PRELIMINARY RF Plug-In Appliance Module Cat. No. RZP15 Incandescent 1800W Fluorescent: 1800VA Resistive: 15A Motor: 1/2HP TV: 8A 120VAC, 60Hz INSTALLATION INSTRUCTIONS DI-000-RZP15-00A-X1 WARNINGS AND CAUTIONS: •To be installed and/or used in accordance with appropriate electrical codes and regulations. •If you are unsure about any part of these instructions, consult a qualified electrician. INTRODUCTION Leviton’s Vizia™ Z-wave™ components are designed to communicate with each other via Radio Frequency (RF) to provide remote control of your lighting. Using RF technology allows Leviton to provide the greatest signal integrity possible. Each module in Leviton’s Vizia™ RF component line is a Z-wave™ enabled device. In a Z-wave™ network, each device is designed to act as a router. These routers will re-transmit the RF signal from one device to another until the intended device is reached. This ensures that the signal is received by its intended device by routing the signal around obstacles and radio dead spots. The RZP15 Plug-In Appliance Module is fully compatible with any Z-wave™ enabled network, regardless of the manufacturer and can also be used with other devices displaying the Z-wave™ logo. CAUTION: Remember to exercise good common sense when using the Home Automation features of your Remote – especially when scheduling unattended devices. There can be some unexpected consequences if not used with care. For example, an empty coffee pot can be remotely turned on. If that should happen, your coffee pot could be damaged from overheating. If an electric heater is turned on by remote control while clothing is draped over it, a fire could result. DO NOT USE the remote for the control of high power heating appliances such as portable heaters. This device will not control lighting that is used with electronic low-voltage and high frequency power supply transformers, nor high pressure discharge lamps (HID lighting). This includes mercury-vapor, sodium vapor and metal halide lamps. FEATURES •Switch ON/OFF •Works with Z-wave™ compatible Controllers •Scene Capable •ON/OFF LED indicates status of load •Two way communication to provide status reporting to controllers •RF reliability •Ease of installation – No new wiring •Compatible with other Z-wave™ enabled devices INSTALLING YOUR APPLIANCE MODULE NOTE: Use check boxes when Steps are completed. Attaching Load to Plug-In Appliance Module: NOTE: In order to use your Vizia™ RF module in a Z-Wave™ network, it must be Enrolled in the network using a Primary Programmer/Controller, such as Leviton’s Cat. No., RZCPG-1LG. Before Enrolling your module, please refer to the Primary Controller/ Programmer instruction sheet for complete information. Refer to Step 3 for further details. •Locate Load to be controlled by Plug-In Appliance Module and ensure it is fully operational. Attach Load plug into Plug-In Appliance Module receptacle noting proper polarity of blades. Attaching Plug-In Appliance Module to Wall Receptacle: •Plug the Plug-In Appliance Module into wall receptacle. Verify that receptacle is live. If controlled by a wall switch, the switch must be kept ON at all times. Step 1 Enrolling Plug-In Appliance Module into Network: NOTES: •Some non-Leviton programmers may be built on older Z-Wave™ libraries which may require your module to be replicated in the network instead of enrolling it in the network. First try to enroll module in your network. If it is unable to enroll, refer to the Primary Controller/Programmer instruction sheet for replicating a device. A)When first powering Plug-In Appliance Module, there is a 30 second enrollmemnt access period before your device times out. Within 30 seconds, depress and hold the programming button located on the front of the module until the LED beneath the button turns to solid Amber (approx. 10 seconds). NOTE: If Plug-In Appliance Module times out, unplug device from receptacle and plug back in. The 30 second enrollment access period will then begin again. B)After LED turns solid Amber, release the button. The LED will start to blink Amber. The unit is now in the Enrollment/Un-Enrollment mode. If necessary to exit the Enrollment/Un-Enrollment mode, press the programming button. Step 2 Step 3 WARNINGS AND CAUTIONS: •Unplug unit when servicing fixture or changing bulbs. •Save this instruction sheet. It contains important technical data along with testing and troubleshooting information which will be useful after installation is complete. Step 2 cont’d. C)If using a Leviton Z-wave™ Programmer/ Controller, Cat. No. RZCPG, select the Menu Screen, then select Network and scroll down to the Enrollment screen. D)While standing close to the module, select it to enroll it in the network. NOTE: Only one device may be enrolled at a time. DO NOT put multiple devices into the Enrollment mode at any time. Step 3 cont’d. Programming and ON/OFF Button 1 ON 2 ON 3 ON 4 ON OFF OFF OFF OFF √ PRELIMINARY LIMITED 5 YEAR WARRANTY AND EXCLUSIONS Leviton warrants to the original consumer purchaser and not for the benefit of anyone else that this product at the time of its sale by Leviton is free of defects in materials and workmanship under normal and proper use for five years from the purchase date. Leviton’s only obligation is to correct such defects by repair or replacement, at its option, if within such five year period the product is returned prepaid, with proof of purchase date, and a description of the problem to Leviton Manufacturing Co., Inc., Att: Quality Assurance Department, 59-25 Little Neck Parkway, Little Neck, New York 11362-2591. This warranty excludes and there is disclaimed liability for labor for removal of this product or reinstallation. This warranty is void if this product is installed improperly or in an improper environment, overloaded, misused, opened, abused, or altered in any manner, or is not used under normal operating conditions or not in accordance with any labels or instructions. There are no other or i…
Text truncated - open the document above for the full version.
AHD EMC Lab, 92723 M152, Dowagiac, MI 49047, (269) 424-7014 FCC_Confident1.doc Request for CONFIDENTIALITY: Page 1 of 1 NVLAP ACCREDITED NARTE Certified Engineer Professional Engineer Federal Communications Commission Equipment Approval Services, P.O. Box 358315 Pittsburgh, PA 15251-5315 ELITE Electronic Engineering TCB Services 1516 Centre Circle Downers Grove, IL 60515-1082 Re: Request for exhibits to be kept confidential. FCC ID: QGH-RZP15 Gentlemen: Pursuant to 47CRF 0.459, Leviton Manufacturing Inc., and Twisthink LLC requests that these listed exhibits be held confidential. Circuit Block Diagram file names: EXB_CircuitBlockdiagram.pdf Theory/Description of Operation, file name: EXB_TechnicalDesc.pdf Schematics file names: EXB_schematicPwrRelayPCB.pdf EXB_schematic_RFPCB.pdf Leviton Manufacturing and Twisthink have invested considerable resources into developing this product. Having sections of Exhibit B, listed above, available to ‘competition’ would negate the advantage achieved in developing this product. Since this product type is a major product line for Leviton Manufacturing, not protecting the details of the design would result in a financial hardship for the company. The Federal Communications Commission will be notified, in writing, of any changes in the software/programming of the device that could affect the device’s RF characteristics. Your prompt consideration of this application for product certification will be greatly appreciated. Should you have any questions regarding the content of this report, kindly contact me. Sincerely, Ted Chaffee, Technical Lab Manager Narte Certified Engineer, #EMC-002025-NE tel/fax: 269. 424.7014 email: [email protected]
Test report #0500786APLF FCC 15.249 for RZP15 FCC ID: QGH-RZP15 Tested June 8, 2005 AHD EMC Lab, 92723 M152, Dowagiac, MI 49047, (269) 424-7014 EXmisc_RFexpose.doc Misc. EXHIBIT: Page 1 of 1 MISC. EXHIBIT: RF EXPOSURE INFORMATION [2.1093(C)] The manufacturer and applicant: LEVITON MANUFACTURING, INC. 59-25 Little Neck Pkwy. Little Neck, NY 11362 Product: RF Plug-In Appliance Module. Model: RZP15 Applicable Rules: 47CFR Part 15.249 Pursuant to 47CFR Part 1.1307(b), 47CFR Part 2.1091(c), and 47CFR Part 2.1093(c) this transmitting device, compliant to 47CFR Part 15.249, is categorically excluded from evaluation regarding the Maximum Permissible Exposure of RF energy.
Test report #0500786APLF FCC 15.249 for RZP15 FCC ID: QGH-RZP15 Tested June 8, 2005 AHD EMC Lab, 92723 M152, Dowagiac, MI 49047, (269) 424-7014 EXE_TestRprt.doc EXHIBIT E: Page 1 of 18 EXHIBIT E: REPORT OF MEASUREMENTS [2.1033(B6)] Test Report for FCC ID: QGH-RZP15 FCC Part 2.1031, Part 15 Subpart C(15.249) Report #0500786APLF Issued 06/23/05 908.42MHZ TRANSCEIVER MODEL RZP15 Prepared for: LEVITON MANUFACTURING, Inc. 59-25 Little Neck Pkwy Little Neck, NY 11362 Test Date(s): April 13, May 5,6,11,19,25, June 8, 2005 data recorded by Ted Chaffee, NCE Gordon L. Helm, NCE This report prepared by: Ted Chaffee, NCE Technical Manager/Test Engineer, AHD Test report #0500786APLF FCC 15.249 for RZP15 FCC ID: QGH-RZP15 Tested June 8, 2005 AHD EMC Lab, 92723 M152, Dowagiac, MI 49047, (269) 424-7014 EXE_TestRprt.doc EXHIBIT E: Page 2 of 18 TABLE OF CONTENTS EXHIBIT E: Report of Measurements [2.1033(b6)] .....................................................................................1 TABLE OF CONTENTS.........................................................................................................................2 Statements Concerning this Report.......................................................................................................3 Manufacturer/Applicant [2.1033(b1)] ....................................................................................................4 Measurement/Test Site Facility & Equipment........................................................................................4 Test Site1 [2.948, 2.1033(b6)] ....................................................................................................4 Measurement Equipment Used [2.947(d), 15.31(b)] ....................................................................4 Test Site2 [2.948, 2.1033(b6)] ....................................................................................................5 Tested Configuration /Setup: [2.1033(b8)] ............................................................................................6 Support Equipment & Cabling .......................................................................................................6 Setup Diagram ...............................................................................................................................6 Summary of Results: .............................................................................................................................7 Changes made to achieve compliance..........................................................................................7 Standards Applied to Test: [2.1033(b6)]................................................................................................8 Test Methodology: [2.1033(b6)].............................................................................................................8 FORMULAS AND SAMPLE CALCULATIONS: ...........................................................................10 Test Data [2.1033(b6)].........................................................................................................................11 Relative Emission Level vs. Supply Voltage [15.31(e)] ...............................................................11 Modulation Characteristics ..........................................................................................................12 Occupied Bandwidth ....................................................................................................................12 Radiated Field Strength Measurements: [15.209, 15.249(a,d)] .................................................13 Out of Band Emissions [15.249(d)]..............................................................................................16 Line Conducted Measurements: [15.207(a)]...............................................................................17 Test report #0500786APLF FCC 15.249 for RZP15 FCC ID: QGH-RZP15 Tested June 8, 2005 AHD EMC Lab, 92723 M152, Dowagiac, MI 49047, (269) 424-7014 EXE_TestRprt.doc EXHIBIT E: Page 3 of 18 Statements Concerning this Report NVLAP Accreditation: NVLAP Lab Code 200129-0 The scope of AHD accreditation is the conducted emissions, radiated emissions test methods of: IEC/CISPR 22: Limits and methods measurement of radio disturbance characteristics of information technology equipment. FCC Method – 47 CFT Part 15: . AS/NZS 3548: Electromagnetic Interference – Limits and Methods of Measurement of Information Technology Equipment. IEC61000-4-2 and Amend.1: ElectroStatic Discharge Immunity IEC61000-4-5: Surge Immunity Test Data: This test report contains data covered by the NVLAP accreditation. Subcontracted Testing: This report contains data recorded at the University of Michigan Radiation Laboratory. The University of Michigan test facility is located at 8501 Beck Road, Belleville, Michigan 48111. This test facility has been fully described and accepted by the FCC and Industry Canada. This facility was utilized to measure emissions occurring at frequencies greater than 6GHz. Test Traceability: The calibration of all measuring and test equipment and the measured data using this equipment are traceable to the National Institute for Standards and Technology (NIST). Limitations on results: The test results contained in this report relate only to the Item(s) tested. Any electrical or mechanical modification made to the test item subsequent to the test date shall invalidate the data presented in this report. Any electrical or mechanical modification made to the test item subsequent to this test date shall require an evaluation to verify continued compliance. Limitations on copying: This report shall not be reproduced, except in full, without the written approval of AHD. Limitations of the report: This report shall not be used to claim product endorsement by NVLAP, FCC, or any agency of the US Government. Statement of Test Results Uncertainty: Following the guidelines of NAMAS publi…
