QZ9-BURYBCM001Bluetooth Module for Audio and Data Transfer

Bury GmbH & Co KG

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: Apr 27, 2003
Application Purpose: Original Equipment
Date of Application: Apr 27, 2003
Equipment Note: Bluetooth Module for Audio and Data Transfer
Frequency Range: 2402.00000000 - 2480.00000000
Company: Bury GmbH & Co KG
Country: Germany

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

BURY GMBH & CO. KG ROBERT-KOCH-STRASSE 1-7 32584 LÖHNE BURY GMBH & CO. KG • ROBERT-KOCH-STR. 1-7 • 32584 LÖHNE FB QS / Stand 02.03 / Rev. 02 THB “Bluetooth Comfort Module” BCM001 OEM User Operation Manual Date of preparation: April 2003 BURY GMBH & CO. KG ROBERT-KOCH-STRASSE 1-7 32584 LÖHNE BURY GMBH & CO. KG • ROBERT-KOCH-STR. 1-7 • 32584 LÖHNE FB QS / Stand 02.03 / Rev. 02 General Notes: This document is issued by Bury GmbH & Co.KG (hereinafter called Bury) in confidence, and is not to be reproduced in whole or in part without the prior written permission of Bury. The information contained herein is the property of Bury and is to be used only for the purpose for which it is submitted and is not to be released in whole or in part without the prior written permission of Bury. Important 1. This module is intended to use for wireles audio and data transfer for OEM integration in final products. 2. When integrating the THB “Bluetooth Comfort Module” into a final product, the following information must be considered: All products containing the module must be labelled. The label must be affixed on an exterior surface of the end product such that it will be visible upon inspection in compliance with the modular approval guidelines developed by the FCC. The label must state “This device contains FCC ID QZ9-BURYBCM001” In addition, the user manual for the end product must contain the following information: "This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation." 3. Take care of electrostatic discharge while handling the module. This may destroy the module. 4. Don ́t place the module in a metal housing. This may reduce the operating distance. 5. This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. 6. For using antennas not mounted on the module see related document “Bluetooth Comfort Module Antenna Specification “. Take only the specified antennas, otherwise loss of FCC and Bluetooth Approval will result. 7. The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 8. The OEM Manufacturer must not describe to the end user how to install or deinstall the Bluetooth Comfort Module. BURY GMBH & CO. KG ROBERT-KOCH-STRASSE 1-7 32584 LÖHNE BURY GMBH & CO. KG • ROBERT-KOCH-STR. 1-7 • 32584 LÖHNE FB QS / Stand 02.03 / Rev. 02 Bluetooth module – Top side electret microphone + --- speaker --- + Picture 1. BURY GMBH & CO. KG ROBERT-KOCH-STRASSE 1-7 32584 LÖHNE BURY GMBH & CO. KG • ROBERT-KOCH-STR. 1-7 • 32584 LÖHNE FB QS / Stand 02.03 / Rev. 02 Bluetooth module – Bottom side J1 - 18 side contacts: 18 – Speaker + 12 – Volume - 6 – Voice IN + 17 – Speaker - 11 – Microphone mute 5 – Voice IN - 16 – Ground (supply - ) 10 – MFB/GPIO 4 – Serial Data Receive 15 – LED Green 9 – REF_CLK 3 – Serial Data Transmit 14 – LED Red 8 - VMIC 2 – Supply voltage + 13 – Volume + 7 - RESET 1 – Ground (supply - ) Note: For detailed pinout description of J1 see Table 2 . J4 charging -- voltage + J3 + Battery -- voltage Thermistor connection PRESS volume DOWN volume UP 3-functional SWITCH J2 40 contacts connector optionally mounted charger & power supply regulator components 18 - - 15 - - 12 - - 9 - - 6 - - 3 - - Picture 2. BURY GMBH & CO. KG ROBERT-KOCH-STRASSE 1-7 32584 LÖHNE BURY GMBH & CO. KG • ROBERT-KOCH-STR. 1-7 • 32584 LÖHNE FB QS / Stand 02.03 / Rev. 02 1. USAGE SCENARIO: Turn On Turn Off Answer a call Call Reject volume up/down Button functions LED signals BURY GMBH & CO. KG ROBERT-KOCH-STRASSE 1-7 32584 LÖHNE BURY GMBH & CO. KG • ROBERT-KOCH-STR. 1-7 • 32584 LÖHNE FB QS / Stand 02.03 / Rev. 02 2. ELECTRICAL DATA & CHARACTERISTICS: Table 1. “Bluetooth Comfort Module” Electrical Data: PARAMETER VALUE Charging voltage - DC 4,8 ÷ 5,8 V Absolute maximum charging voltage 6,0 V Main power supply (onboard regulator) Regulator maximum current 3,0 180 V mA Battery voltage Minimum operational battery voltage typ. 3,7 max. 4,2 min. 3,2 V V V Absolute maximum supply voltage NOTE! Supply voltage higher than 6 Volts - only if battery charger and its output capacitor are not mounted !!! 16,0 V Battery type Lithium Polymer Supply options: There is possibility to supply module from battery or from any other external power supply, regarding maximum input voltage of voltage regulator and other components. 3. THREE options for connecting external signals & power supply: 3.1. PCB pads shown in Picture 1. and Picture 2. 3.2. 40 contacts connector on bottom side shown in Picture 2. 3.3. Side contacts on bottom of Picture 2. 4. TWO options for operation: 4.1. Through 3-functional switch and I/O lines mentioned in points 3.2. and 3.3. 4.2. Through AT commands BURY GMBH & CO. KG ROBERT-KOCH-STRASSE 1-7 32584 LÖHNE BURY GMBH & CO. KG • ROBERT-KOCH-STR. 1-7 • 32584 LÖHNE FB QS / Stand 02.03 / Rev. 02 5. Microphone & speaker connections. Picture 3. Part of Bluetooth Comfort Module schematic - audio connections There are 3 options for connecting audio signals: Audio input: - electret microphone connections to pads J8, J9 on top of board - VOICE_IN – ( J1 – 5 ) & VOICE_IN + ( J1 – 6 ) audio direct input and also microphone power supply VMIC (J1 – 8 ) - if needed - J2 connector Audio output: - loudspeaker connections to pads J6, J7 on top of board - J1–18 & J1–17 - side contacts - J2 connector BURY GMBH & CO. KG ROBERT-KOCH-STRASSE 1-7 32584 LÖHNE BURY GMBH & CO. KG • ROBERT-KOCH-STR. 1-7 • 32584 LÖHNE FB QS / Stand 02.03 / Rev. 02 Picture 4. Sample connections – headset application. 6. Battery & charger: Charging voltage: External, 5V charging voltage is delivered to J4 on bo…

Text truncated - open the document above for the full version.
