QLM0040405Bluetooth Telephony Base

2 2 2 3 4 6 7 8 8 8 9 10 11 Introduction ATA Telephony Base BT41 Usage Requirement Product information Appearance Setup the unit Pairing Operating BT41 Making outgoing call Receiving incoming call Troubleshooting Important Information Warranty FCC Statement Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Par t 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to tr y to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected! - Consult the dealer or an experienced radio TV technician for help. War ning: You are cautioned that any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Par t 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. To comply with FCC RF exposure requirement, this device and its antenna must be co-located or operating in conjunction with any other antenna or transmitter. Introduction ATA Bluetooth Neckset BT25 Usage Requirement Appearance Special Features Changing the Battery Putting on the Neckset Turning on/off the Neckset Adjusting the Listening Volume Pairing Bluetooth Passkey Pairing the Neckset Making and Receiving Calls Call transfer Enchance Handsfree Profile Features Neckset Battery Level Troubleshooting Important Information This User's Guide is published by ATO without any warranty. Improvements and changes to this User's Guide necessitated by typographical errors, inaccuracies of current information ,or improvements to programs and /or equipment, may be made by ATO at any time and without notice. FCC Statement This device complies with part 15 of the FCC rules, Operation is subject the following two conditions : (1)This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. "Static eletricity may cause the headset to turn off. If happen, please turn on the headset by press and hold the ON/OFF button." ATA T elephony Base BT41 Thanks you for purchasing Bluetooth Telephony Base BT41. BT41 telephony Base is designed and manufactured in accordance with Bluetooth specification v1.1. Bluetooth wireless technology is a global specification for personal area wireless connectivity to ensure communication compatibility worldwide. It connects any portable and stationary communication devices with Bluetooth enabled devices easily without a single inch of cable. BT41 Telephony Base accepts calls from both your desktop and mobile phones. It will also let you make call / answer from either your desktop phone via your Bluetooth wireless headset. This User's Guide will show you how to connect and operate BT41 Telephony Base. Usage Requirement You can use the Bluetooth Telephony Base with any desktop phone and Bluetooth wireless headset that is compatible with Bluetooth wireless technology and supports the Headset Profile (as audio gateway). This User's Guide is published by ATO without any warranty. Improvements and changes to this User's Guide necessitated by typographical errors, inaccuracies of current information ,or improvements to programs and /or equipment, may be made by ATO at any time and without notice. Headset / Handsfree Profile-Defined by the Bluetooth Special Interest Group (SIG), it describes how manufacture should implement the various features supported by a Bluetooth Headset. The Bluetooth trademarks are owned by Bluetooth SIG, Inc.USA. To use BT41 with a Bluetooth wireless headset, you must first pair the two devices. 1. After power on BT41, the indicator light will turned green. 2. Set the Bluetooth headset in pairing mode. 3. Press the pairing button of BT41 for one second and the indicator light will turned from green to a blinking blue. Now BT41 is ready to be paired. 4. Blue light will stop blinking when paired and now both units enter ready mode. Making outgoing call 1. Press the number you want to call from the desktop phone pad (as you normally will do when trying to make a call with the desktop phone). 2. Press Bluetooth headset TALK button and wait for a dial tone (indicator light will turned blue). 3. After the call is connected, user may talk with the headset. 4. When the call is finished, press the TALK button again to end. Receive incoming call 1. When there is incoming call (ringing sound can be heard in both headset and the desktop phone), press the headset TALK button to receive the call. 2. To hang up, press the headset TALK button once again. Battery chamber Volume / pairing button Front viewBack view Bottom view (+) volume up (-) volume down TELEPHONY BASE BT41 Bluetooth Wireless Headset Telephony base AC/DC adapter to wall socket Wall phone jack (RJ11) (RJ11) (RJ11) Desktop phone This section lists some problems that you might encounter while using your headset. No sound contact bet ween headset and other device The headset and the device you are using with it have to be paired to r…

Text truncated - open the document above for the full version.

Hello Mike, Attached file is the revised user manual of BT-41 (AN04T4038) for your reference, thanks! Best regards, Rick Hu

ETC Report No.: ET93S-05-209-01 Page A1 of A1 FCC ID: QLM0040405 ANNEX A: EXTERNAL CONSTRUCTION PHOTOS OF EUT 1. Outside View 1 of EUT 2. Outside View 2 of EUT

Rev. No 1.0 FCC Part 15 EMI TEST REPORT of E.U.T. : Bluetooth Telephony Base MODEL : BT41 FCC ID. : QLM0040405 for APPLICANT : Antonio Precise Products Manufactory Ltd. ADDRESS: 3/F, Photonics Centre, No. 2 Science Park East Avenue, Hong Kong Science Park, Shatin, Honk Kong Test Performed by ELECTRONICS TESTING CENTER, TAIWAN NO. 8 LANE 29, WENMIMG ROAD, LOSHAN TSUN, KWEISHAN HSIANG, TAOYUAN, TAIWAN, R.O.C. Tel:(03)3280026#570~576 Fax:(03)3276188 Report Number : ET93S-05-209-01 ETC Report No. : ET93S-05-209-01FCC ID. : QLM0040405 Rev. No 1.0 TEST REPORT CERTIFICATION Applicant: Antonio Precise Products Manufactory Ltd. 3/F, Photonics Centre, No. 2 Science Park East Avenue, Hong Kong Science Park, Shatin, Honk Kong Manufacturer: Antonio Precise Products Manufactory Ltd. 3/F, Photonics Centre, No. 2 Science Park East Avenue, Hong Kong Science Park, Shatin, Honk Kong Description of EUT: a) Type of EUT: Bluetooth Telephony Base b) Trade Name: Bluetooth Telephony Base c) Model No.: BT41 d) Power Supply: AC Adaptor (A20635N) Input: 120VAC, 60Hz, 5W ; Output: 5.5VDC, 350mA Regulation Applied: FCC Rules and Regulations Part 15 Subpart B & C (2003) I HEREBY CERTIFY THAT: The data shown in this report were made in accordance with the procedures given in ANSI C63.4, and the energy emitted by the device was founded to be within the limits applicable. I assume full responsibility for accuracy and completeness of these data. Note: 1. The result of the testing report relate only to the item tested. 2. The testing report shall not be reproduced expect in full, without the written approval of ETC. Issued Date :May 31, 2004 Test Engineer : Approve & Authorized Signer : Signature Win-Po Tsai Manager of EMC Testing Department Electronics Testing Center, Taiwan ETC Report No. : ET93S-05-209-01FCC ID. : QLM0040405 Rev. No 1.0 Table of ContentsPage 1 GENERAL INFORMATION .....................................................................................................................1 1.1 Product Description ....................................................................................................................................1 1.2 Characteristics of Device ............................................................................................................................1 1.3 Test Methodology .......................................................................................................................................1 1.4 Modifiction List of EUT .............................................................................................................................1 1.5 Test Facility ................................................................................................................................................1 2 PROVISIONS APPLICABLE ....................................................................................................................2 2.1 Definition ....................................................................................................................................................2 2.2 Requirement for Compliance ......................................................................................................................3 2.3 Restricted Bands of Operation ....................................................................................................................5 2.4 Labeling Requirement.................................................................................................................................5 2.5 User Information .........................................................................................................................................6 3. SYSTEM TEST CONFIGURATION ........................................................................................................7 3.1 Justification .................................................................................................................................................7 3.2 Devices for Tested System..........................................................................................................................7 4 RADIATED EMISSION MEASUREMENT ............................................................................................8 4.1 Applicable Standard....................................................................................................................................8 4.2 Measurement Procedure .............................................................................................................................8 4.3 Measuring Instrument ...............................................................................................................................10 4.4 Radiated Emission Data ............................................................................................................................11 4.4.1 RF Portion.........................................................................................................................................................11 4.4.2 Other Emission .................................................................................................................................................14 4.5 Field Strength Calculation ........................................................................................................................16 5 CONDUCTED EMISSION MEASUREMENT ......................................................................................17 5.1 Standard Applicable..................................................................................................................................17 5.2 Measurement Procedure ...........................................................................................................................17 5.3 Conducted Emission Data.........................................................................................................................18 5.4 Result …

Text truncated - open the document above for the full version.

ETC Report No.:ET93S-05-209-01Sheet 1 of 2 Sheets FCC ID.: QLM0040405 4.6 Photos of Radiation Measuring Setup ETC Report No.:ET93S-05-209-01Sheet 2 of 2 Sheets FCC ID.: QLM0040405 5.6 Photos of Conduction Measuring Setup
