51; ρ = 1000 kg/m 3 ; Liquid level : 155 mm Phantom section: Flat Section ; Separation distance : 13 mm (The bottom side of the EUT to the Phantom) Antenna type : Printed Antenna ; Air temp. : 23.3 degrees ; Liquid temp. : 22.1 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.13, 4.13, 4.13) ; Calibrated: 2005/9/15 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2005/8/17 …

Text truncated - open the document above for the full version.

B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION D4: SYSTEM VALIDATION DIPOLE D4：ET3DV6 E-Field Probe (Cal Date：September 15.2005)

D4：DAE3 (Cal Date：August 17.2005) APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM

Report no.: SA950525L031Report Format Version 2.0.3 SAR TEST REPORT REPORT NO.: SA950525L03 MODEL NO.: WPC4400N RECEIVED: May 25, 2006 TESTED: Jun. 08, 2006 ISSUED: Jun. 19, 2006 APPLICANT: Cisco-Linksys LLC ADDRESS:121 Theory Drive Irvine, CA 92617 (USA) ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: 47 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 46 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report no.: SA950525L032Report Format Version 2.0.3 TABLE OF CONTENTS 1.CERTIFICATION..................................................................................................................3 2.GENERAL INFORMATION...................................................................................................4 2.1GENERAL DESCRIPTION OF EUT................................................................................4 2.2GENERAL DESCRIPTION OF APPLIED STANDARDS..................................................5 2.3GENERAL INOFRMATION OF THE SAR SYSTEM........................................................7 2.4GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION......................10 3.DESCRIPTION OF SUPPORT UNITS................................................................................14 4.DESCRIPTION OF TEST MODES AND CONFIGURATIONS..............................................15 4.1.DESCRIPTION OF ANTENNA LOCATION...................................................................15 4.2.DESCRIPTION OF ASSESSMENT POSITION.............................................................16 4.3.DESCRIPTION OF TEST MODE..................................................................................17 4.4.SUMMARY OF TEST RESULTS...................................................................................18 5.TEST RESULTS.................................................................................................................19 5.1TEST PROCEDURES..................................................................................................19 5.2MEASURED SAR RESULTS........................................................................................21 5.3SAR LIMITS.................................................................................................................23 5.4RECIPES FOR TISSUE SIMULATING LIQUIDS...........................................................30 5.5TEST EQUIPMENT FOR TISSUE PROPERTY............................................................33 6.SYSTEM VALIDATION.......................................................................................................34 6.1TEST EQUIPMENT......................................................................................................34 6.2TEST PROCEDURE.....................................................................................................35 6.3VALIDATION RESULTS................................................................................................37 6.4SYSTEM VALIDATION UNCERTAINTIES....................................................................38 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES....................................................39 7.1.PROBE CALIBRATION UNCERTAINTY.......................................................................39 7.2.ISOTROPY UNCERTAINTY.........................................................................................40 7.3.BOUNDARY EFFECT UNCERTAINTY.........................................................................40 7.4.PROBE LINEARITY UNCERTAINTY............................................................................41 7.5.READOUT ELECTRONICS UNCERTAINTY................................................................41 7.6.RESPONSE TIME UNCERTAINTY..............................................................................41 7.7.INTEGRATION TIME UNCERTAINTY..........................................................................42 7.8.PROBE POSITIONER MECHANICAL TOLERANCE....................................................43 7.9.PROBE POSITIONING.................................................................................................43 7.10.PHANTOM UNCERTAINTY.........................................................................................44 7.11.DASY4 UNCERTAINTY BUDGET................................................................................45 8.INFORMATION ON THE TESTING LABORATORIES.........................................................46 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report no.: SA950525L033Report Format Version 2.0.3 1. CERTIFICATION PRODUCT: Wireless-N Business Notebook Adapter MODEL: WPC4400N BRAND: Linksys APPLICANT: Cisco-Linksys LLC TESTED : Jun. 08, 2006 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS:FCC Part 2 (Section 2.1093), RSS-102 FCC OET Bulletin 65, Supplement C (01-01) The above equipment have been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY :, DATE:Jun. 19, 2006 Rennie Wang TECHNICAL ACCEPTANCE:, DATE:Jun. 19, 2006 Responsible for RF Stanely Hsu APPROVED BY : , DATE: Jun. 19, 2006 Gary Chang / Supervisor Report no…

Text truncated - open the document above for the full version.

Report No.: RF950525L031Report Format Version 2.0.4 FCC TEST REPORT REPORT NO.: RF950525L03 MODEL NO.: WPC4400N RECEIVED: May 29, 2006 TESTED: May 29 ~ Jun. 07, 2006 ISSUED: Jun. 12, 2006 APPLICANT: Cisco-Linksys LLC ADDRESS: 121 Theory Drive Irvine, CA 92617 (USA) ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: 47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 134 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF950525L032Report Format Version 2.0.4 TABLE OF CONTENTS 1. CERTIFICATION................................................................................................4 2.SUMMARY OF TEST RESULTS.......................................................................5 2.1 MEASUREMENT UNCERTAINTY....................................................................5 3.GENERAL INFORMATION...............................................................................6 3.1GENERAL DESCRIPTION OF EUT..................................................................6 3.2DESCRIPTION OF TEST MODES...................................................................7 3.2.1CONFIGURATION OF SYSTEM UNDER TEST..........................................................7 3.2.2TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL................................8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS.................................11 3.4DESCRIPTION OF SUPPORT UNITS............................................................11 4.TEST TYPES AND RESULTS.........................................................................12 4.1CONDUCTED EMISSION MEASUREMENT..................................................12 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT...........................................12 4.1.2TEST INSTRUMENTS.............................…

Text truncated - open the document above for the full version.
