RC6AWU-902TIEEE 802.11g WIRELESS POCKET USB

RaConfig Operation Manual RaConfig or windows zero configuration Start RaConfig Utility Site Survey Page Encryption Setting [WEP/TKIP/AES] 802.1X Authentication CA Server Setting Profile Page Link Status Page Statistic Page Advance Page Country Channel List QoS Page About Page Example on adding profile in site survey page Example to add profile in profile page Example to configure connection with WEP on Example to configure connection with WPA-PSK Example to configure connection with WPA2-PSK Example to configure connection with WPA Example to configure connection with WPA2 Example to configure to enable Wi-Fi Multi-Media Example to configure to enable WMM – Power Save Example to configure to enable DLS (Direct Link Setup) EXCURSUS Example to configure to enable DLS (Direct Link Setup) 1. Click “Direct Link Setup Enable”. And Click “Apply” button. 2. Change to “Site Survey Page”. And add a AP that supports DLS features to a Profile. The result will look like the below figure in Profile page. The setting of DLS indicates as follow: 1. Fill in the blanks of Direct Link with MAC Address of STA. The STA must conform to two conditions as follow: Connect with the same AP that support DLS features. Have to enable DLS. 2. Timeout Value represents that it disconnect automatically after some seconds. The value is integer. The integer must be between 0~65535. It represents that it always connects if the value is zero. Default value of Timeout Value is 60 seconds. 3. Click “Apply” button. The result will look like the below figure. Describe “DLS Status” as follow: 1. As the up figure, after configuring DLS successfully, show MAC address of the opposite side and Timeout Value of setting in “DLS Status”. In “DLS Status” of the opposite side, it shows MAC address of myself and Timeout Value of setting. 2. Display the values of “DLS Status” to “Direct Link Setup” as follow: 1. In “DLS Status”, select a direct link STA what you want to show it’s values in “Direct Link Setup”. 2. Double click. And the result will look like the below figure. 3. Disconnect Direct Link Setup as follow: 1. Select a direct link STA. 2. Click “Tear Down” button. The result will look like the below figure. Example to configure to enable WMM – Power Save 1. Click “WMM – Power Save Enable”. And Click “Setting...” button. 2. After clicking “Setting...” button, show “Power Save Setting” dialog. Please select which ACs you want to enable. Then click “Apply” button. The setting of enabling WMM – Power Save is successfully. Example to configure to enable WMM – Power Save 1. Click “WMM – Power Save Enable”. And Click “Setting...” button. 2. After clicking “Setting...” button, show “Power Save Setting” dialog. Please select which ACs you want to enable. Then click “Apply” button. The setting of enabling WMM – Power Save is successfully. Example to configure to enable Wi-Fi Multi-Media If you want to use “WMM – Power Save” or “Direct Link”, you must enable WMM. The setting method of enabling WMM indicates as follows: 1. Click “WMM Enable”. 2. Click “Apply”. 3. Change to “Site Survey Page”. And add a AP that supports WMM features to a Profile. The result will look like the below figure in Profile page. Configure connection with WPA2 by 802.1x setting 1. Select A.P with WPA2 authentication mode. 2. Click CONNECT or double click the intended network. 3. Authentication & Security page will pop up. TKIP, AES and Both (TKIP+AES) security are support. *If AP setup security to Both (TKIP + AES), system defines is AES that security is severely. 4. Click 802.1x setting. 5. 802.1x setting page will pop up. 5. Authentication type and setting method: PEAP: 1. Authentication type chooses PEAP, key identity into wpatest2. Protocol chooses EAP-MSCHAP v2 for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. 2. Click OK. The result will look like the below figure. TLS / Smart Card: 1. Authentication type chooses TLS / Smart Card, TLS only need identity that is wpatest2 for server authentication. 2. TLS must use client certicate. Click more to choose certicate. 3. Certicate page will pop up; choose a certicate for server authentication. 3. Display certicate information in use client certicate page. 4. Click OK. The result will look like the below figure. TTLS: 1. Authentication type chooses TTLS, identity is wpatest2. Protocol chooses CHAP for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. 2. Click OK. The result will look like the below figure. MD5: 1. Authentication type chooses MD5, MD5 only need identity and password that are wpatest2 and test2 for server authentication. 2. Click OK. The result will look like the below figure. Configure connection with WPA by 802.1x setting 1. Select A.P with WPA authentication mode. 2. Click CONNECT or double click the intended network. 3. Authentication & Security page will pop up. TKIP, AES and Both (TKIP+AES) security are support. *If AP setup security to Both (TKIP + AES), system defines is AES that security is severely. 4. Click 802.1x setting. 5. 802.1x setting page will pop up. 6. Authentication type and setting method: PEAP: 1. Authentication type chooses PEAP, key identity into wpatest2. Protocol chooses EAP-MSCHAP v2 for tunnel authentication, tunnel identity is wpatest2 and tunnel password is test2. Those setting are same as our intended AP’s setting. 2. Click OK. The result will look like the below figure. TLS / Smart Card: 1. Authentication type chooses TLS / Smart Card, TLS only need identity that is wpatest2 for server authentication. 2. TLS must use client certicate. Click more to choose certicate. 3. Certicate page will pop up; choose a certicate for server authentication. 4. Display certicate information in use client certicate page. 5. Click OK. The result will look like the below figure. TTLS: 1. Authentication type chooses TTLS, i…

Text truncated - open the document above for the full version.

USB I/F and Power MAC RT2571W Transceiver RT2528 PA and TX/RX XTAL/5x3.2/40MHz TX RX XTAL

Page:1/6 Report Number: MLT0609P15002 Page:2/6 Report Number: MLT0609P15002

Page:3/6 Report Number: MLT0609P15002 Page:4/6 Report Number: MLT0609P15002 Page:5/6 Report Number: MLT0609P15002 Page:6/6 Report Number: MLT0609P15002

Product Description - Item no. Product name: IEEE 802.11b/g Wireless Pocket USB This product is designed with the following features, benefits, specifications...etc.: FEATURES & BENEFITS  Easy Installation  On-Board Printed Type Antenna  Operates in the 2.4GHz, Backward Compatible in a 802.11b environment  Wireless link speeds up to 108Mpbs; 5 times faster than 802.11b devices.  Up to 152-bit WEP Encryption  Seamless roaming from cell to cell and between 802.11b to 802.11g  Support Windows XP/2000 PRODUCT HIGHLIGHTS  COMPATIBLE WITH 802.11b DEVICES This 802.11g Wireless LAN client product with a data transmission rate up to 108Mbps. Operating in 2.4GHz, is backward compatible with other 802.11b wireless LAN devices. UP TO Super-G 28Mbps This Adapter connects you with 802.11g networks at an incredible 28Mbps! And for added versatility, also capable of inter-operating with all the 802.11b wireless products found in homes, businesses, and public wireless hotspots around the country. SPECIFICATIONS INTERFACE Standards IEEE 802.11g, 802.11b Frequency Bands 2.412~ 2.4835GHz ISM Band Modulation Tech 802.11b: CCK,DSSS 802.11g: OFDM Media Access Protocol CSMA/CA with ACK Transmit Power 802.11g :13 dBm 802.11b : 17dBm Receive Sensitivity 11 Mbps 10-5 BER @ -83 dBm, TYP 54 Mbps 10-5 BER @ -70 dBm, TYP Data Rates 802.11b: 11Mbps, 5.5Mbps, 2Mbps, 1Mbps, auto fallback 802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps ENVIRONMENTAL SPECIFICATIONS Operating Systems Windows XP/2000 Security 64/128-Bit WEP Key, WPA, WPA-PSK, TKIP Configuration Utility Configuration tray & Zero configuration for WinXP CERTIFICATION PACKAGE CONTENTS

Report No：071L039-HPUSP09V01 Page: 1 of 22 Version:1.0 SAR Test Report Product Name ： IEEE 802.11g Wireless Pocket USB Model No. ： AWU-902T, NV-902T, WA-2110, HWGUSB2-54, Thrustmaster FunAccess WiFi USB Key, TER/GUSB2 Applicant ： Amigo Technology Inc. Address ： 1F, No. 258, Sec 2, Ti-Ding Blvd., Nei Hu, Taipei, Taiwan 114, R.O.C. Date of Receipt ：2007/01/05 Issued Date ：2007/01/12 Report No. ：071L039-HPUSP09V01 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No：071L039-HPUSP09V01 Page: 2 of 22 Version:1.0 Test Report Certification Issued Date: 2007/01/12 Report No.:071L039-HPUSP09V01 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Product Name ： IEEE 802.11g Wireless Pocket USB Applicant ： Amigo Technology Inc. Address ： 1F, No. 258, Sec 2, Ti-Ding Blvd., Nei Hu, Taipei, Taiwan 114, R.O.C. Manufacturer ： FAIRWAY ELECTRONICS Co., LTD. Model No. ： AWU-902T, NV-902T, WA-2110, HWGUSB2-54, Thrustmaster FunAccess WiFi USB Key, TER/GUSB2 Trade Name ： Amigo, Novatech, Sapido, Hercules, Amigo Communication, INC., Thrustmaster, Natopia, Guillemot Applicable Standard ： FCC Oet65 Supplement C June 2001 Test Result ： Max. SAR Measurement (1g) 802.11b: 0.731 W/kg 802.11g: 0.398 W/kg Application Type Certification Documented By ： (Eva Huang) Tested By ： (Shine Hsu) Approved By ： (George Chen) Report No：071L039-HPUSP09V01 Page: 3 of 22 Version:1.0 TABLE OF CONTENTS Description Page 1. General Information.............................................................................. 5 1.1 EUT Description ............................................................................................................5 1.2 Test Environment ...........................................................................................................5 2. SAR Measurement System .................................................................. 6 2.1 ALSAS-10U System Description .................................................................................. 6 2.1.1 Applications ................................................................................................................ 6 2.1.2 Area Scans................................................................................................................... 6 2.1.3 Zoom Scan (Cube Scan Averaging)............................................................................ 7 2.1.4 ALSAS-10U Interpolation and Extrapolation Uncertainty......................................... 7 2.2 Isotropic E-Field Probe .................................................................................................. 7 2.2.1 Isotropic E-Field Probe Specification ......................................................................... 9 2.3 Boundary Detection Unit and Probe Mounting Device ................................................. 9 2.4 Daq-Paq (Analog to Digital Electronics) ..................................................................... 10 2.5 Axis Articulated Robot ................................................................................................ 10 2.6 ALSAS Universal Workstation.................................................................................... 11 2.7 Universal Device Positioner......................................................................................... 11 2.8 Phantom Types............................................................................................................. 11 2.8.1 APREL SAM Phantoms ........................................................................................... 12 2.8.2 APREL Laboratories Universal Phantom ................................................................. 12 3. Tissue Simulating Liquid ................................................................... 13 3.1 The composition of the tissue simulating liquid .......................................................... 13 3.2 Tissue Calibration Result ............................................................................................. 13 3.3 Tissue Dielectric Parameters for Head and Body Phantoms ....................................... 14 4. SAR Measurement Procedure ........................................................... 15 4.1 SAR System Validation................................................................................................ 15 4.1.1 Validation Dipoles..................................................................................................... 15 4.1.2 Validation Result ....................................................................................................... 15 4.2 SAR Measurement Procedure ...................................................................................... 16 5. SAR Exposure Limits ......................................................................... 17 6. Test Equipment List............................................................................ 18 7. Measurement Uncertainty .................................................................. 19 8. Test Results ......................................................................................... 20 Report No：071L039-HPUSP09V01 Page: 4 of 22 Version:1.0 8.1 SAR Test Results Summary ......................................................................................... 20 Appendix A. SAR System Validation Data........................................................................ 22 Appendix B. SAR measurement Data................................................................................ 22 Appendix C. Test Setup Photographs & EUT Photographs............................................... 22 Appendix D. Probe Calibration Data ................................................................................. 22 Appendix E. Dipole Calibration Data…

Text truncated - open the document above for the full version.

Report No：071L039-HPUSP09V01 Page: 1 of 4 Version:1.0 SAR System Validation Data ALSAS-10U VER 2.3.1 APREL Laboratories SAR Test Report Report Date : 09-Jan-2007 Measurement Date : 09-Jan-2007 Product Data Device Name : Dipole-2450 Type : Dipole Model : Standard Frequency : 2450.00 MHz Max. Transmit Pwr : 0.25 W Drift Time : 0 min(s) Length : 51.5 mm Width : 3.6 mm Depth : 30.4 mm Power Drift-Start : 6.529 W/kg Power Drift-Finish: 6.506 W/kg Power Drift (%) : -0.359 Phantom Data Name : APREL-Uni Type : Uni-Phantom Size (mm) : 280 x 280 x 200 Location : Center Tissue Data Type : HEAD Serial No. : 325-H Frequency : 2450.00 MHz Last Calib. Date : 09-Jan-2007 Temperature : 21.40 °C Ambient Temp. : 21.70 °C Humidity : 53.00 RH% Epsilon : 38.36 F/m Sigma : 1.858 S/m Density : 1000.00 kg/cu. m Probe Data Name : Probe 264 Model : E020 Type : E-Field Triangle Serial No. : 264 Last Calib. Date : 29-Dec-2006 Frequency : 2450.00 MHz Duty Cycle Factor: 1 Conversion Factor: 5 Probe Sensitivity: 1.20 1.20 1.20 μV/(V/m) 2 Compression Point: 95.00 mV Offset : 1.56 mm Report No：071L039-HPUSP09V01 Page: 2 of 4 Version:1.0 Measurement Data Crest Factor : 1 Tissue Temp. : 21.40 °C Ambient Temp. : 21.70 °C Area Scan : 5x5x1 : Measurement x=12mm, y=12mm, z=4mm Zoom Scan : 7x7x7 : Measurement x=5mm, y=5mm, z=5mm Frequency : 2450 1 gram SAR value : 12.842 W/kg 10 gram SAR value : 5.751 W/kg Area Scan Peak SAR : 14.929 W/kg Zoom Scan Peak SAR : 26.622 W/kg Report No：071L039-HPUSP09V01 Page: 3 of 4 Version:1.0 This is previous page plot (zoom in) Report No：071L039-HPUSP09V01 Page: 4 of 4 Version:1.0 Report No：071L039-HPUSP09V01 Page: 1 of 24 Version:1.0 SAR Measurement Data ALSAS-10U VER 2.3.2APREL Laboratories SAR Test Report (802.11b) Report Date : 09-Jan-2007 Measurement Date : 09-Jan-2007 Product Data Device Name : MAX LIGHT Type : Other Model : AWU-902T, NV-902T, WA-2110, HWGUSB2-54, Thrustmaster FunAccess WiFi USB Key, TER/GUSB2 Frequency : 2450.00 MHz Length : 75 mm Width : 26 mm Depth : 10.4 mm Antenna Type : Internal Phantom Data Type : Uni-Phantom Size (mm) : 280 x 280 x 200 Location : Center Tissue Data Type : BODY Serial No. : 325-B Frequency : 2450.00 MHz Last Calib. Date : 09-Jan-2007 Temperature : 21.40 °C Ambient Temp. : 21.70 °C Humidity : 53.00 RH% Epsilon : 51.35 F/m Sigma : 1.981 S/m Density : 1000.00 kg/cu. m Probe Data Name : Probe 264 Model : E020 Type : E-Field Triangle Serial No. : 264 Last Calib. Date : 29-Dec-2006 Frequency : 2450.00 MHz Duty Cycle Factor: 1 Conversion Factor: 5.2 Probe Sensitivity: 1.20 1.20 1.20 μV/(V/m) 2 Compression Point: 95.00 mV Offset : 1.56 mm Report No：071L039-HPUSP09V01 Page: 2 of 24 Version:1.0 Measurement Data Crest Factor : 1 Tissue Temp. : 21.40 °C Ambient Temp. : 21.70 °C Area Scan : 7x4x1 : Measurement x=12mm, y=12mm, z=4mm Zoom Scan : 7x7x8 : Measurement x=5mm, y=5mm, z=5mm Power Drift-Start : 0.095 W/kg Power Drift-Finish: 0.098 W/kg Power Drift (%) : 3.111 DUT Position : Touch EUT BACK Channel : 1 1 gram SAR value : 0.731 W/kg 10 gram SAR value : 0.370 W/kg Area Scan Peak SAR : 0.737 W/kg Zoom Scan Peak SAR : 1.551 W/kg Report No：071L039-HPUSP09V01 Page: 3 of 24 Version:1.0 Report No：071L039-HPUSP09V01 Page: 4 of 24 Version:1.0 This is previous page plot (zoom in) Report No：071L039-HPUSP09V01 Page: 5 of 24 Version:1.0 Measurement Data Crest Factor : 1 Tissue Temp. : 21.40 °C Ambient Temp. : 21.70 °C Area Scan : 7x4x1 : Measurement x=12mm, y=12mm, z=4mm Zoom Scan : 7x7x7 : Measurement x=5mm, y=5mm, z=5mm Power Drift-Start : 0.098 W/kg Power Drift-Finish: 0.096 W/kg Power Drift (%) : -2.094 DUT Position : Touch EUT BACK Channel : 6 1 gram SAR value : 0.564 W/kg 10 gram SAR value : 0.273 W/kg Area Scan Peak SAR : 0.609 W/kg Zoom Scan Peak SAR : 1.161 W/kg Report No：071L039-HPUSP09V01 Page: 6 of 24 Version:1.0 This is previous page plot (zoom in) Report No：071L039-HPUSP09V01 Page: 7 of 24 Version:1.0 Measurement Data Crest Factor : 1 Tissue Temp. : 21.40 °C Ambient Temp. : 21.70 °C Area Scan : 7x4x1 : Measurement x=12mm, y=12mm, z=4mm Zoom Scan : 7x7x7 : Measurement x=5mm, y=5mm, z=5mm Power Drift-Start : 0.084 W/kg Power Drift-Finish: 0.088 W/kg Power Drift (%) : 4.632 DUT Position : Touch EUT BACK Channel : 11 1 gram SAR value : 0.457 W/kg 10 gram SAR value : 0.283 W/kg Area Scan Peak SAR : 0.571 W/kg Zoom Scan Peak SAR : 0.980 W/kg Report No：071L039-HPUSP09V01 Page: 8 of 24 Version:1.0 This is previous page plot (zoom in) Report No：071L039-HPUSP09V01 Page: 9 of 24 Version:1.0 Measurement Data Crest Factor : 1 Tissue Temp. : 21.40 °C Ambient Temp. : 21.70 °C Area Scan : 5x5x1 : Measurement x=12mm, y=12mm, z=4mm Zoom Scan : 7x7x7 : Measurement x=5mm, y=5mm, z=5mm Power Drift-Start : 0.219 W/kg Power Drift-Finish: 0.226 W/kg Power Drift (%) : 3.310 DUT Position : Touch EUT TOP Channel : 6 1 gram SAR value : 0.224 W/kg 10 gram SAR value : 0.128 W/kg Area Scan Peak SAR : 0.227 W/kg Zoom Scan Peak SAR : 0.480 W/kg Report No：071L039-HPUSP09V01 Page: 10 of 24 Version:1.0 This is previous page plot (zoom in) Report No：071L039-HPUSP09V01 Page: 11 of 24 Version:1.0 Measurement Data Crest Factor : 1 Tissue Temp. : 21.40 °C Ambient Temp. : 21.70 °C Area Scan : 7x4x1 : Measurement x=12mm, y=12mm, z=4mm Zoom Scan : 7x7x7 : Measurement x=5mm, y=5mm, z=5mm Power Drift-Start : 0.127 W/kg Power Drift-Finish: 0.127 W/kg Power Drift (%) : 0.781 DUT Position : Touch EUT FRONT Channel : 6 1 gram SAR value : 0.175 W/kg 10 gram SAR value : 0.148 W/kg Area Scan Peak SAR : 0.235 W/kg Zoom Scan Peak SAR : 0.340 W/kg Report No：071L039-HPUSP09V01 Page: 12 of 24 Version:1.0 This is previous page plot (zoom in) Report No：071L039-HPUSP09V01 Page: 13 of 24 Version:1.0 ALSAS-10U VER 2.3.2APREL Laboratories SAR Test Report (802.11g) Report Date : 09-Jan-2007 Measurement Date : 09-Jan-2007 Product Data Device Name : MAX LIGHT Type : Other Model : AWU-902T, NV-902T, WA-2110, HWGUSB2-54, Thrustmaster FunAccess WiFi USB Key, TER/GUSB2 Frequency : 2450.00 MHz Length : 75 mm Width : 26 mm Dept…

Text truncated - open the document above for the full version.

Page: 1 of 21 Appendix - Probe Calibration Miniature Isotropic RF Probe M/N: ALS-E-020 S/N: 264 2450MHz Head Calibration page 2~11 2450MHz Body Calibration page 12~21 Page: 2 of 21 Page: 3 of 21 Page: 4 of 21 Page: 5 of 21 Page: 6 of 21 Page: 7 of 21 Page: 8 of 21 Page: 9 of 21 Page: 10 of 21 Page: 11 of 21 Page: 12 of 21 Page: 13 of 21 Page: 14 of 21 Page: 15 of 21 Page: 16 of 21 Page: 17 of 21 Page: 18 of 21 Page: 19 of 21 Page: 20 of 21 Page: 21 of 21 Appendix - Dipole Calibration Validation Dipole 2450MHz P/N: ALS-D-2450-S-2 S/N: QTK-319

Report Number: MLT0609P15002 EXHIBIT D Circuit Diagram 5 5 4 4 3 3 2 2 1 1 DD CC BB AA Printed antenna Amigo Technology Co., Ltd. 2 PA 1.0 AWU-902T USB 2.0 802.11 b /g dongle C 5Tuesday, September 19, 2006 Title SizeDocument NumberRev Date:Sheetof MPAO_G TRSW TRSWN TR_SW TR_SWN ANTE2E GND GND D E T 2 PA_IN RFIN_G PA_PE_G VB2 VCCB 3 . 3 V D PA_RFOMPAO_G GND V C 1 3.3VD MDTRANTE2ANTE2 P A G GND P A F GND PARFINGPAIN GND VB1 PA_RFING G N D GND GND GND GND 3.3VD GND GND GND G N D GND L1 2.7pF 1 2 C9 0.1uF 1 2 C4 10pF/NI 1 2 C6 2.7nH 1 2 R7 0 ohm/SB 1 2 C12 1.8pF 12 L4 4.7nH 12 E1 USB-ANT-RA-2C 12 IOGND C362 10uF/6.3V 1 2 R12 1K ohm 12 R15 0 ohm/SB 12 R210 390 ohm 12 C3 0.5pF 12C13 0.5pF 1 2 C462 0.1uF/NI 1 2 C1 2.2pF 1 2 L5 2.7nH 1 2 C190 0.5pF 1 2 C74 2.2nH 12 R8 360 ohm/NI 12 C11 10pF 12 C8 0.1uF/NI 1 2 C7 2.7pF 12 L3 3.9nH 1 2 C340 10pF/NI 12 C16 0.8pF 12 C78 C/NI 1 2 U53 SST12LP14A 2 1 3 1 9 86 4 10 11 12 1 5 1 6 1 7 1 4 5 3 7 RFin N C NC Vdet_out N C V r e f NC RFOUT RFOUT Vcc2 N C V c c 1 G N D N C V c c b RFin V r e f C30 10pF 12 L6 2.2nH 12 C325 10pF/NI 1 2 L2 1nH 1 2 C17 0.5pF 1 2 C5 0.1uF/NI 1 2 L7 1nH 1 2 C341 10pF/NI 12 C2 1.8pF 1 2 U3 uPG2179TB 3 2 16 5 4 OUT1 GND OUT2VC2 IN VC1 TR_SW TR_SWN RFIN_G PA_RFING PA_PE_G 5 5 4 4 3 3 2 2 1 1 DD CC BB AA XTAL: CL=15pF, Co=1.5pF 33 Amigo Technology Co., Ltd. RF 1.0 AWU-902T USB 2.0 802.11 b /g dongle C 5Tuesday, September 19, 2006 Title SizeDocument NumberRev Date:Sheetof LNA0 RFRX_PE O F F _ C A L RFOUTG+ RFOUTG- LNAG0 RFING+ RFING- I R E F G N D GND GND RFIN_G LNA1LNAG1 VGA_CALOFF_CAL IREF VCCA A G C 3 AGC3 A G C 1 A G C 2 AGC2 GND VCCA AGC1 R F R X _ P E R F T X _ P E RFTX_PE SYNCLK R F _ L E - G # RF_LE-G# S Y N D A T A SYNDATA S Y N C L K RX_BB_I-RX_BB_I- RX_BB_I+RX_BB_I+ RX_BB_Q+RX_BB_Q+ AGC5AGC5 AGC4AGC4 T X _ B B _ I - T X _ B B _ I+ TX_BB_Q+ TX_BB_Q- TX_BB_Q+ VCCA SUSPB VCCA VCCA VCCA V C C A V C C A PA_RFING 3.3VD T X R _ V O 2 GNDRFLDOBP GND G N D G N D T X R _ V O 2 R F R C GND VCCA VCCA TXR_VO2TXR_VO2 GND GNDVCCA V C T R L 1 T X R _ V O 3 GND GND GND VE T X R _ V O 3 C_VCC TXR_VO3 RX_BB_Q-RX_BB_Q- TX_BB_Q- TX_BB_I- TX_BB_I+ VCCPLLA GND GND GND GND GND GND 3.3VA VCCA GND 40 MX1 40 MX2F40M C _ V C C C _ V C C GND G N D RFIN_F 40MI G N D TXR-40MO GND VCCA 3.3VA RF_VCCD G N D GND VCCA GND GND VCCA VCCA VCCA GND GNDGND GND 3.3VD GND GND GND GND GND GND VCCA GND GND VCCA GND GND GND VCCA 3.3VA GND GND GND GND 3.3VA GND VCCA GND C28 4.7uF/6.3V 12 C413 4.7uF/6.3V 12 C244 0.1uF 1 2 C437 22pF 12 C48 2.2nH 12 C454 2.4K/NI 12 C443 39pF 12 C414 4.7uF/6.3V 12 C461 0.01uF 12 R221 0 ohm/NI 12 R267 18K 12 L10 2.2pF 12 R263 0 ohm/SB 12 L20 0 ohm/NI 12 C436 1pF/NI 12 C419 0.01uF 12 R115 0 ohm/SB 12 C452 3.3nF 1 2 R20 0 ohm/SB 12 R258 0 ohm/SB 12 C21 0.5pF 1 2 C24 27pF 12 L26 0 ohm 12 C426 1nF 1 2 5x3.2 U50 XTAL/5x3.2/40MHz 1 2 4 3 C439 4.7pF 12 L54 1nH 12 L8 2.2pF 12 C27 33pF/NI 1 2 C442 1nF 1 2 C424 1pF/NI 12 C50 0.01uF 12 C453 15pF 1 2 R259 68pF 12 R5 0 ohm/SB 12 C428 1nF 1 2 R160 27 12 R260 68pF 12 C245 4.7uF/6.3V/NI 1 2 R14 0 ohm/NI 12 L36 0.8pF/NI 1 2 U47 RT2528 1 2 3 4 5 6 7 8 9 10 11 12 13 5 2 4 6 4 7 4 8 2 4 2 3 2 2 2 7 32 5 7 2 6 2 5 30 31 40 42 5 5 5 4 37 36 35 34 33 41 5 3 29 2 8 5 6 4 9 5 0 5 1 1 9 4 4 4 3 39 38 1 7 1 6 1 5 4 5 14 1 8 2 0 2 1 LNA_Gain1 RFinP2 RFinM2 VCC2 RFoutP2 RFoutM2 NC NC NC NC NC NC LNA_Gain0 T R _ P E C L K D a t a L E L O _ B s V c C o r e _ V c c L O _ V c c V C C A VCCD G N D V P 1 L O _ V c LD_fo CLK_Out AGC5 Base_Vcc1 A G C 1 A G C 2 I_OutP I_OutM Base_Vcc2 Q_OutP Q_OutM AGC4 A G C 3 X1/OSCI X 2 V C C 1 I r e f B i a s _ V c c R F _ P E L D O _ O u t 3 I _ I n P I _ I n M Q_InP Q_InM L D O _ B y p a s s L D O _ I n L D O _ P E O f f s e t _ C a l LDO_Out1 L D O _ O u t 2 N C N C L63 0 ohm/SB 12 C15 33pF 12 C417 100pF 1 2 C45 4.7nH 12 C446 100pF 1 2 C321 5.6pF 12 R268 0 ohm/SB 12 C409 4.7uF/6.3V 12 L55 2.7nH 12 RFIN_G VGA_CAL IREF RFRX_PE LNA1 LNA0 AGC1 AGC2 AGC3 RFTX_PE RF_LE-G# SYNDATA SYNCLK RX_BB_I+ RX_BB_I- RX_BB_Q+ AGC5 AGC4 PA_RFING RX_BB_Q- TX_BB_Q- TX_BB_I+ TX_BB_Q+ TX_BB_I- 40MI SUSPB 5 5 4 4 3 3 2 2 1 1 DD CC BB AA Link/TX INT C353,C354,R207, R230,R246,U38 C353,C354,R207,R246 R230,U38 InstallMode Internal 12Hz R245,R247 Not Install R245,R247 External 12MHz Change connection from VCCA to RFRX_PE. (0603) (0603) (0603) (0603) (0603) 4 Amigo Technology Co., Ltd. CHIP 1.0 AWU-902T USB 2.0 802.11 b /g dongle C 5Tuesday, September 19, 2006 Title SizeDocument NumberRev Date:Sheetof TSSI_AG VREF01 3.3VA DMRS UXI TR_SWN VREF25N SYNDATA VREF25P UDM GND RPU SYNCLK TX_BB_I- TX_BB_I+ 1 . 8 V A R UDP VREFP VREFN RF_LE-G# GND UCLK V S P L L SUSPB G N D 3.3VD G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D G N D 1 . 8 V D 3 . 3 V D 1 . 8 V D 1 . 8 V A 1 . 8 V A 3 . 3 V D 3 . 3 V D 1 . 8 V A 1 . 8 V A 1 . 8 V D 3 . 3 V A 1 . 8 V D 3 . 3 V D 3 . 3 V A 3 . 3 V D 3 . 3 V A 1 . 8 V D 3 . 3 V A 3 . 3 V A 3 . 3 V D 3 . 3 V D 3 . 3 V A 3 . 3 V D 3 . 3 V D 3 . 3 V A 3 . 3 V D 1 . 8 V D 3 . 3 V A 3 . 3 V A GND GND GND GND GND GND GND GND GND RFTX_PE RFRX_PE TX_BB_Q- TX_BB_Q+ PA_PE_G LNA0 IREF RB VCCA VCCA TR_SW GND 3 . 3 V D 3 . 3 V D 3 . 3 V D LD1_GN GND S N O R P L L M D UXO GND 1.8VD RXBB_I- RXBB_Q- RXBB_Q+ RXBB_I+ RX_BB_I- RX_BB_Q- RX_BB_I+ RX_BB_Q+ AGC4 AGC1 AGC3 AGC2 AGC5 VGA_CAL LNA1 40MI SNOR RFRX_PE 3.3VD UXI X1 3.3VDEECS 3.3VD GND 3.3VD GND RREF G N D G N D G N D G N D LED_LKACT# 3.3VD3.3VA 3.3VD LD2_YN 1.8VD 1 . 8 V A EEDI GND GND GND LED_RDY# WPN# GND GND GND EESK GND EEDO GND UDM DPRS MRSTB UF GND G N D GND GND GND GND UDP GND GND GND GND GND GND 3.3VD GND GND GND GND 1.8VA 3.3VD VCCA 1.8VD 3.3VD GNDGND 3.3VA GND GND R227 39/NI 12 U31 RT2571W-TFBGA180 E4 E 1 F 1 G 4 F 3 F 2 A 1 3 C 1 2 B 6 G1 H1 J1 G3 G2 K1 L1 M1 A11 D12 B13 E13 A14 E12 F13 F12 J4 K2 M5 N4 N3 M4 P5 P4 P3 N5 P2 N1 H12 J14 K3 L2 H14 G14 P1 L3 L4 N2 N6 M7 L7 N7 N8 P7 P8 P10 N10 P11 P12 P13 N13 P14 N14 K12 K14 K13 H2 H3 J2 M2 J3 M3 A1 A2 C1 B1 B2 D2 C4 B5 E3 D 1 E2 F 4…

Text truncated - open the document above for the full version.

Page: 1 /80 Report Number: MLT0609P15002 (FCC : Part 15 Subpart B & C (15.247) / ANSI C63.4-2003) Product :IEEE 802.11g Wireless Pocket USB Trade Name :Amigo(The other see Appendix II) Model No. :AWU-902T(The other see Appendix II) Applicant :Amigo Technology Inc. Applicant Address :1F,No. 285,Sec 2,Ti-Ding Blvd., Nei Hu, Taipei,Taiwan 114, R.O.C. Page: 2 /80 Report Number: MLT0609P15002 Report Number MLT0609P15002 Applicant Amigo Technology Inc. Product IEEE 802.11g Wireless Pocket USB Sample Received Date 2006/09/14 Report Prepared By Jesse Tien Signature Date Prepared 2006/09/18 ～ 2006/09/29 Report Authorized By Roger Chen Signature Date Authorized 2007/01/15 Test By Max Light Technology Co., Ltd. Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan., R.O.C. Office：Tel: 886-2-2363-2447 Fax: 886-2-2363-2597 Lab ：Tel:886-2-2663-3486 Fax:886-2-2663-3582 I I t t m m a a y y b b e e d d u u p p l l i i c c a a t t e e d d c c o o m m p p l l e e t t e e l l y y f f o o r r l l e e g g a a l l u u s s e e w w i i t t h h t t h h e e a a l l l l o o w w a a n n c c e e o o f f t t h h e e a a p p p p l l i i c c a a n n t t . . I I t t s s h h a a l l l l n n o o t t b b e e r r e e p p r r o o d d u u c c e e d d e e x x c c e e p p t t i i n n f f u u l l l l , , w w i i t t h h o o u u t t t t h h e e w w r r i i t t t t e e n n a a p p p p r r o o v v a a l l o o f f o o u u r r l l a a b b o o r r a a t t o o r r y y . . Page: 3 /80 Report Number: MLT0609P15002 Table of Contents : I. General 5. II. Conducted Emissions Requirements 9. III. Radiated Emissions Requirements 19. IV. Maximum Conducted Output Power Requirements 41. V. Minimum 6dB RF Bandwidth Requirements 46. VI. Maximum Power Density Requirements 51. VII. Out of Band Conducted Emissions Requirements 56. VIII. Band Edges Requirements 74. IX. Antenna Requirements 77. Appendix I ( EUT Test Setup ) 78. Appendix II ( Brand / Trade Name & Model No. List ) 80 Page: 4 /80 Report Number: MLT0609P15002 CERTIFICATION We here by verify that : The test data, data evaluation, test procedures and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4: 2003. All test were conducted by MLT(Max Light Technology Co.,Ltd) Room 5, 8F, No.125, Section 3 Roosevelt Road, Taipei, Taiwan, R.O.C Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with Class B radiated and conducted emission limit of FCC Rules Part 15 Subpart B & C (15.247). Applicant Name Amigo Technology Inc. Applicant Address 1F,No. 285,Sec 2,Ti-Ding Blvd.,Nei Hu,Taipei,Taiwan 114, R.O.C. Manufacturer Name FAIRWAY ELECTRONIC CO.,LTD. Manufacturer Address Huang Cjong No. 3 Industrial Area, Zhong Tang Town, Dong Guan, City, Guang Dong Province, China Equipment IEEE 802.11g Wireless Pocket USB Model No AWU-902T(The other see Appendix II) FCC ID RC6AWU-902T Report Prepared By Jesse Tien Signature Report Authorized By Roger Chen Signature Page: 5 /80 Report Number: MLT0609P15002 I. GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Amigo Technology Inc. In support of a Class B Digital Device certification in accordance with Part2 Subpart J and Part 15 Subpart A , B and C of the Commission’s and Regulations. 1.2 Customer Details Applicant Name Amigo Technology Inc. Applicant Address 1F,No. 285,Sec 2,Ti-Ding Blvd.,Nei Hu,Taipei,Taiwan 114, R.O…

Text truncated - open the document above for the full version.
