Q87-WUSB11V4Wireless USB Network Adapter

A Division of Cisco Systems, Inc. ® Model No. USB Network Adapter Wireless-B WUSB11 User Guide WIRELESS GHz 2.4 802.11b Wireless-B USB Network Adapter Copyright and Trademarks Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2003 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders. This User Guide The User Guide to the Wireless-B USB Network Adapter has been designed to make understanding networking easier than ever. Look for the following items when reading this guide: In addition to these symbols, there are definitions for technical terms that are presented like this: Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like this: Figure numbers and descriptions can also be found in the "List of Figures" section in the “Table of Contents”. This exclamation point means there is a Caution or warning and is something that could damage your property or the USB Network Adapter. word: definition. This checkmark means there is a Note of interest and is something you should pay special attention to while using the USB Network Adapter. This question mark provides you with a reminder about something you might need to do while using the USB Figure 0-1: Sample Figure Description wusb11 v3-UG-31029NC KL Wireless-B USB Network Adapter Table of Contents Chapter 1: Introduction1 Welcome1 What’s in this Guide?2 Chapter 2: Planning your Wireless Network4 Network Topology4 Roaming4 Network Layout5 Chapter 3: Getting to Know the USB Network Adapter6 The USB Port6 The LED Indicators6 Chapter 4: Software Installation and Configuration for Windows 98SE, Me, and 2000 7 The Installation Procedure8 Chapter 5: Hardware Installation11 Connecting the Adapter11 Using the Adapter’s Wall Mount13 Chapter 6: Driver Installation and Configuration for Windows XP15 Windows XP Wireless Zero Configuration16 Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and 200018 Accessing the WLAN Monitor18 Link Information18 Site Survey20 Profiles21 Creating a New Profile23 Appendix A: Troubleshooting27 Common Problems and Solutions27 Frequently Asked Questions28 Appendix B: Wireless Security31 Security Precautions31 Security Threats Facing Wireless Networks31 Appendix C: Windows Help34 Appendix D: Glossary35 Wireless-B USB Network Adapter Appendix E: Specifications38 Appendix F: Warranty Information40 Appendix G: Regulatory Information41 Appendix H: Contact Information44 Wireless-B USB Network Adapter List of Figures Figure 3-1: Back Panel6 Figure 3-2: Front Panel6 Figure 4-1: The Setup Wizard’s Welcome screen7 Figure 4-2: The Setup Wizard’s License Agreement8 Figure 4-3: The Setup Wizard’s Network Mode screen8 Figure 4-4: The Setup Wizard’s Wireless Channels screen9 Figure 4-5: The Setup Wizard’s Finalize Settings screen9 Figure 4-6: The Setup Wizard’s Congratulations Screen10 Figure 5-1: How the Adapter connects to your PC11 Figure 5-2: The Adapter’s USB Port11 Figure 5-3: A PC’s USB port11 Figure 5-4: The Adapter’s LEDs12 Figure 5-5: Positioning the LEDs antenna12 Figure 5-6: The Adapter’s Wall Mount13 Figure 5-7: Using the Wall Mount - Step A13 Figure 5-8: Using the Wall Mount - Step B14 Figure 5-9: Using the Wall Mount - Step C14 Figure 6-1: Install Software Automatically15 Figure 6-2: wizard Finished15 Figure 6-3: The Zero Configuration Icon16 Figure 6-4: Zero Configuration Connection without WEP16 Figure 6-5: Zero Configuration Connection with WEP17 Figure 6-6: Zero Configuration Active Wireless Connection17 Figure 7-1: The WLAN Monitor icon18 Figure 7-2: The Link Information screen18 Figure 7-3: More Link Information19 Figure 7-4: Site Survey20 Figure 7-5: WEP Encryption20 Figure 7-6: Profiles21 Figure 7-7: Importing a Profile22 Wireless-B USB Network Adapter Figure 7-8: Exporting a Profile22 Figure 7-9: Creating a New Profile23 Figure 7-10: Enter Profile Name23 Figure 7-11: Network Settings for New Profile24 Figure 7-12: Network Mode for New Profile24 Figure 7-13: Wireless Channels for New Profile25 Figure 7-14: Security Settings for New Profile25 Figure 7-15: Confirm New Settings for New Profile26 Figure 7-16: Congratulations for New Profile26 1 Chapter 1: Introduction Welcome Wireless-B USB Network Adapter Chapter 1: Introduction Welcome Thank you for choosing the Wireless-B USB Network Adapter. With this Adapter, your wireless networking experience will be faster and easier than ever. How does the Adapter do this? Like all wireless products, the Adapter allows for greater range and mobility within your wireless network. Connecting to your PC via the USB port means that this Adapter leaves the PC’s slots open for other purposes. This adapter communicates over the 802.11b wireless standard, one of the most popular wireless standards, to communicate with your network. But what does all of this mean? Networks are useful tools for sharing computer resources. You can access one printer from different computers and access data located on another computer's hard drive. Networks are even used for playing multiplayer video games. So, networks are not only useful in homes and offices, they can also be fun. PCs equipped with wireless cards and adapters can communicate without cumbersome cables. By sharing the same wireless settings, within their transmission radius, they form a wireless network. Use the instructions in this Guide to help you connect the Access Point, set it up, and configure it to bridge your different networks. These instructions should be all you need to get the most out of the Access Point. 802.11b: an IEEE wireless networking standard that specifies a maximum data transfer rate of 11Mbps and an operating frequency of 2.4GHz. adapter: a device that adds network functionality to your PC. network: a series of computers or dev…

Text truncated - open the document above for the full version.

15 Chapter 6: Driver Installation and Configuration for Windows XP Wireless-B USB Network Adapter Chapter 6: Driver Installation and Configuration for Windows XP After connecting the Adapter to your computer, you will install the driver and configure the Adapter. 1. Windows XP will automatically detect the Adapter. Insert the Setup CD-ROM into your CD-ROM drive. Click the radio button next to Install the software automatically (Recommended). Then click the Next button. 2. When Windows has finished installing the driver, click the Finish button. You have now completed the driver installation for the Wireless-B USB Network Adapter. To configure the Adapter, proceed to the next section, “Windows XP Wireless Zero Configuration.” IMPORTANT:Do NOT run the Wireless-B USB Network Adapter Setup Wizard. If the Setup Wizard runs automatically after the Setup CD-ROM has been inserted, click the Exit button. Figure 6-1: Install Software Automatically Figure 6-2: wizard Finished 16 Chapter 6: Driver Installation and Configuration for Windows XP Windows XP Wireless Zero Configuration Wireless-B USB Network Adapter Windows XP Wireless Zero Configuration 1. After installing the Adapter, the Windows XP Wireless Zero Configuration icon will appear in your computer’s system tray. Double-click the icon. 2. The screen that appears will show any available wireless network. Select the network you want. If this network has WEP encryption enabled, go to step 3. If this network does not have WEP encryption enabled, make sure the box next to Allow me to connect to the selected wireless network, even though it is not secure is checked. Then click the Connect button, and go to step 4. encryption: encoding data transmitted in a network. NOTE:Windows XP has a built-in configuration tool. Use Windows XP Wireless Zero Configuration (in the system tray at the bottom of your screen) to configure the Adapter. NOTE:Steps 2 and 3 are the instructions and screenshots for Windows XP with Service Pack 1 installed. If you have not installed Service Pack 1, select the network you want, and click the Connect button. If the network has WEP encryption enabled, enter the WEP key in the Network key field, and then click the Connect button. Figure 6-3: The Zero Configuration Icon Figure 6-4: Zero Configuration Connection without WEP 17 Chapter 6: Driver Installation and Configuration for Windows XP Windows XP Wireless Zero Configuration Wireless-B USB Network Adapter 3. If WEP is enabled, enter the WEP key of your wireless network in the Network key field, and re-enter it in the Confirm network key field. Then, click the Connect button, and go to step 4. 4. The Zero Configuration icon will show a wireless connection when your connection is active. For more information about wireless networking on a Windows XP computer, click Start and then Help and Support. Enter the keyword wireless in the field provided, and press the Enter key. Congratulations! The installation of the Wireless-B USB Network Adapter is complete. Figure 6-5: Zero Configuration Connection with WEP NOTE:Windows XP Wireless Zero Configuration does not support the use of a passphrase. Enter the exact WEP key used by your access point. Figure 6-6: Zero Configuration Active Wireless Connection 18 Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and 2000 Accessing the WLAN Monitor Wireless-B USB Network Adapter Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and 2000 Use the WLAN Monitor to check the link information, search for available wireless networks, or create profiles that hold different configuration settings. Accessing the WLAN Monitor After installing the Adapter, the Wireless-B USB Network Adapter WLAN Monitor icon will appear in your system tray. Double-click the icon. The Link Information screen will appear. From this screen, you can find out how strong the current wireless signal is and how good the connection’s quality is. You can also click the More Information button to view additional status information about the current wireless connection. To search for available wireless networks, click the Site Survey tab. To perform configuration changes, click the Profiles tab. Link Information The Link Information screen displays network mode, signal strength, and link quality information about the current connection. It also provides a button to click for additional status information. Ad-Hoc Mode or Infrastructure Mode - The screen indicates whether the Adapter is currently working in ad- hoc or infrastructure mode. Signal Strength - The Signal Strength bar indicates signal strength, from 0 to 100%. Link Quality - The Link Quality bar indicates the quality of the wireless network connection, from 0 to 100%. Click the More Information button to view additional information about the wireless network connection. Click the X (Close) button in the upper right corner to exit the WLAN Monitor. IMPORTANT: Windows XP users. Windows XP has a built-in configuration tool. Use the Windows XP Wireless Zero Configuration (in the system tray at the bottom of your screen) to configure the Adapter. See “Chapter 6: Driver Installation and Configuration for Windows XP.” Figure 7-1: The WLAN Monitor icon Figure 7-2: The Link Information screen 19 Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and 2000 Link Information Wireless-B USB Network Adapter Wireless Network Status Status - The status of the wireless network connection. SSID - The SSID of the wireless network. Network Mode - The wireless mode currently in use. Transfer Rate - The data transfer rate of the current connection. Channel - The channel to which the wireless network devices are set. WEP - The status of the WEP encryption security feature. MAC - The MAC address of the wireless network’s access point. TCP/IP Setting IP Address - The IP Address of the Adapter. Subnet Mask - The Subnet Mask of the Adapter. Default Gateway - The Default Gateway address of the Adapter. DNS - The DNS address of the Ada…

Text truncated - open the document above for the full version.

A Division of Cisco Systems, Inc. ® Model No. USB Network Adapter Wireless-B WUSB11 User Guide WIRELESS GHz 2.4 802.11b Wireless-B USB Network Adapter Copyright and Trademarks Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2003 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders. This User Guide The User Guide to the Wireless-B USB Network Adapter has been designed to make understanding networking easier than ever. Look for the following items when reading this guide: In addition to these symbols, there are definitions for technical terms that are presented like this: Also, each figure (diagram, screenshot, or other image) is provided with a figure number and description, like this: Figure numbers and descriptions can also be found in the "List of Figures" section in the “Table of Contents”. This exclamation point means there is a Caution or warning and is something that could damage your property or the USB Network Adapter. word: definition. This checkmark means there is a Note of interest and is something you should pay special attention to while using the USB Network Adapter. This question mark provides you with a reminder about something you might need to do while using the USB Figure 0-1: Sample Figure Description wusb11 v3-UG-31029NC KL Wireless-B USB Network Adapter Table of Contents Chapter 1: Introduction1 Welcome1 What’s in this Guide?2 Chapter 2: Planning your Wireless Network4 Network Topology4 Roaming4 Network Layout5 Chapter 3: Getting to Know the USB Network Adapter6 The USB Port6 The LED Indicators6 Chapter 4: Software Installation and Configuration for Windows 98SE, Me, and 2000 7 The Installation Procedure8 Chapter 5: Hardware Installation11 Connecting the Adapter11 Using the Adapter’s Wall Mount13 Chapter 6: Driver Installation and Configuration for Windows XP15 Windows XP Wireless Zero Configuration16 Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and 200018 Accessing the WLAN Monitor18 Link Information18 Site Survey20 Profiles21 Creating a New Profile23 Appendix A: Troubleshooting27 Common Problems and Solutions27 Frequently Asked Questions28 Appendix B: Wireless Security31 Security Precautions31 Security Threats Facing Wireless Networks31 Appendix C: Windows Help34 Appendix D: Glossary35 Wireless-B USB Network Adapter Appendix E: Specifications38 Appendix F: Warranty Information40 Appendix G: Regulatory Information41 Appendix H: Contact Information44 Wireless-B USB Network Adapter List of Figures Figure 3-1: Back Panel6 Figure 3-2: Front Panel6 Figure 4-1: The Setup Wizard’s Welcome screen7 Figure 4-2: The Setup Wizard’s License Agreement8 Figure 4-3: The Setup Wizard’s Network Mode screen8 Figure 4-4: The Setup Wizard’s Wireless Channels screen9 Figure 4-5: The Setup Wizard’s Finalize Settings screen9 Figure 4-6: The Setup Wizard’s Congratulations Screen10 Figure 5-1: How the Adapter connects to your PC11 Figure 5-2: The Adapter’s USB Port11 Figure 5-3: A PC’s USB port11 Figure 5-4: The Adapter’s LEDs12 Figure 5-5: Positioning the LEDs antenna12 Figure 5-6: The Adapter’s Wall Mount13 Figure 5-7: Using the Wall Mount - Step A13 Figure 5-8: Using the Wall Mount - Step B14 Figure 5-9: Using the Wall Mount - Step C14 Figure 6-1: Install Software Automatically15 Figure 6-2: wizard Finished15 Figure 6-3: The Zero Configuration Icon16 Figure 6-4: Zero Configuration Connection without WEP16 Figure 6-5: Zero Configuration Connection with WEP17 Figure 6-6: Zero Configuration Active Wireless Connection17 Figure 7-1: The WLAN Monitor icon18 Figure 7-2: The Link Information screen18 Figure 7-3: More Link Information19 Figure 7-4: Site Survey20 Figure 7-5: WEP Encryption20 Figure 7-6: Profiles21 Figure 7-7: Importing a Profile22 Wireless-B USB Network Adapter Figure 7-8: Exporting a Profile22 Figure 7-9: Creating a New Profile23 Figure 7-10: Enter Profile Name23 Figure 7-11: Network Settings for New Profile24 Figure 7-12: Network Mode for New Profile24 Figure 7-13: Wireless Channels for New Profile25 Figure 7-14: Security Settings for New Profile25 Figure 7-15: Confirm New Settings for New Profile26 Figure 7-16: Congratulations for New Profile26 1 Chapter 1: Introduction Welcome Wireless-B USB Network Adapter Chapter 1: Introduction Welcome Thank you for choosing the Wireless-B USB Network Adapter. With this Adapter, your wireless networking experience will be faster and easier than ever. How does the Adapter do this? Like all wireless products, the Adapter allows for greater range and mobility within your wireless network. Connecting to your PC via the USB port means that this Adapter leaves the PC’s slots open for other purposes. This adapter communicates over the 802.11b wireless standard, one of the most popular wireless standards, to communicate with your network. But what does all of this mean? Networks are useful tools for sharing computer resources. You can access one printer from different computers and access data located on another computer's hard drive. Networks are even used for playing multiplayer video games. So, networks are not only useful in homes and offices, they can also be fun. PCs equipped with wireless cards and adapters can communicate without cumbersome cables. By sharing the same wireless settings, within their transmission radius, they form a wireless network. Use the instructions in this Guide to help you connect the Access Point, set it up, and configure it to bridge your different networks. These instructions should be all you need to get the most out of the Access Point. 802.11b: an IEEE wireless networking standard that specifies a maximum data transfer rate of 11Mbps and an operating frequency of 2.4GHz. adapter: a device that adds network functionality to your PC. network: a series of computers or dev…

Text truncated - open the document above for the full version.

15 Chapter 6: Driver Installation and Configuration for Windows XP Wireless-B USB Network Adapter Chapter 6: Driver Installation and Configuration for Windows XP After connecting the Adapter to your computer, you will install the driver and configure the Adapter. 1. Windows XP will automatically detect the Adapter. Insert the Setup CD-ROM into your CD-ROM drive. Click the radio button next to Install the software automatically (Recommended). Then click the Next button. 2. When Windows has finished installing the driver, click the Finish button. You have now completed the driver installation for the Wireless-B USB Network Adapter. To configure the Adapter, proceed to the next section, “Windows XP Wireless Zero Configuration.” IMPORTANT:Do NOT run the Wireless-B USB Network Adapter Setup Wizard. If the Setup Wizard runs automatically after the Setup CD-ROM has been inserted, click the Exit button. Figure 6-1: Install Software Automatically Figure 6-2: wizard Finished 16 Chapter 6: Driver Installation and Configuration for Windows XP Windows XP Wireless Zero Configuration Wireless-B USB Network Adapter Windows XP Wireless Zero Configuration 1. After installing the Adapter, the Windows XP Wireless Zero Configuration icon will appear in your computer’s system tray. Double-click the icon. 2. The screen that appears will show any available wireless network. Select the network you want. If this network has WEP encryption enabled, go to step 3. If this network does not have WEP encryption enabled, make sure the box next to Allow me to connect to the selected wireless network, even though it is not secure is checked. Then click the Connect button, and go to step 4. encryption: encoding data transmitted in a network. NOTE:Windows XP has a built-in configuration tool. Use Windows XP Wireless Zero Configuration (in the system tray at the bottom of your screen) to configure the Adapter. NOTE:Steps 2 and 3 are the instructions and screenshots for Windows XP with Service Pack 1 installed. If you have not installed Service Pack 1, select the network you want, and click the Connect button. If the network has WEP encryption enabled, enter the WEP key in the Network key field, and then click the Connect button. Figure 6-3: The Zero Configuration Icon Figure 6-4: Zero Configuration Connection without WEP 17 Chapter 6: Driver Installation and Configuration for Windows XP Windows XP Wireless Zero Configuration Wireless-B USB Network Adapter 3. If WEP is enabled, enter the WEP key of your wireless network in the Network key field, and re-enter it in the Confirm network key field. Then, click the Connect button, and go to step 4. 4. The Zero Configuration icon will show a wireless connection when your connection is active. For more information about wireless networking on a Windows XP computer, click Start and then Help and Support. Enter the keyword wireless in the field provided, and press the Enter key. Congratulations! The installation of the Wireless-B USB Network Adapter is complete. Figure 6-5: Zero Configuration Connection with WEP NOTE:Windows XP Wireless Zero Configuration does not support the use of a passphrase. Enter the exact WEP key used by your access point. Figure 6-6: Zero Configuration Active Wireless Connection 18 Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and 2000 Accessing the WLAN Monitor Wireless-B USB Network Adapter Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and 2000 Use the WLAN Monitor to check the link information, search for available wireless networks, or create profiles that hold different configuration settings. Accessing the WLAN Monitor After installing the Adapter, the Wireless-B USB Network Adapter WLAN Monitor icon will appear in your system tray. Double-click the icon. The Link Information screen will appear. From this screen, you can find out how strong the current wireless signal is and how good the connection’s quality is. You can also click the More Information button to view additional status information about the current wireless connection. To search for available wireless networks, click the Site Survey tab. To perform configuration changes, click the Profiles tab. Link Information The Link Information screen displays network mode, signal strength, and link quality information about the current connection. It also provides a button to click for additional status information. Ad-Hoc Mode or Infrastructure Mode - The screen indicates whether the Adapter is currently working in ad- hoc or infrastructure mode. Signal Strength - The Signal Strength bar indicates signal strength, from 0 to 100%. Link Quality - The Link Quality bar indicates the quality of the wireless network connection, from 0 to 100%. Click the More Information button to view additional information about the wireless network connection. Click the X (Close) button in the upper right corner to exit the WLAN Monitor. IMPORTANT: Windows XP users. Windows XP has a built-in configuration tool. Use the Windows XP Wireless Zero Configuration (in the system tray at the bottom of your screen) to configure the Adapter. See “Chapter 6: Driver Installation and Configuration for Windows XP.” Figure 7-1: The WLAN Monitor icon Figure 7-2: The Link Information screen 19 Chapter 7: Using the WLAN Monitor for Windows 98SE, Me, and 2000 Link Information Wireless-B USB Network Adapter Wireless Network Status Status - The status of the wireless network connection. SSID - The SSID of the wireless network. Network Mode - The wireless mode currently in use. Transfer Rate - The data transfer rate of the current connection. Channel - The channel to which the wireless network devices are set. WEP - The status of the WEP encryption security feature. MAC - The MAC address of the wireless network’s access point. TCP/IP Setting IP Address - The IP Address of the Adapter. Subnet Mask - The Subnet Mask of the Adapter. Default Gateway - The Default Gateway address of the Adapter. DNS - The DNS address of the Ada…

Text truncated - open the document above for the full version.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 May 14, 2004 RE: Cisco/Linksys FCC ID: Q87-WUSB11V4 I have a few comments on this Application. Depending on your responses, kindly understand there may be additional comments. 1.) Please add “Information to User” statement as required by 15.21. William H. Graff President and Director of Engineering mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

Page 6 Page 7 Page 8 Page 9

FCC ID: Q87-WUSB11V4 Report No.: RF930409L02 Operational Description The transmitter of the EUT is powered by host equipment. The antenna type is External dipole antenna without any connector. The other instruction, please have a look at the users manual. DSSS Information This device is Direct Sequence Spread Spectrum, the data is mixed by pseudorandom code which is an orthogonal code. The mixed data is digital modulated by BPSK and QPSK technique depends on the data rates. The CCK coding is applied for increasing the data rate, and also the processing gain will be increased. The bit rates are 1,2,5.5,11Mbps, the symbol rates are 1,1,1.375,1.375Mbps, the chip rates are always 11Mbps. So, the Chip/symbol is 11,11,8 and 8 respectively. Although is higher bit rate, the processing gain is lower than 10, but the CCK coding used in higher bit rate will provide 2.2dB coding gain.

FCC ID: Q87-WUSB11V4 Report No: SA930409L02 1 RF EXPOSURE REPORT REPORT NO.: SA930409L02 MODEL NO.: WUSB11v4 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: Cisco-Linksys, LLC ADDRESS: 121 Theory Drive, Irvine, CA 92612 (USA) ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. FCC ID: Q87-WUSB11V4 Report No: SA930409L02 2 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: Q87-WUSB11V4 Report No: SA930409L02 3 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification The antenna of the product, under normal use condition, is at least 20cm away from the body of the user. Warning statement for keeping 20cm-separation distance and the prohibition of operating next to a person has been printed on the user’s manual. So, this product is classified as the Mobile Device. FCC ID: Q87-WUSB11V4 Report No: SA930409L02 4 6 Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1dBi or 1.259 (numeric). 6.2 Output Power Into Antenna & RF Exposure Distance : For Part 802.11b (CCK technique): Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241252.4810.0131.0 6243760.2560.0151.0 11246252.4810.0131.0

FCC ID: Q87-WUSB11V4 Report No.: RF930409L021Issued: Apr. 15, 2004 FCC TEST REPORT REPORT NO.: RF930409L02 MODEL NO.: WUSB11v4 RECEIVED: Apr. 9, 2004 TESTED: Apr. 12 ~ Apr. 14, 2004 APPLICANT: Cisco-Linksys, LLC ADDRESS: 121 Theory Drive, Irvine, CA 92612 (USA) ISSUED BY: Advance Data Technology Corporation LAB LOCATION: 47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 51 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, w…
