RFK-LMSWDJH819Single Channel Power Amplifier

Dual Band CA -819 Amplifier Installation Manual Page 1 of 2 All brands and trademarks are the property of their respective owners. Copyright 2003, Janizary Holdings, Inc. All rights reserved. Rev C D00000413 Designed and Manufactured under License from Motorola, Inc. in the U.S.A. Note: Before installing the Cyfre™ Amplifier, please read the entire contents of this manual. Section # 1 Parts List Ite m Q ty Description 1 1 Cyfre ™ Amplifier 2 1 2 Meter (78”) DC Power Cable Section # 2 Tools and Other Materials Required Item Description 1 Electric drill (as required for signal amplifier mounting holes) 2 Screw driver 3 Qty 4 screws (length and type as required for signal amplifier mounting) 4 Wire cutters / strippers 5 Qty 2 wire connection insulators or insulating material (as required for DC power cable connection to 12V DC system) Section # 3 WARNINGS! ∇ Directly wired vehicle antennas, mounted a minimum distance of 49.5 cm (19.5”) away from any person, are recommended. ∇ Mounting a signal amplifier in the engine cavity or on the underside of the vehicle will void the manufacturer’s warranty. ∇ Subjecting the amplifier to voltages greater than 30 Volts DC will damage the amplifier and void the manufacturers warranty. ∇ Any vehicle with an electrical system of greater than 30 Volts DC should use a step-down voltage regulator to bring the voltage within the DC operating power range of the amplifier (10 to 30V dc). ∇ Under no circumstances should the amplifier be powered up without a properly connected 50 ohm 800/1900 MHz dual band cellular/PCS antenna or the amplifier may be damaged, resulting in the manufacturer’ warranty being void. ∇ For optimum performance and compatibility with cellular service provider requirements, it is recommended that an external antenna with a maximum gain of 3dB be installed. ∇ Use of cellular amplifiers with antennas of higher gains than 7dBi gain is in violation of FCC regulations for which the offender will be fully liable, and warranty claims will be voided. It is recommended that only certified automotive installation technicians install this product in a vehicle. Installation by any other person is at the risk of the vehicle owner and operator. Section # 4 Installation Selecting a Suitable Location To Mount The Signal Amplifier Locate a suitable place to mount and conceal the signal amplifier. Suggested mounting locations include: under the dashboard, under the seat, or in the trunk. For peak performance the signal amplifier should be mounted as close to the phone handset as possible. The amplifier’s location should be easily accessible and mounted away from moving parts, as well as excessive heat and moisture. Dual Band CA -819 Amplifier Installation Manual Page 2 of 2 All brands and trademarks are the property of their respective owners. Copyright 2003, Janizary Holdings, Inc. All rights reserved. Rev C D00000413 Designed and Manufactured under License from Motorola, Inc. in the U.S.A. Section # 5 Installation Cautions ∇ Use caution to avoid drilling through or near fuel lines or fuel tanks; brake lines; or electrical wiring. ∇ Do not mount the signal amplifier or its associated wiring in a location that may interfere with the safe operation of the vehicle. ∇ If the fuse is changed from the 3 amps to a higher rating the warranty is void. Purchaser of the amplifier would be responsible for the repair of the unit. ∇ Caution: Connection to the negative side with the positive lead will cause damage to the amplifier. Section # 6 Installation Of The Signal Amplifier Typical Installation For Under The Seat Mounting 1. For safety, disconnect the vehicle’s negative “−“ battery terminal to remove power from the vehicle. 2. Drill holes or Velcro tape and mount the signal amplifier (ITEM 1) in the selected location. 3. Connect the coloured striped black wire of the supplied 2 Meter (78”) power cable (ITEM 2) for the signal amplifier to a positive connection on the vehicle’s electrical system. Choose a 10 to 30 Volt DC circuit that is: fuse protected; and ignition switched. (Often referred to as the “Accessory output”) 4. Attach the solid black wire of the supplied 2 Meter (78”) power cable (ITEM 2) to a vehicle electrical ground point. 5. Attach an external antenna cable (7dbi max) to the amplifier's input connector. The output connector on the amplifier is connected to a cellular phone handset via a RF cradle or an RF cable 6. Reconnect the vehicle’s negative “−“ Battery terminal. Section # 7 Limited Warranty Cyfre™ warrants that this product is free from any defects in material or workmanship for a period of one year. If a defect in material or workmanship is found, Inteligain Corporation agrees to repair or replace the product at its own discretion, free of charge to the original purchaser. Please return the product along with proof of purchase to the original authorized dealer. This warranty is null and void if the product has been modified, abused, tampered with, subjected to abnormal conditions, if the fuse is changed to a higher rating than 3 amp, or transferred to someone other than the original purchaser. Use a 3dB antenna for Optimal Performance

Dual Band CA -819 Amplifier Installation Manual Page 1 of 2 All brands and trademarks are the property of their respective owners. Copyright 2003, Janizary Holdings, Inc. All rights reserved. Rev C D00000413 Designed and Manufactured under License from Motorola, Inc. in the U.S.A. Note: Before installing the Cyfre™ Amplifier, please read the entire contents of this manual. Section # 1 Parts List Ite m Q ty Description 1 1 Cyfre ™ Amplifier 2 1 2 Meter (78”) DC Power Cable Section # 2 Tools and Other Materials Required Item Description 1 Electric drill (as required for signal amplifier mounting holes) 2 Screw driver 3 Qty 4 screws (length and type as required for signal amplifier mounting) 4 Wire cutters / strippers 5 Qty 2 wire connection insulators or insulating material (as required for DC power cable connection to 12V DC system) Section # 3 WARNINGS! ∇ Directly wired vehicle antennas must be mounted a minimum distance of 20 cm (7.87”) away from the body of any user or nearby persons and the antenna. ∇ Mounting a signal amplifier in the engine cavity or on the underside of the vehicle will void the manufacturer’s warranty. ∇ Subjecting the amplifier to voltages greater than 30 Volts DC will damage the amplifier and void the manufacturers warranty. ∇ Any vehicle with an electrical system of greater than 30 Volts DC should use a step-down voltage regulator to bring the voltage within the DC operating power range of the amplifier (10 to 30V dc). ∇ Under no circumstances should the amplifier be powered up without a properly connected 50 ohm 800/1900 MHz dual band cellular/PCS antenna or the amplifier may be damaged, resulting in the manufacturer’ warranty being void. ∇ For optimum performance and compatibility with cellular service provider requirements, it is recommended that an external antenna with a maximum gain of 3dB be installed. ∇ Use of cellular amplifiers with antennas of higher gains than 7dBi gain is in violation of FCC regulations for which the offender will be fully liable, and warranty claims will be voided. It is recommended that only certified automotive installation technicians install this product in a vehicle. Installation by any other person is at the risk of the vehicle owner and operator. Section # 4 Installation Selecting a Suitable Location To Mount The Signal Amplifier Locate a suitable place to mount and conceal the signal amplifier. Suggested mounting locations include: under the dashboard, under the seat, or in the trunk. For peak performance the signal amplifier should be mounted as close to the phone handset as possible. The amplifier’s location should be easily accessible and mounted away from moving parts, as well as excessive heat and moisture. Dual Band CA -819 Amplifier Installation Manual Page 2 of 2 All brands and trademarks are the property of their respective owners. Copyright 2003, Janizary Holdings, Inc. All rights reserved. Rev C D00000413 Designed and Manufactured under License from Motorola, Inc. in the U.S.A. Section # 5 Installation Cautions ∇ Use caution to avoid drilling through or near fuel lines or fuel tanks; brake lines; or electrical wiring. ∇ Do not mount the signal amplifier or its associated wiring in a location that may interfere with the safe operation of the vehicle. ∇ If the fuse is changed from the 3 amps to a higher rating the warranty is void. Purchaser of the amplifier would be responsible for the repair of the unit. ∇ Caution: Connection to the negative side with the positive lead will cause damage to the amplifier. Section # 6 Installation Of The Signal Amplifier To meet the FCC Exposure Guidelines, the antenna should be installed so there is at least 20 cm of separation between the body of the user or nearby persons and the antenna. Typical Installation For Under The Seat Mounting 1. For safety, disconnect the vehicle’s negative “−“ battery terminal to remove power from the vehicle. 2. Drill holes or Velcro tape and mount the signal amplifier (ITEM 1) in the selected location. 3. Connect the coloured striped black wire of the supplied 2 Meter (78”) power cable (ITEM 2) for the signal amplifier to a positive connection on the vehicle’s electrical system. Choose a 10 to 30 Volt DC circuit that is: fuse protected; and ignition switched. (Often referred to as the “Accessory output”) 4. Attach the solid black wire of the supplied 2 Meter (78”) power cable (ITEM 2) to a vehicle electrical ground point. 5. Attach an external antenna cable (7dbi max) to the amplifier's input connector. The output connector on the amplifier is connected to a cellular phone handset via a RF cradle or an RF cable 6. Reconnect the vehicle’s negative “−“ Battery terminal. Section # 7 Limited Warranty Cyfre™ warrants that this product is free from any defects in material or workmanship for a period of one year. If a defect in material or workmanship is found, Inteligain Corporation agrees to repair or replace the product at its own discretion, free of charge to the original purchaser. Please return the product along with proof of purchase to the original authorized dealer. This warranty is null and void if the product has been modified, abused, tampered with, subjected to abnormal conditions, if the fuse is changed to a higher rating than 3 amp, or transferred to someone other than the original purchaser. Use a 3dB antenna for Optimal Performance

Dual Band CA -819 Amplifier Installation Manual Page 1 of 2 All brands and trademarks are the property of their respective owners. Copyright 2003, Janizary Holdings, Inc. All rights reserved. Rev C D00000413 Designed and Manufactured under License from Motorola, Inc. in the U.S.A. Note: Before installing the Cyfre™ Amplifier, please read the entire contents of this manual. Section # 1 Parts List Ite m Q ty Description 1 1 Cyfre ™ Amplifier 2 1 2 Meter (78”) DC Power Cable Section # 2 Tools and Other Materials Required Item Description 1 Electric drill (as required for signal amplifier mounting holes) 2 Screw driver 3 Qty 4 screws (length and type as required for signal amplifier mounting) 4 Wire cutters / strippers 5 Qty 2 wire connection insulators or insulating material (as required for DC power cable connection to 12V DC system) Section # 3 WARNINGS! ∇ Directly wired vehicle antennas must be mounted a minimum distance of 20 cm (7.87”) away from the body of any user or nearby persons and the antenna. ∇ Mounting a signal amplifier in the engine cavity or on the underside of the vehicle will void the manufacturer’s warranty. ∇ Subjecting the amplifier to voltages greater than 30 Volts DC will damage the amplifier and void the manufacturers warranty. ∇ Any vehicle with an electrical system of greater than 30 Volts DC should use a step-down voltage regulator to bring the voltage within the DC operating power range of the amplifier (10 to 30V dc). ∇ Under no circumstances should the amplifier be powered up without a properly connected 50 ohm 800/1900 MHz dual band cellular/PCS antenna or the amplifier may be damaged, resulting in the manufacturer’ warranty being void. ∇ For optimum performance and compatibility with cellular service provider requirements, it is recommended that an external antenna with a maximum gain of 3dB be installed. ∇ Use of cellular amplifiers with antennas of higher gains than 7dBi gain is in violation of FCC regulations for which the offender will be fully liable, and warranty claims will be voided. It is recommended that only certified automotive installation technicians install this product in a vehicle. Installation by any other person is at the risk of the vehicle owner and operator. Section # 4 Installation Selecting a Suitable Location To Mount The Signal Amplifier Locate a suitable place to mount and conceal the signal amplifier. Suggested mounting locations include: under the dashboard, under the seat, or in the trunk. For peak performance the signal amplifier should be mounted as close to the phone handset as possible. The amplifier’s location should be easily accessible and mounted away from moving parts, as well as excessive heat and moisture. Dual Band CA -819 Amplifier Installation Manual Page 2 of 2 All brands and trademarks are the property of their respective owners. Copyright 2003, Janizary Holdings, Inc. All rights reserved. Rev C D00000413 Designed and Manufactured under License from Motorola, Inc. in the U.S.A. Section # 5 Installation Cautions ∇ Use caution to avoid drilling through or near fuel lines or fuel tanks; brake lines; or electrical wiring. ∇ Do not mount the signal amplifier or its associated wiring in a location that may interfere with the safe operation of the vehicle. ∇ If the fuse is changed from the 3 amps to a higher rating the warranty is void. Purchaser of the amplifier would be responsible for the repair of the unit. ∇ Caution: Connection to the negative side with the positive lead will cause damage to the amplifier. Section # 6 Installation Of The Signal Amplifier To meet the FCC Exposure Guidelines, the antenna should be installed so there is at least 20 cm of separation between the body of the user or nearby persons and the antenna. Typical Installation For Under The Seat Mounting 1. For safety, disconnect the vehicle’s negative “−“ battery terminal to remove power from the vehicle. 2. Drill holes or Velcro tape and mount the signal amplifier (ITEM 1) in the selected location. 3. Connect the coloured striped black wire of the supplied 2 Meter (78”) power cable (ITEM 2) for the signal amplifier to a positive connection on the vehicle’s electrical system. Choose a 10 to 30 Volt DC circuit that is: fuse protected; and ignition switched. (Often referred to as the “Accessory output”) 4. Attach the solid black wire of the supplied 2 Meter (78”) power cable (ITEM 2) to a vehicle electrical ground point. 5. Attach an external antenna cable (7dbi max) to the amplifier's input connector. The output connector on the amplifier is connected to a cellular phone handset via a RF cradle or an RF cable, or connect the optional RF cable for your handset, from the cellular handset to amplifier port labelled “Phone”. 6. Reconnect the vehicle’s negative “−“ Battery terminal. Section # 7 Limited Warranty Cyfre™ warrants that this product is free from any defects in material or workmanship for a period of one year. If a defect in material or workmanship is found, Inteligain Corporation agrees to repair or replace the product at its own discretion, free of charge to the original purchaser. Please return the product along with proof of purchase to the original authorized dealer. This warranty is null and void if the product has been modified, abused, tampered with, subjected to abnormal conditions, if the fuse is changed to a higher rating than 3 amp, or transferred to someone other than the original purchaser. Use a 3dB antenna for Optimal Performance

LEON PAUL KASS, LLC CONSULTANT IN WIRELESS COMMUNICATION 9695 135 th Street Seminole, Florida 33776-1434 Phone 727-593-3100 Fax 727-593-7950 E Mail lpk @ fdn.com February 9, 2004 FEDERAL COMMUNICATIONS COMMISSION Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 Re: REQUEST FOR CONFIDENTIALITY FCC ID:RFKLMSWDJH819 Model CA-819 Dear Sir/ Madam: Due to Janizary Holdings, Inc. requirement for proprietary information in conjunction with a Manufacturing Agreement with Leon Paul Kass LLC which is in conjunction with a License to use specific patented technology from Motorola, Inc. in the development and production of this unit, we are requesting to hold the following exhibits as Confidential. 1. Block Diagram 2. Parts List 3. Schematic drawing 4. Theory of operation Thank you very much Regards Leon Paul Kass

5330 Derry Avenue, Suite F, Agoura Hills, California 91301 tel: 818-707-6000 fax: 818-874-9259 1/19/04 AGENT AUTHORIZATION To whom it may concern, In regards to the F.C.C. application for equipment authorization, Janizary Holdings, Inc. dba Cyfre has appointed Leon Paul Kass, of Leon Kass LLC., Consultant to act as our agent pursuant to the following sections of the F.C.C. document listed below. Mr. Kass has full authority to respond to all necessary answers to complete this transaction for our model CA-819 amplifier. SECTION5301 (ANTI-DRUG ABUSE) CERTIFICATION: The applicant hereby certifies that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a “party” for these purposes. APPLICANT/AGENT CERTIFICATION: I certify that I have authorized Leon Paul Kass to sign this application. All of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization issued by the FCC as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. Authorizing an agent to sign this application is done solely at the applicant’s discretion; however, the applicant remains responsible for all statements in this application. Thank You William H. Rogers Chief Financial Officer

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 February 3, 2004 RE: FCC ID: RFK-LMSWDJH819 Attention: Leon Paul Kass I have a few comments on this Application. 1. Please provide a completed 731. This form is required by ATCB quality to allow tracking of applications etc. Please indicate on the 731 which frequency ranges are for which rule part. If all frequency ranges are for all rule parts, please so indicate. Please remove the tolerances in the power field and please put the maximum measured conducted power. 2. Please indicate the appropriate equipment code for the device on the 731 form (item 4a on the 731). 3. Please note that except in extenuating circumstances internal photos are not allowed to be held confidential. Please remove the internal photos from the confidentiality request. 4. Please note that the request for confidentiality is not the proper place for the technical specifications of a device. Please remove the technical specs shown on the request for confidentiality and restrict the request for confidentiality to listing those items that are to be confidential. 5. Please provide the external photos for this device showing the device from the various sides of the exterior. 6. Please provide the factory tune up procedure for this device. This tune up procedure should indicate how the automatic power adjustment is set. 7. Please provide a manual that contains the appropriate rf exposure statements for this mobile device (i.e. the 20 cm or appropriate separation distance statement). 8. Please provide an MPE report for this device as required by the FCC rules. 9. Please note that the list of test equipment shows that the testing was apparently done using out of cal equipment (i.e. analyzer due cal 1/10/04 and testing done 1/20/04). Please explain and retest as appropriate using properly calibrated test equipment. 10. Please note that as this application is for parts 22 cellular, 24 PCS and 90 frequency bands, it is unlikely that this device will be used strictly in F3E modulation. Please note that amplifiers must be shown to be able to reproduce all emissions types that are to be used. Please provide evidence that this device will comply using all of the appropriate modulation types. Alternately, please show how this device restricts use to F3E modulation types only. 11. Amplifiers are to faithfully reproduce the input. This means that each modulation type is to be input to the device and a plot of both input and output is to be provided. The report shows what appears to be an unmodulated input signal. Please provide evidence of testing all modulation types (i.e. provide input and output plots of all modulation types used). 12. Please note that it is unclear from your report if you used the antenna substitution method specified in TIA 603. Your reference to 2.2.1.1 is for conducted carrier output power, not radiated spurious emissions as stated in the report. The limits listed in the report are also 54. However, you have not specified 54 what? It is assumed this is 54dBuV. This, however, would not be correct as the limit for ERP/EIRP measurements of spurious emissions of licensed devices is -13dBm (94dBuv). The report data indicates that only field strength emissions levels were measured. Please explain, and or retest using the proper antenna substitution method specified in 2.2.12 of the latest edition of TIA 603. 13. Please note that the report on page 39 states that this device is used in the part 22E paging bands. Please note that this device frequency range lies in the part 22H cellular bands and is not in the allocated part 22E frequency bands. Please explain and/or please test to the correct frequency bands for device operation as stated in the application. 14. Please provide a test report that addresses all of the rule parts to which this application applies. 15. Please note that your report references 90.219g. Please note that there is no such section in 90.219. Please use current CFR rule parts when referencing CFR 47. Please provide a report specifically referencing all appropriate rules parts for which this application applies. z Page 2 February 3, 2004 Dennis Ward mailto:[email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

RF Exposure RFK-LMSWDJH819 The CA-819 (800 / 1900 MHz) dual band RF Compensator is operated as a mobile device as defined in 2.1091(b) bases on its design and installation. The compensator is installed into a vehicle such that it is physically secured and is generally located more than 20 cm from the end-user. This information is included in the user manual. It is suggested that the antenna be installed such that there is at least 20 cm of separation between the occupants of the vehicle and the antenna. The CA-819 (800 / 1900 MHz) dual band RF Compensator has a transmitted conducted power of 0.5 W in both cellular and PCS bands. The mobile antenna supplied with the transceiver has a maximum gain of 3 dB, and minimum cable loss of –1.0 dB, together resulting in a maximum EIRP of 1 W. Since the transmit cellular band (824-849 MHz) is below 1.5 GHz and its EIRP with the supplied antenna is below 1.5 and transmit PCS band (1850-1910 MHz) is above 1.5 GHz and its EIRP with the supplied antenna is below 3W, the 800 / 1900 MHz RF Compensator is categorically excluded from routine environmental evaluation per 2.1091(c). RF Exposure – MPE Calculations Input Transmitter Power: 500 mW Antenna Gain: 3 dB Cable loss: 1 dB @ 824 – 849 MHz 2 dB @ 1850 – 1910 MHz Frequency range: 824-849 MHz and 1850-1910 MHz Assumptions 1. A single ¼ wavelength radiating antenna is assumed. 2. Closest exposure distance is assumed to be 20 cm RF Exposure – MPE Calculations Calculations The following results shall be assumed to be accurate for the far-field only. These predictions will over-estimate power density in the near–field. Based on the use of a ¼ wavelength radiator, a distance of 20 cm is considered to be in the far-field for all cases. S = PG/4*PI*R 2 @ 824 – 849 MHz P is 500 mW G is 2 dB (Antenna gain – loss) or 10 (2/20) or 1.25 R is 20 cm S = 0.125 mW/cm 2 For Occupational/Controlled Exposure From 300 to 1500 MHz, power density limit is f/300 mW/cm 2 @ 824 MHz, power density limit is 2.75 mW/cm 2 for 6 minutes. For General Population/Uncontrolled Exposure From 300 to 1500 MHz, power density limit is f/1500 mW/cm 2 @ 824 MHz, Power density limit is 0.55 mW/cm 2 for 30 minutes. Conclusion: Meets MPE limits @ 1850 – 1910 MHz P is 500 mW G is 1 dB (Antenna gain – loss) or 10 (1/20) or 1.12 R is 20 cm S = 0.112 mW/cm 2 For Occupational/Controlled Exposure From 1,500 to 100,000 MHz, power density limit is 5 mW/cm 2 for 6 minutes. For General Population/Uncontrolled Exposure From 1,500 to 100,000 MHz, power density limit is 1 mW/cm 2 for 30 minutes. Conclusion: Meets MPE limits

FCC ID: RFK-LMSWDJH819 1 Application for Certification For an RF amplifier Janizary Holdings Inc. 5330 Derry Ave, Suite F Agoura Hills, CA 91301 RF amplifier FCC ID: RFK-LMSWDJH819 REPORT # RV48085A-002 This report was prepared in accordance with the requirements of the FCC Rules and Regulations Part 2, Subpart J, 2.1031 through 2.1057, and Parts 22, 24, and 90 and other applicable sections of the rules as indicated herein. Prepared By: Kevin Meyers DNB Engineering, Inc. 5969 Robinson Avenue Riverside, Ca 92503-8620 20 Jan 2004 FCC ID: RFK-LMSWDJH819 2 TEST LAB PERSONNEL Test Performed by: Date Signature Thomas Elders 20 Jan 2004 APPROVALS Management Approval Date Signature Les Payne Sr. Engineering Manager 10 Feb 2004 Original report RV48085A-001 Dated 20 Jan 2004 Revised report RV48085A-002 Dated 10 Feb 2004 FCC ID: RFK-LMSWDJH819 3 TABLE OF CONTENTS Section Title Sheet # Test Lab Personnel and Approvals 2 Table of Contents 3 Table of Figures 4 1.0 ADMINISTRATIVE DATA 5 1.1 Certifications and Qualifications 5 1.2 Measurements and Repeatability Information 5 1.3 Test Methodology 6 1.4 Test Equipment 6 1.5 Deviations 6 1.6 Test Description 7 Note: Paragraph numbers in this report follow the application section numbers found in the FEDERAL COMMUNICATIONS COMMISSION Rules and Regulations, Part 2, Subpart J for Certification of electronic equipment. 2.1033 (C) (1) Application for Certification 8 2.1033 (C) (2) FCC Identifier 9 2.1033 (C) (3) Installation and Operating Instructions (Service manual) 9 2.1033 (C) (4) Type of Emissions 9 2.1033 (C) (5) Frequency Range 9 2.1033 (C) (6) Operating Power 9 2.1033 (C) (7) Maximum Power Allowed in Applicable part(s) of the Rules 9 2.1033 (C) (8) Final RF amplifier Input Power Characteristics 9 2.1033 (C) (9) Tune Up Procedure 9 2.1033 (C) (10) Schematic Diagram and Circuit Description 10 2.1033 (C) (11) Equipment Identification Plate 10 2.1033 (C) (12) Equipment Photographs (Internal) 10 2.1033 (C) (12) Equipment Photographs (External) 10 2.1033 (C) (13) Digital Modulation Techniques 10 2.1033 (C) (14) Test Data 10 Test Set-Up 11-12 2.1046 Measurement of RF Power Output 13-25 2.1049 Measurement of Occupied Bandwidth 26-86 2.1051 Spurious Emissions at Antenna Terminals 87-100 2.1053 Measurement of Field Strength of Spurious Radiation 101-103 Radiated Emissions 104-105 2.1055 Measurement of Frequency Stability 106 2.1057 Frequency Spectrum to be Investigated 107 RF Exposure 108-110 Appendix A Photographs 115-115 FCC ID: RFK-LMSWDJH819 4 TABLE OF FIGURES Figure 1 : Test Equipment 6 Figure 2 : Test Result Summary 10 Figure 3 : Test Set Up Block Diagram 12 Figure 4 : Block Diagram Radiated Emissions 12 Figure 5 : Output Power Plots 14 Figure 6 : Occupied Bandwidth / Modulation Characteristic Plots 27 Figure 7 : Antenna Conducted Spurious Plots 88 Figure 8 : Radiated Spurious Tabular Data 102 Figure 9 : Unintentional Radiated Emissions 105 Appendix A : Photos 111 FCC ID: RFK-LMSWDJH819 5 1.0 ADMINISTRATIVE DATA 1.1 Certifications and Qualifications I certify that DNB Engineering, Inc conducted the tests performed in order to obtain the technical data presented in this application. Also, based on the results of the enclosed data, I have concluded that the equipment tested meets or exceeds the requirements of the Rules and Regulations governing this application. 1.2 Measurement Repeatability Information The test data presented in this report has been acquired using the guidelines set forth in FCC Part 2.1031 t…
