QVE-0103-001Remote Control Transmitter No. RRC9200-08xxR

March 5, 2003 Federal Communications Commission Authorization & Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: SMK Manufacturing, Inc. FCC ID: QVE-0103-001 Gentlemen: Submitted herewith, on behalf of SMK Manufacturing, Inc., is an application for Part 15.231 certification of the remote control transmitter. Attached are the authorization letter, measurement report (measurement data and test plots), FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), schematic diagram (confidential), parts list (confidential), operational description, and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: SMK Manufacturing, Inc.

May 27, 2003 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Katie Hawkins SUBJECT: SMK Manufacturing, Inc. FCC ID: QVE-0103-001 731 Confirmation No.: TC155739 Correspondence Reference No.: 8062 Transmitted herewith, on behalf of SMK Manufacturing, Inc. is an amendment provided in response to the request for technical information dated April 29, 2003. 1. All keypad inputs to the CPU input port are momentarily normally open switches. When no keys are depressed no transmission will occur. Eight clock cycles after a key is released U1 terminates the output enable, thereby, ceasing transmission via RF cut off transistor Q-4. With the 6 MHz clock, RF transmission is terminated well within a 5-millisecond time period, thereby, complying with the 5-second limit. 2. We confirm that the EUT as tested in 3 orthogonal planes from 30 MHz- 4.28 GHz. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: SMK Manufacturing, Inc.

© 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100) © 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100) © 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100) © 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100)

© 2003 PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

© 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100) © 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100) © 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100) © 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100) © 2003 PCTEST Lab SMK FCC ID: QVE-0103-001 NVLAP Lab Code: 100431-0 RF Remote Control (Model: DST-3100)

Operational Description Product Description The Remotecontrol controls its Satellite Set Top Box via IR and RF. IR optical wavelength is 950 nm. RF transmission is off as default. User can chose disable and able RF transition. The microcontroller used is a Zilog Z86L88. The RF transmission frequency is 428 MHz that is generated by 428MHz Saw resonator. The receiver receives 428 MHz.

PCTEST PT. 15.231 REPORT EVALUATION REPORT Reviewed By: Quality Manager TEST REPORT S/N: TX.221030560.QVE Test Dates: Oct. 31, 2002 EUT Type: RF Remote Control FCC ID: QVE-0103-001 Page 1 of 12 © 2003 PCTEST ENGINEERING LABORATORY, INC. PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE SMK MANUFACTURING. INC. Dates of Tests: October 31, 2002 1055 Tierra Del Rey Test Report S/N: TX.221030560.QVE Chula Vista, CA 91910 Test Site: PCTEST Lab, MD U.S.A. Attention: Tom Fukushima, Engineering Manager FCC ID QVE-0103-001 APPLICANT SMK MANUFACTURING. INC. FCC Rule Part(s): § 15.231 Subpart C — Intentional Radiator Classification: Remote Control Transmitter (DSC) EUT Type: RF Transmitter Remote Control Freq. Range: 428.0MHz ~ 428.0MHz Model: DST-3100 This device has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified is ANSI C63.4-1992. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. PCTEST PT. 15.231 REPORT EVALUATION REPORT Reviewed By: Quality Manager TEST REPORT S/N: TX.221030560.QVE Test Dates: Oct. 31, 2002 EUT Type: RF Remote Control FCC ID: QVE-0103-001 Page 2 of 14 © 2003 PCTEST ENGINEERING LABORATORY, INC. TABLE OF CONTENTS ATTACHMENT A: COVER LETTER(S) ATTACHMENT B: ATTESTATION STATEMENT(S) ATTACHMENT C: TEST REPORT SCOPE 3 INTRODUCTION (SITE DESCRIPTION) 4 PRODUCTION INFORMATION 5 DESCRIPTION OF TESTS (CONDUCTED) 6 DESCRIPTION OF TESTS (RADIATED) 7 ANTENNA REQUIREMENT / BANDWIDTH MEASUREMENT 8 FREQUENCY MEASUREMENTS (SPURIOUS) 9 PLOTS OF EMISSION 10 SAMPLE CALCULATIONS 11 ACCURACY OF MEASUREMENT 12 LIST OF TEST EQUIPMENT 13 CONCLUSION 14 ATTACHMENT D: TEST PLOTS ATTACHMENT E: FCC ID LABEL / LOCATION ATTACHMENT F: TEST SETUP PHOTOGRAPHS ATTACHMENT G: EXTERNAL PHOTOGRAPHS ATTACHMENT H: INTERNAL PHOTOGRAPHS ATTACHMENT I: BLOCK DIAGRAM(S) ATTACHMENT J: SCHEMATIC DIAGRAM(S) ATTACHMENT K: OPERATIONAL / CIRCUIT DESCRIPTION ATTACHMENT L: PARTS LIST ATTACHMENT M: USER’S MANUAL PCTEST PT. 15.231 REPORT EVALUATION REPORT Reviewed By: Quality Manager TEST REPORT S/N: TX.221030560.QVE Test Dates: Oct. 31, 2002 EUT Type: RF Remote Control FCC ID: QVE-0103-001 Page 3 of 14 © 2003 PCTEST ENGINEERING LABORATORY, INC. MEASUREMENT REPORT Scope - Measurement and determination of electromagnetic emissions (EME) of radio frequency devices including intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal Communications Commission. Company Name: SMK MANUFACTURING. INC. Address: 1055 Tierra Del Rey Chula Vista, CA 91910 Attention: Tom Fukushima, Engineering Manager • FCC ID: QVE-0103-001 • Model: DST-3100 • EUT Type: RF Transmitter Remote Control • Application Type: Transmitter Certification • Freq. Range: 428.0MHz ~ 428.0MHz • FCC Rule Part(s): § 15.231 Subpart C — Intentional Radiator • Dates of Tests: October 31, 2002 • Place of Tests: PCTEST Lab, Columbia, MD U.S.A. • Test Report S/N: TX. 221030560.QVE PCTEST PT. 15.231 REPORT EVALUATION REPORT Reviewed By: Quality Manager TEST REPORT S/N: TX.221030560.QVE Test Dates: Oct. 31, 2002 EUT Type: RF Remote Control FCC ID: QVE-0103-001 Page 4 of 14 © 2003 PCTEST ENGINEERING LABORATORY, INC. 1.1 INTRODUCTION The measurement procedure described in American National Standard for Methods of Measurement of Radio- Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz (ANSI C63.4-1992) was used in determining radiated and conducted emissions emanating from SMK (Model: DST-3100) RF Transmitter Remote Control FCC ID: QVE-0103-001. These measurement tests were conducted at PCTEST Engineering Laboratory, Inc. facility in New Concept Business Park, Guilford Industrial Park, Columbia, Maryland. The site address is 6660-B Dobbin Road, Columbia, MD 21045. The test site is one of the highest points in the Columbia area with an elevation of 390 feet above mean sea level. The site coordinates are 39° 11'15" N latitude and 76° 49'38" W longitude. The facility is 1.5 miles North of the FCC laboratory, and the ambient signal and ambient signal strength are approximately equal to those of the FCC laboratory. There are no FM or TV transmitters within 15 miles of the site. The detailed description of the measurement facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4 on October 19, 1992. 1.2 PCTEST Location The map at right shows the location of the PCTEST Lab, its proximity to the FCC Lab, the Columbia vicinity area, the Baltimore-Washington International (BWI) airport, and the city of Baltimore, and the Washington, D.C. area. (see Figure1). Figure 1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area. PCTEST PT. 15.231 REPORT EVALUATION REPORT Reviewed By: Quality Manager TEST REPORT S/N: TX.221030560.QVE Test Dates: Oct. 31, 2002 EUT Type: RF Remote Control FCC ID: QVE-0103-001 Page 5 of 14 © 2003 PCTEST ENGINEERING LABORATORY, INC. 2.1 Product Information 2.2 Equipment Description The Equipment Under Test (EUT) is the SMK Manufacturing (Model: DST-3100) RF Transmitter Remote Control FCC ID: QVE-0103-001. * Tx Freq. Range: 428.0MHz ~ 428.0MHz * Oscillator(s): 428MHz * Antenna: Built-in internal looped antenna on-board * Power Supply: (4) AAA Batteries PCTEST PT. 15.231 REPORT EVALUATION REPORT Reviewed By: Quality Manager TEST REPORT S/N: TX.2…
