1 Start-up Leica DISTO™ A6 1.0.0 gb D GB F I E P NL DK S N FIN J CN RC ROK PL H RUS CZ User Manual Version 1.0 English Congratulations on your purchase of a Leica DISTO™. The safety instructions can be found in a separate booklet, which accompanies this user manual. The safety instructions along with the user manual should be read carefully before initial operation. Helpful Hint: The first and last page including the pictures should be folded out and left open, whilst reading through the manual. Letters and Numbers in braces {} refer to the illustrations. Content Start-up................................................................ 1 Menu functions................................................... 3 Operation............................................................. 4 Measuring............................................................ 4 Functions............................................................. 5 Working with BLUETOOTH®.............................. 8 Appendix.............................................................. 9 Start-up Inserting / replacing Batteries See figure {C} - Open the positioning bracket. Remove the locking clip and slide the endpiece down. Slide the red locking mechanism to the side and open the battery compartment. Insert new or replace used batteries. Close battery cover, reinsert the endpiece and fix locking clip. The battery symbol {B, 21} appears permanently blin- king in the display when the battery voltage is too low. The batteries should be replaced as soon as possible. •Pay attention to correct polarity. •Use alkaline batteries. •Batteries should be removed if the device will not be used for a long time (danger of corrosion). When changing the batteries the settings and stack content remain unchanged. Multifunctional Endpiece See figure {D} The device can be used for different measurement situations: •For measurements from an edge open the posi- tioning bracket until it locks in place. See figure {E}. •For measurements from a corner, open the posi- tioning bracket until it locks in place, with a slight 2 Start-up Leica DISTO™ A6 1.0.0 gb D GB F I E P NL DK S N FIN J CN RC ROK PL H RUS CZ push to the right the bracket can be turned further. See figure {D and F}. A built-in sensor automatically detects the orienta- tion of the positioning bracket and calculates the corresponding distances accordingly. Integrated telescopic viewfinder The device is equipped with a telescopic viewfinder on the right hand side. The viewfinder is especially helpful when aiming at distant targets. When looking through the viewfinder, the target is clearly visible thanks to the 2x magnification. At distances beyond 30 m laser spot is centered on the crosshair, below 30 m the laser spot appears on the edge of the cros- shair, which is normal. Level The integrated bubble level allows simple horizontal levelling of the instrument. Keypad See figure {A}: 1 ON/MEASURING 22nd FUNCTION LEVEL 3PLUS [+] 4TIMER 5EQUAL [=] 6AREA/VOLUME 7STORAGE 8MEASUREMENT REFERENCE 9CLEAR/OFF 10MENU 11 ILLUMINATION 12INDIRECT MEASUREMENT (PYTHAGORAS) 13 MINUS [-] 14 BLUETOOTH ® Display See figure {B} 1 Information about faulty measurements 2 Laser active 3 Circumference 4 Maximum value of continuous measurement 5 Minimum value of continuous measurement 6 Measurement reference 7 Recall of Historical Storage 8 Storage of constant 9 Main line 10 Units with exponents ( 2 / 3 ) 11 Ceiling area 12 Wall area 13 Three auxiliary lines (e.g. previous results) 14 BLUETOOTH ® on/off 15 2nd Function Level on 16 Hardware error 17 Indirect measurement - Pythagoras 18 Indirect measurement - Pythagoras - partial height 19 Area / Volume 20 Offset setting 21 Battery indication 3 Menu functions Leica DISTO™ A6 1.0.0 gb D GB F I E P NL DK S N FIN J CN RC ROK PL H RUS CZ Menu functions Presettings The menu allows selection of the settings that will remain in memory after the instrument is switched off. Navigation in the Menu Press the MENU -key {A, 10} repeatedly to scroll through the possible menu functions (UNIT, OFFSET, TRIPOD, RESET). When the desired menu option appears, select it with the EQUAL - key {A, 5}, scroll through the possible settings with the PLUS - key {A, 3} or the MINUS - key {A, 13} and store the selected setting with the EQUAL - key {A, 5}. Press CLEAR - key {A, 9} to leave the menu without saving any changes in the settings. Selecting Units "UNIT" blinks in the display. Possible units: Measure with offset An offset automatically adds or subtracts a value to/ from ALL measurements. With this feature toler- ances can be taken into consideration e.g. between unfinished and finished dimensions. Select the menu function OFFSET {B, 20} (OFFSET blinks in the display), confirm with the EQUAL - key {A, 5}. Adjust the OFFSET with the PLUS - key {A, 3} or the MINUS - key {A, 13}. By holding the keys down, the setting values will increase/decrease faster. Once you have entered the proper offset confirm your selection with the EQUAL - key {A, 5}. As long as an OFFSET {B, 20} is added/ subtracted the symbol is visible on the display. Measuring with tripod Using a tripod eliminates shaking when measuring over long distances. On the back of the instrument is an industry standard ¼"-threaded hole for use with a camera tripod mounting screw. For correct measure- ments the reference needs to be adapted. Select the menu function TRIPOD {A, 8} ("triPod" blinks in the display) and confirm with the EQUAL - key {A, 5}. DistanceAreaVolume 0.000 m 0.000 m²0.000 m³ 0.00 m 0.00 m²0.00 m³ 0 mm 0.000 m²0.000 m³ 0.00 ft 0.00 ft²0.00 ft³ 0.00 1 / 32 ft in 0.00 ft²0.00 ft³ 0' 0'' 1 / 32 0.00 ft²0.00 ft³ 0.0 in 0.00 ft²0.00 ft³ 0 1 / 32 in 0.00 ft²0.00 ft³ DistanceAreaVolume 4 Operation Leica DISTO™ A6 1.0.0 gb D GB F I E P NL DK S N FIN J CN RC ROK PL H RUS CZ Reset When you select the menu function RESET ("rESET" will blink in the display) and press the EQUAL-key {A, 5} twice the device will default to factory settin…

Text truncated - open the document above for the full version.

1 Leica DISTO™ 743363b gb D GB F I E P NL DK S N FIN J CN RC ROK PL HR H RUS CZ GR LT LV EST SLO SK M TR Safety Instructions English The User Manual in a separate brochure, forms a part of the Safety Instructions. Carefully read the Safety Instruc- tions and the User Manual before using this product. The person responsible for the instrument must ensure that all users understand these directions and adhere to them. Symbols used The symbols used in the Safety Instructions have the following meanings:  WARNING: Indicates a potentially hazardous situation or an unintended use which, if not avoided, will result in death or serious injury.  CAUTION: Indicates a potentially hazardous situation or an unintended use which, if not avoided, may result in minor injury and/or in appreciable material, finan- cial and environmental damage. ) Important paragraphs which must be adhered to in practice as they enabled the product to be used in a technically correct and efficient manner. Use of the instrument Permitted use •Measuring distances •Computing functions, e. g. areas and volumes •Storing measurements (BLUETOOTH®) Prohibited use •Using the instrument without instruction •Using outside the stated limits •Deactivation of safety systems and removal of explanatory and hazard labels •Opening of the equipment by using tools (screw- drivers, etc.), as far as not specifically permitted for certain cases •Carrying out modification or conversion of the product •Use after misappropriation •Use of accessories from other manufacturers without the express approval of Leica Geosys- tems. •Deliberate or irresponsible behaviour on scaf- folding, when using ladders, when measuring near machines which are running, or near parts of machines or installations which are unprotected •Aiming directly into the sun •Deliberate dazzling of third parties; also in the dark •Inadequate safeguards at the surveying site (e.g. when measuring on roads, construction sites, etc.) 2 Leica DISTO™ 743363b gb D GB F I E P NL DK S N FIN J CN RC ROK PL HR H RUS CZ GR LT LV EST SLO SK M TR Limits of use ) See section “Technical Data“. The Leica DISTO™ is designed for use in areas perma- nently habitable by humans, do not use the product in explosion hazardous areas or in aggressive envi- ronments. Areas of responsibility Responsibilities of the manufacturer of the original equipment Leica Geosystems AG, CH-9435 Heerbrugg (for short Leica Geosystems): Leica Geosystems is responsible for supplying the product, including the User Manual and original accessories, in a completely safe condition. (addi- tional language versions can be found at: www.disto.com. Responsibilities of the manufacturer of non- Leica accessories: ) The manufacturers of non-Leica accessories for the Leica DISTO™ are responsible for developing, implementing and communicating safety concepts for their products. They are also responsible for the effectiviness of these safety concepts in combination with the Leica Geosystems equipment. Responsibilities of the person in charge of the instrument:  WARNING The person responsible for the instrument must ensure that the equipment is used in accor- dance with the instructions. This person is also accountable for the deployment of personnel and for their training and for the safety of the equipment when in use. The person in charge of the instrument has the following duties: •To understand the safety instructions on the product and the instructions in the User Manual. •To be familiar with local safety regulations relating to accident prevention. •To inform Leica Geosystems immediately if the equipment becomes unsafe. Hazards in use  CAUTION: Watch out for erroneous distance measure- ments if the instrument is defective or if it has been dropped or has been misused or modified. Precautions: Carry out periodic test measurements. Particularly after the instrument has been subject to abnormal use, and before, during and after important measure- ments. Make sure the Leica DISTO™ optics is kept clean and that there is no mechanical damage to the bumpers. 3 Leica DISTO™ 743363b gb D GB F I E P NL DK S N FIN J CN RC ROK PL HR H RUS CZ GR LT LV EST SLO SK M TR  CAUTION: In using the instrument for distance measure- ments or for positioning moving objects (e.g. cranes, building equipment, platforms, etc.) unforeseen events may cause erroneous measurements. Precautions: Only use this product as a measuring sensor, not as a control device. Your system must be configured and operated in such a way, that in case of an erroneous measurement, malfunction of the device or power failure due to installed safety measures (e.g. safety limit switch), it is assured that no damage will occur.  WARNING: Flat batteries must not be disposed of with household waste. Care for the environment and take them to the collection points provided in accordance with national or local regulations. The product must not be disposed of with household waste. Dispose of the product appropriately in accordance with the national regulations in force in your country. Always prevent access to the product by unauthorized personnel. Product specific treatment and waste management information can be downloaded from the Leica Geosystems home page at http://www.leica-geosystems.com/treatment or received from your Leica Geosystems dealer.  CAUTION: Aiming the telescopic viewer directly at the sun or at the reflected laser beam (reflected off metallic or mirroring surfaces, prisms...) is hazardous to the eyes. Precautions: Never aim the telescopic viewer directly at the sun or at highly reflecting surfaces (metallic or mirroring surfaces, prisms......). Electromagnetic Compatibility (EMC) The term "electromagnetic compatibility" is taken to mean the capability of the product to function smoothly in an environment where electromagnetic radiation and electrostatic discharges are present, and without causing electromagnetic interference to other equipment.  WARNING: The Leica DISTO…

Text truncated - open the document above for the full version.

Data sheet 2.4/5 GHz Mica Dual Band SMD Antenna Embedded antenna for soldering on PCB This surface-mounted antenna is intended for use with all wireless applications where small size and high performance are key factors. The antenna requires a ground plane, i.e. your device acts as an active part of the antenna and thus demands careful consideration concerning its placement. To obtain a secure and reliable implementation we strongly recommend customers to take advantage of our advanced measuring equipment, custom tuning and technical support. The Mica Dual Band antenna is suitable for Bluetooth TM , Wireless LANs, Home RF and ISM products within the following frequency ranges: 2.4-2.5 GHz and 5.15-5.35 GHz. Typical application areas are: • Mobile phones • PDAs • Headsets • Laptop PCs • Peripheral equipment • PC cards Description The antenna consists of a carrier with an etched antenna pattern. The pattern is as standard designed for 2.4/5 GHz dual band. Customised design of pattern can be arranged on request. The antenna is soldered on the PCB. Matching network is needed. Size:20.5x3.35x3.6 mm gigaAnt, E-mail: [email protected], www.gigaAnt.com Specification subject to change without notice, AE020138-A, June 03 02 Mounting interface Antenna Specification Nominal impedance:50 Ohm Mounting:SMT Operating temperatur:-40 °C – 85 °C Weight:0.4 g -19.26 -16.9 -14.55 -12.19 -0.41 -20 -10 0 10 -15 -10 -5 0 -10 -5 0 5 10 15 X Y Z 15 10 5 -15 -9.83 -7.48 -5.12 -2.77 1.94 4.3 dBi Typical 3D Radiation patterns 2.45 GHz Dimensions (mm) Technical data* 2.4-2.5 GHz 5.15-5.35 Efficiency:>60 %>30% Gain:1.8 dBi0 dBi VSWR:<2:1<2.5:1 * Typical values -21.56 -15.49 -9.42 -3.35 -40 -20 0 20 40 -40 -20 -20 -10 0 10 20 30 X Y Z 0 20 -30 -2.72 dBi -40 40 40 Product name Mica Dual Band 2.4/5 GHz3030A5854-01Tape On Reel Packaging Article No. 5.25GHz

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________ ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 1 of 10 Appendix A. Pictures ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________ ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 2 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________ ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 3 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________ ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 4 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________ ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 5 of 10

18.11.05 22.03.06 APJ / 3452 APJ / 3452 � � � � � � � � 751314 - � � 11 � �� Schild A6 310 � .. Art.No.: Barcode EAN 128, 3.5 mm hoch, ( 751961 ) S.No.: Klartext, Flextronics QDS - Nummer ( 10 Stellen 1x Typ, 2x Jahr, 2x Woche, 1x Tag, 4x Anzahl ) Barcode EAN 128, 3.5 mm hoch ( QDS - Nummer ) Manufactured: aktuelle Monats- und Jahreszahl MAC ID: die letzten 4 Stellen laufende Nummer von Flextronics 745030 (Rolle) Klischee KLZ: 751314 ( Las File ) www.leica-geosystems.com This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) this device must accept any interference received including interference that may cause undesired operation. Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated July 26, 2001. Power: Art.No.: S.No.: Manufactured: xx Made in Austria xxx 740689 3V= / 0.3A PATENTS: WO 9427164 US 5949531 WO 0216964 WO 0244754 WO 9818019 EP 1195617 Type:Leica DISTO TMTM A6 2 IC: 3177A-MTD0506 FCC ID: RFFMTD0506 MAC: 00:17:17:00:XX:XX

ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________ ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 6 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________ ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 7 of 10 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH ___________________________________________________________________ ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 8 of 10

ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH TEST - REPORT FCC RULES PARTS 15.247 IC RADIO STANDARDS RSS-210 Annex 8 FCC ID: RFFMTD0506 IC: 3177A-MTD0506 Model Name: Leica DISTO A6 Test report no.: G0M20603-0338 - P-15 Certificate 1983-01 ELECTRONIC TECHNOLOGY SYSTEMS STORKOWER STRASSE 38C, D-15526 REICHENWALDE B. BERLIN DR. GENZ GMBH PHONE +49-33631-888 00 FAX +49-33631-888 660 ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 1 of 34 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH TABLE OF CONTENTS 1 General information 1.1 Notes 1.2 Testing laboratory 1.3 Details of approval holder 1.4 Application details 1.5 Test item 1.6 Test standards 2 Technical test 2.1 Summary of test results 2.2 Test environment 2.3 Test equipment utilized 2.4 General test procedure 2.5 Test results 3 Transmitter parameters 3.1 RF power output conducted 3.2 RF power output radiated (EIRP) 3.3 20 dB bandwidth 3.4 Time of occupancy (dwell time) 3.5 Number of hopping frequencies 3.6 Carrier frequency separation 3.7 Spurious emission conducted 3.8 Spurious emission radiated 3.9 Band-edge compliance 3.10 AC power line conducted emission 4 Receiver parameters 4.1 Radiated emission APPENDIX ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 2 of 34 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1 General information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification. Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that is performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.5. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ELECTRONIC TECHNOLOGY SYSTEMS DR. GENZ GMBH. Tester: 22.05.2006 D. Hoppe Date ETS-Lab. Name Signature Technical responsibility for area of testing: 22.05.2006 N. Kaspar Date ETS Name Signature ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 3 of 34 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.2 Testing laboratory 1.2.1 Location ELECTRONIC TECHNOLOGY SYSTEM DR. GENZ GMBH (ETS) Storkower Straße 38c D-15526 Reichenwalde b. Berlin Germany Telephone : +49 33631 888 00 Telefax : +49 33631 888 66 1.2.2 Details of accreditation status ACCREDITED TESTING LABORATORY DAR-REGISTRATION NUMBER: DAT-P-201/96 A CCREDITED COMPETENT BODY DAR-REGISTRATION NUMBER: BPT-ZE-026/96 FCC FILED TEST LABORATORY: REG. NO. 96970 INDUSTRY CANADA FILED TEST LABORATORY REG. NO. IC 3470 A2LA ACCREDITED CERTIFICATE NUMBER: 1983-01 B LUETOOTH QUALIFICATION TEST FACILITY (BQTF) A CCREDITED BY: BLUETOOTH QUALIFICATION REVIEW BOARD (BQRF) 1.3 Details of approval holder Name : Leica Geosystems AG Street : Heinrich Wild Strasse Town : CH-9435 Heerbrugg Country : Switzerland Telephone : +41 71 727 36 06 Fax : +41 71 727 57 06 Contact : Herr Bernhard Fiegl E-Mail : [email protected] ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 4 of 34 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.4 Application details Date of receipt of application : 09.05.2006 Date of receipt of test item : 09.05.2006 Date of test : 10.05.2006 – 11.05.2006 1.5 Test item Description of test item : Laser Distance Meter with Bluetooth Type identification : Leica DISTO A6 Serial number : without Photos : See annex A. Technical data Frequency band : 2.4 - 2.4835 GHz Frequency Ch A : 2402 MHz Frequency Ch B : 2441 MHz Frequency Ch C : 2480 MHz Transmitter Vnom Power (ch A) : Conducted: -3.18 dBm Power (ch B) : Conducted: -3.43 dBm Power (ch C) : Conducted: -3.41 dBm Antenna Type : internal antenna Antenna Gain : 6 dBi Power supply : 3.0 V DC Operating mode : duplex Type of modulation : FHSS Host device : none ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 5 of 34 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH Classification : Fixed Device Mobile Device (Human Body distance > 20 cm) Portable Device (Human Body distance < 20 cm) Manufacturer: (if applicable) Name : Flextronics International GmbH Street : Friesacher Strasse 3 Town : A-9330 Althofen Country : Austria Additional information: The test sample is designed as Bluetooth device. Its pseudorandom hopping scheme, authentication, receiver parameters, synchronization procedure and other parameters are determined by Bluetooth Core Specification. Spurious emission tests in RX mode are performed by RX operating on all receiving frequencies. According to attached declaration of manufacturer this device don’t work in master inquiry mode. So we have only one frequency hopping system and the hopping sequence of the master inquiry mode is not very feed. ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 6 of 34 ELECTRONIC TECHNOLOGY SYSTEMS DR.GENZ GMBH 1.6 Test standards Technical standard: FCC Parts: 15.247 IC Standards: RSS 210 Issue 6 Annex 8.1 2 Technical test 2.1 Summary of test results No deviations from the technical specification(s) were ascertained in the course : of the tests performed. or The deviations as specified in 2.5 were ascertained in the course of the tests … performed. 2.2 Test environment Temperature : 25 ° C Relative humidity content : 20 ... 75 % Air pressure : 86 ... 103 kPa ETS Dr. Genz GmbH, Germany Registration number: G0M20603-0338-P-15 Page 7 of 34 ELECTRONIC TECHNOLOGY SYST…
