RC6AWI-922TIEEE WIRELESS 802.11g WIRELESS MINI PCI ADAPTER

RaConfig Operation Manual RaConfig or windows zero configuration Start RaConfig Utility Site Survey Page Encryption Setting [WEP/TKIP/AES] 802.1X Authentication CA Server Setting Profile Page Link Status Page Statistic Page Advance Page Country Channel List QoS Page About Page Example on adding profile in site survey page Example to add profile in profile page Example to configure connection with WEP on Example to configure connection with WPA-PSK Example to configure connection with WPA2-PSK Example to configure connection with WPA Example to configure connection with WPA2 Example to configure to enable Wi-Fi Multi-Media Example to configure to enable WMM – Power Save Example to configure to enable DLS (Direct Link Setup) EXCURSUS Example to configure to enable DLS (Direct Link Setup) 1. Click “Direct Link Setup Enable”. And Click “Apply” button. 2. Change to “Site Survey Page”. And add a AP that supports DLS features to a Profile. The result will look like the below figure in Profile page. The setting of DLS indicates as follow: 1. Fill in the blanks of Direct Link with MAC Address of STA. The STA must conform to two conditions as follow: Connect with the same AP that support DLS features. Have to enable DLS. 2. Timeout Value represents that it disconnect automatically after some seconds. The value is integer. The integer must be between 0~65535. It represents that it always connects if the value is zero. Default value of Timeout Value is 60 seconds. 3. Click “Apply” button. The result will look like the below figure. Describe “DLS Status” as follow: 1. As the up figure, after configuring DLS successfully, show MAC address of the opposite side and Timeout Value of setting in “DLS Status”. In “DLS Status” of the opposite side, it shows MAC address of myself and Timeout Value of setting. 2. Display the values of “DLS Status” to “Direct Link Setup” as follow: 1. In “DLS Status”, select a direct link STA what you want to show it’s values in “Direct Link Setup”. 2. Double click. And the result will look like the below figure. 3. Disconnect Direct Link Setup as follow: 1. Select a direct link STA. 2. Click “Tear Down” button. The result will look like the below figure. Example to configure to enable WMM – Power Save 1. Click “WMM – Power Save Enable”. And Click “Setting...” button. 2. After clicking “Setting...” button, show “Power Save Setting” dialog. Please select which ACs you want to enable. Then click “Apply” button. The setting of enabling WMM – Power Save is successfully. Example to configure to enable Wi-Fi Multi-Media If you want to use “WMM – Power Save” or “Direct Link”, you must enable WMM. The setting method of enabling WMM indicates as follows: 1. Click “WMM Enable”. 2. Click “Apply”. 3. Change to “Site Survey Page”. And add a AP that supports WMM features to a Profile. The result will look like the below figure in Profile page. Configure connection with WPA2 by 802.1x setting 1. Select A.P with WPA2 authentication mode. 2. Click CONNECT or double click the intended network. 3. Authentication & Security page will pop up. TKIP, AES and Both (TKIP+AES) security are support. *If AP setup security to Both (TKIP + AES), system defines is AES that security is severely. 4. Click 802.1x setting. 5. 802.1x setting page will pop up. 5. Authentication type and setting method: PEAP: 1. Authentication type chooses PEAP, key identity into wpatest2. Protocol chooses EAP-MSCHAP v2 for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. 2. Click OK. The result will look like the below figure. TLS / Smart Card: 1. Authentication type chooses TLS / Smart Card, TLS only need identity that is wpatest2 for server authentication. 2. TLS must use client certicate. Click more to choose certicate. 3. Certicate page will pop up; choose a certicate for server authentication. 3. Display certicate information in use client certicate page. 4. Click OK. The result will look like the below figure. TTLS: 1. Authentication type chooses TTLS, identity is wpatest2. Protocol chooses CHAP for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. 2. Click OK. The result will look like the below figure. MD5: 1. Authentication type chooses MD5, MD5 only need identity and password that are wpatest2 and test2 for server authentication. 2. Click OK. The result will look like the below figure. Configure connection with WPA by 802.1x setting 1. Select A.P with WPA authentication mode. 2. Click CONNECT or double click the intended network. 3. Authentication & Security page will pop up. TKIP, AES and Both (TKIP+AES) security are support. *If AP setup security to Both (TKIP + AES), system defines is AES that security is severely. 4. Click 802.1x setting. 5. 802.1x setting page will pop up. 6. Authentication type and setting method: PEAP: 1. Authentication type chooses PEAP, key identity into wpatest2. Protocol chooses EAP-MSCHAP v2 for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. 2. Click OK. The result will look like the below figure. TLS / Smart Card: 1. Authentication type chooses TLS / Smart Card, TLS only need identity that is wpatest2 for server authentication. 2. TLS must use client certicate. Click more to choose certicate. 3. Certicate page will pop up; choose a certicate for server authentication. 4. Display certicate information in use client certicate page. 5. Click OK. The result will look like the below figure. TTLS: 1. Authentication type chooses TTLS, identity is wpatest2. Protocol chooses CHAP for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. 2. Click OK. The result will look like the below figure. MD5: 1. Authentication type chooses MD5, MD5 only need identity and password th…

Text truncated - open the document above for the full version.

Mini PCI I/F and Power MAC RT2561 Transceiver RT2527 PA SST12L07 and TX/RX XTAL/5x3.2/40MHz TX RX XTAL

Page:1/5 Report Number: MLT0609P15005 Page:2/5 Report Number: MLT0609P15005 Page:3/5 Report Number: MLT0609P15005 Page:4/5 Report Number: MLT0609P15005 Page:5/5 Report Number: MLT0609P15005

Page:1/5 Report Number: MLT0609P15005 Page:2/5 Report Number: MLT0609P15005 Page:4/5 Report Number: MLT0609P15005 Page:5/5 Report Number: MLT0609P15005

Report Number: MLT0609P15005 Label Format: Label Position: Equipment Label Rear View

Page:3/5 Report Number: MLT0609P15005

Product Description - Item no. Product name:IEEE 802.11g Wireless Mini PCI Adapter This product is designed with the following features, benefits, specifications...etc.: FEATURES & BENEFITS  Easy Installation  On-Board Printed Type Antenna  Operates in the 2.4GHz, Backward Compatible in a 802.11b environment  Wireless link speeds up to 108Mpbs; 5 times faster than 802.11b devices.  Up to 152-bit WEP Encryption  Seamless roaming from cell to cell and between 802.11b to 802.11g  Support Windows XP/2000 PRODUCT HIGHLIGHTS  COMPATIBLE WITH 802.11b DEVICES This 802.11g Wireless LAN client product with a data transmission rate up to 108Mbps. Operating in 2.4GHz, is backward compatible with other 802.11b wireless LAN devices. UP TO Super-G 28Mbps This Adapter connects you with 802.11g networks at an incredible 28Mbps! And for added versatility, also capable of inter-operating with all the 802.11b wireless products found in homes, businesses, and public wireless hotspots around the country. SPECIFICATIONS INTERFACE Standards IEEE 802.11g, 802.11b Frequency Bands 2.412~ 2.4835GHz ISM Band Modulation Tech 802.11b: CCK,DSSS 802.11g: OFDM Media Access Protocol CSMA/CA with ACK Transmit Power 802.11g :13 dBm 802.11b : 17dBm Receive Sensitivity 11 Mbps 10-5 BER @ -83 dBm, TYP 54 Mbps 10-5 BER @ -70 dBm, TYP Data Rates 802.11b: 11Mbps, 5.5Mbps, 2Mbps, 1Mbps, auto fallback 802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps ENVIRONMENTAL SPECIFICATIONS Operating Systems Windows XP/2000 Security 64/128-Bit WEP Key, WPA, WPA-PSK, TKIP Configuration Utility Configuration tray & Zero configuration for WinXP CERTIFICATION PACKAGE CONTENTS

1/2 Report Number: MLT0609P15005 M M a a x x i i m m u u m m P P e e r r m m i i s s s s i i b b l l e e E E x x p p o o s s u u r r e e 1. Introduction In this document, we try to prove the safety of radiation harmfulness to the human body for our product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The Gain of the antenna used in this product is measured in a Fully Anechoic Chamber (FAC), and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis transmission formula is a far field assumption, the calculated result of that is an over-prediction for near field power density. We will take that as the worst case to specify the safety range. 2. Description of EUT EUT : IEEE 802.11g Wireless Mini PCI Adapter Applicant : Amigo Technology Inc. 1F,No. 285,Sec 2,Ti-Ding Blvd., Nei Hu, Taipei, Taiwan 114, R.O.C. Manufacturer : FAIRWAY ELECTRONIC CO.,LTD. Huang Cjong No. 3 Industryal Area, Zhong Tang Town, Dong Guan, City, Guang Dong Province, China Model No : AWI-922T FCC ID : RC6AWI-922T 3. Classification The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. Warning statement to the user for keeping at least 20cm or more separation distance with the antenna should be included in users manual. So, this device is classified as Mobile Device. 2/2 Report Number: MLT0609P15005 4. Friis Formula Friis transmission formula : Pd = (Pout*G) / (4*pi*r^2) Where Pd = power density in mW/cm^2 Pout = output pwer to antenna in Mw G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 5. Test Result: 802.11b Max RF Power (dBm) TX Antenna Gain (dBi) Testing Result (mW/cm^2) MPE Limit (mW/cm^2) 15.44 2.0 0.0034 1 802.11g Max RF Power (dBm) TX Antenna Gain (dBi) Testing Result (mW/cm^2) MPE Limit (mW/cm^2) 11.36 2.0 0.0026 1

55 44 33 22 11 D D C C B B A A RALINK TECHNOLOGY, CORP. CONFIDENTIAL XTAL:CL=15pF, Co=1.5pF 1-RT2527-XTAL.SCH 1.1 Transceiver - RT2527 C 25 Monday, August 29, 2005 TitleSize Document Number Rev Date: Sheet of SYNCLK RF_LE-G# GND RF_LE-G# GND RFLDOBP IREF SYNDATA RADIO_PD# SYNDATA IREF SYNCLK 40MX1 RX_BB_Q- RX_BB_Q- RFOUTG+RFING+ PA_RFING GND GNDGNDGND VCCAVCCA RFIN_G RFOUTG-RFING- GND TXR_VO3 VCTRL1 TXR_VO3 GND TXR_VO2 VCCA C_VCC VE RFRC C_VCC TXR_VO3 GNDGND RFRX_PE RFRX_PE RFTX_PE RFTX_PE VCCA VCCA VCCA VCCA VCCARX_BB_Q+ RX_BB_Q+ RX_BB_I- RX_BB_I-RX_BB_I+ RX_BB_I+ TX_BB_I- RF_VCCD VCCA GND 1.8VA 1.8VA GND GND GND GND GND3.3VA 3.3VD VCCA GND VCCA GND GND GND TX_BB_I- TX_BB_Q- TX_BB_Q-TX_BB_Q+ TX_BB_Q+ TX_BB_I+ TX_BB_I+ TXR_VO2 TXR_VO2 40MI TXR-40MO GND RFIN_F F40M 40MX2 GND GND VCCA GND VCCA GND VCCA GNDGND GND GND GND GND GND GNDGND VCCA VCCA GND 1.8VA GND GND GND GND GND3.3VA 3.3VDVCCA GND GND VCCA GND GND C492 4.7pF 1 2 C15 33pF 1 2 C27 33pF/NI 12 R115 0 ohm 1 2 C437 10pF 1 2 C2810uF/6.3V 12 C491 100pF 1 2 C2440.1uF 12 R259 68pF 1 2 L36 0.8pF 1 2 L63 0 ohm/NI 1 2 C443 39pF 1 2 C409 10uF/6.3V 1 2 L54 1.5nH 1 2 C413 10uF/6.3V 12 R160 27 1 2 C24 10pF 1 2 L552.7nH 1 2 C461 0.01uF 1 2 5x3.2 U50 XTAL/5x3.2/40MHz 1 2 4 3 R20 0 ohm 1 2 C417 10pF 12 C4261nF 12 C4421nF 12 C4281nF 12 R7 0 ohm 1 2 C2454.7uF/6.3V 12 C454 10pF/NI 1 2 C48 1.5pF 1 2 C464 1nF 1 2 C321 1nH 1 2 U47RT2527-48P 123456789 1011 47 41 42 43 21 20 24 29 49 23 22 2728 37 34333231302625 48 44 45 46 17 40 39 3635 15 14 13 12 16 18 19 38 RFinP2RFinM2VCC2RFoutP2RFoutM2NCNCNCNCNCNC TR_PE CLK Data LE Core_Vcc LO_Vcc VCCA VCCD GND VP1 LO_Vc LD_fo CLK_Out Base_Vcc1 I_OutP I_OutM Base_Vcc2 Q_OutP Q_OutM X1/OSCI X2 VCC1 Iref Bias_Vcc RF_PE LDO_Out3 I_InP I_InM Q_InP Q_InM LDO_Bypass LDO_In LDO_PE LDO_Out1 LDO_Out2 LO_IOM LO_IOP DAC_Vcc L8 2.2nH 1 2 C414 10uF/6.3V 1 2 L10 6.8nH 1 2 C4394.7pF 12 C452 3.3nF 12 L26100nH 1 2 R267 18K 1 2 C453 15pF 12 C419 0.01uF 1 2 R260 68pF 1 2 C446 100pF 12 C45 1.8pF 1 2 RF_LE-G#IREF RADIO_PD# SYNCLKSYNDATA RX_BB_Q- RFIN_G PA_RFING RFTX_PERFRX_PE RX_BB_Q+RX_BB_I-RX_BB_I+TX_BB_I-TX_BB_I+TX_BB_Q+TX_BB_Q- 40MI 55 44 33 22 11 D D C C B B A A RALINK TECHNOLOGY, CORP. CONFIDENTIAL AUX.AntennaMainAntenna 2-PA-TQP777002.SCH 1.1 PA and TX/RX C 35 Monday, August 29, 2005 TitleSize Document Number Rev Date: Sheet of 3.3VD ANTSEL_NANTSEL_P ANTE2EANTE1E ANTE1 ANTE2 PA_RFING AVC2 MVC1 DTR2 ANT_E1 STR25 AVC2 MVC1 GND GND GND PARF GND GND GND GND GND DTR5 GNDPAF BPF_OG GND GND GND PA_PE_G GND GND PARFO GND VB1 GND GND PA_IN RFIN_G VC2 3.3VD VC1 DET1 GND 3.3VD GND GNDGND GND GND GND GND GND GND GND GND GND GND GND GND U14 TQS5202 3 2 45 8 6 9 7 10121113 1 VC1 NC/G A1GND NC/G A2 NC/G VC2 RX TX GNDGND NC/G C472 C/NI 12 C468C/NI 12 C219 0.5pF/NI 12 L1 1.2nH/NI 12 C26 10pF 1 2 C466 10pF 1 2 C465 10pF 1 2 C21.8pF 12 C362 10uF/6.3V 12 R12 0 ohm/SB 1 2 C469 10pF 1 2 U6 BF2520 -E2R4CAE 4 2 3 1 BI BO G G C467C/NI 12 C3600.1uF/NI 12 C525 10pF 1 2 R150 ohm/SB 1 2 L232.7nH/NI 12 C30 2.7nH 1 2 C29 10pF 1 2 C341 100pF/NI 12 CON2 SMA/UFLR 1 2 3 L100 10nH 12 CON1 SMA/UFLR 1 2 3 C63.3nH/NI 12 R210 0 ohm 1 2 U5 TQP777002 23 13 1 8 7 6 5 9101112 15 16 17 14 4 RFinGND Vcc1 GND Vdet_out NC NC NC NC GND RFOUT GND NC Vcc1 GND Vcc2 Vpc C3291uF 12 C325 0.01uF 12 L101 0 ohm 12 C1 1.8pF 12 C4712.7nH/NI 12 C7 10pF 1 2 C340100pF/NI 12 C3281uF 12 ANTSEL_NANTSEL_P PA_RFING RFIN_G PA_PE_G 55 44 33 22 11 D D C C B B A A RALINK TECHNOLOGY, CORP. CONFIDENTIAL Install R206R1 R1 Mode 93C66 R206 Not Ins tall 93C463-RT2561-MPCI.SCH 1.1 WLAN MAC+BBP - RT2561 C 45 Monday, August 29, 2005 TitleSize Document Number Rev Date: Sheet of 1.8VD 1.8VD 3.3VD 3.3VD 3.3VD GND PARCBE1B 3.3VD CBE0B CLKRUNB GNTBIRDYBPERRBSTOPBMRSTBDEVSELB GND INTABFRAMEBREQBSERRBTRDYB 3.3VD 1.8VD LD1P_ACT LED_RDYG#LED_LKACT# LD2P_24G DEVSELBSERRBPERRBSTOPBTRDYBCLKRUNB 1.8VD FRAMEBIRDYBCBE2B 1.8VD EEDIEECS ORG 3.3VD3.3VD3.3VD3.3VD 3.3VD 1.8VD IDSEL INTAB REQB GNTB MRSTBREQB MRSTB CBE3BGNTB CBE3B INTABIDSEL AD23 AD30 AD7AD12AD13AD5AD18AD10 AD31 AD29 AD27 AD22 AD21 AD19AD3AD9 AD24 AD25 AD16 AD[0..31] AD8AD2 AD28 AD26 AD4AD17 AD20 AD14AD15 AD6AD11AD1AD0 CCLK CCLK 1.8VC 1.8VC 1.8VC VREF25P 3.3VD 1.8VD 1.8VD 1.8VA1.8VC1.8VA EECS EEDO EEDO RFTX_PERFRX_PEANTSEL_NANTSEL_PRADIO_PD# GND SYNDATA PA_PE_G TX_BB_Q-TX_BB_I+TX_BB_Q+TX_BB_I- VREF IREF TSSI_AG 3.3VARF_LE0 LED_RDYA# LD2_YN5 1.8VC 1.8VA 3.3VA GND RX_BB_Q-RX_BB_Q+RX_BB_I-RX_BB_I+ GND GPIO5 RF_LE-G# RF_DATA0 VREF25N 1.8VDPLL 1.8VD 1.8VDPLL GND 1.8VDPLL 1.8VD EESK 3.3VD3.3VD 3.3VD 3.3VD 3.3VD3.3VD3.3VD3.3VD3.3VD 3.3VD 3.3VD 3.3VD GND EESK EEDI 1.8VA1.8VAVREFP GND GND GND 1.8VA GND GND GND GND GND VREFN GND GND VCCA PA_PWR SYNCLK RF_CLK TR_SW0 TR_SW0 3.3VDGND RFTXDIS# GND 3.3VD GND 1.8VD GND GND 3.3VD GND GND GND 3.3VA GND GND VCCA GND 1.8VC GND 3.3VA GND GND 1.8VD 1.8VA 3.3VD GND GND GND VCCA GND3.3VD R6 0 ohm/SB 1 2 C4840.1uF 12 R279 510 1 2 D2 LED/NI 12 C164 0.1uF 12 R273 100 1 2 R276 0 ohm/NI 1 2 C252 10pF/NI 12 C299 0.1uF/NI 12 C302 1uF 1 2 R2 330 1 2 C301 1uF 1 2 D3 LED/NI 12 C4870.1uF 12 RA4 RA 4.7K*4/NI 1357 2468 C303 1uF 1 2 R227 10K 1 2 D1 LED/NI 12 R274 100 1 2 C172 0.1uF 12 C4830.1uF 12 C167 0.1uF 12 C1730.1uF 12 C2610.1uF 12 R1 4.7K 1 2 R4 330 1 2 C1650.1uF 12 R1610K 12 R163 4.7K 1 2 C477 0.1uF 12 C12 0.1uF/NI 12 R207 820 1 2 C265 0.1uF 12 U31 RT2561-LQFP128 113 10111213924181527283132 121 2334 120 122 123 126 6 127 128 114 119 118 117 116 44 46 43 65 48 47 49 50 51 52 53 54 55 57 58 59 61 60 62 63 64 666875697074 45 7173727677817984807867828385948687889091 125 92939596 97 98 89 99 100 103 101 102 104 106 107 108 109 111 112 14262530717 124 41 40 39 42 29 56 85 38 37 36 35 34 33 115 110 105 211619202122 129 GPIO0 RFTXI_P0 RFTXI_N0 RFTXQ_P0 RFTXQ_N0 IREF VREFP VCC18A TSSI_A0 NCNCNCNC TR_PE VCC18A RF_SCLK NC RF_PE TR_SW0 TR_SWN0 RADIO_PE PA_PE_G ANSEL_P ANSEL_N VCCIO EEDO EEDI EESK EECS INTA_N RST_N VDD18 VCCIO GNT_N REQ_N AD[31] AD[30] AD[29] AD[28] AD[27] AD[26] VCCIO AD[25] AD[24] CBE[3]_N IDSEL AD[23] AD[22] AD[21] AD[20] AD[19]AD[18]VD…

Text truncated - open the document above for the full version.

Page: 1 /80 Report Number: MLT0609P15005 (FCC : Part 15 Subpart B & C (15.247) / ANSI C63.4:2003) Product :IEEE 802.11g Wireless Mini PCI Adapter Trade Name :Amigo (The other see Appendix II) Model No. :AWI-922T (The other see Appendix II) Applicant :Amigo Technology Inc. Applicant Address :1F,No. 285,Sec 2,Ti-Ding Blvd., Nei Hu, Taipei,Taiwan 114, R.O.C. Page: 2 /80 Report Number: MLT0609P15005 Report Number MLT0609P15005 Applicant Amigo Technology Inc. Product IEEE 802.11g Wireless Mini PCI Adapter Sample Received Date 2006/09/28 Report Prepared By Jesse Tien Signature Date Prepared 2006/09/28 ～ 2007/01/16 Report Authorized By Roger Chen Signature Date Authorized 2007/01/18 Test By Max Light Technology Co., Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Office：Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 Lab：Tel:886-2-2663-3486 Fax:886-2-2663-3582 I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . Page: 3 /80 Report Number: MLT0609P15005 Table of Contents : I. General 5. II. Conducted Emissions Requirements 9. III. Radiated Emissions Requirements 19. IV. Maximum Conducted Output Power Requirements 41. V. Minimum 6dB RF Bandwidth Requirements 46. VI. Maximum Power Density Requirements 51. VII. Out of Band Conducted Emissions Requirements 56. VIII. Band Edges Requirements 74. IX. Antenna Requirements 77. Appendix I ( EUT Test Setup ) 78. Appendix II ( Brand / Trade Name & Model No. List ) 80 Page: 4 /80 Report Number: MLT0609P15005 CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with Class B radiated and conducted emission limit of FCC Rules Part 15 Subpart B & C (15.247). Applicant Name Amigo Technology Inc. Applicant Address 1F,No. 285,Sec 2,Ti-Ding Blvd.,Nei Hu,Taipei,Taiwan 114, R.O.C. Manufacturer Name FAIRWAY ELECTRONIC CO.,LTD. Manufacturer Address Huang Cjong No. 3 Industrial Area, Zhong Tang Town, Dong Guan, City, Guang Dong Province, China Equipment IEEE 802.11G WIRELESS MINI PCI ADAPTER Model No AWI-922T(THE OTHER SEE APPENDIX II) FCC ID RC6AWI-922T Report Prepared By Jesse Tien Signature Report Authorized By Roger Chen Signature Page: 5 /80 Report Number: MLT0609P15005 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Amigo Technology Inc. In support of a Class B Digital Device certification in accordance with Part2 Subpart J and Part 15 Subpart A , B and C of the Commission’s and Regulations. 1.2 Customer Details Applicant Name Amigo Technology Inc. Applicant Address 1F,No. 285,Sec 2,Ti-Ding Blvd.,Nei Hu,Taipei,Taiwan 114, R.O.C. Manufacturer Name FAIRWAY ELECTRONIC CO.,LTD. Manufacturer Address Huang Cjong No. 3 Industrial Area, Zhong Tang Town, Dong Guan, City, Guang Dong Province, China 1.3 Technical data of EUT Equipment IEEE 802.11G WIRELESS MINI PCI ADAPTER Model No AWI-922T(THE OTHER SEE APPENDIX II) FCC ID RC6AWI-922T Power Type Powered by PC(Desktop) Type of Modulation 802.11b: CCK,DSSS 802.11g: OFDM Type of Antenna 1/4λ Dipole Sleeve Frequency of Channel See Next page During testing the EUT was operated at Tx or Rx mode for each emission measured. This was done in order to ensure that maximum emission levels were attained. Page: 6 /80 Report Number: MLT0609P15005 802.11b & 802.11g Frequency of Each Channel (Working Frequency) Channel No. Frequency (MHz) 01 2412 02 2417 03 2422 04 2427 05 2432 06 2437 07 2442 08 2447 09 2452 10 2457 11 2462 1.4 Summary Of Tests 47 CFR Part 15 Subpart C Reference Test Results Note 15.107 AC Power Conducted EmissionPASS 15.247(c) Transmitter Radiated EmissionsPASS 15.247(b) Max. Output Power PASS 15.247(a)(2) 6dB RF Bandwidth PASS 15.247(d) Max. Power Density PASS 15.247(c) Out of Band Conducted Spurious Emission PASS 15.247(c) Band Edge Measurement PASS 15.203 Antenna Requirement PASS Page: 7 /80 Report Number: MLT0609P15005 1.5 Description of Support Equipment In order to construct the minimum system which required by the ANSI C63.4: 2003, following equipments were used as the support units. Component Manufacturer Model No. Serial No. FCC ID Computer IBM OVH 99FGZXX FCC DOC Monitor Sam Sung 193T NB19HMEX104973D FCC DOC Keyboard IBM KB-0225 0059709 FCC DOC Mouse DELL M-SAW94 LZB34304316 FCC DOC Printer PANASONIC KX-P10801 70KAKE93933 FCC DOC Modem ASKEY WS1414SV V1414VQE FCC DOC NB DELL PP19L TD108 A00 FCC DOC 1.6 Configuration of System Under Test Mouse Keyboard PC Power Supply Modem Printer Monitor EUT Page: 8 /80 Report Number: MLT0609P15005 1.7 Test Procedure All measurements contained in this report were performed according to the techniques described in Measurement procedure ANSI C63.4:2003 "Measurement of un-Intentional Radiators." 1.8 General Test Condition The conditions under which the EUT operates were varied to determine their effect on the equipment's emission characteristics. The final configuration of the test system and the mode of operation used during these tests were chosen as that which produced the highest emission levels. However, only those conditions which the EUT was considered likely to encounter…

Text truncated - open the document above for the full version.

Page: 22 /80 Report Number: MLT0609P15005 3.3 Test Configuration: Front View of The Test Configuration Page: 23 /80 Report Number: MLT0609P15005 Rear View of The Test Configuration Page: 10 /80 Report Number: MLT0609P15005 2.3 Test Configuration: Front View of The Test Configuration Page: 11 /80 Report Number: MLT0609P15005 Rear View of The Test Configuration
