QQ7EGUARDRC900NRemote controller

RC900N remote controller 1 Environments: Operating temperature：0°C—40°C Storage temperature：－40°C—60°C Relative humidity：5%—95% 2 Technical: Operating voltage.............................................+3.0VDC Operating current.............................................＜17 mA Remote control range.....................................≥15cm（+3V） 3 Dimensions: 106mm*37mm*18mm 4 Introduction This product is used with IRAT for detecting and cut off the alarm. 5 How to use To make sure the IRAT works OK in standby mode, move the remote controller close to IRAT and press RESET key on it. If the red LED spark, that means the IRAT works well. To cut off the IRAT alarm, the operation is the same. Caution: Any changes or modifications not expressly approved by the party responsible for product compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

REMOTE CONTROL OPERAT. CURRENT : 15mA 3VDC RATING ： RC900N MODEL No:FCC ID:QQ7EGUARDRC900N 0197 REMOTE CONTROL OPERAT. CURRENT : 15mA 3VDC RATING ： RC900N MODEL No:FCC ID:QQ7EGUARDRC900N 0197 PDF 文件使用 "pdfFactory Pro" 试用版本创建 www.fineprint.cn

Page 1/21 FCC TEST REPORT For Remote controller Model Number: RC900N FCC ID: QQ7EGUARDRC900N Report Number : WT108004909 Test Laboratory : Shenzhen Academy of Metrology and Quality Inspection National Testing Center for Digital Electronic Products Site Location : Bldg. Metrology and Quality Inspection, Longzhu Road, Shenzhen, Guangdong, China Tel : 0086-755-26941599 Fax : 0086-755-26941545 Web : www.smq.com.cn Report No.:WT108004909 Page 2 of 21 Test report declaration Applicant : Shenzhen ronghua electric Co., Ltd Address : 3rd floor, 524th building, Bagualing, Futian, Shenzhen Manufacturer : Shenzhen ronghua electric Co., Ltd Address : 3rd floor, 524th building, Bagualing, Futian, Shenzhen EUT Description : Remote controller Model No : RC900N FCC ID : QQ7EGUARDRC900N Test Standards: FCC Part 15 15.31, 15.35, 15.203, 15.205, 15.209, 15.223 The EUT described above is tested by Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory to determine the maximum emissions from the EUT. Shenzhen Academy of Metrology and Quality Inspection EMC Laboratory is assumed full responsibility for the accuracy of the test results. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 (2003) and the energy emitted by the sample EUT tested as described in this report is in compliance with FCC Rules Part 15.203, 15.205, 15.207, 15.209 and15.223. The test report is valid for above tested sample only and shall not be reproduced in part without written approval of the laboratory. Project Engineer: Date: Jan.21,2011 (Ryan Chen) Checked by: Date: Jan.21,2011 (Dewelly Yang) Approved by: Date: Jan.21,2011 (Peter Lin) Report No.:WT108004909 Page 3 of 21 TABLE OF CONTENTS TEST REPORT DECLARATION........................................................................................................2 1. TEST RESULTS SUMMARY...................................................................................................4 2. GENERAL INFORMATION......................................................................................................5 2.1. Report information..........................................................................................................5 2.2. Laboratory Accreditation and Relationship to Customer.........................................5 2.3. Measurement Uncertainty.............................................................................................6 3. PRODUCT DESCRIPTION.......................................................................................................7 3.1. EUT Description..............................................................................................................7 3.2. Related Submittal(s) / Grant (s)...................................................................................7 3.3. Block Diagram of EUT Configuration..........................................................................7 3.4. Operating Condition of EUT..........................................................................................7 3.5. Support Equipment List.................................................................................................7 3.6. Test Conditions...............................................................................................................8 3.7. Special Accessories.......................................................................................................8 3.8. Equipment Modifications...............................................................................................8 4. TEST EQUIPMENT USED........................................................................................................9 5. CONDUCTED DISTURBANCE TEST..................................................................................10 5.1. Test Standard and Limit..............................................................................................10 5.2. Test Procedure.............................................................................................................10 5.3. Test Arrangement.........................................................................................................10 5.4. Test Data.......................................................................................................................10 6. OCCUPIED BANDWIDTH......................................................................................................11 6.1. Test Standard and Limit..............................................................................................11 6.2. Test Procedure.............................................................................................................11 6.3. Test Arrangement.........................................................................................................11 6.4. Test Data.......................................................................................................................11 7. RADIATED DISTURBANCE TEST.......................................................................................13 7.1. Test Standard and Limit..............................................................................................13 7.2. Test Procedure.............................................................................................................14 7.3. Test Arrangement.........................................................................................................14 7.4. Test Data.......................................................................................................................14 8. ANTENNA REQUIREMENT...................................................................................................21 8.1. STANDARD APPLICABLE.........................................................................................21 8.2. ANTENNA CONNECTED CONSTRUCTION.................…
