RFF-LD1BTLeica DISTO E7100i

Leica DISTO TM E7100i The original laser distance meter Leica DISTO TM E7100i The original laser distance meter Leica DISTO TM E7100i 812795b 1 ENTable of Contents Instrument Set-up - - - - - - - - - - - - - - - - - - - - - - - - - - 2 Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 Display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 Insert batteries - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 Attach / Remove clip - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Switching ON/OFF - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Clear - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Message Codes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Unit setting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Measuring Functions- - - - - - - - - - - - - - - - - - - - - - - - 5 Measuring single distance - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Permanent measuring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Area - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Bluetooth ® Smart- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6 Technical Data- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7 Message Codes- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 Care - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 Disposal - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 Warranty- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Symbols used - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Permitted use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Prohibited use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Hazards in use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Limits of use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Areas of responsibility - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 Electromagnetic Compatibility (EMC) - - - - - - - - - - - - - - - - - 10 FCC statement (applicable in U.S.) - - - - - - - - - - - - - - - - - - - 10 Use of the product with Bluetooth ® - - - - - - - - - - - - - - - - - - - 11 Laser classification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11 Labelling - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11 Leica DISTO TM E7100i 812795b 2 ENInstrument Set-up Introduction The safety instructions and the user manual should be read through carefully before the product is used for the first time. The person responsible for the product must ensure that all users understand these directions and adhere to them. The symbols used have the following meanings: WARNING Indicates a potentially hazardous situation or an unintended use which, if not avoided, will result in death or serious injury. CAUTION Indicates a potentially hazardous situation or an unintended use which, if not avoided, may result in minor injury and/or appreciable material, financial and environmental damage. Important paragraphs which must be adhered to in practice as they enable the product to be used in a technically correct and efficient manner. i Overview Display On/Measure Area / Units Clear / Off Bluetooth ® Leica DISTO TM E7100i 812795b 3 ENInstrument Set-up Display Info Units Battery Main line Area Bluetooth ® Insert batteries Attach / Remove clip + + - - i To ensure a relia- ble use, do not use zinc-carbon batteries. Change batteries when battery symbol is flashing. click! Leica DISTO TM E7100i 812795b 4 ENOperations Switching ON/OFFClearMessage Codes ONOFF 2 sec Device is turned OFF. i Press ON button 2 sec to start continuous laser mode. 1x Undo last action. 2x Leave actual func- tion, go to default operation mode. If the message "InFo" appears with a number, observe the instructions in "Message Codes" section. Example: Unit setting 0.000 m 0.0000 m 0.00 ft 0‘00‘‘ 1/32 0 in 1/32 2 sec Switch between the following units: Leica DISTO TM E7100i 812795b 5 ENMeasuring Functions Measuring single distance 1 Aim active laser at target. 2 8.532 m 3 i Target surfaces: Measuring errors can occur when measuring to colourless liquids, glass, styrofoam or permaeble surfaces or when aiming at high gloss surfaces. Against dark surfaces the measuring time increases. Permanent measuring 1 2 sec 8.532 m Aim active laser at target. The last value measured is dis- played. 2 Stops permanent measuring. 3 Area 12 Aim laser at first target point. 34 Aim laser at sec- ond target point. 24.352 m 2 5 Leica DISTO TM E7100i 812795b 6 ENMeasuring Functions Bluetooth ® Smart I8.462 m 2 Value from main- line is transferred Deactivate/Activate Bluetooth ® 2 sec i App Mode: Use this mode to transfer the data using an App. Bluetooth ® Smart is always active when the device is switched on. Connect the device with your smart-phone, tablet, laptop,... Measurement values will be transferred automatically right after a meas- urement. To tranfer a result from the main line, press the Bluetooth ® key. Bluetooth ® switches off as soon as the laser distance meter is switched off. The efficient and innovative Bluetooth ® Smart module (with the new Bluetooth ® standard V4.0) works together with all Bluetooth ® Smart Ready devices. All other Bluetooth ® devices do not support the energy saving Bluetooth ® Smart Module, which is integrated in the device. We provide no warranty for free DISTO ™ software and offer no support for it. We accept no liability whatsoe…

Text truncated - open the document above for the full version.

Leica DISTO TM E7100i The original laser distance meter Leica DISTO TM E7100i The original laser distance meter Leica DISTO TM E7100i 812795b 1 ENTable of Contents Instrument Set-up - - - - - - - - - - - - - - - - - - - - - - - - - - 2 Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 Overview - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 Display - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 Insert batteries - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 Attach / Remove clip - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 Operations - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Switching ON/OFF - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Clear - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Message Codes - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Unit setting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 Measuring Functions- - - - - - - - - - - - - - - - - - - - - - - - 5 Measuring single distance - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Permanent measuring - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Area - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 5 Bluetooth ® Smart- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6 Technical Data- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7 Message Codes- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 Care - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 Disposal - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 Warranty- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Symbols used - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Permitted use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Prohibited use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Hazards in use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Limits of use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 Areas of responsibility - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10 Electromagnetic Compatibility (EMC) - - - - - - - - - - - - - - - - - 10 FCC statement (applicable in U.S.) - - - - - - - - - - - - - - - - - - - 10 Use of the product with Bluetooth ® - - - - - - - - - - - - - - - - - - - 11 Laser classification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11 Labelling - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11 Leica DISTO TM E7100i 812795b 2 ENInstrument Set-up Introduction The safety instructions and the user manual should be read through carefully before the product is used for the first time. The person responsible for the product must ensure that all users understand these directions and adhere to them. The symbols used have the following meanings: WARNING Indicates a potentially hazardous situation or an unintended use which, if not avoided, will result in death or serious injury. CAUTION Indicates a potentially hazardous situation or an unintended use which, if not avoided, may result in minor injury and/or appreciable material, financial and environmental damage. Important paragraphs which must be adhered to in practice as they enable the product to be used in a technically correct and efficient manner. i Overview Display On/Measure Area / Units Clear / Off Bluetooth ® Leica DISTO TM E7100i 812795b 3 ENInstrument Set-up Display Info Units Battery Main line Area Bluetooth ® Insert batteries Attach / Remove clip + + - - i To ensure a relia- ble use, do not use zinc-carbon batteries. Change batteries when battery symbol is flashing. click! Leica DISTO TM E7100i 812795b 4 ENOperations Switching ON/OFFClearMessage Codes ONOFF 2 sec Device is turned OFF. i Press ON button 2 sec to start continuous laser mode. 1x Undo last action. 2x Leave actual func- tion, go to default operation mode. If the message "InFo" appears with a number, observe the instructions in "Message Codes" section. Example: Unit setting 0.000 m 0.0000 m 0.00 ft 0‘00‘‘ 1/32 0 in 1/32 2 sec Switch between the following units: Leica DISTO TM E7100i 812795b 5 ENMeasuring Functions Measuring single distance 1 Aim active laser at target. 2 8.532 m 3 i Target surfaces: Measuring errors can occur when measuring to colourless liquids, glass, styrofoam or permaeble surfaces or when aiming at high gloss surfaces. Against dark surfaces the measuring time increases. Permanent measuring 1 2 sec 8.532 m Aim active laser at target. The last value measured is dis- played. 2 Stops permanent measuring. 3 Area 12 Aim laser at first target point. 34 Aim laser at sec- ond target point. 24.352 m 2 5 Leica DISTO TM E7100i 812795b 6 ENMeasuring Functions Bluetooth ® Smart I8.462 m 2 Value from main- line is transferred Deactivate/Activate Bluetooth ® 2 sec i App Mode: Use this mode to transfer the data using an App. Bluetooth ® Smart is always active when the device is switched on. Connect the device with your smart-phone, tablet, laptop,... Measurement values will be transferred automatically right after a meas- urement. To tranfer a result from the main line, press the Bluetooth ® key. Bluetooth ® switches off as soon as the laser distance meter is switched off. The efficient and innovative Bluetooth ® Smart module (with the new Bluetooth ® standard V4.0) works together with all Bluetooth ® Smart Ready devices. All other Bluetooth ® devices do not support the energy saving Bluetooth ® Smart Module, which is integrated in the device. We provide no warranty for free DISTO ™ software and offer no support for it. We accept no liability whatsoe…

Text truncated - open the document above for the full version.

Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 4/30/2014 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: RFF-LD1BT including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature Ralph Meyer Electronic Design Engineer Leica Geosystems AG Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 4/30/2014 Request for Confidentiality Company name: Leica Geosystems AG FCC ID: RFF-LD1BT FCC Part 15 Certification Gentlemen, In accordance with CFR 47 § 0.457 and CFR 47 § 0.459 Leica Geosystems AG hereby requests confidentiality of following attachments: (1) schematic diagrams, (2) detailed block diagrams, (3) detailed operational descriptions, (4) parts lists. These documents contain detailed system and equipment description and related information about the product which Leica Geosystems AG considers to be proprietary, confidential and a custom design and otherwise would not release to the general public. Since the design is a basis from which future technological products will evolve, Leica Geosystems AG considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, Signature Ralph Meyer Electronic Design Engineer Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg

Test Report No.: G0M-1405-3836-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 79 1.1 Photos – Equipment External EUT FRONT EUT BACK Test Report No.: G0M-1405-3836-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 79 EUT SIDE VIEW EUT TOP Test Report No.: G0M-1405-3836-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 79 EUT BATTERY CHASE OPEN

RAL 1023 traffic yellow traffic red RAL 3020 graphite black RAL 9011 traffic white RAL 9016green PANTONE 348 U 190 3 KLZ 817689 A 0122 1:1 Typelabel Disto mini US 330 07.11.13STHOM/4170 11.12.13 STHOM/4170 Printing offsets between different colors: +/- 0.1mm Printing offsets within one color: +/- 0.1mm confidential! A08.05.2014

Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Direct Phone: +41 71 727 34 47 Phone +41 71 727 31 31 E-Mail: [email protected] www.leica-geosystems.com Heerbrugg, April 30 th , 2014 Leica DISTO™ E7100i Label Location

Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 4/30/2014 Label Location Statement Company name: Leica Geosystems AG FCC ID: RFF-LD1BT FCC Part 15 Certification To whom it may concern: The text as defined in 15.19(a)(3) and RSS-Gen §5.2 (IC) is too large to be placed on the label of the Device and the device itself is smaller than defined in KDB 784748. Therefore it will be placed in a prominent location of the user guide. Sincerely, Signature Ralph Meyer Electronic Design Engineer Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg Switzerland Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg

Test Report No.: G0M-1405-3836-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 79 1.2 Photos – Equipment internal EUT OPEN EUT OPEN PCB Test Report No.: G0M-1405-3836-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 79 PCB TOP PCB BOTTOM Test Report No.: G0M-1405-3836-TFC247BL-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 11 of 79 BT PCB TOP BT PCB BOTTOM

Provided by Eurofins Product Service GmbH v.0. 2 Declaration concerning Antenna Specification It is hereby declared that the product Model No.: Leica DISTO E7100i FCC ID: RFF-LD1BT fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: 2450AT18B100 Type of antenna: Ceramic Chip Antenna Soldered to the PCB Peak Gain of the antenna: 0.5 dBi Frequency range: 2400 - 2500 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Leica GEosystems AG Address: Heinrich-Wild-Strasse City: Heerbrugg ZIP / Postal code: 9435 Country: Switzerland Place: Heerbrugg Date: 2014-04-29 Signature: Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg

Provided by Eurofins Product Service GmbH v.0. 2 Declaration concerning Antenna Specification It is hereby declared that the product Model No.: Leica DISTO E7100i FCC ID: RFF-LD1BT fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type described below: Model No. of antenna: 2450AT18B100 Type of antenna: Ceramic Chip Antenna Soldered to the PCB Peak Gain of the antenna: 0.5 dBi Frequency range: 2400 - 2500 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Leica GEosystems AG Address: Heinrich-Wild-Strasse City: Heerbrugg ZIP / Postal code: 9435 Country: Switzerland Place: Heerbrugg Date: 2014-04-29 Signature: Leica Geosystems AG Heinrich-Wild-Strasse CH-9435 Heerbrugg

Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 12 RF-EXPOSURE ASSESSMENT REPORT FCC 47 CFR Part 2.1093 Industry Canada RSS-102 RF-Exposure evaluation of portable equipment Report Reference No. ..................... : G0M-1405-3836-TFC093PE-V01 Testing Laboratory ......................... : Eurofins Product Service GmbH Address............................................. : Storkower Str. 38c 15526 Reichenwalde Germany Accreditation ..................................... : A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Filed Test Laboratory, Reg.-No.: 96970 IC OATS Filing assigned code: 3470A Applicant’s name ............................ : Leica Geosystems AG Address............................................. : Heinrich Wild Strasse 9435 Heerbrugg SWITZERLAND Test specification: Standard ........................................... : 47 CFR 1.1310 / 47 CFR 2.1091 / 47 CFR 2.1093 OET Bulletin 65:1997 KDB 447498 D01 v05r01:2013-05-28 RSS-102, Issue 4:2010 Safety Code 6:2009 Equipment under test (EUT): Product description Laser Distance Meter Model No. Leica DISTO E7100i Additional Model(s) None Brand Name(s) Leica DISTO Hardware version V04 Firmware / Software version 0309 FCC-ID: RFF-LD1BT IC: 3177A-LD1BT Test result Passed Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 12 Version History Version Issue Date Remarks Revised by 01 2014-05-23 Initial Release Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 12 REPORT INDEX 1 EQUIPMENT (TEST ITEM) DESCRIPTION 5 1.1 Reference Documents 6 1.2 Radiation Sources 7 2 RESULT SUMMARY 8 3 RF-EXPOSURE CLASSIFICATIONS 9 4 ASSESSMENT 10 4.1 SAR Exemption Assessment –FCC KDB447498 / RSS-102 10 Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 12 1 Equipment (Test item) Description Description Laser Distance Meter Model Leica DISTO E7100i Additional Model(s) None Brand Name(s) Leica DISTO Serial number None Hardware version V04 Software / Firmware version 0309 FCC-ID RFF-LD1BT IC 3177A-LD1BT Equipment type End product Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 6 of 12 1.1 Reference Documents Document type Document No. Issued by Date FCC 15.247 test report G0M-1405-3836-TFC247BL-V01 Eurofins Product Service GmbH 2014-05-23 Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 7 of 12 1.2 Radiation Sources Mode # Description Bluetooth LE Frequency range [MHz] 2402 – 2480 Channels 40 Modulations GFSK Maximum conducted power [dBm] -1.59 Maximum transmission duty cycle [%] 100 Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 8 of 12 2 Result Summary FCC 47 CFR Part 2.1093, KDB447498, IC RSS-102 Product Specific Standard Section Requirement Result Remarks 47 CFR 2.1093 KDB447498 SAR evaluation exemption : Bluetooth LE PASS RSS-102 2.5.1 SAR evaluation exemption : Bluetooth LE PASS Remarks: Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 9 of 12 3 RF-Exposure Classifications Device Types Fixed A fixed device is defined as a device physically secured at one fixed location and cannot be easily re-located. Mobile A mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. (47 CFR 2.1091) Portable A portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. (47 CFR 2.1093) Exposure Categories Occupational / Controlled Limits apply in situations in which persons are exposed as a consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Limits for occupational/controlled exposure also apply in situations when an individual is transient through a location where occupational/controlled limits apply provided he or she is made aware of the potential for exposure. General population / uncontrolled Exposures apply in situations in which the general public may be exposed, or in which persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or cannot exercise control over their exposure. Test Report No.: G0M-1405-3836-TFC093PE-V01 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 10 of 12 4 Assessment 4.1 SAR Exemption Assessment –FCC KDB447498 / RSS-102 Low Power Exclusion acc. to FCC KDB447498 / IC RSS-102 Verdict: PASS Assessment according to reference Reference Method KDB447498 & 2.1093 / RSS-102 & Safety Code 6 Device type portable Exposure category General population FCC/IC SAR Limits Region Occupational SAR values [W/kg] General public SAR values [W/kg] Whole-body SAR averaging mass = entire body 0.4 0.08 Partial-body SAR averaging mass = 1g 8.0 1.6 Hands, Wrists, Feet and Ankles SAR averaging mass = 10g 20 4 FCC SAR test exclusion Excerpt from KDB 447498: Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is s…
