October 21, 2005 RE: FCC ID: QFXRM-99_ATCB002857 Attention: Alison Kingston I have a few comments on this Application. Please note that further comments may arise in response to answers provided to the questions below. 1. Please note that the required antenna terminal spurious emissions test does not appear to have been performed. Please provide this data as required by 2.1051 of the FCC rules. 2. FYI - Please note that as of September RSS 210 has undergone a revision. Please note that the new RSS210 reference for FHSS devices is RSS210 Issue 6 Annex 8. Please consider referencing the latest RSS210 standard. 3. It appears that this application is also for part 15B computer peripheral. Please note that the part 15B test report does not appear to contain test data showing the device being used as a computer peripheral device (i.e. data being sent and received via the I/O cable to/from the computer). Please explain and please show/provide this test data with the EUT as a computer peripheral. Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

Response to ATCB comments: 1. Please note that the required antenna terminal spurious emissions test does not appear to have been performed. Please provide this data as required by 2.1051 of the FCC rules. Due to the fact there is no conducted power output available in the product, it is not possible to carry out these measurements. 2. FYI - Please note that as of September RSS 210 has undergone a revision. Please note that the new RSS210 reference for FHSS devices is RSS210 Issue 6 Annex 8. Please consider referencing the latest RSS210 standard. Noted 3. It appears that this application is also for part 15B computer peripheral. Please note that the part 15B test report does not appear to contain test data showing the device being used as a computer peripheral device (i.e. data being sent and received via the I/O cable to/from the computer). Please explain and please show/provide this test data with the EUT as a computer peripheral. Please see report Tre_FCC_0537_05. In this report you will find the results for this listed in section 3. The computer and peripherals used for this test are included in the accessories listed in section 1.1. The set-up used for this can be seen in exhibit 7 – test set-up photographs.

NOKIA 15 th July 2005 External Photographs FCC ID: QFXRM-99 Exhibit; 3 IC: 661Z-RM99 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved NOKIA 15 th July 2005 External Photographs FCC ID: QFXRM-99 Exhibit; 3 IC: 661Z-RM99 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved NOKIA 15 th July 2005 External Photographs FCC ID: QFXRM-99 Exhibit; 3 IC: 661Z-RM99 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved

CONFIDENTIAL Exhibit 01: Label and Location FCC ID: QFXRM-99 Label Location IC ID: 661Z-RM99 Applicant: Nokia Mobile Phones Copyright © 2005 Nokia

NOKIA 15 th July 2005 Internal Photographs FCC ID: QFXRM-99 Exhibit: 9 IC: 661Z-RM99 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved NOKIA 15 th July 2005 Internal Photographs FCC ID: QFXRM-99 Exhibit: 9 IC: 661Z-RM99 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved NOKIA 15 th July 2005 Internal Photographs FCC ID: QFXRM-99 Exhibit: 9 IC: 661Z-RM99 Applicant: Nokia Corporation Copyright© Nokia. All rights reserved

FCC Part 15B Compliance Test Report / Template Version 3.0 T:\Projects\RM-99\EMC\Results\FCC\Tre_FCC_0537_05.doc Copyright © TCC Nokia 1 (12) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC Part 15B Compliance Test Report Test Report no.: Tre_FCC_0537_05.doc Date of Report: 3.10.2005 Number of pages: 12 Customer’s Contact person: Alison Kingston Testing laboratory: TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 FCC listing no.: IC recognition no.: 94436 3608 Client: Nokia Corporation Nokia House Summit Avenue, Southwood FARNBOROUGH HAMPSHIRE GU14 0NG UK Tel. +44 1252 866000 Fax. +44 1252 866001 Tested devices/ accessories: GSM phone RM-99 / Battery BL-5C, AC-charger AC-4, Memory card MU- 30, Laptop IBM Thinkpad T22, AC adapter 02K6543, Printer HP deskjet 1600CC3540A, Digital camera FUJI DS-7, Serial cable for camera, Parallel cable for printer FCC ID: QFXRM-99 IC: 661Z-RM99 Supplement reports: - Testing has been carried out in accordance with: CFR 47, FCC rules Part 15 Subpart B, ANSI C63.4 (2003), ICES-003, CISPR 22 and IC standards RSS-132, RSS-133 and RSS-210. Deviations, modifications or clarifications (if any) to above mentioned documents are written in each section under "Test method and limit". Documentation: The test report must always be reproduced in full; reproduction of an excerpt only is subject to written approval of the testing laboratory. The documentation of the testing performed on the tested devices is archived for 15 years at TCC Nokia. Test Results: The EUT complies with the requirements in respect of all parameters subject to the test. The test results relate only to devices specified in this document. Date and signature for the contents: Jari Jantunen, System Manager FCC Part 15B Compliance Test Report / Template Version 3.0 T:\Projects\RM-99\EMC\Results\FCC\Tre_FCC_0537_05.doc Copyright © TCC Nokia 2 (12) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 1. Summary for FCC Part 15B Compliance Test Report Date of receipt 12.9.2005 Testing completed 14.9.2005 The customer's contact person Alison Kingston Test Plan referred to \EMC\TESTPLAN\ Notes - Document name T:\Projects\RM-99\EMC\Results\FCC\Tre_FCC_0537_05.doc 1.1. EUT and Accessory Information The EUT is a triple band (GSM900/1800/1900) mobile phone with GPRS, EGPRS and Bluetooth. GSM band is tested in TX/RX mode. Bluetooth is tested with maximum rated TX power. Product Type SN HW MV SW DUT GSM phone RM-99 004400731614614 5601 - 2.0531.5.1 40335 Battery BL-5C M034111101614 - - - 40337 AC-Charger AC-4 - 1.1 1.0 - 40341 Memory Card MU-30 - - - - 40376 Data cable CA-53 - - - - 40339 Laptop IBM Thinkpad T22 555V2PT - - - 40201 AC Adapter 02K6543 - - - 40202 Printer HP deskjet 1600CC3540A USB8302546 - - - 40077 Digital camera FUJI DS-7 7102516 - - - 40076 Serial cable for camera - - - - - 40088 Parallel cable for printer - - - - - 40087 1.2. Summary of Test Results GSM 1900: Section in CFR 47 Section in ICES-003 (RSS-133) Name of the test Result 15.107, a 5.3 AC powerline conducted emissions PASSED 15.109, a 5.5 (9) Radiated emissions PASSED Bluetooth: Section in CFR 47 Section in ICES-003 Name of the test Result 15.107, a 5.3 AC powerline conducted emissions PASSED 15.109, a 5.5 Radiated emissions PASSED PASSED The EUT complies with the essential requirements in the standard. FAILED The EUT does not comply with the essential requirements in the standard. NP The test was not performed by the TCC Nokia Tampere Laborator y. FCC Part 15B Compliance Test Report / Template Version 3.0 T:\Projects\RM-99\EMC\Results\FCC\Tre_FCC_0537_05.doc Copyright © TCC Nokia 3 (12) TCC Nokia Tampere Laboratory P.O. Box 68 Sinitaival 5 FIN-33720 TAMPERE, FINLAND Tel. +358 (0) 7180 46800 Fax. +358 (0) 7180 46880 CONTENTS 1. Summary for FCC Part 15B Compliance Test Report.............................................. 2 1.1. EUT and Accessory Information ............................................................................................2 1.2. Summary of Test Results .......................................................................................................2 2. AC powerline conducted emissions (FCC §15.107, ICES-003 section 5.3)...................... 4 2.1. Test setup ..............................................................................................................................4 2.2. Test method and limit .............................................................................................................4 2.3. GSM 1900 Test results ..........................................................................................................5 2.4. Bluetooth Test results ............................................................................................................6 2.5. GFSK modulation, PRBS packet type....................................................................................6 3. Radiated emissions (FCC §15.109, ICES-003 section 5.5, RSS-132 6.6, RSS-133 9)............. 7 3.1. Test setup ..............................................................................................................................7 3.2. Test method and limit .............................................................................................................8 3.3. GSM 1900 Test results ..........................................................................................................9 3.4. Bluetooth Test results ..........................................................................................................10 4. Test Equipment......................................................................................................... 12 4.1. Conducted measurements ..................................................................…

Text truncated - open the document above for the full version.

RM-99_test_setup_photographs.DOC 1 (2) TCC Tampere P.O. Box 68 FIN -33721 Tampere FINLAND Tel. +358 7180 46800 Fax. +358 7180 46880 TCC Tampere EUT test setups Picture 1 Spurious radiated emission measurement Picture 2 Radiated emission measurement RM-99_test_setup_photographs.DOC 2 (2) TCC Tampere P.O. Box 68 FIN -33721 Tampere FINLAND Tel. +358 7180 46800 Fax. +358 7180 46880 TCC Tampere Picture 3 AC powerline conducted emission measurement
