RNT-WS300PCUSWireless Weather Station

 Weather Station WS 300 PC-US Operating Manual  Please read these operating manual completely and thor- oughly before start up and save it for future reference. Please hand-over the operating manual as well when you hand-over the device to other persons for use. Contents: 1. Introduction .................................................................................4 1.1. Intended usage ...........................................................................4 2. Scope of delivery .........................................................................5 3. Symbol description ......................................................................5 4. Features and functions ................................................................6 4.1. General function ..........................................................................6 4.2. Data logger, USB interface ..........................................................6 4.3. Internal sensors ...........................................................................6 4.4. Display .........................................................................................6 4.5. Software ......................................................................................6 5. Safety information .......................................................................7 6. Battery and environmental information .......................................8 7. Preparations for operation, start up ............................................8 7.1. Starting up the base station ........................................................9 8. Operating and display elements ................................................10 9. Operation/display on the device ................................................11 9.1. Assigning a measurement value to the display .........................11 9.2. Resetting the total rain quantity.................................................12 9.3. Weather forecast display ...........................................................12 9.4. Memory capacity display ...........................................................12 The climate and weather data sensors mentioned in these instructions are not included in the scope of delivery of the weather station. These items are to be commissioned and operated according to the respectively provided operating manual.  10. Configuration, Display unit settings ...........................................13 11. Software installation .................................................................14 12. Firmware update ........................................................................15 13. Changing the batteries ..............................................................15 13.1. Base station ...............................................................................15 13.2. Combination sensor, external sensors, pool sensor .................16 14. Rectifying faults .........................................................................16 15. Transmission range ....................................................................18 16. Maintenance and cleaning.........................................................19 16.1. General ......................................................................................19 16.2. Cleaning the base station ..........................................................19 17. Operation ...................................................................................20 17.1. General ......................................................................................20 17.2. Base station ...............................................................................20 18. Disposal .....................................................................................21 18.1. General ......................................................................................21 19. Technical specifications .............................................................21 20. FCC information ........................................................................22 1. English Edition November 2006 Documentation © eQ-3 Limited Hongkong All rights reserved. No parts of this manual may be reproduced or processed in any form using electronic, mechanical or chemical processes in part or in full without the prior explicit written permission of the publisher. It is quite possible that this manual has printing errors or defects. The details provided in this manual are checked regularly and corrections are done in the next edition. We do not assume any liability for technical or printing errors. All registered trade marks and copyrights are acknowledged. Printed in Hong Kong. We reserve the right to make changes due to technical advancements without prior notice. 00073784 Y2006 V1.0  1. Introduction Dear customer, thank you for purchasing this product. The product has been EMC-tested and meets the requirements of the applicable national regulations. Read the respective FCC infor- mation as well. In order to maintain this status and to ensure safe and long-term operation, you as the user must know the information in these operating manual! At this time, we would like to bring your attention to the correct sequence of the procedures for starting up the product. Observe the installation information in these oper- ating manual as well as the information on interferences to the radio transmission between the sensors and the base station as well. All of the company names and product designations are trademarks of the respective owners. All rights reserved. 1.1. Intended usage The PC weather station WS 300 PC-US creates the interface between the radio weather sensors that are received by this weather station and a PC. The following radio sensors can be used: - Pool temperature sensor S 300PT-US (water temperature) - Combination sensor KS 300-2US (temperature, humidity, wind velocity, rain quantity) - Combination sensor KS 200US (temperature, humidity, wind ve…

Text truncated - open the document above for the full version.

REGISTRATION NUMBER: «REGISTRIERNUMMER»-FCC-P ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 1 of 11 Appendix A. Pictures REGISTRATION NUMBER: «REGISTRIERNUMMER»-FCC-P ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 2 of 11 REGISTRATION NUMBER: «REGISTRIERNUMMER»-FCC-P ETS PRODUCT SERVICE AG STORKOWER STR. 38C, D-15526 REICHENWALDE B. BERLIN PAGE 3 of 11

eQ-3 Limited, Hong Kong 01 December 2006 File Name: eq-3_ws300pc-us_labelsmpl.doc Page : 1 / 2 FCC ID Label Sample Wireless Weather Station eQ-3 WS 300PC-US eQ-3 Limited, Hong Kong 01 December 2006 File Name: eq-3_ws300pc-us_labelsmpl.doc Page : 2 / 2

eQ-3 Limited, Hong Kong 31 January 2007 File Name: eq-3_ws300pc-us_labelloc.doc Page : 1 / 1 FCC ID Label Location Information Wireless Weather Station eQ-3 WS 300PC-US

ETS PRODUCT SERVICE AG TEST - REPORT FCC RULES PART 15 / SUBPART B Test report no.: G0M20611-1015-C-1 Certificate 1983-01 ETS STORKOWER STRASSE 38C, D-15526 REICHENWALDE B. BERLIN PRODUCT SERVICE AG PHONE +49-33631-888 00 FAX +49-33631-888 660 Registration number: G0M20611-1015-C-1 ETS PRODUCT SERVICE AG STORKOWER STRASSE 38C D-15526 REICHENWALDE B. BERLIN Page 1 of 26 TABLE OF CONTENTS 1.1 Notes 2 1.2 Tester 4 1.3 Testing laboratory 5 1.3.1 Location 5 1.3.2 Details of accreditation status 5 1.3.3 Test location, where different 5 1.4 Details of applicant 6 1.5 Application details 6 1.6 Test item 6 1.6.1 Description of test item 6 1.6.2 Manufacturer (if different from applicant in point 1.4) 7 1.6.3 Frequency behavior 7 1.7 Test standards 7 2 Technical test 7 2.1 Summary of test results 7 2.2 Test environment 8 2.3 Test equipment utilized 9 2.4 Test results 19 2.4.1 Conducted Emission 20 2.4.2 Spurious Emission 22 2.5 Test protocols 23 3 Normative references 26 Annex: Pictures and diagrams Registration number: G0M20611-1015-C-1 ETS PRODUCT SERVICE AG STORKOWER STRASSE 38C D-15526 REICHENWALDE B. BERLIN Page 2 of 26 1 General Information 1.1 Notes The purpose of conformity testing is to increase the probability of adherence to the essential requirements or conformity specifications, as appropriate. The tests were carried out and passed in accordance to the standards: FCC part 15 : January 2005 The complexity of the technical specifications, however, means that full and thorough testing is impractical for both technical and economic reasons. Furthermore, there is no guarantee that a test sample which has passed all the relevant tests conforms to a specification (only telecommunication products). Neither is there any guarantee that such a test sample will interwork with other genuinely open systems. The existence of the tests nevertheless provides the confidence that the test sample possesses the qualities as maintained and that its performance generally conforms to representative cases of communications equipment. The test results of this test report relate exclusively to the item tested as specified in 1.6. The test report may only be reproduced or published in full. Reproduction or publication of extracts from the report requires the prior written approval of the ETS PRODUCT SERVICE AG. Registration number: G0M20611-1015-C-1 ETS PRODUCT SERVICE AG STORKOWER STRASSE 38C D-15526 REICHENWALDE B. BERLIN Page 3 of 26 Important Notes: Proper labeling is required for each device. Devices shall be labeled in accordance with labeling requirements pursuant to section 15.19 and section 2.1074 of the FCC rules. Devices subject to a Declaration of Conformity shall be uniquely identified by the responsible party. This identification shall not be of a format which could be confused with the FCC Identifier required on certified, notified type accepted or type approved equipment. The responsible party shall maintain adequate identification records to facilitate positive identification for each device. The user manual or instruction manual shall included also a warning statement that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Reference Section 15.21 Furthermore information to the user regarding to the interference potential of the device and about simple measures that can be taken to correct interference is required. Reference Section 15.105 The responsible party must warrant that each unit of equipment marketed under a Declaration of Conformity is identical to the unit tested and found acceptable with the standards and that the records maintained by the responsible party continue to reflect the equipment being produced under the Declaration of Conformity within the variation that can be expected due to quantity production and testing on a statistical basis. Registration number: G0M20611-1015-C-1 ETS PRODUCT SERVICE AG STORKOWER STRASSE 38C D-15526 REICHENWALDE B. BERLIN Page 4 of 26 1.2 Tester 13.12.2006 Tester ___________________________________________________________________ Date ETS-Lab. Name Signature Technical responsibility for area of testing: 13.12.2006 N. Kaspar ____________________________________________________________________ Date ETS Name Signature Registration number: G0M20611-1015-C-1 ETS PRODUCT SERVICE AG STORKOWER STRASSE 38C D-15526 REICHENWALDE B. BERLIN Page 5 of 26 1.3 Testing laboratory 1.3.1 Location ETS PRODUCT SERVICE AG Storkower Strasse 38c D- 15526 Reichenwalde Germany Telephone : + 49 33631 888 00 Telefax : + 49 33631 888 660 1.3.2 Details of accreditation status ACCREDITED TESTING LABORATORY DAR-REGISTRATION NUMBER: DAT-P-201/96 ACCREDITED COMPETENT BODY BNetzA -REGISTRATION NUMBER: BNetzA-zS-026/96 FCC FILED TEST LABORATORY: REG. NO. 96970 INDUSTRY CANADA FILED TEST LABORATORY REG. NO. IC 3470 A2LA ACCREDITED CERTIFICATE NUMBER: 1983-01 BLUETOOTH QUALIFICATION TEST FACILITY (BQTF) ACCREDITED BY: BLUETOOTH QUALIFICATION REVIEW BOARD (BQRF) 1.3.3 Test location, where different Name : ./. Street : ./. Town : ./. Country : ./. Telephone : ./. Fax : ./. Teletex : ./. Registration number: G0M20611-1015-C-1 ETS PRODUCT SERVICE AG STORKOWER STRASSE 38C D-15526 REICHENWALDE B. BERLIN Page 6 of 26 1.4 Details of applicant Name : eQ-3 Limited Street : Room A8 & A10, 16/F Kailey Industrial Centre, No.12, Fung Yip Street Town : Chaiwan Country : Hong Kong Telephone : +852 23670322 Fax : +852 23670322 Teletex : ./. Contact : Mrs. Shirley Hui Lai Chu Telephone : +852 23670322 1.5 Application details Date of receipt of application : 23.11.2006 Date of receipt of test item : 23.11.2006 Date of test : 30.11.2006 - 05.12.2006 1.6 Test item 1.6.1 Description of test item Type of product : Wireless Weather Station - Indoor Unit (Receiver) Type identification : WS 300PC-US Trade Name : Brand name: eQ-3 Serial number : without Photos : Please find in Appendix. Power supply : 4,5 V DC (battery)…
