Page 1 PHOTOS OF EUT Page 2 Page 3

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

FCC ID: Q87-WUSB54G ADT No.920825R07 Operational Description This device is a Wireless-G USB Network Adapter which operates in the 2.4Ghz frequency spectrum with throughput of up to 54Mbps which OFDM technique will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment via a USB interface. The antenna is Dipole antenna without a connector. The other instruction, please have a look at the users manual.

FCC ID: Q87-WUSB54G ADT No.: 920825R07 RF EXPOSURE REPORT REPORT NO.: RF920825R07 MODEL NO.: WUSB54G ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT:Cisco-Linksys, LLC ADDRESS:17401 Armstrong Ave., Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: Q87-WUSB54G ADT No.: 920825R07 RF Exposure Measurement (Mobile Device) 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC) calibrated for antenna measurement in ADT, and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A)Limits For Occupational / Control Exposures 300-1500......F/3006 1500-100,000......56 (B)Limits For General Population / Uncontrolled Exposure 300-1500......F/15006 1500-100,000......1.030 F = Frequency in MHz FCC ID: Q87-WUSB54G ADT No.: 920825R07 3. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm If we know the maximum Gain of the antenna and the total power input to the antenna, through the calculation, we will know the MPE value at distance 20cm. Ref. : David K. Cheng, Field and Wave Electromagnetics, Second Edition, Page 640, Eq. (11-133). 4 EUT Operating condition The software provided by Manufacturer enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. 5. Classification This device is not fixed inside the host equipment, it is connected with host through wire. So it is easy to be re-located in the place where at least 20cm far away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. FCC ID: Q87-WUSB54G ADT No.: 920825R07 6. Test Results 6.1 Antenna Gain The maximum Gain measured in Fully Anechoic Chamber is 1dBi or 1.259 (numeric). 6.2 Output Power Into Antenna & RF Exposure value at distance 20cm : For Part 802.11b (CCK technique): Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241239.9940.0101.0 6243739.6280.0101.0 11246239.7190.0101.0 For Part 802.11g (OFDM technique): Channel Channel Frequency (MHz) Output Power to Antenna (mW) Power Density (mW/cm 2 ) Limit of Power Density (mW/cm 2 ) 1241231.6230.0081.0 6243731.6960.0081.0 11246231.4770.0081.0

FCC ID: Q87-WUSB54G Report No.: RF920825R071Issued: Sep. 4, 2003 FCC TEST REPORT REPORT NO.: RF920825R07 MODEL NO.: WUSB54G BRAND: Linksys RECEIVED: Aug. 25, 2003 TESTED: Aug. 25 ~ Sep. 1, 2003 APPLICANT:Cisco-Linksys, LLC ADDRESS:17401 Armstrong Ave., Irvine, CA 92614 ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. This test report consists of 62 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, NVLAP or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA Lab Code: 200102-0 FCC ID: Q87-WUSB54G Report No.: RF920825R072Issued: Sep. 4, 2003 Table of Contents 1CERTIFICATION...........................................................................................4 2SUMMARY OF TEST RESULTS...................................................................5 3GENERAL INFORMATION............................................................................6 3.1GENERAL DESCRIPTION OF EUT..............................................................6 3.2DESCRIPTION OF TEST MODES................................................................7 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS...............................7 3.4DESCRIPTION OF SUPPORT UNITS..........................................................8 4TEST TYPES AND RESULTS.......................................................................9 4.1CONDUCTED EMISSION MEASUREMENT................................................9 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT..............................9 4.1.2TEST INSTRUMENTS..................................................................................9 4.1.3TEST PROCEDURES.................................................................................10 4.1.4DEVIATION FROM TEST STANDARD.......................................................10 4.1.5TEST SETUP..............................................................................................11 4.1.6EUT OPERATING CONDITIONS................................................................11 4.1.7TEST RESULTS..........................................................................................12 4.2RADIATED EMISSION MEASUREMENT...................................................18 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT.................................18 4.2.2TEST INSTRUMENTS................................................................................19 4.2.3TEST PROCEDURES.................................................................................20 4.2.4DEVIATION FROM TEST STANDARD.......................................................20 4.2.5TEST SETUP..............................................................................................21 4.2.6EUT OPERATING CONDITIONS................................................................21 4.2.7TEST RESULTS..........................................................................................22 4.36dB BANDWIDTH MEASUREMENT...........................................................30 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................30 4.3.2TEST INSTRUMENTS................................................................................30 4.3.3TEST PROCEDURE...................................................................................31 4.3.4DEVIATION FROM TEST STANDARD.......................................................31 4.3.5TEST SETUP..............................................................................................31 4.3.6EUT OPERATING CONDITIONS................................................................31 4.3.7TEST RESULTS..........................................................................................32 4.4MAXIMUM PEAK OUTPUT POWER..........................................................40 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...........40 4.4.2TEST INSTRUMENTS................................................................................40 FCC ID: Q87-WUSB54G Report No.: RF920825R073Issued: Sep. 4, 2003 4.4.3TEST PROCEDURES.................................................................................41 4.4.4DEVIATION FROM TEST STANDARD.......................................................41 4.4.5TEST SETUP..............................................................................................41 4.4.6EUT OPERATING CONDITIONS................................................................41 1.1.1TEST RESULTS..........................................................................................42 4.5POWER SPECTRAL DENSITY MEASUREMENT......................................43 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT...................43 4.5.2TEST INSTRUMENTS................................................................................43 4.5.3TEST PROCEDURE...................................................................................44 4.5.4DEVIATION FROM TEST STANDARD.......................................................44 4.5.5TEST SETUP..............................................................................................44 4.5.6EUT OPERATING CONDITIONS................................................................44 4.5.7TEST RESULTS..........................................................................................45 4.6BAND EDGES MEASUREMENT................................................................53 4.6.1LIMITS OF BAND EDGES MEASUREMENT..............................................53 4.6.2TEST INSTRUMENTS................................................................................53 4.6.3TEST PROCEDURE...................................................................................53 4.6.4DEVIATION FROM …

Text truncated - open the document above for the full version.

FCC ID: Q87-WUSB54G Report No.: RF920825R0731Issued: Sep. 4, 2003 4.3.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator. The bandwidth of the fundamental frequency was measured by spectrum analyzer with 100 kHz RBW and 100kHz VBW. The 6dB bandwidth is defined as the total spectrum the power of which is higher than peak power minus 6dB. 4.3.4 DEVIATION FROM TEST STANDARD No deviation 4.3.5 TEST SETUP For the actual test configuration, please refer to the related Item – Photographs of the Test Configuration. 4.3.6 EUT OPERATING CONDITIONS The software provided by client to enable the EUT under transmission condition continuously at lowest, middle and highest channel frequencies individually. EUT SPECTRUM ANALYZER FCC ID: Q87-WUSB54G Report No.: RF920825R0732Issued: Sep. 4, 2003 4.3.7 TEST RESULTS MODEL WUSB54G EUT Wireless-G USB Network Adapter MODE CCK INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 28deg. C, 64%RH, 991hPa TESTED BY: Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) 6dB BANDWIDTH (MHz) MINIMUM LIMIT (MHz) PASS/FAIL 1241211.520.5PASS 6243711.520.5PASS 11246211.480.5PASS FCC ID: Q87-WUSB54G Report No.: RF920825R0733Issued: Sep. 4, 2003 CH1 FCC ID: Q87-WUSB54G Report No.: RF920825R0734Issued: Sep. 4, 2003 CH6 FCC ID: Q87-WUSB54G Report No.: RF920825R0735Issued: Sep. 4, 2003 CH11 FCC ID: Q87-WUSB54G Report No.: RF920825R0736Issued: Sep. 4, 2003 MODEL WUSB54G EUT Wireless-G USB Network Adapter MODE OFDM INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 28deg. C, 64%RH, 991hPa TESTED BY: Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) 6dB BANDWIDTH (MHz) MINIMUM LIMIT (MHz) PASS/FAIL 1241216.440.5PASS 6243716.440.5PASS 11246216.400.5PASS FCC ID: Q87-WUSB54G Report No.: RF920825R0737Issued: Sep. 4, 2003 CH1 FCC ID: Q87-WUSB54G Report No.: RF920825R0738Issued: Sep. 4, 2003 CH6 FCC ID: Q87-WUSB54G Report No.: RF920825R0739Issued: Sep. 4, 2003 CH11 FCC ID: Q87-WUSB54G Report No.: RF920825R0740Issued: Sep. 4, 2003 4.4 MAXIMUM PEAK OUTPUT POWER 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT The Maximum Peak Output Power Measurement is 30dBm. 4.4.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until R&S SPECTRUM ANALYZERFSEK30100049Aug. 12, 2004 R&S SIGNAL GENERATORSMP04100011May 28, 2004 TEKTRONIX OSCILLOSCOPETDS 220B048470Mar. 05, 2004 NARDA DETECTOR4503AFSCM99899NA NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA.. FCC ID: Q87-WUSB54G Report No.: RF920825R0741Issued: Sep. 4, 2003 4.4.3 TEST PROCEDURES 1. A detector was used on the output port of the EUT. An oscilloscope was used to read the response of the detector. 2. Replaced the EUT by the signal generator . The center frequency of the S.G was adjusted to the center frequency of the measured channel. 3. Adjusted the power to have the same reading on oscilloscope. Record the power level. 4.4.4 DEVIATION FROM TEST STANDARD No deviation 4.4.5 TEST SETUP 4.4.6 EUT OPERATING CONDITIONS Same as Item 4.3.6 EUT or S.G OSCILLOSCOPE DETECTOR FCC ID: Q87-WUSB54G Report No.: RF920825R0742Issued: Sep. 4, 2003 1.1.1 TEST RESULTS MODEL WUSB54G EUT Wireless-G USB Network Adapter MODE CCK INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 28deg. C, 64%RH, 991hPa TESTED BY: Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) PASS/FAIL 1241216.0230PASS 6243715.9830PASS 11246215.9930PASS MODEL WUSB54G EUT Wireless-G USB Network Adapter MODE OFDM INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 28deg. C, 64%RH, 991hPa TESTED BY: Steven Lu CHANNEL CHANNEL FREQUENCY (MHz) PEAK POWER OUTPUT (dBm) PEAK POWER LIMIT (dBm) PASS/FAIL 1241215.0030PASS 6243715.0130PASS 11246214.9830PASS FCC ID: Q87-WUSB54G Report No.: RF920825R0743Issued: Sep. 4, 2003 4.5 POWER SPECTRAL DENSITY MEASUREMENT 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT The Maximum of Power Spectral Density Measurement is 8dBm. 4.5.2 TEST INSTRUMENTS Description & ManufacturerModel No.Serial No.Calibrated Until SPECTRUM ANALYZERFSEK30100049Aug. 12, 2004 NOTE: The calibration interval of the above test instruments is 12 months and the calibrations are traceable to NML/ROC and NIST/USA. FCC ID: Q87-WUSB54G Report No.: RF920825R0744Issued: Sep. 4, 2003 4.5.3 TEST PROCEDURE The transmitter output was connected to the spectrum analyzer through an attenuator, the bandwidth of the fundamental frequency was measured with the spectrum analyzer using 3kHz RBW and 30kHz VBW, set sweep time=span/3kHz. The power spectral density was measured and recorded. The sweep time is allowed to be longer than span/3KHz for a full response of the mixer in the spectrum analyzer. 4.5.4 DEVIATION FROM TEST STANDARD No deviation 4.5.5 TEST SETUP 4.5.6 EUT OPERATING CONDITIONS Same as 4.3.6 EUT SPECTRUM ANALYZER FCC ID: Q87-WUSB54G Report No.: RF920825R0745Issued: Sep. 4, 2003 4.5.7 TEST RESULTS MODEL WUSB54G EUT Wireless-G USB Network Adapter MODE CCK INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 28deg. C, 64%RH, 991hPa TESTED BY: Steven Lu CHANNEL CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-8.318PASS 62437-7.948PASS 112462-8.008PASS FCC ID: Q87-WUSB54G Report No.: RF920825R0746Issued: Sep. 4, 2003 CH1 FCC ID: Q87-WUSB54G Report No.: RF920825R0747Issued: Sep. 4, 2003 CH6 FCC ID: Q87-WUSB54G Report No.: RF920825R0748Issued: Sep. 4, 2003 CH11 FCC ID: Q87-WUSB54G Report No.: RF920825R0749Issued: Sep. 4, 2003 MODEL WUSB54G EUT Wireless-G USB Network Adapter MODE OFDM INPUT POWER (SYSTEM) 120Vac, 60 Hz ENVIRONMENTAL CONDITIONS 28deg. C, 64%RH, 991hPa TESTED BY: Steven Lu CHANNEL CHANNEL FREQUENCY (MHz ) RF POWER LEVEL IN 3 kHz BW (dBm) MAXIMUM LIMIT (dBm) PASS/FAIL 12412-16.938PASS 62437-16.488PASS 112462-16.028PASS FCC ID: Q87-WUSB54G Report No.: RF920825R0750Issued: Sep. 4, 2003 CH1 FCC ID: Q87-WUSB54G Report No.: RF920825R0751I…
