QFXNHM-10Dual Band Bluetooth Enabled Imaging Phone

Nokia 3600 and Nokia 3650 User Guide The wireless phones described in this guide are approved for use in the GSM network. LEGAL INFORMATION Part No. 9356743, Issue No. 1a 1 1 Copyright ©2003 Nokia. All rights reserved. Nokia, Nokia Connecting People, Nokia 3600, Nokia 3650, and the Nokia Original Accessories logos are trademarks or registered trademarks of Nokia Corporation. All other product and company names mentioned herein may be trademarks or tradenames of their respective owners. Printed in Canada May 2003 US Patent No 5818437 and other pending patents. T9 text input software Copyright ©1999-2003. Tegic Communications, Inc. All rights reserved. Includes RSA BSAFE cryptographic or security protocol software from RSA Security. Java is a trademark of Sun Microsystems, Inc. Bluetooth is a registered trademark of Bluetooth SIG, Inc. The information in this user guide was written for the Nokia 3600 and Nokia 3650 phones. Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS.” EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE. EXPORT CONTROLS This product contains commodities, technology or software exported from the United States in accordance with the Export Administration regulations. Diversion contrary to U.S. law is prohibited. FCC/INDUSTRY CANADA NOTICE Your phone may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the FCC rules. This device contains a radio transceiver and digital circuitry that supports its features. Operation of the digital device circuitry is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Modifications to this device not authorized by Nokia may void the authority granted for operation of this device and should not be made. [ iii ] Contents 1 For your safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Network services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 2 General information . . . . . . . . . . . . . . . . . . . . . . . . . 5 Register your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Understand your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Options lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Navigation bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Actions common to all applications . . . . . . . . . . . . . . . . . . . . . . 16 Volume control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Shared memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Access alternate formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 3 Your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Make a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Answer a call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Log - Call log and general log . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 SIM folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 4 Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Change general settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Phone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Call settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Connection settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Access points. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 [ iv ] Date and time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Call restriction (system service). . . . . . . . . . . . . . . . . . . . . . . . . . 47 System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Accessory settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 5 Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Create contact cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Copy between SIM card and phone memory . . . . . . . . . . . . . . . 49 Edit contact cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 View a contact card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Manage contact groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Import data from other Nokia phones . . . . . . . . . . . . . . . . . . . . 56 6 Camera a…

Text truncated - open the document above for the full version.

CONFIDENTIAL 09 June 2003 Additional Information FCC ID: QFX NHM-10 Response to ATCB Comments dated 3 rd June 2003 1.) All Bluetooth Part 15 Certifications must have Test Setup photographs and Operational Description. Please be sure to include as separate Exhibits. Bluetooth certification test set up photographs and operational description have been uploaded. 2.) All Part 15 reports must include the language of 15.21 in the owner’s manual. If I have missed it, please show me where it is located. The statement that warns the user about non-authorized modifications to the device and that it may void the authority granted for operation of this device, can be found on page 2 of the User Manual. 3.) Please indicate where in the Manual the SAR values are listed. I could not find it on first glance. The SAR Test values are listed on page 164 of the User Manual 4.) A Confidentiality Request letter must accompany this Application. In general, only Schematics, Block Diagram, Operational Description and Parts List can be held Confidential. Please supply on Nokia letterhead. A confidentiality request letter has been uploaded for this application 5.) Photo #1 and #2 of the External Photographs are confusing. Am I looking at the same device? Please explain. Photo 1 and 2 are the same device. Photo 1 is the front view showing display and keymat. Photo 2 is the rear view showing the battery cover and the camera window 6.) Does the SAR Phantom conform to the requirements of P1528? The SAR report should explicitly indicate this information. The SAR report states that testing has been carried out to IEEE 1528-200X Draft CBD 1.0. The fully compliant phantom is shown in section 3.6. 7.) What is the measured gain of the Bluetooth antenna when mounted within the phone? The gain of the Bluetooth antenna is –1 dBi Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 09 June 2003 Additional Information FCC ID: QFX NHM-10 Response to ATCB Comments dated 5 th June 2003 1.) Please address all the comments from my note of June 3, 2003 on a point by point basis. Please upload your responses to any of these comments to the Additional Information section of the Application at the AmericanTCB.com website. Responses are included in this document 2.) The FCC rules for Part 22 and 24 equipment have changed. It is now necessary to demonstrate Block Edge and not just Band Edge compliance per 22.917(b) and 24.238(b). Please provide these measurements. I have attached the latest version of the Rules for your convenience. Measurements provided, refer to uploaded report “Exhibit 06 part 22 24 updated” dated 9 th June 03 3.) Please provide an Occupied Bandwidth plot for both the Part 22 and Part 24 GSM emissions. Plot provided, refer to uploaded report “Exhibit 06 part 22 24 updated” dated 9 th June 03 4.) Please provide an Occupied Bandwidth plot for the Bluetooth emission. Quote from RFI “The only bandwidth requirement for Bluetooth is a measure of the 20 dB bandwidth. See Part 15.247(a)(1). This measurement was performed with both tabulated and graphical results being reported on page 24 of report RFI/MPTB2/RP44497JD02A” 5.) In addition to the EIRP measurements, it is advisable to provide conducted RF Pout measurements for all equipment which requires SAR testing. Kindly provide this measurement at three channels in both the 800 and 1900 bands. These values must match the target values in the Tune Up procedure and also the SAR report The test sample was tuned identically to mass production. This product has no external RF connector. ERP/EIRP values, measured by RFI, are given in SAR report. 6.) There is a strip outlet used during AC Powerline Conducted testing. This is not allowed. Measurements must be made with the EUT plugged directly into the LISN. Quote from Test House RFI :- There may be confusion with the photos here, I can confirm that the EUT was indeed plugged directly into the LISN for AC conducted tests. Our setup photo "PHT\44497JD02\002 Left view of AC Conducted Emissions" clearly shows the EUT plugged into the LISN. The grey box bolted to the floor via the copper ground plane is the LISN. The right side of the LISN in the photo is the business end where the EUT is plugged. You can make out the black charger. The 4 way stripling extension lead shown at the top of the photo is providing the supply for the LISN only. Please note that C63.4 Section 6.1.4 (3.2) states that multiple outlet strip can be used for non-EUT equipment. The LISN is none-EUT equipment. Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 09 June 2003 Additional Information FCC ID: QFX NHM-10 Quote: "6.1.4 Interconnect and power cabling (or wiring) 3.2) Multiple outlet strip can be used for multiple power cords of non-EUT equipment. Photo "PHT\44497JD02\004 Front view of Radiated Emissions" and "PHT\44497JD02\005 Side view of Radiated Emissions" are the radiated setup photos on our open are test site. They show the EUT connected directly to a 4 way strip extension lead. This is acceptable according to C63.4 Section 5.2.3 which states LISN's may be used for radiated testing but does not state it as mandatory. Quote: "5.2.3 LISN installation LISNs may be required for ac powerline conducted emission measurements and may be used for radiated emission measurements." 7.) Unless I have missed it, I do not see where the required SAR test values are listed in the Manual. Kindly direct me to the listing of the values found during testing. The SAR Test values are listed on page 164 of the User Manual 8.) Please direct me to the required language of 15.21 in the Manual. The statement that warns the user about non-authorized modifications to the device and that it may void the authority granted for operation of this device, can be found on page 2 of the User Manual. Applicant: Nokia Mobile Phones Copyright © 2003 Nokia

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 June 3, 2003 RE: Nokia FCC ID: QFXNHM-10 I have a few immediate comments on this Application. I am sending this to you before I have been able to review your Test Reports. Please be sure to separate the Unlicensed Part 15 Bluetooth EMC report from the Part 22/24 Licensed EMC report. 1.) All Bluetooth Part 15 Certifications must have Test Setup photographs and Operational Description. Please be sure to include as separate Exhibits. 2.) All Part 15 reports must include the language of 15.21 in the owner’s manual. If I have missed it, please show me where it is located. 3.) Please indicate where in the Manual the SAR values are listed. I could not find it on first glance. 4.) A Confidentiality Request letter must accompany this Application. In general, only Schematics, Block Diagram, Operational Description and Parts List can be held Confidential. Please supply on Nokia letterhead. 5.) Photo #1 and #2 of the External Photographs are confusing. Am I looking at the same device? Please explain. 6.) Does the SAR Phantom conform to the requirements of P1528? The SAR report should explicitly indicate this information. 7.) What is the measured gain of the Bluetooth antenna when mounted within the phone? William H. Graff President and Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

CONFIDENTIAL 15 May 2003 Photographs of the Equipment NHM-10 Photograph No 1 Exhibit 03: External Photographs FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 15 May 2003 Photograph No 2 Exhibit 03: External Photographs FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 15 May 2003 Photograph No 3 Exhibit 03: External Photographs FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia

CONFIDENTIAL 15 May 2003 Location of Identification Label for NHM-10 Photograph No 1 Exhibit 01: Label and Location FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 15 May 2003 Exhibit 01: Label and Location FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia

PHOTOGRAPH SECTION – INTERNAL PHOTOS FOR RFI TEST REPORT SERIAL NO’S: RFI/MPTB2/RP44497JD02A AND RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) RADIO FREQUENCY INVESTIGATION LTD. Photograph Section S.No: RFI/MPTB2/RP44497JD02A and RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) This section contains the following photographs: Photo Reference Number Title PHT\44497JD02\008 Top view of Circuit Board PHT\44497JD02\009 Bottom view of Circuit Board PHT\44497JD02\010 Internal view Front Cover Removed PHT\44497JD02\011 Overall Internal view of EUT PHT\44497JD02\012 Overall Internal view of EUT PHT\44497JD02\013 Overall Internal view of EUT Screens Removed PHT\44497JD02\014 Overall Internal view of EUT Screens Removed RADIO FREQUENCY INVESTIGATION LTD. Photograph Section S.No: RFI/MPTB2/RP44497JD02A and RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) PHT\44497JD02\008 Top view of Circuit Board RADIO FREQUENCY INVESTIGATION LTD. Photograph Section S.No: RFI/MPTB2/RP44497JD02A and RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) PHT\44497JD02\009 Bottom view of Circuit Board RADIO FREQUENCY INVESTIGATION LTD. Photograph Section S.No: RFI/MPTB2/RP44497JD02A and RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) PHT\44497JD02\010 Internal view Front Cover Removed RADIO FREQUENCY INVESTIGATION LTD. Photograph Section S.No: RFI/MPTB2/RP44497JD02A and RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) PHT\44497JD02\011 Overall Internal view of EUT RADIO FREQUENCY INVESTIGATION LTD. Photograph Section S.No: RFI/MPTB2/RP44497JD02A and RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) PHT\44497JD02\012 Overall Internal view of EUT RADIO FREQUENCY INVESTIGATION LTD. Photograph Section S.No: RFI/MPTB2/RP44497JD02A and RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) PHT\44497JD02\013 Overall Internal view of EUT Screens Removed RADIO FREQUENCY INVESTIGATION LTD. Photograph Section S.No: RFI/MPTB2/RP44497JD02A and RFI/MPTB1/RP44497JD02C Test Of: Nokia Mobile Phones. 3600 Imaging Phone (Bluetooth Mode) PHT\44497JD02\014 Overall Internal view of EUT Screens Removed

CONFIDENTIAL 03 June 2003 Exhibit 09: Internal Photograph FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 03 June 2003 Exhibit 09: Internal Photograph FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 03 June 2003 Exhibit 09: Internal Photograph FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 03 June 2003 Exhibit 09: Internal Photograph FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 03 June 2003 Exhibit 09: Internal Photograph FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia CONFIDENTIAL 03 June 2003 Exhibit 09: Internal Photograph FCC ID: QFX NHM-10 Applicant: Nokia Mobile Phones Copyright © 2003 Nokia

SAR Test Report Template / Version 1.0 T:\Projects\NHM-10\results\emc\SAR\SAR0316_01.doc Copyright  2003 TCC Salo Copyright  TCC Salo P.O. Box 86 Joensuunkatu 7E / Kiila 1B FIN-24101 SALO, FINLAND Tel. +358 (0) 7180 08000 Fax. +358 (0) 7180 45220 2(80) CONTENTS 1. SUMMARY FOR SAR TEST REPORT.......................................................................................................... 4 1.1 MAXIMUM RESULTS FOUND DURING SAR EVALUATION....................................................................................... 4 1.1.1 Head Configuration / GSM 1900 .................................................................................................................... 4 1.1.2 Body Worn Configuration / GSM 850.......................................................................................................... 4 1.1.3 Measurement Uncertainty .................................................................................................................................. 4 1.2 ERP/EIRP MEASUREMENTS........................................................................................................................................... 5 2. DESCRIPTION OF THE TESTED DEVICE(S).......................................................................................... 6 2.1 D EVICE DESCRIPTION.......................................................................................................................................................... 6 2.2 PICTURE OF PHONE............................................................................................................................................................. 6 2.3 DESCRIPTION OF THE ANTENNA ..................................................................................................................................... 6 2.4 BATTERY OPTIONS............................................................................................................................................................... 6 2.5 ACCESSORIES........................................................................................................................................................................ 7 2.6 B ODY W ORN A CCESSORIES............................................................................................................................................ 7 3. DESCRIPTION OF THE TEST EQUIPMENT............................................................................................ 8 3.1 AUTOMATED NEAR-FIELD SCANNING SYSTEM ............................................................................................................ 8 3.2 ROBOT...................................................................................................................................................................................... 8 3.3 ISOTROPIC E-FIELD PROBE ET3DV6R........................................................................................................................ 9 3.4 D EVICE HOLDER.................................................................................................................................................................... 9 3.5 DIPOLE ANTENNAS FOR VALIDATION............................................................................................................................. 9 3.6 PHANTOM ..............................................................................................................................................................................10 3.7 BASE STATION SIMULALTOR..........................................................................................................................................10 3.8 ADDITIONAL EQUIPMENT NEEDED IN SYSTEM CHECK............................................................................................11 3.9 RF CHARACTERISTICS OF THE TEST SITE.................................................................................................................11 4. TEST CONDITIONS................................................................................................................................................12 4.1 A MBIENT C ONDITIONS......................................................................................................................................................12 4.2 SYSTEM PERFORMANCE CHECK..................................................................................................................................12 4.3 TISSUE SIMULANTS............................................................................................................................................................13 4.3.1 Measured values of liqid parameters .........................................................................................................13 4.3.2 Recipes of tissue simulating liquids............................................................................................................14 5. DEVICE POSITIONING ........................................................................................................................................15 5.1 POSITIONING PROCEDURES............................................................................................................................................15 5.1.1 Cheek/Touch Position........................................................................................................................................15 5.1.2 Ear/Tilted Position................................................................................................................................................15 5.1.3 Photos of setup......................................................................................................................................................16 5.1.4 Body Worn Configuration .................................................................................................................................16 5.2 SCA…

Text truncated - open the document above for the full version.

Radio Frequency Investigation Ltd, Ewhurst Park, Ramsdell, Basingstoke, Hampshire, RG26 5RQ, ENGLAND. Tel: +44 (0) 1256 851193 Fax: +44 (0) 1256 851192 Registered in England, No. 211 7901. Registered Office: Ewhurst Park, Ramsdell, Basingstoke, Hampshire RG26 5RQ 0644 TEST REPORT FROM RADIO FREQUENCY INVESTIGATION LTD. Test Of: Nokia Mobile Phones. 3600 Imaging Phone To: FCC Part 22 and 24 Test Report Serial No: RFI/MPTB3/RP44497JD02C Supersedes Test Report Serial No: RFI/MPTB1/RP44497JD02A & RFI/MPTB1/RP44497JD02C& RFI/MPTB2/RP44497JD02C This Test Report Is Issued Under The Authority Of Richard Jacklin, Operations Director: Checked By: Tested By: pp Release Version No: PDF01 Issue Date: 09 June 2003 Test Dates: 17 April 2003 to 14 May 2003 This report is issued in Adobe Acrobat portable document format (PDF). It is only a valid copy of the report if it is being viewed in PDF format with the following security options not allowed: Changing the document, Selecting text and graphics, Adding or changing notes and form fields. Furthermore, the date of creation must match the issue date stated above. This report may be copied in full. The results in this report apply only to the sample(s) tested. RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB3/RP44497JD02C Operations Department Page 2 of 78 Issue Date: 09 June 2003 Test Of: Nokia Mobile Phones. 3600 Imaging Phone To: FCC Part 22 & 24 This page has been left intentionally blank. RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB3/RP44497JD02C Operations Department Page 3 of 78 Issue Date: 09 June 2003 Test Of: Nokia Mobile Phones. 3600 Imaging Phone To: FCC Part 22 & 24 Table of Contents 1. Client Information..........................................................................................................4 2. Equipment Under Test (EUT) .......................................................................................5 3. Test Specification, Methods And Procedures ..........................................................10 4. Deviations From The Test Specification ...................................................................12 5. Operation Of The EUT During Testing ......................................................................13 6. Summary Of Test Results...........................................................................................15 7. Measurements, Examinations And Derived Results................................................17 8. Test Results FCC Part 22............................................................................................18 9. Measurement Methods – Part 22 ...............................................................................35 10. Test Results FCC Part 24..........................................................................................44 11. Measurement Methods – Part 24 .............................................................................64 12. Measurement Uncertainty ........................................................................................73 Appendix 1. Test Equipment Used ................................................................................74 Appendix 2. Test Configuration Drawings....................................................................76 Note: Test Report Serial No: RFI/MPTB1/RP44497JD02C supersedes Test Report Serial No: RFI/MPTB1/RP44497JD02A, RFI/MPTB1/RP44497JD02C & RFI/MPTB2/RP44497JD02C RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB3/RP44497JD02C Operations Department Page 4 of 78 Issue Date: 09 June 2003 Test Of: Nokia Mobile Phones. 3600 Imaging Phone To: FCC Part 22 & 24 1. Client Information Company Name: Nokia Mobile Phones Address: Nokia House Summit Avenue Southwood Farnborough Hants GU14 0NG UK Contact Name: Mr A White RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB3/RP44497JD02C Operations Department Page 5 of 78 Issue Date: 09 June 2003 Test Of: Nokia Mobile Phones. 3600 Imaging Phone To: FCC Part 22 & 24 2. Equipment Under Test (EUT) The following information (with the exception of the Date of Receipt) has been supplied by the client: 2.1. Identification Of Equipment Under Test (EUT) Brand Name: Nokia Model Name or Number: 3600 Unique Type Identification: NHM-10 IMEI Number: 004400071717365 Country of Manufacture: Finland Date of Receipt: 17 April 2003 2.2. Description Of EUT The equipment under test is a dual-band (850, 1900) camera mobile handset, which supports IR and Bluetooth. 2.3. Modifications Incorporated In EUT The EUT has not been modified from what is described by the Model Number and Unique Type Identification stated above. RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB3/RP44497JD02C Operations Department Page 6 of 78 Issue Date: 09 June 2003 Test Of: Nokia Mobile Phones. 3600 Imaging Phone To: FCC Part 22 & 24 2.4. Additional Information Related To Testing Power Supply Requirement: (Internal, non-removable lithium ion battery) 4.2 V DC Declared Battery End Point Voltage 3.45 V DC Power Supply Requirement: (AC Battery Charger) Nominal 115 V 60 Hz AC Mains supply Intended Operating Environment: Within GSM/Bluetooth Network Coverage Equipment Category: Portable Type of Unit: Handset Weight: 130 g Dimensions: 130 x 55 x 23 mm Interface Ports: Charger Connection Accessory Connection Highest Fundamental Frequency 1989.8 MHz Highest Oscillator Frequency 3980.0 MHz RADIO FREQUENCY INVESTIGATION LTD TEST REPORT S.No. RFI/MPTB3/RP44497JD02C Operations Department Page 7 of 78 Issue Date: 09 June 2003 Test Of: Nokia Mobile Phones. 3600 Imaging Phone To: FCC Part 22 & 24 Part 22 Transmit Frequency Range 824 MHz to 848 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 128 824.2 Middle 190 836.6 Transmit Channels Tested Top 251 848.8 Receive Frequency Range 869 MHz to 894 MHz Channel ID Channel Number Channel Frequency (MHz) Bottom 128 869.2 Middle 190 881.6 Receive Channels Tested Top 251 893.8 Maximum Power Output (ERP…

Text truncated - open the document above for the full version.

PHOTOGRAPH SECTION …

Text truncated - open the document above for the full version.
