Q87-WPS54GWireless-G Print Server

LINKSYS LLC
Wireless-G Print Server - FCC ID Q87-WPS54G - LINKSYS LLC
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Sep 23, 2004
Application Purpose
Original Equipment
Date of Application
Sep 23, 2004
Equipment Note
Wireless-G Print Server
Frequency Range
2412.00000000 - 2462.00000000
Company
LINKSYS LLC
Country
United States

Documents & Files

Select a file to view

Users Manual

β†—

Cover Letter(s)

β†—
β†—
β†—

External Photos

β†—

ID Label/Location Info

β†—

Internal Photos

β†—

Operational Description

β†—

RF Exposure Info

β†—

Test Report

β†—
β†—
β†—

Test Setup Photos

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

802.11g PC Card/USB Wireless Adapter User Guide Regulatory Approvals FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica- tions. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. (Example - use only shielded interface cables when connecting to computer or peripheral devices). FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Channel The Wireless Channel sets the radio frequency used for communication. Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best performance. In the USA and Canada, 11 channel are available. If using multiple Access Points, it is better if adjacent Access Points use different Channels to reduce interference. In "Infrastructure" mode, Wireless Stations normally scan all Channels, looking for an Access Point. If more than one Access Point can be used, the one with the strongest signal is used. (This can only happen within an ESS.) If using "Ad-hoc" mode (no Access Point), all Wireless stations should be set to use the same Channel. However, most Wireless stations will still scan all Channels to see if there is an existing "Ad-hoc" group they can join. i Table of Contents CHAPTER 1 INTRODUCTION..............................................................................................................1 Package Contents.............................................................................................................................1 LEDs....................................................................................................................................................1 Operation............................................................................................................................................2 CHAPTER 2 INITIAL INSTALLATION...............................................................................................3 Requirements....................................................................................................................................3 Procedure...........................................................................................................................................3 CHAPTER 3 USING THE WINDOWS UTILITY.................................................................................5 Overview.............................................................................................................................................5 System Tray Icon..............................................................................................................................5 Site Survey Screen...........................................................................................................................6 Add Profile Screen...........................................................................................................................7 Profiles Screen...............................................................................................................................10 Link Status Screen........................................................................................................................11 Statistics Screen.............................................................................................................................11 Advanced Screen.............................................................................................................................12 About Screen...................................................................................................................................12 APPENDIX A SPECIFICATIONS........................................................................................................13 PC Card Adapter.............................................................................................................................13 USB Adapter..........................................................................................................................…

Text truncated - open the document above for the full version.

Cover Letter(s)

Sep. 16, 2004 Federal Communications Commission Authorization and Evaluation Division FCC IDQ87-WPS54G Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompaniment this Application As outlined below: 1. Block Diagram, 2. Schematic Diagram, The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, ___________________________ Jennifer Yu / Associate Engineer Cisco-Linksys, LLC Tel: +1-949-823-3188 Fax:+1-949-823-3002 E-Mail: [email protected]

Cover Letter(s)

Federal Communications Commission Dear Sir, We, the undersigned, hereby authorize Exclusive Certification Corp. to act on our behalf in all matters relating to application for Wireless-G Print Server (Model: WPS54G, FCC ID No.: Q87-WPS54G)” authorization, including the signing of all documents relating to these matters. Any and all carried out by Exclusive Certification Corp. on our behalf shall have the same effect as acts of our own. The applicant certifies that in the case of an individual applicant (e.g., corporation), no party to the applicant is subject to a denial of federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-drug abuse Act of 1988.21 U.S.A. 862. For a definition of a β€œparty” for these purposes See 47 C.F.R. 1.2002(b). By: By: Jennifer Yu (Signature) (Printed) Title : Associate Engineer Applicant: Cisco-Linksys, LLC Address: 121 Theory Drive Irvine, CA 92612, U.S.A Tel: +1-949-823-3188 Fax: +1-949-823-3002 E-mail: [email protected] Date: Sep. 16, 2004

Cover Letter(s)

Exclusive Certification Corp. 4F-2, No. 28, Lane 78, Xing-Ai Rd. Nei-hu , Taipei City 114 Taiwan R.O.C 11478284-2F Tel:886-2-2792-3366 Fax:886-2-2792-1100 To whom it may concern: The enclosed documents constitute a formal submittal and application for a Grant of Equipment Authorization pursuant to Subpart C of Part 15 of FCC rules (CFR47) regarding Wireless -G Print Server for the Cisco -Linksys model WPS54G. Data within this report demonstrates that the equipment tested complied with the FCC limits for intentional radiators. Exclusive Certificate Corp. (ECC), as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is enclosed. If there are any questions or if further information is needed, please contact ECC for assistance. Ivy Chen TEL: +886-2-2792-3366 # 204 FAX: +886-2-2792-1100 E-mail: [email protected]

External Photos

External Photos

Internal Photos

Internal Photos

Operational Description

Part Number Date SubjectWPS54G pages1 WPS54G Operation Principle 1. CPU, U6, 88W8510 have a 32-bit RISC processor integrated, operation frequency is 160MHz. It needs an external 44MHz crystal for reference frequency; this crystal is also used for RF module. This chip is responsible to control RF-Baseband Transceiver (88W8000G). 2. FLASH, U13, MX29LV800TTC-70, 8Mbits Flash, bottom sector, 70ns. It is used to store the normal and test firmware. 3. Integrated 2.4GHz ISM Band RF-Baseband Transceiver, U9, 88W8000G which is integrated all RF-Baseband receive and Transmit function. It is also integrated programmable frequency synthesizers with integrated VCOs, I/Q generation and CMOS up/down conversion mixers. 4. Power Amplifier (PA), U30, SE2525L, with up to +20 dBm output power at the antenna port. 5. 88W8510 support 802.3 PHY, automatic MDI/MDIX crossover for 100BASE-TX and 10 BASE-T ports. 6. Power part: there are several regulators are used on the board. U17, AZ1084S-3 is used to transfer DC5V to DC3V3; U1, U8 AME8805DEFT are used to transfer DC3V3 to DC2V5; U20, AZ1117-ADJ is used to transfer DC3V3 to DC1V62. The core of CPU is operate at 1.625V. 7. UB2 NEC uPD720101 complies with the universal serial bus specification ver2.0 And open host controller interface specification for full/low speed signaling, the Part is integrated host controller with PCI interface and USB2.0 transceiver into a Single chip. 8.

RF Exposure Info

1.1. Test Result of RF Exposure Evaluation Product : Wireless-G Print Server Test Item : RF Exposure Evaluation Data Test site : OATSI-SD Test Mode : Normal Operation 1.1.1. Antenna Gain The maximum Gain is 1.8dBi. 1.1.2. EUT Operation condition Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 1.1.3. Output Power into Antenna & RF Exposure Evaluation Distance Modulation Standard: IEEE 802.11b Test Date: Sep. 14, 2004 Temperature: 24 Humidity: 63% Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 16.00 0.012 06 2437 16.60 0.014 11 2462 16.78 0.014 Modulation Standard: IEEE 802.11g Test Date: Sep. 14, 2004 Temperature: 24 Humidity: 63% Channel Channel Frequency (MHz) Output Power to Antenna (dBm) Power Density (S) (mW/cm 2 ) 01 2412 16.60 0.014 06 2437 17.14 0.016 11 2462 17.23 0.016 The MPE is calculated as 0.016 mW / cm 2 < limit 1 mW / cm 2 . So, RF exposure limit warning or SAR test are not required.

Test Report

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 1 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A FCC TEST REPORT according to FCC Rules and Regulations Part 15 Subpart C † The test result refers exclusively to the test presented test model / sample., † Without written approval of Exclusive Certification Corp. the test report shall not be reproduced except in full. Applicant Cisco-Linksys, LLC Address 121 Theory Drive Irvine, CA 92612 USA Equipment Wireless-G Print Server Model No. WPS54G FCC ID Q87-WPS54G Trade Name Linksys Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 2 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Contents 1. Report of Measurements and Examinations..................................................................................3 1.1. List of Measurements and Examinations............................................................................3 1.2. Antenna Requirements......................................................................................................3 1.3. Test of Conducted Emission..............................................................................................3 1.4. Test of Radiated Emission.................................................................................................3 1.5. 6dB Bandwidth.................................................................................................................3 1.6. Maximum Peak Output Power...........................................................................................3 1.7. Band Edges Measurement................................................................................................3 1.8. Power Spectral Density.....................................................................................................3 1.9. Restricted Bands of Operation...........................................................................................3 1.10. Labeling Requirement.......................................................................................................3 1.11. RF Exposure....................................................................................................................3 2. Test Configuration of Equipment under Test..................................................................................3 2.1. Test Mode and Test Software.............................................................................................3 2.2. Description of Test System................................................................................................3 2.3. Connection Diagram of Test System..................................................................................3 2.4. Feature of Equipment under Test.......................................................................................3 2.5. RF Module Specifications..................................................................................................3 2.6. History of this test report...................................................................................................3 3. General Information of Test.........................................................................................................3 4. Test Result and Data...................................................................................................................3 4.1. Antenna Requirement.......................................................................................................3 4.2. Test Result of Conducted Emission....................................................................................3 4.3. RF Portion........................................................................................................................3 4.4. 6dB Bandwidth Measurement Data....................................................................................3 4.5. Peak Output Power Measurement Data.............................................................................3 4.6. Band Edges Measurement Data........................................................................................3 4.7. Power Spectral Density Measurement Data........................................................................3 5. List of Measuring Equipment Used...............................................................................................3 Appendix A. Photographs of EUT......................................................................................A1 ~ A6 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 3 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A CERTIFICATE OF COMPLIANCE according to FCC Rules and Regulations Part 15 Subpart C Applicant Cisco-Linksys, LLC Address 121 Theory Drive Irvine, CA 92612 USA Equipment Wireless-G Print Server Model No. WPS54G FCC ID Q87-WPS54G I HEREBY CERTIFY THAT : The measurements shown in this test report were made in accordance with the procedures given in ANSI C63.4. The equipment was passed the test performed according to FCC Rules and Regulations Part 15 Subpart C (2002). The test was carried out on Sep. 14, 2004 at Exclusive Certification Corp. Signature Anson Chou / Manager Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 4 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A 1. Report of Measurements and Examinations 1.1. List of Measurements and Examinations FCC Rule . Description of Test Result 15.203 . Antenna Requirement Pass 15.207 . Conducted Emission Pass 15.209 . Radiated Emission Pass 15.247(a)(2) . 6dB Bandwidth Pass 15.247(b) . Maximum Peak Output Power Pass 15.247(c) . 100kHz Bandwidth of Frequency Band Edges Pass 15.247(d) . Power Spectral Density Pass 1.1307 1.1310 2.1091 2.1093 . RF Exposure Compliance Pass Test by: Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Is…

Text truncated - open the document above for the full version.

Test Report

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 25 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 26 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 27 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 28 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 29 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 30 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Test by: Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 31 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A 4.2.1. Photographs of Conducted Emission Test FRONT VIEW REAR VIEW Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 32 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A 4.3. RF Portion 4.3.1. Test Result of Conducted Emission Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 33 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 34 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 35 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A 4.3.2. Test Result of Radiated Emission Modulation Standard: IEEE 802.11b a) Emission frequencies below 1 GHz Channel LO Test Date: Sep. 14, 2004 Temperature: 24 Humidity: 63% Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 480.00 H 51.02 -6.55 44.47 46 -1.53 Q.P 100 1.0 800.18 H 43.66 0.73 44.39 46 -1.61 Q.P 120 1.0 33.88 V 48.22 -11.17 37.05 40 -2.95 Q.P 135 1.0 50.55 V 56.27 -19.69 36.58 40 -3.41 Peak 116 1.0 56.19 V 56.98 -19.75 37.23 40 -2.77 Q.P 160 1.0 800.18 V 43.84 0.72 44.56 46 -1.44 Q.P 105 1.0 Notes: 1. Result = Meter Reading + Corrected Factor 2. Corrected Factor = Antenna Factor + Cable Loss – Amplifier b) Emission frequencies above 1 GHz Channel LO Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 1591.5 H 55.94 -4.34 51.60 74 -22.40 Peak 196 1.5 1600.0 V 59.37 -4.88 54.49 74 -19.51 Peak 210 1.5 1600.0 V 54.57 -4.83 49.74 54 -4.26 Ave 215 1.5 1903.5 V 52.49 -3.16 49.33 74 -24.67 Peak 185 1.5 4823.0 V 51.10 6.46 57.56 74 -16.44 Peak 177 1.5 4823.0 V 35.72 6.48 42.20 54 -11.80 Ave 182 1.5 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 36 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Modulation Standard: IEEE 802.11b a) Emission frequencies below 1 GHz Channel MID Test Date: Sep. 14, 2004 Temperature: 24 Humidity: 63% Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 800.18 H 43.60 0.73 44.33 46 -1.67 Q.P 126 1.0 51.34 V 58.73 -20.07 38.67 40 -1.33 Q.P 96 1.0 56.19 V 56.91 -19.75 37.16 40 -2.84 Q.P 120 1.0 800.18 V 43.97 0.73 44.71 46 -1.29 Q.P 130 1.0 Notes: 1. Result = Meter Reading + Corrected Factor 2. Corrected Factor = Antenna Factor + Cable Loss – Amplifier b) Emission frequencies above 1 GHz Channel MID Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 1591.5 H 55.94 -4.34 51.60 74 -22.40 Peak 205 1.5 1600.0 V 59.77 -4.88 54.90 74 -19.10 Peak 225 1.5 1600.0 V 54.50 -4.83 49.67 54 -4.33 Ave 220 1.5 1903.5 V 52.37 -3.16 49.21 74 -24.79 Peak 192 1.5 4872.0 V 53.47 6.63 60.09 74 -13.91 Peak 185 1.5 4872.0 V 35.06 6.64 41.70 54 -12.30 Ave 192 1.5 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 37 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Modulation Standard: IEEE 802.11b a) Emission frequencies below 1 GHz Channel HI Test Date: Sep. 14, 2004 Temperature: 24 Humidity: 63% Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 800.18 H 42.81 0.73 43.54 46 -2.46 Q.P 120 1.0 51.34 V 58.12 -20.07 38.06 40 -1.94 Q.P 100 1.0 56.19 V 56.68 -19.75 36.93 40 -3.07 Peak 113 1.0 800.18 V 43.97 0.73 44.71 46 -1.29 Q.P 120 1.0 Notes: 1. Result = Meter Reading + Corrected Factor 2. Corrected Factor = Antenna Factor + Cable Loss – Amplifier b) Emission frequencies above 1 GHz Channel HI Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 1519.5 H 56.44 -4.34 52.10 74 -21.90 Peak 205 1.5 1600.0 V 59.66 -4.88 54.78 74 -19.22 Peak 210 1.5 1600.0 V 54.58 -4.33 49.75 74 -24.25 Ave 215 1.5 1903.5 V 52.83 -3.16 49.67 74 -24.33 Peak 200 1.5 4923.2 V 52.81 6.80 59.61 74 -14.39 Peak 185 1.5 4923.2 V 35.96 6.81 42.77 54 -11.23 Ave 178 1.5 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 38 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Modulation Standard: IEEE 802.11g a) Emission frequencies below 1 GHz Channel LO Test Date: Sep. 14, 2004 Temperature: 24 Humidity: 63% Frequency (MHz) Ant-Pol H/V Meter Reading (dBuV) Corrected Factor (dB) Result@3m (dBuV/m) Limit@3m (dBuV/m) Margin (dB) Remark Table Deg. Ant High (m) 800.18 H 43.39 0.7…

Text truncated - open the document above for the full version.

Test Report

Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 42 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A 4.4. 6dB Bandwidth Measurement Data (1) Modulation Standard: IEEE 802.11b Test Date: Sep. 8, 2004 Temperature: 24 Humidity: 62% a) Channel 01: 6dB Emission Bandwidth is 8.2 MHz b) Channel 06: 6dB Emission Bandwidth is 7.9 MHz c) Channel 11: 6dB Emission Bandwidth is 8.1 MHz (2) Modulation Standard: IEEE 802.11g Test Date: Sep. 8, 2004 Temperature: 24 Humidity: 62% a) Channel 01: 6dB Emission Bandwidth is 15.5 MHz b) Channel 06: 6dB Emission Bandwidth is 15.5 MHz c) Channel 11: 6dB Emission Bandwidth is 15.3 MHz Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 43 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 44 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 45 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 46 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A 4.5. Peak Output Power Measurement Data (1) Modulation Standard: IEEE 802.11b Test Date: Sep. 8, 2004 Temperature: 24 Humidity: 62% a) Channel 01: Output Peak Power is 16.00 dBm or 39.81 mW b) Channel 06: Output Peak Power is 16.60 dBm or 45.71 mW c) Channel 11: Output Peak Power is 16.78 dBm or 47.64 mW (2) Modulation Standard: IEEE 802.11g Test Date: Sep. 8, 2004 Temperature: 24 Humidity: 62% a) Channel 01: Output Peak Power is 16.60 dBm or 45.71 mW b) Channel 06: Output Peak Power is 17.14 dBm or 51.76 mW c) Channel 11: Output Peak Power is 17.23 dBm or 52.84 mW Note: Conducted Power = Reading Value + Cable Loss Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 47 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 48 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 49 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 50 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A 4.6. Band Edges Measurement Data (1) Modulation Standard: IEEE 802.11b Test Date: Sep. 8, 2004 Temperature: 24 Humidity: 62% a) Lower Band Edge: maximum value is -47.28 dBm that is attenuated more than 20dB b) Upper Band Edge: maximum value is -48.24 dBm that is attenuated more than 20dB (2) Modulation Standard: IEEE 802.11g Test Date: Sep. 8, 2004 Temperature: 24 Humidity: 62% a) Lower Band Edge: maximum value is -49.01 dBm that is attenuated more than 20dB b) Upper Band Edge: maximum value is -49.17 dBm that is attenuated more than 20dB Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 51 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 52 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 53 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 54 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 55 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 56 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 57 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A 4.6.1. Note on Band edge Emission Modulation Standard: IEEE 802.11b Test Date: Sep. 8, 2004 Temperature: 24 Humidity: 62% a) Channel 1 Fundamental Frequency: 2412 MHz Limit@3m (dBuV/m) Frequency (MHz) Level (dBV) Polarization Remark Peak Ave. Margin (dB) Table Deg. (Deg.) Ant High (m) 2375.892 50.08 H Peak 74 54 -23.92 196 1.5 2375.892 --- H Ave. 74 54 --- --- --- 2375.892 55.43 V Peak 74 54 -18.57 186 1.5 2354.064 45.02 V Ave. 74 54 -8.98 192 1.5 b) Channel 11 Fundamental Frequency: 2462 MHz Limit@3m (dBuV/m) Frequency (MHz) Level (dBuV) Polarization Remark Peak Ave. Margin (dB) Table Deg. (Deg.) Ant High (m) 2485.940 50.64 H Peak 74 54 -23.36 188 1.5 2485.940 --- H Ave. 74 54 --- --- --- 2485.864 58.47 V Peak 74 54 -15.53 182 1.5 2486.016 47.58 V Ave. 74 54 -6.42 200 1.5 Modulation Standard: IEEE 802.11g Test Date: Sep. 8, 2004 Temperature: 24 Humidity: 62% a) Channel 1 Fundamental Frequency: 2412 MHz Limit@3m (dBuV/m) Frequency (MHz) Level (dBuV) Polarization Remark Peak Ave. Margin (dB) Table Deg. (Deg.) Ant High (m) 2346.108 50.94 H Peak 74 54 -23.06 182 1.5 2346.108 --- H Ave. 74 54 --- --- --- 2389.764 55.20 V Peak 74 54 -18.80 200 1.5 2310.000 44.26 V Ave. 74 54 -9.74 212 1.5 b) Channel 11 Fundamental Frequency: 2462 MHz Limit@3m (dBuV/m) Frequency (MHz) Level (dBuV) Polarization Remark Peak Ave. Margin (dB) Table Deg. (Deg.) Ant High (m) 2485.636 50.68 H Peak 74 54 -23.32 196 1.5 2485.636 --- H Ave. 74 54 --- --- --- 2485.712 59.01 V Peak 74 54 -14.99 200 1.5 2486.016 48.16 V Ave. 74 54 -5.84 192 1.5 Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15, 2004 58 of 66 FCC ID: Q87-WPS54G FCC Test Report: FI04083001-A Modulation Standard: IEEE 802.11b Pol/Phase: Vertical Exclusive Certification Corp. Tel:886-2-2792-3366 Fax:886-2-2792-1100 Issued date: Sep. 15,…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Po-Wen Cheng(Regulatory Compliance Manager)
[email protected]949-238-4518Fax: 949-265-1429

Technical Contact

Exclusive Certification CorporationIvy Chen
[email protected]+886 2 2792 3366

4F-2, No. 28, Lane 78, Xing-Ai Road Β· Taipei City Β· Taiwan

Test Firm

Cerpass Technology CorporationAnson Chou
[email protected]886-2-27923366Fax: 886-2-27921100

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz53.00 mW
Confidentiality
Long Term
Grant Notes
Power Output listed is Conducted. The antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
