QH7-MP3P-BULLETHost MP3 Player

Quick Guide for Host MP3P index 1 main part of product 2 part name and function 3 display LCD & manu for each mode 4 3 quick step for listening the music 5 caution for safety 6 homepage address & How to firmware upgrade 7 benefit of resistering as a customer 8 features 9 COPYRIGHT NOTICE 10 standard 11 warranty 12 basic instruction for host mp3p bullet cradle 1 main part of product Host MP3P Bullet / stereo earphone / USB data cable / quick guide / keyring case 2 part name and function (lock&unlock/firmware download) choice switch Bullet left side Bullet Front side lock unlock firmware ownload/reset ② display LCD ③ usb data cable connecting port FF:previous song/previous menu menu mode/set repeat [REW]next song/next menu Bullet right side earphone keychain groove seperable usb memory(slide form) Bullet rear Bullet top ⑧ ear phone jack ⑤ ④(previous song/mode menu/shortcut to modemenue/nextsong/repeat track/speed control/jog switch) ⑦volume control spinnig button ⑨ on/off/play/pause button ⑦ volume control spinning button 1. lock/unlock, firmware download(reset)mode select switch - you can lock or unlock the menu butoon for each part, you can download the firmware to solve problem(or reset) 2. display LCD - dsplay condition of playing mp3p player by image and text ex) battery, lock, (repeat) play,condition of play, play process and time,repeat mode, song number, song title, words, sound effect, menu, file, frequency,volume 3. usb data cable connecting port(download firmware - in case of charging or downlading firmware or reset, you can set the downloaded firmware by conneting usb usb data cable after set firmware downloading mode [ff]next song(menu)/[rw]previous song(menu)/mode menu/shortcut to mode menu/[a-b]track repeat/speed control/select jog switch - you can move to next/previous menu by controlling jog switch up and down - you can go to mode menu and select menu by pushing jog switch, , even during playing mode you can go to mode menu by pushing jogswitch for 3 second - during playing you can listen a certain track repeatly if you push jog switch at starting track and finish track - you can control playing speed controlling jogswitch up and down) 4. earphone groove -can attach earphone ketchain 5. seperatible usb memory - as a usb drive and mp3 player memory, you can keep,move,control songs or files easily separated) 6. volume control spinning button -you can control volume by spinning 7. earphone jack - you can hear by connecting stereo earphone 8. 전원켜기&끄기/재생/일시정지 버튼(on&off/play/pause botton) - 전원을 켜려면 3초 이상, 전원을 끄려면 6초 이상 길게 누르시고, 가볍게 한번만 누르시면 음악을 듣거나 일 시정지를 시킬수 있습니다.(push 3 sec for off, 6sec for off, little touch for listening music or pause) 3 LCD display & menu of modes ON) OFF 1. Music Mode PLAY MODE : (Default Repeat All) Normal(NOR) /Shuffle Folder(F)/ Shuffle Once(1)/ Shuffle Repeat(R) /Track Once(TR) /Repeat Folder(RF)/Repeat All(RA)/Repeat Track(RT) / Exit EQUALIZER : (Default Normal) Normal / Rock / Jazz / Classical / Pop / Custom / QBS 3D / Exit SELECT FOLDER : Select Folder / Open Folder / Exit Setting : LCD Contrast [ 0 ~ 30 ] (Default 15) /BackLight Time [ 1 ~ 20 ] (Default 5) /Language [English/Germany/Spain/French/Chinese Trad/Chinese Simp/Japanese/Korean] (Default English) /Idle ShutDown Time [ 1 ~20 ] / Information Memory / Factory Setting : Default Setting / Exit Watch : Time Set : year, month, day, time, minute setting Alram Set : FM frequency, time, minute, Alram On/Off setting Delete : Delete File / Exit Exit : 2. FM Mode FM : Mono/Stereo [ Mono / Stereo ] Auto Preset [ ON / OFF ] Manual Preset [ P01 ~ P20 ] Preset Delete [ All / Each ] 3. Mode Select Mode : [ Music / FM ] 4 3 quick step for listening the music if you want to charge battery, connect player to computer using usb data cable. Charge for 1 hour.(caution : this product need to be connected to a high electricity usb data cable or usb2.0 hub. It doesn’t work by connecting keyboard or low electricity usb port) 1 step : detatching usb(mp3 player memory also push the seperatable usb at the back of mp3 player and connect to usb port) 2 step : 2단계 : saving mp3/bvr/wma/ogg file after saving sound source in usb, detatch usb memory using safe hardware removing icon (if you want to buy music source on line) 3 step : play after connecting usb which has sound source, listen to the music or change institution and enjoy the music 5 homepage address and firmware upgrade you can get access to the information about our product by connecting www.hanausb.com and download file You can upgrade product’s quality by downloading firmware 6 benefit of resistering as a customer email service about online AS,new product information,firmware upgrade,events 7 feature 1. unlimited memory expansion with Seperatable memory It is possible to expand memory by replacing memory and use general USB also, [128MB, 256MB, 512MB, 1GB, 2GB] 2. outstanding quality multi codec / full OGG available Not just MPEG1/2/2.5 LAYER3, VBR, WMA but also OGG which is regarded as the new Audio condensation technique are available to play [OGG, MPEG1/2/2.5 LAYER3, VBR, WMA] 3. various EQ effect which you can enjoy 3D sound with QBS 3D Stereo - 10 levels of selectable sound image position wherever you wish - 10 levels of selectable sound amplification as you wish - QBS 7 Band Graphic Equalizer makes it play outstanding sound by controlling radio frequency [-12dB ~ +12dB] - various EQ Mode “Classic, Rock, Pop, Jazz, Ballad, Live, Bass” is essential - User EQ Mode provide to control it by hands 4. FM Radio receipt and Voice Recording(Under consideration) FM broadcastion receipt by More powerful Stereo Sound with FM Radio receipt function - real time FM broadcasting recording, Voice recording support - Saving of Broadcasting channel up to 20 - Whenever you wish you can save and listen to FM broadcasting as file 5. Enjoy lyrics listening to music lyric support service with throughout lyric Database manager 6. Firmware Upgrade support you can maintain you produ…

Text truncated - open the document above for the full version.

MP3 Host Block Diagram 2005.05.30 TCC760 Core NOR Flash 8Mbit Audio Codec TCC764A LTC4054 Battery Charger +5VDC From Cradle Battery 3500mA 62200 DC/DC 62202 DC/DC AME8800 LDO VDD3V VDD2.7 (2.7V) VDD1.8 (1.8V ) K4S641633LH SDRAM (16MB) 12MHz VDD2.7 (2.7V) VDD1.8 (1.8V ) LCD MP3 Power Block EL Driver VDD2.7 (2.7V) Reset IC GND Reset S/W DA3001 FM Receiver RTC PCF8563 ENCODER Key JOG Switch Slide Switch FUSB11 Analog S/W Main USB Connector Ear Jack External Audio line Cradle Main MP3 +5VDC USB Interface Extra Audio Line Main MP3 / Cradle System Features TCC760 Core NOR Flash 8Mbit Audio Codec 12MHz RTC PCF8563 RTC_SCL K4S641633LH SDRAM (16MB) SD_CLK DA3001 FM 수신기 FMRX_CLK 32.768KHz Cloc k Block Diagram
