RAWLYD203CAWireless Camera

Applicant: Shenzhen Lian Yi Da Science Co., Ltd. FCC ID: RAWLYD203CA MANUAL OF CAMERA Features: Wireless transmission and reception, Small size, light Weight, Low power consumption, High sensitivity, Easy to Install & operate, Easy to conceal. Operation Instructions: 1. Twist the receiver antenna into the receiver 2. Connect the receiver to the monitor with AV cable; 3. Plug the DC9V 500mA adaptor into the power jack of the receiver; 4. Insert the DC 8V200mA adapto r into the power jack of the camera; 5. Adjust the frequency controller on the receiver to the required position; 6. Adjust the lens of the camera to best position, Mount the camera with the screw. Function: Suitable for facilities in the supermarket, shop, department Store, clothes shop, workshop, wa rehouse, school, office and home. Important: The person who uses this product to peep, shoot and undertake Other illegal activities will be punished. Image pickup device 1/3, 1/4 TV system PLA/CCIR NTSC/EIA Resolution 380 TV lines Scan frequency PLA/CCIR: 50Hz NTSC/EIA: 60Hz Minimum illumination 3LUX Output power 50mW, 200mW Output frequency 902MHz~928MHz Power supply DC + 6 ~ 12V FCC Information This device complies with part 15 of the FCC Rules, Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expr essly approved by summer infant may void the user’s authority to operate this equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interfer ence to radio communications, however, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: z Reorient or relocate the receiving antenna z Increase the separation between the equipment and the receiver z Consult the dealer or an experienced radio / TV technician for help.

Applicant: Shenzhen Lian Yi Da Science Co., Ltd. FCC ID: RAWLYD203CA Block Diagram Video Audio Power DC8V 5V Regulator CMOS Camera 903~928 MHz Modulator RF Power AMP Microphone 5.5MHz Modulator Audio AMP

Applicant: Shenzhen Lian Yi Da Science Co., Ltd. FCC ID: RAWLYD203CA Proposed Label Location on EUT EUT Bottom View/Proposed FCC Mark Location FCC ID: RAWLYD203CA

Applicant: Shenzhen Lian Yi Da Science Co., Ltd. FCC ID: RAWLYD203CA (3) EUT inside whole view (4) Main board component side (5) Main board solders side

Applicant: Shenzhen Lian Yi Da Science Co., Ltd. FCC ID: RAWLYD203CA Operational Description LYD203CA wireless transmitter module intended for in 906MHz wireless A/V signal Sender and Receive set as RF output modulator, which converts the FM video and audio signal into the RF signal for TV or monitor. 1) This circuit modulates the voice or data onto a carrier frequency using FM. The modulated carrier signal is amplified and feeds to the antenna. 2) The audio signal picked up by the microphone is a very low- signal a microphone amplifier is used to amplify this signal so that it can be transmitted. This device has an outside antenna. And this device can also be seemed as a portable device with the monitor and can use within 30 feet indoor or 120 feet if without obstruction. You can fixed the device on a table or wall by screwed the mounting base. To fix the device, please follow the installation. And please make sure the supervision and monitor are set the same band before in use. Specification for LYD203CA wireless camera： * Transistors frequency ： 902~928MHz * Audio modulate: 5.5MHz * Oscillator types: Three capacitance Oscillator * Power supply: DC8V 200mA * Video System: NTSC * Output RF Power: 10mW * Video Level: 1Vp-p * Max Range: 120 feet * Transmitter Antenna: Directional * Transmitter Sensitivity: 0dbm FCC * Indoor/Outdoor: Indoor Only * Differential Gain ±8% * Audio Input Impedance 1.0K * Video Input Impedance 1.2K

FCC TEST REPORT UNDER FCC 15 Subpart C, Paragraph 15.249: 2003 PREPARED FOR： Shenzhen Lian Yi Da Science Co., Ltd. #2009A, Saige Building, Huaqiang Road North, Shenzhen China. July 8, 2003 PREPARED BY : Shenzhen Academy of Metrology & Quality Inspection Longzhu Road, Nanshan FCC Registration Number: 97379 FCC ID: RAWLYD203CA EUT: Wireless Camera Model: LYD203CA(LYD), LYD203C(LYD) Report Type: Original Report Test Engineer: Peter Lin Test Date: June 26, 2003 Review By: Apollo Liu Shenzhen Lian Yi Da Science Co., Ltd. FCC ID: RAWLYD203CA FCC ID Report Report #: KSZ2003061002J Page 2 of 23 TABLE OF CONTENTS 1. Summary of Test Results..................................................................................................................................................... 3 2. Test Statement ...................................................................................................................................................................... 4 2. 1 Test Statement................................................................................................................................................................. 4 2. 2 Departure From Document Policies, Procedure or Specifications, The Statement ......................................................... 4 3. EUT Modifications .............................................................................................................................................................. 5 4. Conducted Power Line Test ................................................................................................................................................ 6 4. 1 Test Equipment ............................................................................................................................................................... 6 4. 2 Test Procedure ................................................................................................................................................................ 6 4. 3 Test Setup ....................................................................................................................................................................... 6 4. 4 Configuration of The EUT.............................................................................................................................................. 7 4. 5 EUT Operating Condition............................................................................................................................................... 8 4. 6 Conducted Power Line Emission Limits......................................................................................................................... 8 4. 7 Conducted Power Line Test Result ................................................................................................................................. 9 5. Radiated Emission Test ..................................................................................................................................................... 11 5. 1 Test Equipment ............................................................................................................................................................. 11 5. 2 Test Procedure .............................................................................................................................................................. 11 5. 3 Radiated Test Setup ...................................................................................................................................................... 11 5. 4 Configuration of The EUT............................................................................................................................................ 12 5. 5 EUT Operating Condition............................................................................................................................................. 12 5. 6 Radiated Emission Limit .............................................................................................................................................. 12 5. 7 Radiated Emission Test Result...................................................................................................................................... 13 6. Band Edge .......................................................................................................................................................................... 15 6. 1 Test Equipment ............................................................................................................................................................. 15 6. 2 Test Procedure .............................................................................................................................................................. 15 6. 3 Radiated Test Setup ...................................................................................................................................................... 15 6. 4 Configuration of The EUT............................................................................................................................................ 16 6. 5 EUT Operating Condition............................................................................................................................................. 16 6. 6 Band Edge FCC 15.231(c) Limit .................................................................................................................................. 16 6. 7 Band Edge Test Result .................................................................................................................................................. 16 7. Photos of Testing ................................................................................................................................................................ 17 7. 1 EUT Test Photographs ............................................................…

Text truncated - open the document above for the full version.

Applicant: Shenzhen Lian Yi Da Science Co., Ltd. FCC ID: RAWLYD203CA Conducted emission test view Radiated emission test view
