Q87-WRT600NV11Dual-Band Wireless-N Gigabit Router w/ Storage Lin

LINKSYS LLC

Click to zoom

Application Details

Equipment Class: NII - Unlicensed National Information Infrastructure TX
Date of Grant: Oct 24, 2007
Application Purpose: Original Equipment
Date of Application: May 04, 2007
Equipment Note: Dual-Band Wireless-N Gigabit Router w/ Storage Lin
Frequency Range: 5180.00000000 - 5320.00000000
Company: LINKSYS LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Model No. Gigabit Router with Wireless-N WRT600N User Guide WIRELESS Storage Link Dual-Band 802.11g GHz 5 Dual-Band 4 2 . GHz 802.11a Dual-Band Wireless-N Gigabit Router with Storage Link Copyright and Trademarks Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2006 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders. How to Use This User Guide This User Guide has been designed to make understanding networking with the Wireless-N Gigabit Router with Storage Link easier than ever. Look for the following items when reading this User Guide: In addition to these symbols, there are definitions for technical terms that are presented like this: Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like this: Figure numbers and descriptions can also be found in the “List of Figures” section in the “Table of Contents”. This exclamation point means there is a caution or warning and is something that could damage the Router. This checkmark means there is a note of interest and is something you should pay special attention to while using the Wireless-N Gigabit Router with Storage Link. This question mark provides you with a reminder about something you might need to do while using the Wireless-N Gigabit Router with Storage Link. word: definition. Figure 0-1: Sample Figure Description WRT600NN-UG-61122NC BW WARNING:This product contains chemicals, including lead, known to the State of California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling. Dual-Band Wireless-N Gigabit Router with Storage Link Table of Contents Chapter 1: Introduction1 Welcome1 What’s in this User Guide?2 Chapter 2: Planning Your Wireless Network4 Network Topology4 Ad-Hoc versus Infrastructure Mode4 Network Layout5 Chapter 3: Getting to Know the Wireless-N Gigabit Router with Storage Link6 The Back Panel6 The Front Panel7 The Top Panel7 Chapter 4: Connecting the Wireless-N Gigabit Router with Storage Link8 Hardware Installation8 Chapter 5: Configuring the Wireless-N Gigabit Router with Storage Link9 Overview9 How to Access the Web-based Utility11 The Setup Tab - Basic Setup11 The Setup Tab - DDNS17 The Setup Tab - MAC Address Clone19 The Setup Tab - Advanced Routing20 The Wireless Tab - Basic Wireless Settings22 The Wireless Tab - Wireless Security24 The Wireless Tab - Wireless MAC Filter27 The Wireless Tab - Advanced Wireless Settings28 The Security Tab - Firewall30 The Security Tab - VPN Passthrough31 The Storage Tab - Disk32 The Storage Tab - Media Server33 The Storage Tab - FTP Server34 The Storage Tab - Administration36 The Access Restrictions Tab - Internet Access Policy38 The Applications & Gaming Tab - Single Port Forwarding40 Dual-Band Wireless-N Gigabit Router with Storage Link The Applications & Gaming Tab - Port Range Forwarding41 The Applications & Gaming Tab - Port Range Triggering42 The Applications & Gaming Tab - DMZ43 The Applications and Gaming Tab - QoS44 The Administration Tab - Management47 The Administration Tab - Log49 The Administration Tab - Diagnostics50 The Administration Tab - Factory Defaults51 The Administration Tab - Firmware Upgrade52 The Status Tab - Router53 The Status Tab - Local Network54 The Status Tab - Wireless55 Appendix A: Troubleshooting56 Common Problems and Solutions56 Frequently Asked Questions64 Appendix B: Wireless Security70 Security Precautions70 Security Threats Facing Wireless Networks70 Appendix C: Upgrading Firmware73 Appendix D: Windows Help74 Appendix E: Finding the MAC Address and IP Address for your Ethernet Adapter75 Windows 98SE or Me Instructions75 Windows 2000 or XP Instructions76 For the Router’s Web-based Utility76 Appendix F: Glossary77 Appendix G: Specifications82 Appendix H: Warranty Information84 Appendix I: Regulatory Information85 Appendix J: Contact Information91 Dual-Band Wireless-N Gigabit Router with Storage Link List of Figures Figure 3-1: The Router’s Back Panel6 Figure 3-2: The Router’s Front Panel7 Figure 3-3: The Router’s Top Panel7 Figure 4-1: Connect the USB cable8 Figure 4-2: Connect the internet8 Figure 4-3: Connect the ethernet8 Figure 4-4: Connect the power8 Figure 5-1: Router Login11 Figure 5-2: Setup Tab - Basic Setup (Automatic Configuration - DHCP)11 Figure 5-3: Static IP12 Figure 5-4: PPPoE12 Figure 5-5: PPTP13 Figure 5-6: Telstra Cable14 Figure 5-7: L2TP14 Figure 5-8: DHCP Reservation16 Figure 5-9: Setup Tab - DynDDNS.org17 Figure 5-10: Setup Tab - TZO.com18 Figure 5-11: Setup Tab - MAC Clone19 Figure 5-12: Setup Tab - Advanced Routing20 Figure 5-13: Routing Table21 Figure 5-14: Wireless Tab - Basic Wireless Settings22 Figure 5-15: Wireless Tab - Wireless Security (WPA-Personal)24 Figure 5-16: Wireless Security - WPA2-Personal24 Figure 5-17: Wireless Security - WPA-Enterprise25 Figure 5-18: Wireless Security - WPA2-Enterprise25 Figure 5-19: Wireless Security - RADIUS26 Figure 5-20: Wireless Security - WEP26 Figure 5-21: Wireless Tab - Wireless MAC Filter27 Figure 5-22: Wireless Client List27 Figure 5-23: Wireless Tab - Advanced Wireless Settings28 Figure 5-24: Security Tab - Firewall30 Dual-Band Wireless-N Gigabit Router with Storage Link Figure 5-25: VPN Passthrough31 Figure 5-26: Storage Tab - Disk32 Figure 5-27: Storage Tab - Shared Folder32 Figure 5-28: Storage Tab - Media Server33 Figure 5-29: Media Folder33 Figure 5-30: Storage Tab - FTP Server34 Figure 5-31: FTP Folder34 Figure 5-32: Storage Tab - Administration36 Figure 5-33: User Account36 Figure 5-34: Group Account37 Figure 5-35: Access Restrictions Tab - Internet Access Policy38 Figure 5-36: Summary38 Figure 5-37: List of PCs39 Figure 5-38: Applications & Gaming Tab - Single Port Forwarding40 Figure 5-39: Applications & Gaming Tab - Port Range Forwarding41 F…

Text truncated - open the document above for the full version.

Users Manual

44 Chapter 5: Configuring the Wireless-N Gigabit Router with Storage Link The Applications and Gaming Tab - QoS Dual-Band Wireless-N Gigabit Router with Storage Link The Applications and Gaming Tab - QoS Quality of Service (QoS) ensures better service to high-priority types of network traffic, which may involve demanding, real-time applications, such as videoconferencing. QoS (Quality of Service) Wireless The Router features Wireless QoS. The No Acknowledgement feature is available only when the Wireless QoS Support feature is enabled. Wireless QoS. If you have other devices on your network that support Wireless QoS, select Enabled. Otherwise, keep the default, Disabled. No Acknowledgement. If you want to disable the Router’s Acknowledgement feature, so the Router will not re- send data if an error occurs, then keep the default, Enabled. Otherwise, select Disabled. Internet Access Priority In this section, you can set the bandwidth priority for a variety of applications and devices. There are four levels priority: High, Medium, Normal, or Low. When you set priority, do not set all applications to High, because this will defeat the purpose of allocating the available bandwidth. If you want to select below normal bandwidth, select Low. Depending on the application, a few attempts may be needed to set the appropriate bandwidth priority. Enabled/Disabled. To use the QoS policies you have set, select Enabled. Otherwise, select Disabled. Category There are four categories available. Select one of the following: Applications, Online Games, MAC Address, Ethernet Port, or Voice Device. Proceed to the instructions for your selection. Applications Applications. Select the appropriate application. If you select Add a New Application, follow the Add a New Application instructions. Priority. Select the appropriate priority: High, Medium, Normal, or Low. Click the Add button to save your changes. Your new entry will appear in the Summary list. Figure 5-43: Applications & Gaming Tab - QoS (Applications) 45 Chapter 5: Configuring the Wireless-N Gigabit Router with Storage Link The Applications and Gaming Tab - QoS Dual-Band Wireless-N Gigabit Router with Storage Link Add a New Application Enter a NameEnter any name to indicate the name of the entry. Port RangeEnter the port range that the application will be using. For example, if you want to allocate bandwidth for FTP, you can enter 21-21. If you need services for an application that uses from 1000 to 1250, you enter 1000-1250 as your settings. You can have up to three ranges to define for this bandwidth allocation. Port numbers can range from 1 to 65535. Check your application's documentation for details on the service ports used. Select the protocol TCP or UDP, or select Both. PrioritySelect the appropriate priority: High, Medium, Normal, or Low. Click the Add button to save your changes. Your new entry will appear in the Summary list. Online Games Games. Select the appropriate game. Priority. Select the appropriate priority: High, Medium, Normal, or Low. Click the Add button to save your changes. Your new entry will appear in the Summary list. MAC Address Enter a Name. Enter a name for your device. MAC Address. Enter the MAC address of your device. Priority. Select the appropriate priority: High, Medium, Normal, or Low. Click the Add button to save your changes. Your new entry will appear in the Summary list. Ethernet Port Ethernet. Select the appropriate Ethernet port. Priority. Select the appropriate priority: High, Medium, Normal, or Low. Click the Add button to save your changes. Your new entry will appear in the Summary list. Figure 5-44: QoS - Applications (Add a New Application) Figure 5-45: QoS - Online Games Figure 5-46: QoS - MAC Address Figure 5-47: QoS - Ethernet 46 Chapter 5: Configuring the Wireless-N Gigabit Router with Storage Link The Applications and Gaming Tab - QoS Dual-Band Wireless-N Gigabit Router with Storage Link Voice Device Enter a Name. Enter a name for your voice device. MAC Address. Enter the MAC address of your voice device. Priority. Select the appropriate priority: High, Medium, Normal, or Low. Click the Add button to save your changes. Your new entry will appear in the Summary list. Summary This lists the QoS entries you have created for your applications and devices. PriorityThis displays the bandwidth priority of High, Medium, Normal, or Low. NameThis displays the application, device, or port name. InformationThis displays the port range or MAC address entered for your entry. If a pre-configured application or game was selected, there will be no valid entry shown in this section. RemoveClick this button to remove an entry. EditClick this button to make changes. When you have finished making changes to this screen, click the Save Settings button to save the changes, or click the Cancel Changes button to undo your changes. For more information, click Help. Figure 5-48: QoS - Voice Device 47 Chapter 5: Configuring the Wireless-N Gigabit Router with Storage Link The Administration Tab - Management Dual-Band Wireless-N Gigabit Router with Storage Link The Administration Tab - Management When you click the Administration tab, you will see the Management screen. This screen allows you to change the Router’s access settings and configure the UPnP (Universal Plug and Play) features. You can also back up and restore the Router’s configuration file. Management Router Access To ensure the Router’s security, you will be asked for your password when you access the Router’s Web-based Utility. The default password is admin. Router Password. Router Password and Re-enter to Confirm. It is recommended that you change the default password to one of your choice. Enter a new Router password and then enter it again in the Re-enter to Confirm field. Web Access Web Utility Access. HTTP (HyperText Transport Protocol) is the communications protocol used to connect to servers on the World Wide Web. HTTPS uses SSL (Secured Socket Layer) to enc…

Text truncated - open the document above for the full version.

Users Manual

Text truncated - open the document above for the full version.

Attestation Statements

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 April 20, 2007 Elliott TCB 684 West Maude Ave. Sunnyvale, CA. 94085 Subject: FCC ID: Q87-WRT600NV1 Gentlemen: We hereby confirm that the user will not have access to any controls (HW or SW) that would allow the user to configure the device to transmit on a frequency outside of the allowed US / Canada operating bands. Sincerely, Jennifer Yu / Project Manager

Attestation Statements

Page 1 of 1 ElliottTCB 684 West Maude Avenue Sunnyvale, CA 94085 Dear TCB reviewer, The WRT600N device also requires a +/- 20 ppm XTAL over temperature and with aging. This is required per the 802.11a specification. Based on the tolerance of the XTAL and the 20 MHz guard band at 5.15GHz the device will maintain emissions within the UNII 1 bands under normal operating conditions specified in the user manual. Regards, Juan Martinez Sr. EMC Engineer

Cover Letter(s)

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 April 3, 2007 Gentlemen: This is your letter of authorization to accept our appointment of Elliott Laboratories, Inc. as Agent for Cisco-Linksys LLC, located at 121 Theory Drive Irvine, CA 92617 (USA), to sign applications before the Commission and to make representations to you on our behalf. Elliott Laboratories is to receive and exchange data between our company and the Commission. This authorization is made pursuant to Section 2.911(c) of the FCC Rules and expires until further notice. I hereby certify on behalf of Cisco-Linksys LLC, located at 121 Theory Drive Irvine, CA 92617 (USA) ("Applicant") that neither Applicant nor any party to the application (officers, directors, and 5% shareholders) is subject to a denial of Federal benefits that includes FCC benefits pursuant to section 5301 of the Anti-Drug Abuse Act of 1988. 21 U.S.C. 853a. Sincerely, Jennifer Yu / Project Manager

Cover Letter(s)

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 April 3, 2007 Dear Examiner: I am writing to avoid the possibility of an inadvertent disclosure of proprietary information. The accompanying Form 731 is being filed with the commission on our behalf by Elliott Laboratories, Inc., a consulting and testing laboratory. Included as exhibits with the enclosed application are block diagrams, schematics, and a detailed description of the theory of operation of the device. It is our intention to provide the commission with a full disclosure of our product so that its merits can be evaluated. Indeed, we are pleased to provide any further information that the commission might wish to see. It is not our intention, however, to make our proprietary process a matter of public record. In view of the fact that the block diagrams, schematics, and associated theory of operation disclose the mechanism of our process, we ask that these portions (block diagrams, schematics, and theory of operation) of our application be withheld from public inspection as provided under FCC section 0.459. These documents contain details of the proprietary operation of product. These details are not readily discernible - even to technically sophisticated individuals - from our hardware and constitute trade secrets. We request therefore that these documents and this letter be segregated from the body of our evaluation report and withheld from public inspection. Thank you for your attention. Please let the undersigned know if the Commission disagrees with our position or requires further justification. Sincerely, Jennifer Yu / Project Manager

Cover Letter(s)

April 30, 2007 Office of Engineering and Technology Federal Communication Commission 445 12th Street, SW Washington, DC 20554 Gentlemen: The enclosed documents constitute a formal submittal and application for a Grant of Equipment Authorization pursuant to the following: Subpart E of Part 15 of FCC Rules (CFR 47) , UNII Devices RSS-210, Issue 6, September 2005, “Low-power Licence-exempt Radiocommunication Devices (All Frequency Bands): Category I Equipment” Data within this report demonstrates that the equipment tested complies with the relevant limits for unlicensed wireless devices. Elliott Laboratories, as duly authorized agent prepared this submittal. A copy of the letter of our appointment as agent is enclosed. If there are any questions or if further information is needed, please contact Elliott Laboratories for assistance. Sincerely, Juan Martinez Senior EMC Engineer JM/dmg Enclosures: Agent Authorization Letter Emissions Test Report with Exhibits

Cover Letter(s)

Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 (USA) Phone: 949-261-1288 Fax: 949-823-3002 Date: October 1, 2007 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Subject: FCC ID: Q87-WRT600NV11 Dear Examiner, Please accept this letter as an authorization for Broadcom to contact you and discuss with you directly about the subject application, concerning current status and additional requirements if any. If you have any questions regarding this authorization, please feel free to contact me. Sincerely, Jennifer Yu / Program Manager Cisco-Linksys LLC 121 Theory Drive Irvine, CA 92617 Direct: 949-823-3188 Fax: 949-823-3002 [email protected]

RF Exposure Info

... ... ... ... . ... ... ... ... ... ... RF Antenna Cable Assembly Specification 1. Electrical Properties : 1.1Frequency Range.........4.9GHz ~ 5.825GHz 1.2 Impedance .................. 50 Nominal 1.3VSWR ..................... 1.92 Max. 1.4Return Loss...............-10 dB Maximum 1.5Radiation .................. Directional 1.6Gain(peak)...................5GHz 3.9dBi (including Cable loss) 1.7Cable Loss.................. 5G : 0.85dB 1.8Polarization............... Linear Vertical 1.9Admitted Power............1W 2. Physical Properties : 2.1Cable........................1.32 Coaxial Cable 2.2Operating Temp. .........-20 ~ +65 2.3Storage Temp. ............-30 ~ +75 2.4PIFA........................Copper 2.5Connector.................. HRS Connector 1 2 RF Antenna Assembly P/NO : C210-510391A 3 2007/4/4 RF Antenna Assembly P/NO SPEC :5GHz 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-V.nsi 4.9GHz Gain = 3.41142 dBi Gain = -4.68568 dBi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-V.nsi 5.15GHz Gain = 2.69709 dBi Gain = -3.37781 dBi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-V.nsi 5.25GHz Gain = 3.74096 dBi Gain = -3.36081 dBi 4 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-V.nsi 5.35GHz Gain = 3.32047 dBi Gain = -5.06414 dBi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-V.nsi 5.725GHz Gain = 2.6845 dBi Gain = -5.20223 dBi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-H.nsi 0 345 330 315 300 285 270 255 240 225 210 195 180 165 150 135 120 105 90 75 60 45 30 15 -20-100 dB Far-field amplitude of 5G-PIFA-V.nsi 5.825GHz Gain = 2.9865 dBi Gain = -3.8171 dBi 2007/4/4 5

RF Exposure Info

Anne Liang Subject: FW: abot the maximum antenna gain of WRT600N Page 1 of 1 冰河 4/9/2007 From: Kevin_Lee-李宗晟 [mailto:[email protected]] Sent: Thursday, March 22, 2007 7:37 AM To: David Boldy Subject: FW: abot the maximum antenna gain of WRT600N When lie down When stand Daniel Tai 戴思良/業務行銷處譁裕實業股份有限公司新竹市公道五路二段326號 TEL：886-3-5714225 EXT.1507 FAX：886-3-601-1000 MB：0982-862143 E-MAIL：[email protected] Web Site：www.whayu.com Diple antenna PiFA antennaPCB antenna 2.4G 3.0 2.5 1.9 5150-5350 3.7 3.7 2.5 5470-5725 3.0 3.3 2.7 5725-5825 2.8 2.9 2.8 Diple antenna PiFA antennaPCB antenna 2.4G 3.6 1.5 1.9 5150-5350 3.7 1.8 2.9 5470-5725 1.8 1.6 2.7 5725-5825 2.3 1.5 3.3

RF Exposure Info

What is the name and model name of this antenna? What is the name and model name of this antenna? I need a photo of the PCB antenna. Also need name and model name of it too.

RF Exposure Info

Dipole antenna, C210- 510388-A AN1 Dipole antenna, C210- 510388-A AN2, AN3 Dipole antenna, C210- 510388-A AN4 PIFA antenna, C210-510391-A & C210- 510389-A. You can see the antenna drawing the spec files.

RF Exposure Info

Formula is: 1 940.78 8.7 Peak Average dBm W W dBm 2400 - 2483.5 CCK - 21.5 6.6 28.1 0.65 11 1 0.646 28.10 5150 - 5750 OFDM - 18.0 6.7 24.7 0.30 30 1 0.295 24.70 2 0.941 29.73 Please not that under "Antenna Gain (Max)" normal gain for 2.4GHz is 3.6dBi and 5GHz is 3.7dBi. In this MPE calculation used the MIMO antenna gain, which doubles due to the coherent nature of the device. 2400 - 5725 0.19 Distance where Pd = Limit (cm) Channels Available Frequency (MHz) MPE Limit (mW/cm 2 ) Eirp (mW) Pd at 20cm (mW/cm 2 ) Channels Used MPE Calculations (Fixed Location) The device is not a portable device (i.e. intended to be worn on the body or be hand-held), so it is classified as a fixed moun ted device. The user’s manual specifies a minimum separation distance of at least 20cm, consistent with this classification. FCC part 1.1310, Table 1 limits the power density for uncontrolled exposure. The power density, Pd (mW/cm2 ) calculated from t he maximum EIRP, Pt (mW) and the distance, d (m), between the transmitting antenna and the closest person, can be calculated using: Pd = Pt / (4*pi*d 2 ) Total EIRP Totals: MPE exposure is based on two 2.4GHz with two 5GHz transmitter. Device can be programmed to transmitt simultaneously. Band Mode Output Power Antenna gain (Max) EIRP
