QFXRM-132GSM 850/900/1800/1900MHz Cellphone w/BT

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 July 11, 2006 RE: FCC ID: QFXRM-132_ATCB003718 Attention: Alison Kingston I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that the power levels in the EMC reports do not match the power levels listed on the 731. Please make power levels consistent throughout documentation. 2. Please note that in the test report FCC_0623_v1 the EGPRS data listed in section 2.3 for the 850MHz band shows data for the 1900Bnad. Please provide the EGPRS data for the 850MHz Band. 3. Please note that while it is acceptable to have up to 3dB varaiance between the SAR report and the EMC report EIRP power levels, when there is a variance the highest reported power must still be in the SAR report. Please note that the highest EIRP power in the EMC reports are 32.5dBm (see page 6 of report FCC_0623_01TCFv1) while the highest EIRP in the SAR report is only 31.1 (see pages 16 and 18 of the SAR report). This is an almost 1.5dB difference with the SAR report not showing the highest reading. Please retest SAR using the higher power level or please retest EMC to show a consistent power relation to the SAR report. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

RE: FCC ID: QFXRM-132_ATCB003718 1. Please note that the power levels in the EMC reports do not match the power levels listed on the 731. Please make power levels consistent throughout documentation. The 731 form has been updated with the correct power levels. 2. Please note that in the test report FCC_0623_v1 the EGPRS data listed in section 2.3 for the 850MHz band shows data for the 1900Bnad. Please provide the EGPRS data for the 850MHz Band. This testing has now been carried out and the results can be found in test report Cph_FCC_0623_01v2. 3. Please note that while it is acceptable to have up to 3dB varaiance between the SAR report and the EMC report EIRP power levels, when there is a variance the highest reported power must still be in the SAR report. Please note that the highest EIRP power in the EMC reports are 32.5dBm (see page 6 of report FCC_0623_01TCFv1) while the highest EIRP in the SAR report is only 31.1 (see pages 16 and 18 of the SAR report). This is an almost 1.5dB difference with the SAR report not showing the highest reading. Please retest SAR using the higher power level or please retest EMC to show a consistent power relation to the SAR report. EMC testing has been repeated and the value is now 31.14dBm (Cph_FCC_0623_01v2). If the EMC report was to state the result to 1 decimal place, rather than the 2 it uses, this would mean that the value is the same (31.1dBm) in both reports.

NOKIA External Photographs FCC ID: QFXRM-132 Exhibit: 3 IC: 661Z-RM132 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved NOKIA External Photographs FCC ID: QFXRM-132 Exhibit: 3 IC: 661Z-RM132 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved NOKIA External Photographs FCC ID: QFXRM-132 Exhibit: 3 IC: 661Z-RM132 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved

1 (1) Exhibit 1 Label and Location FCC ID: QFXRM-132 Applicant Nokia UK IC ID: 661Z-RM132 Label: Location:

NOKIA Internal Photographs FCC ID: QFXRM-132 Exhibit: 9 IC: 661Z-RM132 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved NOKIA Internal Photographs FCC ID: QFXRM-132 Exhibit: 9 IC: 661Z-RM132 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved NOKIA Internal Photographs FCC ID: QFXRM-132 Exhibit: 9 IC: 661Z-RM132 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved

FCC Part 15C Compliance Test Report / Template Version 6.0 T:\Projects\RM-132\EMC\Results\FCC\Tre_FCC_0619_02.doc Copyright © TCC Nokia 1 (36) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 15C Compliance Test Report Test Report no.: Tre_FCC_0619_02.doc Date of Report: 15.5.2006 Number of pages: 36 Customer’s Contact person: Alison Kingston Testing laboratory: TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 94436 3608 Client: Nokia Corporation Nokia House Summit Avenue, Southwood FARNBOROUGH HAMPSHIRE GU14 0NG UK Tel. +44 1252 866000 Fax. +44 1252 866001 Tested devices/ accessories: GSM phone RM-132 /Battery BP-6M, AC-Charger AC-4, Headset HS-23 FCC ID: QFXRM-132 IC: 661Z-RM132 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart C, ANSI C63.4 (2003), IC standards RSS-GEN and RSS-210. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Jan-Erik Lilja, System Manager FCC Part 15C Compliance Test Report / Template Version 6.0 T:\Projects\RM-132\EMC\Results\FCC\Tre_FCC_0619_02.doc Copyright © TCC Nokia 2 (36) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 15C Compliance Test Report Date of receipt 2.5.2006 Testing completed 12.5.2006 The customer's contact person Alison Kingston Test Plan referred to \EMC\TESTPLAN\ Notes - Document name T:\Projects\RM-132\EMC\Results\FCC\Tre_FCC_0619_02.doc 1.1. EUT and Accessory Information The EUT is a quadri band (GSM850/900/1800/1900) mobile phone with GPRS, EGPRS and Bluetooth. Bluetooth is tested with maximum rated TX power. Product Type SN HW MV SW DUT GSM phone RM-132 004400711716512 5120 - 1.0613.0.4 40653 GSM phone RM-132 004400711716645 5120 - 1.0613.0.4 40654 Battery BP-6M - - - - 40599 Headset HS-23 - 0.6 1.2 0.2 40655 AC-Charger AC-4 - 1.1 1.0 - 40656 AC-Charger AC-4 - 1.1 1.0 - 40657 1.2. Summary of Test Results Bluetooth: Section in CFR 47 Section in RSS-GEN or RSS-210 Name of the test Result 15.247(b)(1) A8.4 (2) Peak output power PASSED 15.247(c) A8.5 Band edge compliance of RF emissions PASSED 15.247(c) A8.5 Spurious RF conducted emissions PASSED 15.247(c), 15.209 A8.5 Spurious radiated emissions PASSED 15.207 7.2.2 AC powerline conducted emissions PASSED 15.247(a)(1) A8.1 (1) 20 dB bandwidth PASSED 15.247(a)(1) A8.1 (2) Carrier frequency separation PASSED 15.247(a)(1)(iii) A8.1 (4) Number of hopping frequencies PASSED 15.247(a)(1)(iii) A8.1 (4) Time of occupancy PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Tampere Laboratory. FCC Part 15C Compliance Test Report / Template Version 6.0 T:\Projects\RM-132\EMC\Results\FCC\Tre_FCC_0619_02.doc Copyright © TCC Nokia 3 (36) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 CONTENTS 1. Summary for FCC Part 15C Compliance Test Report.............................................. 2 1.1. EUT and Accessory Information ............................................................................................2 1.2. Summary of Test Results .......................................................................................................2 2. Test setups.................................................................................................................. 5 2.1. Conducted RF test setup .......................................................................................................5 2.2. AC powerline conducted emissions test setup.......................................................................5 2.3. Spurious radiated emissions test setup .................................................................................5 3. Peak output power (FCC §15.247(b)(1), RSS-210 A8.4 (2))...................................... 6 3.1. Test method and limit .............................................................................................................6 3.2. Bluetooth Test results ............................................................................................................6 4. Band edge compliance of RF emissions (FCC §15.247(c), RSS-210 A8.5) ............ 9 4.1. Test method and limit .............................................................................................................9 4.2. Bluetooth Test results ............................................................................................................9 5. Spurious RF conducted emissions (FCC §15.247(c), RSS-A8.5).......................... 14 5.1. Test method and limit ...........................................................................................................14 5.2. Bluetooth Test results ..........................................................................................................14 6. Spurious radiated emissions (FCC §15.247(c), §15.209, RSS-210 A8.5).............. 18 6.1. Test method and limit ...........................................................................................................18 6.2.…

Text truncated - open the document above for the full version.

RM-132_test_setup_photographs.DOC 1 (2) TCC Tampere EUT test setups Picture 1 Spurious radiated emission measurement Picture 2 Radiated emission measurement GSM RX / Bluetooth TX + Computer peripherals TCC Tampere P.O. Box 68 FIN -33721 Tampere FINLAND Tel. +358 7180 46800 Fax. +358 7180 46880 RM-132_test_setup_photographs.DOC 2 (2) TCC Tampere Picture 3 AC powerline conducted emission measurement GSM RX / Bluetooth TX + Computer peripherals Picture 4 AC powerline conducted emission measurement Bluetooth TX TCC Tampere P.O. Box 68 FIN -33721 Tampere FINLAND Tel. +358 7180 46800 Fax. +358 7180 46880
