Q87-WPS54GU2Wireless-G Printer Server

A Division of Cisco Systems, Inc. ® Model No. Wireless 1 Quick Installation Guide GHz 2 802.11g 4 , WPS54GU2-UK PrintServer for USB 2.0 Wireless-G Package Contents • Wireless-G PrintServer for USB 2.0 • Setup Wizard CD-ROM • User Guide on CD-ROM • USB 2.0 Cable •Network Cable • Power Supply • Quick Installation 2 1 Before starting the physical installation, note the PrintServer’s Default Name, which is located on the bottom of the PrintServer. APlug one end of the Ethernet network cable into the PrintServer ’s LAN port. BConnect the other end to your networked hub, switch, or router. CUse the USB cable to connect your USB printer to the PrintServer ’s USB port. DUse the parallel printer cable (not included) to connect your parallel printer to the PrintServer’s parallel port. EPower on your printer. FPlug the power adapter’s cord into the PrintServer’s Power port. GPlug the power adapter into an electrical outlet. Connect the PrintServer A C D F 3 2 B Configure the PrintServer AInsert the Setup CD-ROM into the computer’s CD-ROM drive. The Setup Wizard should run automatically. If it does not, clickStart and choose Run. In the box that appears, enter D:\setupWizard.exe (if “D” is the letter of your CD-ROM drive). BOn the Welcome screen, click Setup Wizard. CThe Setup Wizard will search for the PrintServer. After it has been found, the screen in Figure C will appear. If this is the first time you have run the Setup Wizard, make sure that List only new (unconfigured) Print Servers is selected and your PrintServer is listed by its default server name. If you have previously configured the PrintServer, selectList all compatible Print Servers. Click Next. DOn the Password screen, enter the default password, admin. ClickEnter. EOn the Basic Settings screen, you may change the Device Name and Domain Name settings if you want. Then click Next. FTheIP Settings screen will appear. If your network uses a C D E 4 router that automatically assigns IP addresses, select Automatically obtain an IP address (DHCP) and click Next. If you need to assign the PrintServer a static IP address, selectSet IP configuration manually, and enter the IP Address, Subnet Mask, and Gateway in the fields provided. Then click Next. GOn the Set PrintServer’s Password screen, enter the PrintServer’s default password, admin, in the Current Password field. Enter a new password in the New Password field, and enter it again in the Verify Password field. Click Next. HOn the Wireless Settings screen, enter your wireless network’s SSID or name. If your network is set to ad-hoc mode, select the channel at which the network broadcasts its wireless signal. For the Network Type setting, select infrastructure if the PrintServer will communicate using an access point or wireless router. SelectAd-Hoc if the PrintServer will communicate directly with wireless-equipped computers. ClickNext. G F H 5 IOn the Wireless Security Settings screen, select a level of WEP encryption, 64 Bit Keys or128 Bit Keys. Then enter a Passphrase to automatically generate a WEP key. If you would like to enter your WEP key manually, leave the Passphrase field blank and enter the WEP key on the next screen. ClickNext. JIf you used a Passphrase, then a WEP key will appear on the following screen. Otherwise, enter your WEP key in the Key 1 field. Click Next. KOn the Confirmation screen, make sure your settings are correct. Click Yes to save your new settings. LOn the Congratulations screen, click User Install to install the PrintServer’s driver. K L J I 6 Linksys recommends that you set up your printer and install your printer’s driver before you install the PrintServer’s driver. AOn the Print Server Driver Setup Welcome screen, click Next. BOn the Choose Destination Location screen, select the location where the driver’s folder will be installed. If you want the folder to be installed in a different location, click Browse and select the location. Click Next. CThe Select Program Folder screen will appear. An icon will be added to the program folder listed. If you want, you may change the name of the program folder. Click Next. DAfter the driver is installed, the Setup Complete screen will appear. Make sure Configure Print Driver now is selected. ClickFinish to end the driver installation and begin the driver configuration. A 3 Install and Configure the PrintServer’s Driver B C D 7 F EDouble-click the Print Driver Setup icon on your desktop. If you do not see the icon, click Start,Programs,Print Server Utility, and Print Driver Setup. FRead the Information screen, and click OK. GOn the Printer Port Setup screen, select a printer port to add, and click Next. HYou will be informed that the PrintServer Port has been added successfully. Click OK. ITheConfigure Printer Port screen will appear. Your installed printer(s) will appear in theExisting Printers field. Select the printer you want, and click theConnect button to associate the printer with your selected printer port. To add another printer, click Add New Printer and follow the on- screen instructions. G I E H 8 JWhen you have finished configuring the PrintServer’s driver, click Close on the Printer Port Setup screen. Congratulations! The installation of the PrintServer is complete. For additional information or troubleshooting help, refer to the User Guide on the Setup CD- ROM. You can also call or e-mail for further support. E-mail Support United Kingdom and Ireland [email protected] Latin America [email protected] Website http://www.linksys.com/international or http://www.linksys.com/uk Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2003 Cisco Systems, Inc. All rights reserved. WPS54GU2-UK-QIG-31010NC JL J A Division of Cisco Systems, Inc. ® Modèle Sans fil 1 Guide d’installation rapide GHz 2 802.11g 4 , Serveur d’impression Sans fil-G WPS54GU2-FR Contenu de l'emballage • Serveur d'impression sans fil G USB 2…

Text truncated - open the document above for the full version.

1 Mike Kuo From: rick Sent: December162003Tuesday 4:45 AM To: Mike Kuo Subject: Re: CisCo-Linksys, LLC, FCC ID:Q87-WPS54GU2, AN03T3459 RE01.JPGRE02.JPGPCB1.JPGPCB2.JPGPCB3.JPGID Label.pdfspec (7).jpg antenna spec.pdf Dear Mike, Regarding your questions, please see the following: 1. This application is seeking for Printer Server approval. 2. Attached please find internal/setup photos, ID Label and specifications. Thank you very much for your greatly support. Best regards, Rick Hu ----- Original Message ----- From: "Mike Kuo" <[email protected]> Sent: Tuesday, December 16, 2003 8:15 AM Subject: FW: CisCo-Linksys, LLC, FCC ID:Q87-WPS54GU2, AN03T3459 > Hi Rick : > > I took this application from Chris Harvey. Below is the questions. > > M.Kuo > > -----Original Message----- > From: CERTADM > Sent: Monday, December 15, 2003 4:14 PM > To: Mike Kuo > Subject: CisCo-Linksys, LLC, FCC ID:Q87-WPS54GU2, AN03T3459 > > > Notice_content > ------------- > Question #1: The intend for this application is not clear. Is this > application seeking transmitter module approval or for Printer server > approval ? If this device is seeking for modular approval, please provide a > cover letter to address all 8 requirements per FCC public notice DA 001407. > > Question #2: If this device is for transmitter module approval, please > provide FCC ID label format that will be affixed on the mini-PCI module. > > Question #3: If this device is for Print Server approval, please remove the > wording " Contains an approved R F Module " from the FCC ID label format. > > Question #4: The test setup photo is not clear. During the radiated 2 > spurious emission tests, is the mini-PCI card placed outside the print > server ? > > Question #5: Please provide additional internal photos by removing the metal > plate on the mini-PCI card. > > Question #6: Based upon the information contains in the operational > description , you may want to consider to include operational description as > one of requested item in the request for confidentiality letter. > > Question #7 : Please provide antenna specification sheet. > > Best Regards > > Mike Kuo > The items indicated above must be submitted before processing can continue > on the above referenced application. Failure to provide the requested > information within 30 days of the original e-mail date may result in > application dismissal and forfeiture of the filing fee. Also, please note > that partial responses increase processing time and should not be submitted. > Any questions about the content of this correspondence should be directed to > the e-mail address listed below the name of the sender.

ETC Report No.: ET92S-10-163-03 Page A1 of A1 FCC ID: Q87-WPS54GU2 ANNEX A: EXTERNAL CONSTRUCTION PHOTOS OF EUT 1. Outside view 1 of EUT 2. Outside view 2 of EUT

1.80PP 2. 3. 4. 5. 0.2mm 9320LM3008 ®ø» ÈÀs /Li nks ys ( WPS54GU2) C onta ins an a pproved RF Module F CC ID: Q 87-WP S 54G U 2 T his Clas s ( B) digital appa ra tus complies with Ca na dian ICE S-003, RS S210.IC ID: 3839A-WP S54G U2

ETC Report No.: ET92S-10-163-03 Page B1 of B4 FCC ID: Q87-WPS54GU2 ANNEX B: INTERNAL CONSTRUCTION PHOTOS OF EUT 1. Inside view 1 of EUT 2. Inside view 2 of EUT ETC Report No.: ET92S-10-163-03 Page B2 of B4 FCC ID: Q87-WPS54GU2 3. Inside view 3 of EUT 4. Front view of PCB1 ETC Report No.: ET92S-10-163-03 Page B3 of B4 FCC ID: Q87-WPS54GU2 5. Rear view of PCB1 6. Front view of PCB2 ETC Report No.: ET92S-10-163-03 Page B4 of B4 FCC ID: Q87-WPS54GU2 7. Rear view of PCB2

WPS54G WPS54G Product NO: 0LM HW ID: 04C04D955C DATEVER. CHANGE HISTORY 03/27/030.1 New Draft 03/04/040.2 Power consumption and modify some register 03/06/030.3 LED modify 03/06/090.4 Parallel modify 03/06/090.5 Modify Ver 0.3 2003/6/03 WPS54G High Level Design GVP Chang Sercomm Confidential 12/3/2003 1:40 PM 2 Table of Contents Page 1. Introduction.......................................................................3 2. Function Description............................................................4 3. Block Diagram....................................................................6 4. Memory and I/O Mapping......................................................7 5. Interrupts...........................................................................8 6. DMA................................................................................8 7. Component Select................................................................8 8. Critical Component...............................................................9 9. Detail Function Design.........................................................10 10. Power Consumption Estimate................................................15 11. Power Specification...........................................................15 12. PCB Specification.............................................................16 13. Thermal Estimate..............................................................16 14. Environment.....................................................................16 15. EMC Certification..............................................................16 16. Appendix A – CPU Register Settings.......................................17 17. Appendix B –Performance Estimate........................................24 18. Appendix C – Register Compare.............................................27 19. Appendix D – Revise list......................................................28 Ver 0.3 2003/6/03 WPS54G High Level Design GVP Chang Sercomm Confidential 12/3/2003 1:40 PM 3 1. INTRODUCTION The WPS54G project is to develop a faster printer, which with 802.11g wireless module, USB2.0 and one parallel port by mini PCI interface, with one LAN port (10/100Mbps Ethernet). This product uses Brecis MSP2007 microcontroller, which include two 10Mbps/100Mbps Ethernet MAC controllers and one mini PCI bus. Ver 0.3 2003/6/03 WPS54G High Level Design GVP Chang Sercomm Confidential 12/3/2003 1:40 PM 4 2. FUNCTION DESCRIPTION This project uses the Brecis MSP2007 CPU the microcontroller and it offers a memory configuration of 4M bytes Flash and 256M bytes SDRAM. This device supports 10/100 Base-TX LAN network interfaces using Davicom DM9161 as the PHY controller. The interface to the LAN network is through an RJ45 STP port. A parallel port is available with I/O transmission by AT7601F. USB print port uses NEC uPD720101 host controller, which fully compliant USB specification 2.0. WE support one USB ports. Using WLAN module using mini PCI wireless module. There are eight LEDs to indicate the status of the device and LAN network connection: LAN has two, WLAN has one, and Parallel has two, USB has two. This device derives its power from a 12V DC @ 1A power adapter which needs to be converted to 2.5V, 3.3V and 5V DC. The functional requirements of the system are as follows: 1. CPU Brecis MSP2007 2. CODE SIZE 1M bytes, HY29LV800TT-70 3. SDRAM 4M bytes, IS42S16100-7T 4. PHY Davicom DM9161 5. USB NEC uPD720101 6. LAN Port One RJ45 STP Port 7. Printer Port One parallel port 8. USB Port One USB ports 9. Power Adapter 12V 1A 10. Debug Support Can Connect to JTAG interface for S/W Development 11. EMC FCC, CE , VCCI Class–B 12. PCB Spec. 105 x 135 x 30 mm, 4 layer. 13. Wireless module Mini PCI module 14. Printer controller AT7601F Ver 0.3 2003/6/03 WPS54G High Level Design GVP Chang Sercomm Confidential 12/3/2003 1:40 PM 5 LED: LEDColor(s)ActivityDesc. BlinkingBooting / System Self-Test / Firmware upgrade OnError StatusOrange OffNo Ethernet Link Green OnEthernet Link Green Blinking Traffic Orange Blinking Collision EthernetGreen + Orange OffNo Wireless Link. (if wireless initiate failed) Green On802.11g module is functional. Green Blinking Sending/Receiving Wireless-G Green OffNo printer is connected Green OnPrinter is connected. Green Blinking Sending data Orange OnProblem on printer Parallel Port Green + Orange OffNo printer is connected Green OnPrinter is connected. Green Blinking Sending data Orange OnProblem on printer USB PortGreen + Orange OffNo printer is connected OnPower onPowerGreen OffPower Off Ver 0.3 2003/6/03 WPS54G High Level Design GVP Chang Sercomm Confidential 12/3/2003 1:40 PM 6 3. BLOCK DIAGRAM System BUS CPU BRECIS MSP2007 Rate = 4 Flash RAM 1M Bytes SDRAM 4M Bytes PHY controller DM9161-25MHz USB controller UPD721010 Parallel Port AT7601F LEDs LAN port RJ45 STP USB Connect Print Port DB25 STP Mini PCI module Ver 0.3 2003/6/03 WPS54G High Level Design GVP Chang Sercomm Confidential 12/3/2003 1:40 PM 7 4. MEMORY AND I/O MAPPING 4.1 Memory Mapping There are three types of memory used in the system, Flash Memory, USB Memory and DRAM. Flash Memory is used for program, USB memory is used for USB transitions buffer and DRAM is used for system buffer. - The address space reserved for the Flash Memory is shown in the table below: Size Logical address Chip Selects Bus Width 1M 0xBFC0_0000 ~ 0xBFCF_FFFF -CS0 8 bits INTEL 8-Bit Non-Muxed Mode - The address space reserved for the USB Memory is shown in the table below: Size Logical address PCI Bus Width 32 - The address space reserved for the Wireless module is shown in the table below: Size Logical address PCI Bus Width 32 - The address space reserved for the Parallel port is shown in the table below: Size Logical address I/O Bus Width 4M 0xBE00_0000~0xBE3F_FFFF -CS1 8 - The address space reserved for DRAM is shown in the table below: Size Logical address SDRAM Bus Width 4M 0x0000_0000 ~ 0x003F_FFFF -SDR 32 bits The access time …
