IP•Link 122X Embedded Wireless Module User Manual Version 2.1.05 Helicomm Inc. www.helicomm.com Version 2.1.05 IP-Link 122X User Manual Helicomm, Inc. Page i © 2007 Helicomm, Inc. All rights reserved. No part of this publication may be reproduced, adapted, or translated in any form or by any means without prior written authorization of Helicomm, Inc. Information published here is current or planned as of the date of publication of this document. Because we are improving and adding features to our products continuously, the information in this publication is subject to change without notice. Trademarks Helicomm, IPWINS, IP-Link, WIN-Gate, and IP-Net are trademarks of Helicomm, Inc. ZigBee is a trademark of the ZigBee Alliance. All other product names mentioned in this publication are trademarks of their respective owners. Revision and Iteration History Version Publication Date Authors Summary of Changes and Updates 1.0.0 08/31/2005 CCH Document Creation 1.0.10 12/30/2005 SEAN Verify and modify all AT Commands and Binary Commands 1.0.11 01/23/2006 QF Modify ADC Commands and add DAC Commands 1.0.12 03/02/2006 QF Modify AT register, Routing Table and I/O Commands 1.0.13 03/16/2006 SEAN Add Digital Input function 1.0.14 04/17/2006 SEAN Add RSSI value into Tag Neighbor entries 1.9.90 05/25/2006 SHJ Add application mode, 2.0.00 06/21/2006 SHJ/WF Add additive commands and local awakened sleep 2.0.13 01/19/2007 SHJ/STB/WF Add Scan Neighbor Table Command.Verify and modify all document 2.1.00 06/25/2007 SHJ/STB Modify ADC0 Sample, Modify new tag table mode 2.1.04 12/06/2007 WF Fix a few bugs and optimized the firmware 2.1.05 12/13/2007 Wt.Wu Verify module specifications and delete some AT registers. Version 2.1.05 IP-Link 122X User Manual Helicomm, Inc. Page ii FCC Information Agency Identification Number RF2IPLinkP220 FCC Notice “This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.” FCC Labeling Requirement Notice If the FCC ID is not visible when the module is installed inside another device, the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: "Contains Transmitter Module FCC ID: RF2IPLinkP220" "Contains FCC ID: RF2IPLinkP220." Version 2.1.05 IP-Link 122X User Manual Helicomm, Inc. Page 3 Table of Contents 1 Overview........................................................................................................................1 2 Module Specifications.................................................................................................. 3 2.1 IP-Link 122X-2034 Interface Pin Definitions ........................................................................ 5 2.2 IP-Link 1222-2034 Interface Pin Definitions ........................................................................ 9 2.3 IP-Link 122X-2134 Interface Pin Definitions...................................................................... 12 2.4 IP-Link 122X-2164 Interface Pin Definitions...................................................................... 13 2.5 IP-Link 122X-2264 Interface Pin Definitions...................................................................... 14 2.6 Special Notes on Interface Pins......................................................................................... 17 2.7 Firmware Capabilities Specification................................................................................... 19 3 Absolute Maximum Ratings....................................................................................... 20 4 Operating Conditions ................................................................................................. 21 5 Theory of Networking Operations ............................................................................. 22 5.1 Wireless Networking Topologies ....................................................................................... 22 5.1.1 Connectivity Topology Versus Routing Topology ...................................................... 22 5.1.2 Star Topology............................................................................................................. 23 5.1.3 Peer-to-peer (Mesh) Topology................................................................................... 24 5.2 Topology Selection ............................................................................................................ 25 6 Quick Steps in Establishing an IP-Link 122X Network............................................ 26 6.1 Special Note: Establishing a Full Mesh Network ............................................................... 26 6.2 About the Mesh Topology Configuration of Module .......................................................... 26 7 IP-Link 122X Command Set ....................................................................................... 28 7.1 AT Command Mode........................................................................................................... 28 7.1.1 AT Register Table ...................................................................................................... 29 7.1.2 AT Command Error Codes ........................................................................................ 34 7.2 Binary Mode....................................................................................................................... 34 7.2.1 Generic Frame Format............................................................................................... 35 7.2.1.1 Control Header Field ........................................................................................... 35 7.2.1.2 Link Quality Indicator ...............................................................…

Text truncated - open the document above for the full version.

Date: 29 Jan, 2008 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The Helicomm, Inc., the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen Morlab Communications Technology Co., Ltd., to act on the behalf of the Helicomm, Inc. solely in matters relating to the application for an FCC equipment authorization for FCC ID # RF2IPLINK12212264 including the signing of documents in connection with this Application. Necessary acts carried out by Helicomm, Inc. on our behalf of the Helicomm, Inc. in connection with the Application shall have the same effect as acts of the Helicomm, Inc.. The Helicomm, Inc. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Thank you for your attention to this matter. Yours Sincerely, Signatory Jack Sun Helicomm, Inc.

Date: 29 Jan, 2008 To: Federal Communications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 Re: Helicomm, Inc. FCC ID: RF2IPLINK12212264 FCC Part 15 Subpart C Certification Confidentiality Request Gentlemen: This letter is to comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. Helicomm, Inc. requests that the following documents regarding this submission for FCC ID: RF2IPLINK12212264 be kept confidential: Exhibit Type File Name Block Diagram Block_Diagram.pdf Schematics Circuit_Diagram.pdf Operational Description Operation_Description.pdf Part list BOM.pdf Tune-Up-Procedure Tuning_procedure.pdf Those documents contain detailed system and equipment description and related information about the product which Helicomm, Inc. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, Helicomm, Inc. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Signatory Jack Sun Helicomm, Inc.

External Photos 1. Front View of EUT 2. Inside View of EUT 3. Back View of EUT

Label Label Location

External Photos 1. Front View of EUT 2. Inside View of EUT 3. Back View of EUT

Antenna Connect Photo: Test Setup photo: 1. Conduct Emission 2. Radiated Emission

Product Number: AN2400-0301TM Product Name: 2.4 GHz External Antenna Page 1 Version: 1.0 Issue Date: 2007-09-12 Index: 1. Reliability Testing 2. Specification 3. S Parameter Test Data 4. Antenna Radiation Pattern 5. Mechanical Drawing 6. MSDS & SGS Report ================================================== 1. Reliability Testing Test Item Procedure Requirement 1. Visual inspection and Dimension Check Applicable methods using x5 magnification follow specification 2. Rapid Changing of Temperature -40 ̊C (30minutes) to 90 ̊C (30minutes); 24 cycles After 2 hours recovery: 1. no visible damage 2. Freq. Tol.: < ? % 3. Damp Heat 24 hours at 60 ̊C; 90 ~ 95% RH After 2 hours recovery: 1. no visible damage 2. Freq. Tol. : < ? % 4. Endurance 24 hours at 90 ̊C After 2 hours recovery: 1. no visible damage 2. Freq Tol.: < ? % Product Number: AN2400-0301TM Product Name: 2.4 GHz External Antenna Page 2 Version: 1.0 Issue Date: 2007-09-12 2. Specification A. Electrical Characteristics S.W.R. <= 2.0 @ 2400~2500 MHz Antenna Gain 2.0 ? 0.7 dBi (*Depends on Product Mechanical Environment*) Impedance 50 Ohm B. Material Material of Radiator Cu (Plated) Connector Type 50 Ohm TNC Male C. Environmental Operation Temperature - 30 ̊C ~ + 85 ̊C Storage Temperature - 30 ̊C ~ + 85 ̊C 3. S Parameter Test data Product Number: AN2400-0301TM Product Name: 2.4 GHz External Antenna Page 3 Version: 1.0 Issue Date: 2007-09-12 4. Antenna Radiation Pattern Testing Equipment Specification: Antenna Anechoic Chamber Dimension: 8 x 4 x 4 m Quite Zone: 600mm @1 GHz Isolation: >100dB @ 1 MHz ~ 10 GHz Testing Equipment: Agilent 5071B Received Antenna: 0.7 ~ 6.0 GHz for Gain Calibration Double Ridged Horn Antenna 5. Mechanical Drawing 6. MSDS & SGS Report

Report No.: SZ07120067E06 Page 2 of 43 TABLE OF CONTENTS 1.TEST CERTIFICATION ...........................................................................................................4 2.GENERAL INFORMATION ....................................................................................................5 2.1EUT Description .........................................................................................................................5 2.2Test Standards and Results ........................................................................................................7 2.3Facilities and Accreditations ......................................................................................................8 2.3.1Facilities ....................................................................................................................................8 2.3.2Test Environment Conditions....................................................................................................8 3.47 CFR PART 15C REQUIREMENTS ....................................................................................9 3.1Peak Output Power ....................................................................................................................9 3.1.1Requirement ..............................................................................................................................9 3.1.2Test Description ........................................................................................................................9 3.1.3Test Result ...............................................................................................................................10 3.2Bandwidth .................................................................................................................................12 3.2.1Definition ................................................................................................................................12 3.2.2Test Description ......................................................................................................................12 3.3Conducted Spurious Emissions ...............................................................................................14 3.3.1Requirement ............................................................................................................................14 3.3.2Test Description ......................................................................................................................14 3.3.3Test Result ...............................................................................................................................14 3.4Power spectral density (PSD) ..................................................................................................18 3.4.1Requirement ............................................................................................................................18 3.4.2Test Description ......................................................................................................................18 3.4.3Test Result ...............................................................................................................................18 3.5Band Edge .................................................................................................................................21 3.5.1Requirement ............................................................................................................................21 3.5.2Test Description ......................................................................................................................21 3.5.3Test Result ...............................................................................................................................21 3.6Conducted Emission .................................................................................................................24 3.6.1Requirement ............................................................................................................................24 3.6.2Test Description ......................................................................................................................24 Report No.: SZ07120067E06 Page 3 of 43 3.6.3Test Result ...............................................................................................................................25 3.7Radiated Emission ....................................................................................................................27 3.7.1Requirement ............................................................................................................................27 3.7.2Test Description ......................................................................................................................27 3.7.3Test Result ...............................................................................................................................29 Report No.: SZ07120067E06 Page 5 of 43 2.GENERAL INFORMATION 2.1EUT Description EUT Type.............................. : IP-Link1221-2264 Model Name ......................... : 1221-2264 Serial No. .............................. : (n.a, marked #1 by test site) IMEI ..................................... : (n.a) Hardware Version ................. : 1.0 Software Version .................. : 2.1.05 Modulation Type................... : DSSS Frequency ............................. : 2.405GHz - 2.480GHz (at interval of 5MHz) Power Supply........................ : (see Ancillary Equipments 1/2) Ancillary Equipments 1 ........ : Evaluation Board Model Name: (n.a.) Trade Name: (n.a.) Manufacturer: (n.a.) Serial No.: (n.a., marked #1 by test site) Ancillary Equipments 2 ........ : AC Adapter Model Name: (n.a.) Trade Name: (n.a.) Manufacturer: (n.a.) Serial No.: (n.a., marked #1 by test site) Rated Input: 180-230V, 50/60Hz Rated Output: 9V, 1200mA Wire Length: 150cm…
